SOLTEK SL-65ME User manual

SL-65ME/65ME+ USER MANUAL
The Soul Of Computer Technology
R

USER NOTICE
Product Model : SL-65ME/65ME+
Manual Revision : V1.0
Release Date : uly 2000
This Users Guide & Technical Reference is for assisting system
manufacturers and end-users in setting up and installing the
mainboard.
Every effort has been made to ensure that the information in this
manual is accurate. Soltek omputer Inc. is not responsible for print-
ing or clerical errors. Information in this document is subject to
change without notice and does not represent a commitment on the
part of Soltek omputer Inc.
No part of this manual may be reproduced, transmitted, translated
into any language in any form or by any means, electronic or
mechanical, including photocopying and recording, for any purpose
without the express written permission of Soltek omputer Inc.
ompanies and products mentioned in this manual are for identifi-
cation purpose only. Product names appearing in this manual may
or may not be registered trademarks or copyrights of their respec-
tive companies.
Soltek computer inc. Provides this manual “As is “ without warranty
of any kind, either express or implied, including but not limited to
the implied warranties or conditions of merchantability or fitness for
a particular purpose. In no event shall Soltek computer inc. Be li-
able for any loss or profits, loss of business, loss of use or data,
interruption of business, or for indirect, special, incidental, or con-
sequential damages of any kind, even if Soltek computer inc. Has
been advised of the possibility of such damages arising from any
defect or error in this manual or product.
Copyright © 2000 Solte Computer Inc. All Rights Reserved.
• Intel, eleron, Pentium II, Pentium III are trademarks of Intel orporation.
• Intel 82815 Graphic Memory ontroller Hub(GM H), 82801 I/O ontroller Hub(I H) are trade-
marks of Intel orporation.
• VIA yrix III is trademark of VIA orporation.
• Norton AntiVirus, Norton Ghost are trademarks of Symantec orporation.

SOLTEK AROUND THE WORLD
SOLTEK COMPUTER INC.
Address : 7F, No. 306-3, Ta-Tung Rd, Sec.1, Hsi- hin, Taipei-
Hsien, Taiwan, R.O. .
Telephone : [phone]
Fax : [phone]
E-mail : [email protected]
Web site : http://www.soltek.com.tw
SOLTEK KOREA INC.
Address : 1002, hungjin Bldg. 53-5 Wonhyo-Ro, 3-Ka,
Yongsan-Ku Seoul 140-113, Korea
Telephone : [phone]
Fax : [phone]
E-mail : [email protected]
MOKA HOLDING B.V.
Address : De Run 4428 5503 LR Veldhoven, the Netherlands
Telephone : [phone]
Fax : [phone]
E-mail : [email protected]
SOUL TECHNOLOGY EUROPE B.V.
Address : Sydneystraat 52-54 3047 BP Rotterdam, the Nether-
lands
Telephone : [phone]
Fax : [phone]
E-mail : [email protected]
Web site : http://www.soultech-europe.com

