SOLTEK SL-85DRV3 User manual

R
The Soul Of Computer Technology
Mainboard
SL-85DRV3
User Manual V1.0

85DRV3
2
NOTICE Product Model : SL-85DRV3
Manual Re ision : V1.0
Release Date : December 2001
his Users Guide & Technical Reference is to help system manu-
facturers and end-users set up and install the mainboard.
Every effort has been made to ensure that the information in this
manual is accurate. Soltek Computer nc. is not responsible for print-
ing or clerical errors. nformation in this document is subject to
change without notice and does not represent a commitment on
Soltek Computer nc.
No part of this manual may be reproduced, transmitted, translated
into any language in any form or by any means, electronic or
mechanical, including photocopying and recording, for any purpose
without the express written permission of Soltek Computer nc.
Companies and products mentioned in this manual are for identifi-
cation purpose only. Product names appearing in this manual may
or may not be registered trademarks or copyrights of their respec-
tive companies.
Soltek Computer nc. provides this manual “as is “ without warranty
of any kind, either express or implied, including but not limited to the
implied warranties or conditions of merchantability or fitness for a
particular purpose. n no event shall Soltek Computer nc. be liable
for any loss or profits, loss of business, loss of use or data, interruption of
business, or for indirect, special, incidental, or consequential damages of
any kind, even if Soltek Computer nc. has been advised of the possibility
of such damages arising from any defect or error in this manual or product.
Copyright © 2001 Soltek Computer Inc. All Rights Reser ed.
• ntel Pentium 4 and Northwood are trademarks of ntel Corporation.
• V A , V A Apollo P4X266, V A Appolo P4X266A, VT8233A and VT8233 are trademarks of V A
Technologies, nc.
T

3
85DRV3
SOLTEK AROUND THE WORLD
SOLTEK COMPUTER INC.
Address : 7F, No. 306-3, Ta-Tung Rd, Sec.1, Hsi-Chih, Taipei-
Hsien, Taiwan, R.O.C.
Telephone : [phone]
Fax : [phone]
E-mail : [email protected]
Web site : http://www.soltek.com.tw
SOUL TECHNOLOGY EUROPE B.V.
Address : Hongkongstraat 55, 3047 BP Rotterdam. The Neth-
erlands
Telephone : [phone]
Fax : [phone]
E-mail : [email protected]
Web site : http://www.soultech-europe.com
SOLTEK KOREA INC.
Address : 1002, Chung Jin Bldg. 53-5 Wonhyo-Ro, 3-Ka,
Yongsan-Ku Seoul 140-113, Korea
Telephone : [phone]
Fax : [phone]
E-mail : [email protected]

4
Contents
Contents
Chapter 1 Specification ........................................... 10
1-1 Mainboard Specifications ..................................................... 11
1-1.1 CPU Socket ................................................................................... 11
1-1.2 System Chipsets ........................................................................... 11
1-1.3 Memory ......................................................................................... 11
1-1.4 AWARD BIOS V6.0 ..................................................................... 11
1-1.5 Accelerated Graphics Port (AGP) Interface........................... 11
1-1.6 Ad anced system Power Management, supporting: ............ 12
1-1.7 Multi-I/O Functions: ................................................................... 12
1-1.8 Expansion Slots ............................................................................ 12
1-1.9 Hardware Monitor on board ..................................................... 13
1-1.10 AC’97 Audio Codec on board.................................................. 13
1-1.11 CNR Slot on board .................................................................... 13
1-1.12 Redstorm O erclocking Technology ...................................... 13
1-1.13 Form Factor................................................................................ 13
1-2 Mainboard Specification Table ........................................... 14
1-3 Chipset System Block Diagram........................................... 15
Chapter 2 Hardware Setup..................................... 17
2-1 CPU Installation with Socket 478 ....................................... 18
2-2 Pentium 4 CPU Fan Installation: ....................................... 19
2-3 Memory Installation ............................................................. 20
2-3.1 To Install DDR SDRAM Module for this Series : .................. 20
2-3.2 To Remo e a DIMM:................................................................... 21
2-3.3 Indicator ZD1 DIMM Socket On: ............................................ 21
2-4 AGP (Accelerated Graphics Port) Card Installation :.... 22
2-5 HDD/FDD Installation .......................................................... 23

