Sony IPELA PCS-HG90 User manual

© 2006 Sony Corporation
3-991-626-15 (1)
Video
Communication
System
Operating Instructions (Version 2.2)
Before operating the unit, please read this manual thoroughly and retain it for
future reference.
PCS-HG90

2
Owner’s Record
The model and the serial numbers are
located on the side. Record the serial number
in the space provided below. Refer to these
numbers whenever you call upon your Sony
dealer regarding this product.
Model No. PCS-HG90
Serial No. ______________
WARNING
To reduce a risk of fire or electric
shock, do not expose this product
to rain or moisture.
To avoid electrical shock, do not
open the cabinet. Refer servicing to
qualified personnel only.
WARNING
THIS APPARATUS MUST BE
EARTHED.
CAUTION
The mains plug on this equipment must be
used to disconnect mains power.
Please ensure that the socket outlet is
installed near the equipment and shall be
easily accessible.
In the event of abnormal operations,
disconnect the mains plug.
NOTICE
Use the power cord set approved by the
appropriate testing organization for the
specific countries where this unit is to be
used.
CAUTION for LAN port
For safety reasons, do not connect the LAN
port to any network devices that might have
excessive voltage.
Installing batteries
Two R6 (size AA) batteries are supplied for
Remote Commander.
To avoid risk of explosion, use R6 (size AA)
manganese or alkaline batteries.
CAUTION
RISK OF EXPLOSION IF BATTERY IS
REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES
ACCORDING TO ALL APPLICABLE
LOCAL REGULATIONS.
For the customers in the USA
WARNING
This equipment has been tested and found to
comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference when the equipment is operated
in a commercial environment. This
equipment generates, uses, and can radiate
radio frequency energy and, if not installed
and used in accordance with the instruction
manual, may cause harmful interference to
radio communications. Operation of this
equipment in a residential area is likely to
cause harmful interference in which case the
user will be required to correct the
interference at his own expense.
You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate
this equipment.
This device complies with Part 15 of the
FCC Rules.
Operation is subject to the following two
conditions: (1) This device may not cause
harmful interference, and (2) this device
must accept any interference received,
including interference that may cause
undesired operation.

3
All interface cables used to connect
peripherals must be shielded in order to
comply with the limits for a digital device
pursuant to Subpart B or Part 15 of FCC
Rules.
For the customers in Canada
This Class A digital apparatus complies with
Canadian ICES-003.
Cet appareil numérique de la classe A est
conforme à la norme NMB-003 du Canada.
For the customers in Europe
WARNING
This is a Class A product. In a domestic
environment, this product may cause radio
interference in which case the user may be
required to take adequate measures.
In the case that interference should occur,
consult your nearest authorized Sony service
facility.
Voor de Klanten in Nederland
If you dispose the unit, consult your nearest
Sony Service Center. The built-in battery
must be treated as a chemical waste.
Für Kunden in Deutschland
Entsorgungshinweis: Bitte werfen Sie nur
entladene Batterien in die Sammelboxen
beim Handel oder den Kommunen. Entladen
sind Batterien in der Regel dann, wenn das
Gerät abschaltet und signalisiert “Batterie
leer” oder nach längerer Gebrauchsdauer der
Batterien “nicht mehr einwandfrei
funktioniert”. Um sicherzugehen, kleben Sie
die Batteriepole z.B. mit einem
Klebestreifen ab oder geben Sie die
Batterien einzeln in einen Plastikbeutel.
For Customers in Taiwan only
Gooi de batterij niet weg maar
lever deze in als klein
chemisch afval (KCA).

