Sonoff TH Origin User manual

The Origin/Elite
Smart Temperature and
Humidity Monitoring Switch
User Manual • Uživatelský manuál •
Užívateľský manuál • Használati utasítás •
Benutzerhandbuch

2
English
3 –16
Čeština
17 –30
Slovenčina
31 –44
Magyar
45 –58
Deutsch
59 –72

3
Dear customer,
Thank you for purchasing our product. Please read the following instructions carefully
before first use and keep this user manual for future reference. Pay particular attention to
the safety instructions. If you have any questions or comments about the device, please
contact the customer line.
✉www.alza.co.uk/kontakt
✆[phone]
Importer Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz

4
Product Introduction
TH Origin
TH Elite
Button
Protective cover
Sensor interface
On/Off LED indicator (Red)
Wi-Fi LED indicator(Blue)
Auto mode LED
indicator (Green)
Mounting base
Button
LED screen
Protective cover
Sensor interface
On/Off LED indicator (Red)
Wi-Fi LED indicator(Blue)
Mounting base
Auto mode LED
indicator (Green)
Dry contact interface

5
The device weight is less than 1kg. The installation height of less than 2m is
recommended.
Button instructions
Actions
Results
Single-click
Device on/off
Double-click
Auto-mode enable/disable
Long press for 5s
Enter the Pairing mode
LED indicator status instruction
LED indicator status
Status instruction
Blue LED indicator flashes (one long and
two short)
Pairing mode
Blue LED indicator keeps on
Device is online
Blue LED indicator quick flashes once
Fail to connect to router
Blue LED indicator quick flashes twice
Connected to router but fail to connect
Blue LED indicator quick flashes three
times
Firmware updating
Green LED indicator keeps on
Auto-models on
Features
TH Origin/Elite is a DIY smart switch with temperature and humidity monitoring, and
required to use with the temperature and humidity sensors correspondingly.
Temp &Humi
Monitoring
Temp&Humi
History Data
Graph
Automatic
Mode
Share Control
Inching Mode
Voice Control
Timer Schedule
LAN Control
Wet&Dry
Contact
(TH Elite)
Screen Display
(TH Elite)

6
Device Installation
1. Power off
Please install and maintain the device by a professional electrician. To avoid electric
shock hazard, do not operate any connection or contact the terminal connector while the
device is powered on!
2. Wiring instruction
Remove protective cover
Wiring method of dry contact

7
Press the white button on the top of the wire connecting hole to insert the wire
corresponding, then release.
Dry contact wire conductor size: 0.13-0.5mm2, wire stripping length: 9-10mm.
Make sure all wires are connected correctly.
3. Insert the sensor
Compatible SONOFF sensors: DS18B20, MSO1,THSO1,AM2301, Si7021.
Compatible sensor extension cables: RL560.
Some old version sensors need to be used with the accompanying adapter.
Device pairing
1. Download the eWeLink App

8
2. Power on
After powering on, the device will enter the Bluetooth Pairing Mode during the first use.
The Wi-Fi LED indicator changes in a cycle of two short and one long flash and release.
The device will exit the Bluetooth Pairing Mode if not paired within 3mins. If you want
to enter this mode, please long press button for about 55 until the Wi-Fi LED indicator
changes in a cycle of two short and one long flash and release.
3. Add device
Method 1: Bluetooth Pairing

9
Tap "+" and select "Bluetooth Pairing", then operate following the prompt on the App.
Method 2: Scan QR code
In the Pairing mode, tap “Scan QR code”to add the device by scanning the QR code
on its back.
Alexa voice control instructions
1. Download the Amazon Alexa App and sign up an account.
2. Add Amazon Echo Speaker on the Alexa App.
3. Account Linking (Link Alexa account on the eWeLink App)

10
4. After linking the accounts, you can discover devices to connect on the Alexa App
according the prompt.
Account linking method of Google Assistant, Xiaodu, Tmall Genie, Mate Xiaoai and etc
is similar., the guides on the App shall prevail.
