SOMFY inteo CENTRALIS UNO RTS User manual

CENTRALIS UNO RTS is an individual control system for AC motor dedicated to roller shutters
and interior blind applications.
•
CENTRALIS UNO RTS has an integrated radio receiver compatible with the RT and RTS
transmitters allowing individual, group and master commands. Up to twelve controls can be
recorded in the CENTRALIS UNO RTS memory.
•
The commands coming from the radio controls can be disabled thanks to the 0/auto switch.
•
One or two intermediate positions can be programmed.
•
Compatible with sensor (sun protection functionning only) Up to three sensors can be recorded.
inteo CENTRALIS UNO RTS
INSTALLATION guide
Ref.9007504D
80 mm
80 mm
33 mm 17 mm
•Main supply : 220-240V 50Hz.
•Class II product
•Protection index IP40.
•Output : 250V~ 3A
•Output temporisation : activ for 180s.
•Environmental conditions for use :
- temperature 0°C to +40°C (no condensation allowed).
- pollution degree typical for usual living space.
We reserve the right to make changes due to technical improvements.
1
CENTRALIS uno RTS
FRONT PLATE
CONTROL UNIT
FRAME
BRACKET
WALL
1
Characteristics
2
Installation
The range of radio control is limited by laws regulating
radio devices and by building design.
When planning, please ensure that there is adequate
radio reception.
In order not to affect quality of reception, a minimum
distance of 30 cm between a CENTRALIS uno RTS
and a radio transmitter should be maintained.
CENTRALIS uno RTS should not be installed in the
immediate vicinity of metal surfaces. Powerful local
transmitter equipment (e.g. cordless headphones) with a
transmission frequency identical to the CENTRALIS
uno RTS can affect its function.
Hereby, SOMFY, declares that this equipment
is in compliance with the essential require-
ments and other relevant provisions of
Directive 1999/5/EC.
A Declaration of Conformity is available at the
web address www.somfy.com Heading CE
We reserve the right to make changes due to technical improvements.
CENTRALIS uno RTS
4
Nothing works:
Check the motor.
Check the power supply.
Check the battery of the transmitter.
Check that the transmitter has been properly
recorded in the CENTRALIS uno RTS’s memory.
Check for any other possible source of radio
interferences.
Phantom intermediate position:
The programmed IP can only be reached from the
UP or DOWN limits. not when the shutter is in ano-
ther position.
Lost in your programming mode:
Just make a complete reset and start again
(refer to section 5).
6
Trouble shooting guide
This device must be installed and programmed by qualified installers for whom this instruction is inten-
ded.
Before connecting the unit, read the instructions carefully.
SOMFY SAS, capital 20.000.000 Euros, RCS Bonneville 303.970.230
Assembly
2.1
Set the blind to its DOWN limit before programming in order to always have the same adjustment.
Programming the 2nd intermediate position (IP2)
b
• Move the shutter/blind at its DOWN
limit with the ▼button and immedia-
tely press the ■button briefly.
• Press the ▲and ■button simulta-
neously until the shutter/blind begins
to move DOWN.
• Stop the shutter/blind at the inter-
mediate position you wish.
If necessary, adjust this position with
the ▲or ▼buttons.
• Press the ■button more than 5 sec.
➜The shutter/blind jogs briefly
(UP/DOWN), the 2nd intermediate posi-
tion is recorded.
after
3 seconds
STOP IP2
2
13 4
5 sec.
DOWN
Operating
c
• Press briefly the ■button while the blind is
at its UP limit.
➜The shutter/blind will move down and stop
at the 1st intermediate position.
1st intermediate position
IP1
UP limit
• Press briefly the ■button while the blind is at
its DOWN limit.
➜The shutter/blind will move up and stop at the
2nd intermediate position.
2nd intermediate position
IP2
DOWN limit
If you record a new IP, this will automatically erase the previous one.
If you want to erase without recording a new one, Press briefly on the ■button to reach the IP, then:
To erase the 1st intermediate position, press ■ button for more than 5 seconds.
To erase the 2nd intermediate position, press ■button for more than 5 seconds.
➜The shutter/blind jogs briefly (UP/DOWN) indicating that CENTRALIS uno RTS has deleted the intermediate position.
Delete the intermediate position
d
5
Complete reset
To completely reset the CENTRALIS uno RTS, press its PROG button for more than 7 seconds.
This will erase all of the programmed controls, the intermediate positions.
➜The shutter/blind jogs twice (UP/DOWN), the memory of the CENTRALIS uno RTS is cleared.
P
R
O
G
7 sec.
centralis uno RTS_9007504D 30/08/06 17:17 Page 1

We reserve the right to make changes due to technical improvements.