4Table of Contents
Table of Contents
Chapter 1: Installation and Preparation
Using This Manual ................................................................................................... 9
Features .................................................................................................................. 10
System Components .............................................................................................. 11
Basic System Components ............................................................................... 11
Optional Equipment ......................................................................................... 12
System Configuration ............................................................................................ 14
System Configuration for Peer-to-Peer Connection ........................................ 14
System Configuration for Multipoint Connection ........................................... 15
System Configuration Using the PCSA-A7 Echo Canceling Microphones .... 16
System Connections ............................................................................................... 17
System Connection ........................................................................................... 17
Preparing the System ............................................................................................. 21
Attaching the Remote Control Receiver .......................................................... 21
Inserting Batteries into the Remote Commander ............................................. 22
Turning the System On/Off ................................................................................... 24
Turning On ....................................................................................................... 24
Standby Mode Function ................................................................................... 26
Setting the Video Communication System to Standby Mode .......................... 26
Turning Off ...................................................................................................... 27
Adjusting the Volume on the TV Monitor ....................................................... 27
Displaying Help ............................................................................................... 28
Displaying the Versions ................................................................................... 28
Setting Up the System for the First Time — Initial Setup Wizard ........................ 29
Using the Menus .................................................................................................... 30
Operation .......................................................................................................... 30
Menu Configuration ......................................................................................... 32
Entering Characters .......................................................................................... 34
Chapter 2: Registration and Setup for System
Administrators
Registering Local Information ............................................................................... 36
Opening the Setup Menu .................................................................................. 36
Dial Setup Menu .............................................................................................. 37
Answer Menu ................................................................................................... 37
Communication Mode Menu ........................................................................... 38

5Table of Contents
Status Menu ...................................................................................................... 39
Audio Setup Menu ............................................................................................ 41
Video Setup Menu ............................................................................................ 43
General Setup Menu ......................................................................................... 47
Administrator Setup Menu ............................................................................... 50
LAN Setup Menu ............................................................................................. 54
Encryption Setup Menu .................................................................................... 59
Machine Information Menu .............................................................................. 59
Registering a Remote Party – Phone Book ............................................................ 60
Registering a New Remote Party in the Phone Book ....................................... 60
Changing the Contents of the Phone Book ...................................................... 61
Copying the Registered Remote Party ............................................................. 62
Deleting the Registered Remote Party ............................................................. 62
Registering a Remote Party in the Direct Phone Book .................................... 62
Creating a Private Phone Book ........................................................................ 63
Setting Up the Network Configurations ................................................................. 65
LAN (Connecting via DHCP) .......................................................................... 65
LAN (Connecting Through a Router) .............................................................. 66
LAN (Connecting through a Gatekeeper) ........................................................ 67
LAN (Connecting through NAT) ..................................................................... 68
LAN (PPPoE Connections) .............................................................................. 69
Measuring the Network Quality ............................................................................. 71
Setting the Transmitting Image Quality ................................................................. 74
Chapter 3: Basic Connection
Starting a Communication by Calling a Remote Party .......................................... 76
Turning on the Power ....................................................................................... 76
Using the Launcher Menu ................................................................................ 77
Displaying the Launcher Menu During Communication ................................. 80
Calling a Remote Party ..................................................................................... 81
Receiving a Call from a Remote Party ................................................................... 89
Answering a Call from a Remote Party ............................................................ 89
Ending the communication .................................................................................... 91
Adjusting the Sound ............................................................................................... 92
Adjusting the Volume ...................................................................................... 92
Turning Off the Sound Momentarily – Muting Function ................................. 92
Turning Off the Sound On Answering – Mic on Answer Function ................. 93
Reducing Echo – Echo Canceler ...................................................................... 93
Adjusting the Camera ............................................................................................. 95
Selecting the Camera to be Controlled ............................................................. 95
Adjusting the Camera Angle and Zoom ........................................................... 96

6Table of Contents
Adjusting the Focus and Brightness ................................................................. 98
Presetting the Angle and Zoom Settings .......................................................... 99
Recalling the Preset Angle and Zoom Setting ............................................... 101
Selecting the Input Picture and Sound ................................................................. 103
Switching the Displayed Picture Between the Local and Remote Pictures ... 103
Selecting the Input Picture ............................................................................. 103
Switching the Sound to Be Sent to the Remote Party .................................... 104
Switching Video and Audio simultaneously .................................................. 104
Monitoring the Local Picture as a Window Picture – PinP Feature .................... 105
Monitoring the Local and Remote Pictures at the Same Time – PandP/Side by Side
Feature ................................................................................................................. 107
Capturing the Image ............................................................................................. 109
Using a “Memory Stick” ...................................................................................... 111
Saving Still Images to a “Memory Stick” ...................................................... 111
Formatting a “Memory Stick” ........................................................................ 113
Chapter 4: Connection With Optional Equipment
Using a Monitor Exclusively for Local Pictures ................................................. 115
Using Multiple Microphones ............................................................................... 117
Using the Echo Canceling Microphones ............................................................. 120
Using the Second Camera Unit ............................................................................ 123
Recording During a Communication ................................................................... 124
Sending Audio/Video from the External Equipment to a Remote Party ............. 125
Chapter 5: Encrypted Connection
Preparing for an Encrypted Connection ............................................................... 128
Starting an Encrypted Connection ....................................................................... 130
Chapter 6: Multipoint Connection
Connection Example for a Multipoint Connection .............................................. 131
Setting for a Multipoint Connection .................................................................... 132
Confirming the Communication Mode Menu ................................................ 132
Registering the Remote Parties in the Multipoint Connection List ............... 132
Starting a Multipoint Connection ........................................................................ 136
Calling Remote Parties ................................................................................... 136
Receiving a Call from a Remote Party ........................................................... 140
Using the Display Control ................................................................................... 141