5
Contents
2-6 ATX V 2.03 Power Supply Installation .............................. 25
2-7 Jumper and Switch Settings ................................................ 26
2-7.1 Switch 1 CPU Clock Select ........................................................ 27
2-7.2 JBAT1 Clear CMOS.................................................................... 28
2-7.3 Jp10 CPU Clock Select:.............................................................. 28
2-7.4 Jp16 Suspend to RAM (STR) .................................................... 29
2-7.5 Jp11 Flash ROM Write Protection Select ............................... 29
2-8 Other Connectors Configuration........................................ 30
2-8.1 On Board FAN Connectors ........................................................ 30
2-8.2 WOL1 Wake On LAN ................................................................. 31
2-8.3 CD-ROM Audio Connector CD_IN1........................................ 31
2-8.4 Chassis Panel Connector ............................................................ 32
2-8.5 Thermal Sensor Connector RT1, RT2 ..................................... 33
2-8.6 Complex Header .......................................................................... 34
2-8.7 Communication And Networking Riser Slot (CNR) ............. 36
2-8.8 USB Ports and USB Header (Header USB 3) ......................... 37
2-8.9 PS/2 Mouse And PS/2 Keyboard ............................................... 37
2-9 IRQ Description..................................................................... 38
Chapter 3 Software Setup ....................................... 40
3-1 Open up Suport CD: ............................................................. 41
3-2 Proceed to VIA 4-IN-1 Dri ers Installation ..................... 42
3-3 Proceed to AC’97 AUDIO Dri er Installation.................. 44
3-4 Proceed to Hardware Monitor Installation....................... 45
Chapter 4 BIOS Setup............................................. 48
4-1 About BIOS Setup ................................................................. 49
4-2 To run BIOS Setup ................................................................ 49
4-3 About CMOS .......................................................................... 49
4-4 The POST ( Power On Self Test ) ....................................... 49

6
Contents
4-5 To upgrade BIOS ................................................................... 50
4-5.1 Before Upgrading BIOS ............................................................. 50
4-5.2 Upgrade Process........................................................................... 50
4-6 BIOS SETUP --- CMOS Setup Utility................................ 53
4-6.1 CMOS Setup Utility .................................................................... 53
4-6.2 Standard CMOS Setup ............................................................... 54
4-6.3 Ad anced BIOS Features ........................................................... 57
4-6.4 Ad anced Chipset Features ....................................................... 61
4-6.5 Integrated Peripherals................................................................ 66
4-6.6 Power Management Setup ......................................................... 72
4-6.7 PNP / PCI Configuration............................................................ 78
4-6.8 SmartDoc Anti-burn Shield (PC Health status)..................... 81
4-6.9 Frequency/Voltage Control ....................................................... 83
4-6.10 Load Optimized Defaults ........................................................ 85
4-6.11 SET SUPERVISOR / USER PASSWORD............................. 86
4-6.12 SAVE & EXIT SETUP.............................................................. 87
4-6.13 EXIT WITHOUT SAVING ...................................................... 87
Appendices ............................................................... 89
Appendix-1 Identify BIOS Version & BIOS Part Number ... 90
Appendix-2 Identify Mainboard Model Number ................... 91
Appendix-3 Technical Terms ...................................................... 92

7
Contents

8
85DRV3
Mainboard
Support CD
Bundled Bonus Pack CD
Bundled Bonus Pack Manual
Temperature Sensor Cable (Optional)
ATA66/100/133 DE Cable
FDD Cable
User’s Manual
RS232 Cable
ITEM CHECKUP