4
65ME / 65ME+
C O N T E N T
CHAPTER 1
INTRODUCTION ........................................................................... 6
1-1 ITEM LIST HE KUP............................................................................ 6
1-2 PU ........................................................................................................6
1-3 HIPSET ................................................................................................6
1-4 MEMORY ...............................................................................................7
1-5 BIOS .......................................................................................................7
1-6 MULTI-I/O FUN TION ...........................................................................7
1-7 INTEGRATED GRAPHI S.....................................................................8
1-8 ONBOARD AUDIO DEVI E................................................................... 8
1-9 FORM FA TOR .....................................................................................8
1-10 OTHERS ..............................................................................................8
1-11.1 MOTHERBOARD LAYOUT --- 65ME ................................................9
1-11.2 MOTHERBOARD LAYOUT --- 65ME+ ............................................10
1-12 HIPSET SYSTEM BLO K DIAGRAM ............................................. 11
1-13 SYSTEM MEMORY ONFIGURATION............................................. 12
1-14 AGP INTERFA E ..............................................................................12
CHAPTER 2
HARDWARE SETUP ................................................................... 14
2-1 PU INSTALLATION............................................................................14
2-2 PU FREQUEN Y .............................................................................. 15
2-3 MEMORY INSTALLATION ...................................................................15
2-4 A ELERATED GRAPHI S PORT(AGP) PRO INSTALLATION....... 16
2-5 HDD / FDD INSTALLATION .................................................................17
2-6 JUMPER DEFINITION ......................................................................... 18
2-7 ONNE TORS .................................................................................... 22
2-7.1 J2J3 ...................................................................................................22
2-7.2 HASSIS PANEL ONNE TOR ......................................................25
2-7.3 FLAT-PANEL DISPLAY ONNE TOR..............................................26
2-7.4 ATX POWER SUPPLY ONNE TOR .............................................. 26
2-7.5 SERIAL PORT ONNE TORS ........................................................26
2-7.6 SE OND USB ONNE TOR...........................................................27
2-7.7 PS/2 MOUSE AND PS/2 KEYBOARD .............................................. 28
2-7.8 IRQ DES RIPTION .......................................................................... 28

5
65M E / 65ME+
CHAPTER 3
SOFTWARE SETUP .................................................................... 30
3-1 ABOUT SOLTEK SUPPORT D .......................................................... 30
3-2 INTEL HIPSET DRIVER INSTALLATION .......................................... 30
3-3 INTEL 815 HIPSET GRAPHI S DRIVER INSTALLATION ..............32
3-4 INTEL ULTRA ATA STORAGE DRIVER INSTALLATION..................... 34
3-5 A ’97 DRIVER INSTALLATION ........................................................... 36
3-6 REATIVE SOUND DRIVER INSTALLATION .....................................38
CHAPTER 4
BIOS SETUP ............................................................................... 39
4-1 INTRODU E THE BIOS ...................................................................... 39
4-2 WHAT IS BIOS SETUP ........................................................................ 39
4-3 HOW TO RUN BIOS SETUP ...............................................................39
4-4 WHAT IS MOS ................................................................................... 39
4-5 WHAT IS POST .................................................................................... 40
4-6 BIOS UPGRADE ..................................................................................40
4-6.1 BEFORE UPGRADE BIOS ............................................................... 40
4-6.2 UPGRADE PRO ESS ......................................................................40
4-7 MOS SETUP UTILITY ....................................................................... 43
4-8 STANDARD MOS SETUP ................................................................. 44
4-9 ADVAN ED BIOS FEATURES ............................................................47
4-10 ADVAN ED HIPSET FEATURES ...................................................51
4-11 INTEGRATED PERIPHERALS...........................................................55
4-12 POWER MANAGEMENT SETUP ......................................................60
4-13 PNP / P I ONFIGURATION ............................................................ 64
4-14 P HEALTH STATUS......................................................................... 66
4-15 FREQUEN Y/VOLTAGE ONTROL.................................................67
4-16 LOAD OPTIMIZED DEFAULTS.......................................................... 69
4-17 SET SUPERVISOR / USER PASSWORD .........................................69
4-18 SAVE & EXIT SETUP......................................................................... 70
4-19 EXIT WITHOUT SAVING ................................................................... 70