CENTRALIS uno RTS
2
MAINS
230V - 50Hz
3 wires x 1,5 mm2
4 wires x 0,75 mm2
Neutral
Earth
Phase
1 2 3456
5 wires x 1,5 mm2
NL N
Centralis uno RTS
Junction box MotorSupply
Phase
Neutral
Earth Earth (green/yellow)
Common (blue)
Up (black or brown)
Down (black or brown)
L➜
N➜
N
▲
▼
1
2
3
4
5
6
NL N
SUPPLY
230V 50Hz
Phase
Neutral
Earth
LT motor
DOWN
PE
N
UP
•disconnect mains before carrying out any work.
•ensure that no forces act on the screw terminals
after installation.
3
Radio programming
We reserve the right to make changes due to technical improvements.
3
CENTRALIS uno RTS
4
Operating
Wiring
2.2
Initial installation : record the first control
3.1
GROUP CONTROL (one transmitter for several receivers)
To program one control in several CENTRALIS uno RTS, set all the receivers in their programming mode then repeat the same procedure.
It is recommended not to use a RT control as a general control point.
To record several RTS controls in CENTRALIS uno RTS, repeat the same procedure as described in section 3.1 for each control.
You can also use an already recorded control to set the
CENTRALIS uno RTS in its programming mode
RTS control : press for more than 2 sec. on the “prog” button.
RT control : Contact for more than 2 sec. between the “prog” metallic part and the battery support.
➜The LED of the CENTRALIS uno RTS lights on and the blind jogs briefly UP and DOWN indicating that the
CENTRALIS uno RTS is in programming mode and that you can record a new control.
You can program up to 12 controls to one receiver. If you try to enter a 13th, your instruction will be ignored.
P
R
O
G
Set the CENTRALIS uno RTS in its
programming mode by pressing the PROG
button until the blind jogs briefly (UP/DOWN).
The CENTRALIS uno RTS will remain
ready to record a control for two minutes.
P
R
O
G
➜
2 sec.
00,,55ss
➜
The blind jogs briefly (UP/DOWN)
and the LED of the CENTRALIS
uno RTS blinks during 5 secs.
indicating that the control has been
recorded.
CENTRALIS uno RTS quits its
programming mode.
RTS control
Press briefly the program-
ming button on the RTS
control you wish to record.
RT control
Short contact between the
PROG metallic part and the
battery support, on the RT
control you wish to record
Record new controls
3.2
12
Press the prog button of the CENTRALIS uno RTS to enter in programming mode, then press shortly the prog button of the RTS control
you wish to remove.
It is also possible to set the CENTRALIS uno RTS in its programming mode with another RTS control (see 3.2), then press
shortly the prog button of the RTS control you wish to remove.
To remove all the controls, do a complete reset of the
CENTRALIS uno RTS (see section 5).
Remove a control (on an existing installation)
3.3
CENTRALIS uno RTS can be operated by its push-buttons or with a RT/RTS control.
“auto” position :
All commands from the push buttons of the CENTRALIS uno RTS (local control), from the radio controls
(master control), and sun sensor are taken into account.
“0” position :
Only the push button commands are taken into account and the radio commands are disabled (This feature
allows to isolate a room from the master control). To force the control of the CENTRALIS uno RTS with radio,
the radio command should be longer than 2 sec.
UP/DOWN/STOP commands
4.1
0/auto switch
4.2
Press briefly the ▼or ▲buttons to raise or lower the shutter/blind.
Press briefly the ■button to stop the shutter/blind in motion.
To reach the intermediate position (section 4.4), press briefly the ■
button when the shutter/blind is at its end limits.
UP button
0/auto switch
STOP/IP button
DOWN button
Intermediate positions
4.3
With the CENTRALIS UNO RTS, it is possible to set one or two intermediate positions (IP) : one accessible from the top of the
shutter/blind (IP1) and one from the bottom (IP2).
To record these positions, the CENTRALIS UNO RTS has to record the time for the shutter/blind to go from its top to the IP and
also the time from its bottom one to the IP.
The recording of the intermediate position can be made from the CENTRALIS uno RTS or from a RTS control.
• Move the shutter/blind at its UP
limit with the ▲button and imme-
diately press the ■button briefly.
• Press the ▼and ■button simulta-
neously until the shutter/blind begins
to move DOWN.
• Stop the shutter/blind at the inter-
mediate position you wish.
If necessary, adjust this position with
the ▲or ▼buttons.
• Press the ■button more than 5 sec.
➜The shutter/blind jogs briefly
(UP/DOWN), the 1st intermediate posi-
tion is recorded.
after
3 seconds STOP IP1
Set the blind to its UP limit before programming in order to always have the same adjustment.
2
13 4
5 sec.
UP
Programming the 1st intermediate position (IP1)
a
0,5 s