9
Chapter 1 Specification
85DRV3 -- Components Locations
USB1
COM1
COM2
MIC LINE
OUT
LINE IN
DIM 3
FDC
IDE1
IDE2
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
PCI 6
SCR1
CNR
Li
Battery
FLASH BIOS
FAN3
1
FAN4
AGP 4X
LPC I/O
Controller
Clock
Generator
VT8233A
4
1
CD_IN1
SPK RST
SMI
HDD/LED IR PWR
1
30
WOL1
1
16
USB3
ZD1
Main Power
RT2
RT1
J4
1 2
3 4
J2 Aux Power
FAN1
FAN2
1
SW1
ON DIP
1 2 3 4
JBAT1
1
¤
mPGA478B
1 3
1
JP11
VIA
VT1611A
AC'97
Audio
SUS LED
PWR LED
LPT1
GAME/MIDI PORT
PS/2 K/B
Mouse
(on top)
PS/2
(underside)
1
1
1
1
JP15 JP16
USB0
(on top)
(underside)
DIM 1 DIM 2
VIA
P4X266A
VIA
JP10
1
+12V Power
1
DDR 266

10
85DRV3
This series of mainboards features an integration of the powerful
processor ntel Pentium 4 and the single-chip North Bridge V A P4X266A
plus South Bridge VT8233A, by which the whole system performance
is upgraded to 533/400 MHz system bus.
The ntel P4 processor is a rapid execution engine providing 400MHz
quadpumped system bus to allow 3.2GB data transfer rates possible,
while V A Apollo P4X266A North Bridge plus VT8233A South Bridge
supports ntel P4 processor to implement the AGP 4X external bus, the
LPC Super /O, the DDR SDRAM and UATA 133/100/66 data transfer
rate. This chapter is to introduce to users every advanced function of
this high performance integration.
Topics included in this chapter are:
1-1 Mainboard Specifications
1-2 Mainboard Layout
1-3 Mainboard Specification Table
1-4 Chipset Diagram
Introduction
Chapter 1 Specification

11
Chapter 1 Specification
1-1.1 CPU Socket
CPU Socket 478B on board, supporting ntel® Pentium 4 and North-
wood processors in the 478-pin package for :
• 533/400 MHz System Bus;
• Hyper pipelined technology;
• Advanced dynamic execution;
• Advanced transfer cache;
1-1.2 System Chipsets
North Bridge V A P4X266A plus South Bridge VT8233A to work with
ntel Pentium 4 Processor for managing and arbitrating operations be-
tween all system interfaces.
1-1.3 Memory
3 DDR D MM 184-pin sockets on board for PC2100 and PC1600 DDR
SDRAMs, at 64bit data transfer rate (D MM voltage selectable in B OS
setup):
• P4X266A directly supporting pseudo-synchronous SDRAM up to 1.5GB
unbuffered DDR SDRAMs or 3GB registered DDR SDRAMs.
• nstallation of mixed volumes of DDR SDRAM modules supported .
1-1.4 AWARD BIOS V6.0
• Supporting Plug & Play V1.0;
• Flash Memory for easy upgrade;
• Supporting B OS writing protection and Year 2000 compliant;
• B OS Setup supported (Please see Chapter 4 B OS Setup);
1-1 Mainboard Specifications
1-1.5 Accelerated Graphics Port (AGP) Interface
AGP Controller is embedded in chip, supporting:
• 1.5V/4X, 3.3V/2X power mode , AGP voltage selectable in B OS Setup;
• 2x/ 4x AD and SBA signalling, AGP pipelined split-transection long-
burst transfers up to 1GB/sec.;
• AGP v2.0 compliant;