6
65ME / 65ME+
CHAPTER 1
INTRODUCTION
1-1 ITEM LIST CHECKUP
• Motherboard
• Support D
• User’s Manual
• 2-in-1 Bonus Pack D
• 2-in-1 Bonus Pack Manual
• Temperature Sensor able
• ATA66 IDE able
• RS232 able
1-2 CPU
• Supports Intel® F -PGA Pentium !!!TM oppermine PU up to 1GHz / F -
PGA & PPGA eleron 370 PU up to 700MHz .
• Supports VIA® yrix III PU up to 600MHz.
• Supports PU voltage Auto-Detect circuit.
1-3 CHIPSET
• Intel 82815 GM H (Graphics and Memory ontroller Hub) chipset:
--- Supports Uni-processor system only.
--- Supports 64-bit 66/ 100/ 133 MHz System Bus Frequency.
--- Provides 1x/ 2x/ 4x AGP controller.
--- Supports Suspend to RAM function.
--- A PI compliant power management.
--- Integrated 2D & 3D Graphics Engines.
--- Integrated H/W Motion ompensation Engine.
--- Integrated 24-bit 230 MHz DA .
--- Integrated Digital Video Out Port.
--- Supports 133MHz System Memory while running in non- P mode.
• Intel 82801BA I H2 (I/O ontroller Hub2) chipset:
--- Supports P I at 33MHz.
--- Supports P I Rev 2.2 Specification.
--- Power Management Logic support.
--- Enhanced DMA controller; Interrupt ontroller & Timer Functions.

7
65M E / 65ME+
--- Integrated IDE controller; I H2 supports Ultra ATA33/66/100.
--- USB host interface with support for 4 USB ports.
--- A ’97 2.1 ompliant Link for Audio and Telephony ODE s.
--- Firmware Hub (FWH) interface support.
--- Alert On LAN.
1-4 MEMORY
• Provides 3pcs DIMM slots supporting double-sided DIMMs.
• Supports 100/133MHz SDRAM spec.
• Supports total memory from 32MB to 512MB using 32Mb/64Mb/128Mb/
256Mb technology.
• Supports up to 3 double sided DIMMs at 100MHz system memory bus.
• Supports up to 2 double sided or 3 single sided DIMMs at 133MHz sys-
tem memory bus.
• Unbuffered , Non-E SDRAM only supported.
1-5 BIOS
• Award BIOS 6.0
• Supports Plug & Play (PnP).
• FLASH MEMORY for easy upgrade.
• Supports Advanced Power Management (APM) Rev 1.2 function.
• Supports Advanced onfiguration Power Management Interface (A PI)
Rev 1.0 function.
• Year 2000 compliant.
1-6 MULTI-I/O FUNCTION
• One floppy port supports up to 2.88MB.
• provides 4 Built-in USB connector ports.(Besides the direct use of USB0
and USB1, the others need optional USB connector cable)
• Ultra ATA33/66/100 bus master IDE supports up to 4 IDE devices. (Including
ZIP / LS-120 floppy devices)
• 2x 16550A Built-in fast UART compatible serial port connectors.
• Built-in SPP / EPP / E P parallel port connectors.
• Built-in standard IrDA TX / RX header.
• Peripherals boot function with ATX power.

8
65ME / 65ME+
1-7 INTEGRATED GRAPHICS
• 3D Hyper Pipelined Architecture.
- Parallel Data Processing. (PDP)
- Precise Pixel Interpolation. (PPI)
• Full 2D H/W Acceleration
• 2D Graphics up to 1600 X 1200 in 8-bit olor at 85 Hz Refresh.
• H/W Motion ompensation Assistance for S/W MPEG2 Decode.
• Integrated Graphics Memory ontroller can be disabled to support an
extenal AGP ard or P I Graphics card.
• Provided an AGP Pro Slot which is compatible for AGP 1X/2X/4X mode
and AGP In-Line Memory Module(AIMM) up to 4 MB.
1-8 ONBOARD AUDIO DEVICE
• A ’97 2.1 ompliant Link for Audio and Telephony codecs (up to 6
channels)
• A ’97 ODE on board.
• reative P I128 on board.(SL- 65ME+ only)
1-9 FORM FACTOR
• ATX form factor 4 layers P B.
• Motherboard size: 20.0cm x 30.5cm
1-10 OTHERS
• Provides 5x P I slots, 1x NR slot, 1x AGP Pro slot and 3x DIMM sockets.
• Supports AGP 2.0 including 4X AGP data transfers.
• Supports S SI, D-ROM, ZIP, LS-120 boot up function.
• Supports USB Power-On function.
• Supports Wake On LAN (WOL) boot up function.
• Supports keyboard Power-On function.
• Supports BIOS Writing Protection.
• Supports BIOS ore Voltage Setting.
• Supports Jumper free function that allows user easily overclocking of fre-
quency and Voltage , Vcore through the BIOS setup.
NOTE: To use Wa e On LAN (WOL) function, the ATX
power supply must provide at least 5V/720mA
standby current capacity.