7Table of Contents
What is “Broadcast Mode”? ........................................................................... 141
Switching the Broadcast Mode ....................................................................... 141
Receiving the Broadcast Requested From Any Other Terminal .................... 142
Ending the Multipoint Connection ....................................................................... 143
Chapter 7: Web Control Function
Open the Web page .............................................................................................. 144
Identify a user ....................................................................................................... 145
Select a tool .......................................................................................................... 146
How to use “Controller” ...................................................................................... 147
To control the PCS-HG90 from the on-screen controller .............................. 147
To control the PCS-HG90 from the on-screen Remote Commander ............. 148
How to use “Dial/Disconnect” ............................................................................. 149
For Peer-to-Peer Connection .......................................................................... 149
For Multipoint Connection ............................................................................. 150
How to use “Phone Book” ................................................................................... 151
“Phone Book-Edit” page ................................................................................ 152
“Phone Book-New” page ............................................................................... 153
How to use “Setup” .............................................................................................. 154
“Send Message” page ..................................................................................... 156
“Erase” page ................................................................................................... 157
How to use “Info” ................................................................................................ 158
“Cause Code” list page ................................................................................... 159
“Call Log” page .............................................................................................. 160
Monitor a Meeting Over the Web ........................................................................ 161
Appendix
Location and Function of Parts and Controls ....................................................... 162
PCS-PHG90 Communication Terminal ......................................................... 162
PCSA-CHG90 Camera Unit (Optional) ......................................................... 164
PCSA-RG1 Remote Commander ................................................................... 166
Indicators .............................................................................................................. 168
On-screen Messages ............................................................................................. 171
Troubleshooting ................................................................................................... 177
Specifications ....................................................................................................... 179
PCS-PHG90 Communication Terminal ......................................................... 179
PCSA-RG1 Remote Commander ................................................................... 179
PCSA-CHG90 Camera Unit (optional) .......................................................... 179
PCS-A1 Microphone (Optional) .................................................................... 180

8Table of Contents
PCSA-A3 Microphone (Optional) ................................................................. 180
PCSA-A7P4 Microphone (4-pack, optional) ................................................. 180
Acceptable RGB Input/Output Signals .......................................................... 181
Pin Assignments ............................................................................................. 182
List of Port Numbers Used on the PCS-HG90 ............................................... 184
Video Communication Room Layout .................................................................. 185
Camera Range ................................................................................................ 185
“Memory Stick” Media ........................................................................................ 186
Glossary ............................................................................................................... 188
Menu Configuration ............................................................................................. 190

9Using This Manual
Chapter 1: Installation and Preparation
Using This Manual
The chapters cover the following contents;
please read the chapters that may be required
for your type of connection.
Chapter 1: Installation and
Preparation
This chapter guides you through the system
configuration and information required to
use your Video Communication System for
the first time. It shows you how to install and
connect your Video Communication
System, to turn the system on/off and how to
access basic on-screen menus.
Chapter 2: Registration and Setup for
System Administrator
This chapter describes how to register and
set up all the necessary items for system
administrators, using the on-screen menus.
Chapter 3: Basic Connection
This chapter guides you through the basic
operations and settings for connecting to a
remote party. You will learn how to connect
from start to finish. It is recommended that
this chapter be read by participants in
connection.
Chapter 4: Connection With Optional
Equipment
This chapter shows advanced connection
using the optional equipment.
Chapter 5: Encrypted Connection
This chapter describes how to connect with
encrypted video and audio.
Chapter 6: Multipoint Connection
This chapter shows you how to connect at
the multipoint.
Chapter 7: Web Control Function
This chapter shows you how to control the
PCS-HG90 or set it up via a Web browser.
Appendix
The appendix contains descriptions of the
controls and connectors on the components
of the Video Communication System,
message and troubleshooting lists,
specifications, and a glossary.
Chapter 1:
Installation and
Preparation