12
85DRV3
1-1.7 Multi-I/O Functions:
• PC E DE Controller, supporting:
-- 2x Ultra ATA 133/100 / 66 / 33 DE Connectors supporting up to 4 DE
devices;
• Dedicated R Functions:
-- Third serial port dedicated to R function either through the two complete
serial ports or the third dedicated port nfrared- rDA (HPS R) and ASK
(Amplitude Shift Keyed) R.
• Multi-mode parallel Data transfer:
-- Standard mode, ECP and EPP support;
• Floppy Disk connector:
-- One FDD connector with drive swap support;
• Universal Serial Bus Transfer Mode:
-- USB V1.1 compliant;
-- 2 built-in USB connectors and one USB Headers (USB3) which requires one
optional USB cable to provide 2 more optional USB ports;
• PS/2 Keyboard
• PS/2 Mouse
• UARTs (Universal Asynchronous Receiver / Transmitter):
-- Two complete Serial Ports (COM1 & COM2) on board;
1-1.8 Expansion Slots
• Six PC bus Master slots;
• One AGP 4x/2X slot;
• One CNR slot (supporting Modem / Audio Riser only);
• Three DDR D MM slots;
1-1.6 Ad anced system Power Management, supporting:
• ACP 1.0B compliant (Advanced Configuration and Power nterface);
• APM V1.2 compliant (Legacy power management);
• ACP STR mode (Suspend To RAM) , POS (Power On Suspend) and STD
(Suspend to Disk);
• Wake On Modem (External) and Wake On LAN supported by Ring Power
On Control;
• Real time clock (RTC) with date alarm, month alarm, and century field.
• USB wake-up Function;

13
Chapter 1 Specification
1-1.9 Hardware Monitor on board
Programmable hardware status, to provide monitoring and alarm for
flexible desktop management of hardware temperatures. Utility Soft-
ware is enclosed in Support CD to help display monitoring statuses of:
-- 9 voltages, 2 types of hardware temperatures, 2 Fan speeds;
1-1.10 AC’97 Audio Codec on board
AC’97 Audio codec supported by AC97 Link on chip VT8233A;
1-1.11 CNR Slot on board
CNR Slot on board for Modem Riser card or Audio Riser Card;
1-1.12 Redstorm O erclocking Technology
Redstorm Overclocking Tech is a program embedded in B OS for CPU
automatic overclocking. Please see “ Freguency / Voltage Control “ of
B OS Setup for Redstorm Overclocking Technology setting.
1-1.13 Form Factor
• ATX form factor, ATX spec. version 2.03 compliant, supported by one
Main Power Connector, one +12V Power Connector and one Aux Power
Connector;
• Mainboard size: 305mm x 245mm;

14
85DRV3
1-2 Mainboard Specification Table
Model/Series 85DRV3
Memory
Controller Hub North Bridge VIA 4x266 A
South Bridge VIA VT8233A
ITE IT8705F
I/O
Controller Hub
I/O Chip
AG Interface AG 4X / 2X Mode
Memory Supporting Registered 3GB or unbuffered 1.5GB
DDR SDRAMs with 3 DDR DIMM Slots
Audio
Onboard IDE 2 x UATA 33/66/100/133 IDE ports
I/O Connectors
Yes
Yes
Yes
4 x USB ports, 1 x FDD port, 2 x COM ports,
CI slot 6 CI Master Slots
CNR slot 1 x CNR slot
Hardware
BIOS writin
Keyboard power on
Function &
USB wake up
Function
AC'97 Audio Codec
C U Socket Socket GA478B for Intel entium 4 478-pin package C U
1 x L T port, 1 IrDA, 1 S/2 Mouse, 1 S/2 K/B
rotection
Monitoring