9
65M E / 65ME+
1-11.1 MOTHERBOARD LAYOUT --- 65ME
• Default Setting: Intel eleron 300A/66 MHz
Using non-compliant memory with higher bus cloc (over cloc ing) may severely
compromise the integrity of system.
Cloc 
Generator
LED1
AGP PRO
1 4
1 4
9 16
1 8
J2 J3
SPK RST KEYLOCK T/LED
HDD/LED IR PWR SUSPEND
++
--
+-
1 15 1 15
I/O
Controller
FWH
Intel
ICH2
SOCKET 370
LPT1
VGA1 COM1
GAME/MIDI PORT
LINE OUT
LINE IN
MIC
PS/2 MOUSE PS/2 K/B
upper
lower
USB1 USB0
upper
lower
DVC1
Intel
815E
GMCH
Li
Battery
RT1
DIMM2 DIMM1 DIMM3
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
COM2
JWOL1
CD_IN1
CD_IN2
CNR
USB1 SCR1
1 3
1 3
JBAT1
JBAT2
IDE2 IDE1
FDC1
1 3
1 3
JP2
JP8
JP9
JP10
1 3
JP11
1 3
JP1
CPUFA1
ATX POWER
AUXFA1
1 11
1 3 1 3
JP5 JP6
CHAFA1 RT2
AC'97
Codec

10
65ME / 65ME+
1-11.2 MOTHERBOARD LAYOUT --- 65ME+
• Default Setting: Intel eleron 300A/66 MHz
Using non-compliant memory with higher bus cloc (over cloc ing) may severely
compromise the integrity of system.
Cloc 
Generator
LED1
AGP PRO
1 4
1 4
9 16
1 8
J2 J3
SPK RST KEYLOCK T/LED
HDD/LED IR PWR SUSPEND
++
--
+-
1 15 1 15
I/O
Controller
FWH
Intel
ICH2
SOCKET 370
LPT1
VGA1 COM1
GAME/MIDI PORT
LINE OUT
LINE IN
MIC PS/2
MOUSE PS/2 K/B
upper
lower
USB1 USB0
upper
lower
DVC1
Intel
815E
GMCH
Li
Battery
CREATIVE
ES1373
RT1
DIMM2 DIMM1 DIMM3
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
COM2
JWOL1
TAD1

TV1
CD_IN1
CD_IN2

JP21

1 3
CNR USB1 SCR1
1 3
1 3
JBAT1
JBAT2
IDE2 IDE1
FDC1
1 3
1 3 JP2
JP8
JP9
JP10
1 3
JP11
1 3
JP1
CPUFA1
ATX POWER
AUXFA1
1 11
1 3 1 3
JP5 JP6
CHAFA1 RT2

11
65M E / 65ME+
Intel 82815 GMCH Chipset Diagram
1-12 CHIPSET SYSTEM BLOCK DIAGRAM
System
Memory
PCI
Agent
Super
I/O
Keyboard
Mouse,FD,PP
SP,IR
Intel 82815 Chipset
Digital Video Out
64bit /
100/133MHz
FWH
(Firmware Hub)
ICH2
(I/O Controller Hub)
Intel 82815
(GMCH)
-Memory Controller
-AGP Controller
-Graphics Controller
-3D Engine
-2D Engine
-Video Engine
PCI Bus
GPIO
System Bus (66/100/133MHz)
4 USB Ports
Analog Display
4 IDE Drivers
Ultra DMA100/66/33 PCI Slots
Audio Codec(s)
LAN Connect
Intel Pentium III Processor
or
Intel Celeron Processor
Digital Display
Encoder
TV
AGP Connector
Display Cache
(4MB SDRAM, 
133MHz)
AGP Graphics
AGP 2.0
AC'97 2.1
LPC I/F