10 Features
Features
The PCS-HG90 is a Video Communication
System that connects with a remote party via
a LAN (Local Area Network). It provides
natural, face-to-face communication with
the remote party by transmitting and
receiving high-definition pictures and stereo
sounds at high speed.
Network Quality Measurement
The system is capable of diagnosing the
network conditions easily by measuring
reachability, packet loss, etc.
Supports transmission and
reception of high-definition images
The Video Communication System supports
H.264 high-definition video compression
format, enabling transmission and reception
of pictures with a high resolution of 1280 ×
720 by 60 frames (maximum) per second.
Supports transmission and
reception of wide-range stereo
sound
The system supports MPEG4 AAC
(Advanced Audio Coding) stereo/monaural
audio compression format of 22 kHz with
echo canceler, enabling transmission and
reception of high-quality audio sound.
Equipped with professional-
standard AV interface
The system is equipped with HD-SDI
connectors and YPbPr (component signal)
connectors for video input/output, allowing
shooting, transmission and reception of
digital signal. It is also equipped with XLR-
type audio input/output connectors, enabling
connection with audio equipment for
professional use.
QoS (Quality of Service) function
for optimization of bandwidth and
traffic packet through network
The system includes “Packet Resend
Request”, “Adaptive Rate Control”, and
“Forward Error Control” functions.
Depending on the network status, these
functions are used to guarantee consistent,
high-quality communications.
Easy operation
Help is displayed on the monitor when you
need guidance.
Supports multipoint connection
The system allows a multipoint connection
among up to four points.
Equipped with Memory Stick slot
The Communication Terminal is equipped
with a Memory Stick Slot, allowing saving
of still images, creation of private phone
books and storage of customized settings in
a “Memory Stick”.
Echo Canceling Microphone
Using a cascade connection, up to 40 PCSA-
A7 Echo Canceling Microphones (optional)
can be connected to one port without losing
sound quality.
Supports Encrypted Connection
This system supports the standard
encryption format based on H.235 which is
regulated in ITU-T. A highly confidential
communication can be held.
“IPELA” and are trademarks of Sony Corporation.

11System Components
Chapter 1: Installation and Preparation
System Components
The PCS-HG90 Video Communication System is composed of basic system
components for a basic connection, and optional equipment for an enhanced
communication.
The PCS-PHG90 Communication Terminal is the basic system o f the
PCS-HG90 Video Communication System. It contains the following
comp
onents:
Basic System Components
Unit Description
PCS-PHG90 Communication
Terminal
Contains the video codec, audio codec, echo
canceler, network interfaces and system controller.
PCSA-RG1 Remote
Commander
Used to operate the Communication Terminal and
Camera Unit.
AC power cord Supplies power to the Communication Terminal.
Remote Control Receiver Connects to the Communication Terminal and
receives signals from the Remote Commander.
The Camera Unit cannot receive signals from the
Remote Commander.
Note

12 System Components
TV monitor
A TV or projector, etc. is required to monitor the images.
Optional equipment especially designed for use with the PCS-HG90
The following optional devices are used to perform your video
communication.
Optional Equipment
Unit Description
TV, Projector, etc. Used as a monitor and speakers.
Unit Description
PCSA-CHG90 Camera Unit
Camera unit especially designed for use with the
PCS-HG90.
PCS-A1 Microphone Omni-directional microphone that picks up sound
relatively from all directions, allowing participants to
speak from any location. It is recommended to use in
a quiet situation.
PCSA-A3 Microphone Unidirectional microphone. It is recommended when
you want to pick up the voice of a speaker directed
toward the microphone.