15
Chapter 1 Specification
Intel Pentium 4 + VIA P4X266A + VT8233A Diagram
1-3 Chipset System Block Diagram
Single-chip
Pentium 4
DDR
PC2100/1600 DDR Memory Bus
UATA33/66/100/133
PS/2 key oard
PCI Bus
P4x266A
North Bridge
CPU
AGP
Slot
533/400 MHz FSB
SM Bus
LPC
66MHz QDR, 8Bit V-Link
Super I/O
Serial / IR
Parallel
Floppy Disk
PCI Slots
478-pin package
Modem Codec
CNR Slot
Game Port
H/W Monitor
BIOS
VT8233A
V-Link
Client South
Intel
AGP 2X/4X Bus
SDRAMs
6x USB
AC'97 Audio
PS/2 Mouse

16
85DRV3
MEMO
MEMO

17
Chapter 2 Hardware Setup
Chapter 2 Hardware Setup
1. We recommend to install your CPU before any other components.
For detailed installation instructions of processor, you can also refer
to the pamphlet enclosed in your CPU package.
2. nstalling a cooling fan with a good heatsink is a must for proper heat
dissipation for your CPU. Get ready an appropriate fan with heatsink
for proper installation. mproper fan and installation will damage your
CPU.
3. n case CPU Vcore, CPU clock or Frequency Ratio is adjustable on
board, please follow the instructions described in the User manual
for proper setup. ncorrect setting will cause damage to your CPU.
The following topics are included in this chapter:
2-1 Pentium 4 CPU Installation
2-2 Pentium 4 CPU Fan Installation
2-3 Memory Installation
2-4 HDD/FDD Installation
2-5 AGP (Accelerated Graphic Port) Installation
2-6 ATX 2.03 Power Supply Installation
2-7 Jumper Settings
2-8 Other Connectors Configuration
To Get things ready for Hardware setup !

18
85DRV3
mPGA478B
Pin 1
2-1 CPU Installation with Socket 478
This mainboard is built with CPU Socket 478 ( 47-pin) supporting the
ntel Pentium 4 CPU:
• Follow the steps described in this section to install the 478-pin Pentium 4
CPU into the on board Socket 478.
• After installation of Pentium 4 CPU, you must also install the specific
Pentium 4 CPU fan designed in tandem with this CPU. This CPU Fan
installation is described in next section.
1. First pull sideways the lever of
Socket 478, and then turn it up
900 so as to raise the upper layer
of the socket from the lower
platform.
3. Make sure that all CPU pins have
completely entered the socket
and then lower down the lever
to lock up CPU to socket.
2. Configure Pin 1 of CPU to Pin 1
of the Socket, just as the way
shown in the diagram on the left.
Adjust the position of CPU until
you can feel all CPU pins get
into the socket with ease.
mPGA478B
ntel Pentium 4
mPGA478B
ntel Pentium 4
Pin 1
Pin 1

19
Chapter 2 Hardware Setup
Connect to CPU FAN connector
Press down 4 latches to lock fan to fanbase
Pentium 4 Fanbase CPU Fan Connector
2-2 Pentium 4 CPU Fan Installation:

20
85DRV3
2-3 Memory Installation
• This mainboard only supports up to 3GB registered DDR SDRAM or 1.
5GB unbuffered DDR SDRAM, with 3 DDR D MM sockets on board. Do
not insert other type of modules into these sockets.
• DDR D MM socket has 184-pins and one notch. nsert a DDR SDRAM
vertically into the 184-pin socket with the notch matching the one in the
socket. Press the Module down in a gradual way until it surely reaches
the bottom and clicks straight up the two latches on the left and right of
the socket. f any one of the latches has not turned up completely, you
should unplug the module and press it down the socket a bit more firmly.
How to tackle with the memory Modules:
• Make sure to unplug your power supply before adding or removing
memory module. Failure to do so may cause severe damage to both
your main board and the memory module.
• Pay attention to the orientation of the D MM slots. Forcing a D MM in a
socket improperly will damage the memory module and socket.
• Make sure you have the right type of memory module for your mainboard.
184-Pin DIMM Notch Key Definitions (2.5V)
DRAM Key Position Voltage Key Position
2.5V
Module Latch
2-3.1 To Install DDR SDRAM Module for this Mainboard :