12
65ME / 65ME+
1-13 SYSTEM MEMORY CONFIGURATION
• This Intel 82815 GM H chipset integrates a system memory controller
that supports a 64-bit 100 / 133 MHz SDRAM array. The only DRAM type
supported is industry standard Synchronous DRAM (SDRAM). The
SDRAM controller interface is fully configurate through a set of control
registers.
1-14 AGP INTERFACE
• A single AGP connector is supported by the Intel 82815 GM H AGP
interface. The AGP buffers operate in one of two selectable modes in
order to support the AGP Universal onnector:
1) 3.3V drive, not 5 volt safe - This mode is compliant to the AGP 1.0 and 2.
0 specs.
2) 1.5V drive, not 3.3 volt safe - This mode is compliant with the AGP 2.0
spec.
The following table shows the AGP data rate and the signaling levels sup-
ported by the 82815 GM H chipset.
Signaling Level
1.5 V
Yes
Yes
Yes
3.3 V
Yes
Yes
No
Data Rate
1x AGP
2x AGP
4x AGP
• The 82815 chipset has a new type of clocking architecture. It has inte-
grated SDRAM buffers that run at either 100 or 133MHz, independent of
the system bus frequency. See below for a table of supported system bus
and system memory bus frequencies. The system bus frequency is se-
lectable between 66MHz, 100MHz or 133MHz. The 82815 GM H uses a
copy of the USB clock as the DOT lock input for the graphics pixel clock
PLL.

13
65M E / 65ME+
ATTENTION !!!
1. Please refer to your processor installation or other
documentation attached with your CPU for detailed
installing instruction.
2. Installing a heat sin and cooling fan is necessary for
proper heat dissipation from your CPU. Uncorrected
installation may result in overheating and damage of
your CPU.
3. Before changing the setting of CPU Vcore from BIOS
program, user SHOULD ma e sure of correct specifi-
cation both of CPU CLOCK and RATIO. Uncorrected
setting may cause damage to your CPU.

14
65ME / 65ME+
SOCKET 370
CHAPTER 2
HARDWARE SETUP
2-1 CPU INSTALLATION
1. Pull the lever sidways away from the socket, and then raise the lever up
to a 90-degree angle.
2. Take note of the red circle as below picture. When insert the PU into
socket, you can find out there is a definite pin orientation for PU and
socket.
SOCKET 370

15
65M E / 65ME+
3. Make sure that the PU positions in the socket tightly, and then put the
lever down to complete the PU installation.
SOCKET 370
2-2 CPU FREQUENCY
• The CPU’s “CPU CLOCK RATIO” and “CPU HOST/PCI CLOCK” set-
tings are automatically detected to be default value by BIOS in the
“Frequency/Voltage Control” section.
• We do not suggest and assume the responsibility for any action that
changes the CPU default setting such as overcloc ing. Uncorrect
CLOCK RATIO and HOST/PCI CLOCK settings may cause damage
to your CPU.
2-3 MEMORY INSTALLATION
• Insert the module(s) as shown. DIMMs have 168-pins and two notches
that will match with the onboard DIMM soc et.
168-Pin DIMM Notch Key Definitions(3.3V)
DRAM Key Position Voltage Key Position
Unbuffered 3.3V