13System Components
Chapter 1: Installation and Preparation
PCSA-A7P4 Echo Canceling
Microphone
Narrow coverage monaural microphones that feature
high sound quality and a built-in echo canceler.
Several PCSA-A7 microphones can be connected in
cascade, without losing sound quality.
Recommended when using several microphones.
(4-piece set)
Unit Description

14 System Configuration
System Configuration
The PCS-HG90 Video Communication System has various system
configuration capabilities using the basic components and optional equipment.
This section describes the capabilities and necessary equipment for some
typical configuration examples.
This allows you to:
• Hold a peer-to-peer connection over LAN.
• Pick up the sound of a communication in stereo by connecting two external
microphones.
System configuration
System Configuration for Peer-to-Peer Connection
ONLINE POWER/STANDBY LAN ALERT
ONLINE POWER/STANDBY LANALERT
1PCS-PHG90 Communication Terminal
2PCSA-CHG90 Camera Unit
(not supplied)
3PCSA-RG1 Remote Commander
4Remote Control Receiver
5TV monitor (not supplied)
6PCSA-A3 Microphones (not supplied), 2
pieces

15System Configuration
Chapter 1: Installation and Preparation
This allows you to:
• Hold a multipoint connection among up to four sites over LAN.
System configuration
System Configuration for Multipoint Connection
ONLINE POWER/STANDBY LAN ALERT
ONLINE POWER/STANDBY LANALERT
ONLINE POWER/STANDBY LANALERT
ONLINE POWER/STANDBY LANALERT
1PCS-PHG90 Communication Terminal
2PCSA-CHG90 Camera Unit (not supplied)
3PCSA-RG1 Remote Commander
4Remote Control Receiver
5TV monitor (not supplied)
6PCSA-A3 Microphones (not supplied), 2 pieces

16 System Configuration
This allows you to:
• Connect up to 40 PCSA-A7 Echo Canceling Microphones to one
microphone connector, using a cascade connection. PCSA-A7 Microphones
can be connected in cascade, without a decrease in sound quality, ideal for
large meetings.
• Connect additional microphones during a communication.
System configuration
• Position the Microphones about 50 cm (1.6 ft) away from the participants.
• When using speakers, do not place them in front of the microphones.
• PCSA-A7 echo canceling microphone is monaural type.
For information about PCSA-A7 Microphones, see “Using the Echo
Canceling Microphones” on page 120.
System Configuration Using the PCSA-A7 Echo Canceling
Microphones
Notes
ONLINE POWER/STANDBY LAN ALERT
ONLINE POWER/STANDBY LANALERT
1PCS-PHG90 Communication Terminal
2PCSA-CHG90 Camera Unit (not supplied)
3PCSA-RG1 Remote Commander
4Remote Control Receiver
5TV monitor (not supplied)
6PCSA-A7 Echo Canceling Microphones (PCSA-A7P4: 4-piece set, 2 sets, not supplied)

17System Connections
Chapter 1: Installation and Preparation
System Connections
This section describes the typical system connections.
• Be sure to turn off all the equipment before making any connections.
• Do not connect/disconnect the BNC cable or VISCA cable with the power on. Doing so
may damage the Camera Unit or Communication Terminal.
• For safety, do not connect the 100BASE-TX/10BASE-T connector to a network that
applies an excess voltage via the 100BASE-TX/10BASE-T connector.
• Be sure to connect the Camera Unit to the Communication Terminal using both the
BNC and VISCA cables. The picture from the camera cannot be viewed if it is directly
connected to a TV monitor.
• The REC OUT (MIXED) connectors are used to make an audio recording. These are
not used normaly.
Caution
System Connection
Notes
RGB
AUX CONTROL
CAMERA CONTROL 100BASE-TX/
10BASE-T
(VISCA)
~ AC IN
SUB MAIN
CTRL-S
REC OUT(MIXED)AUDIO OUT
RLR
AUDIO IN
VIDEO IN
S-VIDEO Y
1
VIDEO OUT
YPbPr
(NEAR ONLY)
YPbPr
2
HD-SDI HD-SDIHD-SDI
SUB
CAMERA
MAIN
CAMERA
Pb Pr
RMICL R
AUX 2
R
MIC
EC-MIC(A7)
12
A1/A3
(PLUG IN POWER)
1(R) 2(L)
LRL
AUX 1 L L
REC OUT (MIXED) connectors