16
65ME / 65ME+
AGP Accelerator
AGP Pro slot
blockader
Accelerated Graphics Port (AGP) Pro Slot
Rib(inside slot)
20-pin bay Rib(inside slot) 28-pin bay
• WARNING:Ma e sure that you unplug your power supply when add-
ing or removing memory modules or other system components.
Failure to do so may cause severe damage to both your mainboard
and expansion cards.
Cloc 
Generator
LED1
AGP PRO
1 4
1 4
9 16
1 8
J2 J3
SPK RST KEYLOCK T/LED
HDD/LED IR PWR SUSPEND
++
--
+-
1 15 1 15
I/O
Controller
FWH
Intel
ICH2
SOCKET 370
LPT1
VGA1 COM1
GAME/MIDI PORT
LINE OUT
LINE IN
MIC
PS/2 MOUSE PS/2 K/B
upper
lower
USB1 USB0
upper
lower
DVC1
Intel
815E
GMCH
Li
Battery
CREATIVE
ES1373
RT1
DIMM2 DIMM1 DIMM3
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
COM2
JWOL1
TAD1

TV1
CD_IN1
CD_IN2

JP21

1 3
CNR
USB1 SCR1
1 3
1 3
JBAT1
JBAT2
IDE2 IDE1
FDC1
1 3
1 3
JP2
JP8
JP9
JP10
1 3
JP11
1 3
JP1
CPUFA1
ATX POWER
AUXFA1
1 11
1 3 1 3
JP5 JP6
CHAFA1 RT2
NOTI E : When LED1 light is on ,
meaning that 3.3V is conducting DIMM
slots , please do not add or remove
memory modules .
2-4 ACCELERATED GRAPHICS PORT(AGP) PRO INSTALLATION
• This motherboard provides an accelerated graphics port (AGP) pro
slot to support a new generation of AGP graphics cards with ultra-
high memory bandwidth. This slot can also support an AGP Inline
Memory Module(AIMM) for up to 4MB of 133 MHz SDRAM display
cache to wor with the integrated graphics controller to deliver high
quality video graphics.

17
65M E / 65ME+
CAUTION!!
The AGP Pro slot is shipped with a warning label over the 20-pin bay.Do not remove
this lable and the safety tab underneath it if you will be using an AGP card without
a retention notch.Removing may cause the card to shift and may cause damage to
your card , slot , and motherboard. Remove ONLY when you will be using an AGP
Pro card.
2-5 HDD / FDD INSTALLATION
• To install HDD (Hard Dis Drive), you may connect the cable’s blue
connector to the motherboard’s primary (IDE1) or secondary IDE
connector, and then connect the gray connector to your slave de-
vice and the blac connector to your master device.If you install two
hard dis s , you must configure the second drive to Slave mode by
setting its jumper accordingly.Please refer to your hard dis docu-
mentation for the jumper settings.
• To install FDD (Floppy Dis Drive), you may connect the single end
to the board , and connect two plugs on the other end to the floopy
drives.
Floppy Dis Drive Connector:
Orient the red mar ings on
the floppy ribbon cable to
Pin1.
Hard Dis Drive Connector:
Orient the red mar ings on
the IDE ribbon cable to Pin1.
Cloc 
Generator
LED1
AGP PRO
1 4
1 4
9 16
1 8
J2 J3
SPK RST KEYLOCK T/LED
HDD/LED IR PWR SUSPEND
++
--
+-
1 15 1 15
I/O
Controller
FWH
Intel
ICH2
SOCKET 370
LPT1
VGA1 COM1
GAME/MIDI PORT
LINE OUT
LINE IN
MIC
PS/2 MOUSE PS/2 K/B
upper
lower
USB1 USB0
upper
lower
DVC1
Intel
815E
GMCH
Li
Battery
RT1
DIMM2 DIMM1 DIMM3
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
COM2
JWOL1
CD_IN1
CD_IN2
CNR
USB1 SCR1
1 3
1 3
JBAT1
JBAT2
IDE2 IDE1
FDC1
1 3
1 3
JP2
JP8
JP9
JP10
1 3
JP11
1 3
JP1
CPUFA1
ATX POWER
AUXFA1
1 11
1 3 1 3
JP5 JP6
CHAFA1 RT2
AC'97
Codec

18
65ME / 65ME+
2-6 JUMPER DEFINITION
• The figure below shows the location of the motherboard’s jumper blocks.
CAUTION
• Do not move the jumper with the power on. Always turn off the power and unplug
the power cord from the computer before changing the jumper. Otherwise, the
motherboard could be damaged.
Disabled (default)
Enabled
JP1: KEYBOARD POWER ON
JP1
JP1
3


1
3


1
Those connectors support processor/system/chassis cooling fan with +12V. Those
support three pin head connector. When connecting the wire to FAN connectors
user should give attention that the red wire is the positive and should be connected
to the +12V the black wire is Ground and should be connected to GND. If your
motherboard has Hardware Monitor chipset on-board you must use a specially
designed fan with speed sensor to take advantage of this function.
For fans with fan speed sensor every rotation of the fan will send out 2 pulses.
System Hardware Monitor will count and report the fan rotation speed.
NOTE 1: Always consult vendor for proper CPU cooling fan.
NOTE 2: CPU FAN supports the FAN control. You can install PC Alert utility.
This will automatically control the CPU FAN speed according to the
actual CPU temperature.
PU FAN
CPUFA1/AUXFA1/CHAFA1: ONBOARD FAN (12V)
AUXFA1
CPUFA1
SYSTEM FAN
CHAFA1
HASSIS FAN
GND
+12V
SENSOR

19
65M E / 65ME+
66MHz / 100MHz / 133MHz
Auto Select (default)
JP5/JP6: BUS CLOCK SELECT
3


1
3


1
JP5 JP6
100MHz
3


1
3


1
JP5 JP6
133MHz
3


1
3


1
JP5 JP6
Redirect USB port 0 to USB 
connector (default)
JP2/JP8: USB PORT SELECT (1)
JP2
JP8
JP2
JP8
Redirect USB1 to AGP port
1 3
1 3
Redirect USB port 1 to USB 
connector (default)
JP9/JP10: USB PORT SELECT (2)
Redirect USB1 to NR port
JP9
JP10
1 3
JP9
JP10
1 3
Disabled (default)
Enabled
JP11: USB POWER ON FUNCTION
1
3
JP11
1
3
JP11
Enabled (default)
Disabled
JP21: ONBOARD CREATIVE SOUND SELECT
1


3
JP21
1


3
JP21
NOTE: This jumper is only for 65ME+.

20
65ME / 65ME+
D_IN1PIN NO.
CD_IN1/CD_IN2: CD-ROM AUDIO CONNECTOR
D_IN2
PIN 1 Left Channel
GND
PIN 2 GND
GNDPIN 3
Right ChannelPIN 4
GND
Left Channel
Right Channel
A battery must be used to retain the motherboard configuration in CMOS RAM.
NOTE : You can clear CMOS by shorting 2-3 pin when the system is POWER
OFF. Then return to 1-2 pin position (default). It may damage the
motherboard if clearing the CMOS in POWER ON status. Unplug the
power cord from power supply before clearing CMOS will be a best bet
for user.
lear MOS Data
JBAT1/JBAT2: CLEAR CMOS DATA
1 3
1 3
JBAT1
JBAT2
Retain Data (default)
1 3
1 3
JBAT1
JBAT2
This connector connects to a LAN card with a Wake On LAN output. The connector
powers up the system when a wake-up packet or signal is received through the
LAN card.
This feature requires that Wake On LAN feature is enabled at the BIOS “Power
Management Setup” and that your system has an ATX power supply with at least
720mA / +5V standby power.
onnect the Wake On LAN signal from LAN card
to JWOL1
JWOL1 : WAKE ON LAN (WOL) FUNCTION
JWOL1
TAD1 : Telephone Answering Device / Modem connector.
Connects a voice modem to transmit and receive audio signals.
TV1 : TV Tuner connector.
Connects a TV card or second CD-ROM drive.
TAD1 / TV1 is only for 65ME+
TAD1PIN NO.
TAD1 / TV1 CONNECTOR
TV1
PIN 1 TV_L CHANNEL
PHONE
PIN 2 GND
GNDPIN 3
TADOUTPIN 4
GND
GND
TV_R CHANNEL