18 System Connections
* Use of an optional BNC cable or VISCA cable allows connection of up to 100 m (328
ft.).
VISCARS-422
1 2 3 4 5 6 7 8 9
VISCARS-232C OUT
DCIN 12V
HFBK-HD1
MONITOR HD-SDI
RGB
AUXCONTROL
CAMERA CONTROL 100BASE-TX/
10BASE-T
(VISCA)
~ ACIN
SUB MAIN
CTRL-S
REC OUT(MIXED)AUDIOOUT
RLR
AUDIO IN
VIDEO IN
S-VIDEO Y
1
VIDEO OUT
YPbPr
(NEAR ONLY)
YPbPr
2
HD-SDI HD-SDIHD-SDI
SUB
CAMERA
MAIN
CAMERA
Pb Pr
RMICL R
AUX 2
R
MIC
EC-MIC(A7)
12
A1/A3
(PLUG IN POWER)
1(R) 2(L)
LRL
AUX 1 L L
PCSA-CHG90 Camera Unit
Power cord
(supplied)
PCS-PHG90
Communication Terminal
to a wall outlet
to LAN
to VISCA RS-232C IN
to MIC A1/A3
TV monitor
(not supplied)
UTP cable
(category 5, straight, not supplied)
to video inputs
to AC outlet
PCSA-A3 or
PCS-A1
microphones
(not supplied)
to AC outlet
to HD-SDI
to VIDEO
OUT YPbPr
to AUDIO
OUT R/L
to VIDEO IN HD-SDI
MAIN CAMERA
VISCA cable (supplied with
the Camera Unit)
BNC cable*(supplied
with the Camera Unit)
to CAMERA
CONTROL
(VISCA)
MAIN
Audio connecting
cable (not supplied)
to audio inputs
Video connecting
cable (not supplied)

19System Connections
Chapter 1: Installation and Preparation
To set the BOTTOM switch of the PCSA-CHG90 Camera Unit
When you set the Frequency of Video Format to “50 Hz”, set the BOTTOM
switch (59.94i/50i signal format selector) on the bottom of the Camera Unit to
“ON” (HD video format of 50i system).
For details on the Frequency of Video Format, See page 44.
VISCA (Remote control) connection of the PCSA-CHG90 Camera Unit
Connect either the VISCA RS-232C or VISCA RS-422 connector on the
Camera Unit to the CAMERA CONTROL (VISCA) MAIN (or SUB)
connector.
• VISCA RS-232C: When connecting distance is within 15 m (49 ft.)
• VISCA RS-422: When connecting distance is between 15 m (49 ft.) and
100 m (328 ft.)
To set the RS-232C/RS-422 select switch
Before making the remote control connection, be sure to select RS-232C or
RS-422 with Switch 2 of the BOTTOM switch on the bottom of the Camera
Unit.
Set to ON for VISCA RS-422 connection, and set to OFF for VISCA RS-232C
connection.
O
N
1
2
3
4
O
N
1
2
3
4
Switch 1
BOTTOM switch on the bottom of the Camera Unit
Switch 2

20 System Connections
Connection using the VISCA RS-422
When you use the VISCA RS-422 connector on the Camera Unit to make the
remote control connection with the Communication Terminal instead of the
VISCA RS-232C connector, use of a converter between RS-422 and RS-232C
is required. For details on the converter, consult with the contractor of the
Camera Unit. Preparation of the connecting cable using the RS-422 connector
plug (supplied with the Camera Unit) is also required. For making the cable
and the use of the RS-422 connector plugs, refer to the Operating Instructions
of the Camera Unit.
• For the connector plugs of the connecting cables for the optional converter, prepare
plugs that match the connectors on the converter.
• When using the VISCA RS-422 connector, check that the BOTTOM switch on the
bottom of the Camera Unit is set to RS-422.
Notes
VISCA RS-422
1 2 3 4 5 6 7 8 9
VISCA RS-232C OUT
DC IN 12V
R
HFBK-HD1
MONITOR HD-SDI
RGB
AUXCONTROL
CAMERA CONTROL 100BASE-TX/
10BASE-T
(VISCA)
~ ACIN
SUB MAIN
CTRL-S
REC OUT(MIXED)AUDIOOUT
RLR
AUDIO IN
VIDEO IN
S-VIDEO Y
1
VIDEO OUT
YPbPr
(NEAR ONLY)
YPbPr
2
HD-SDI HD-SDIHD-SDI
SUB
CAMERA
MAIN
CAMERA
Pb Pr
RMICL R
AUX 2
R
MIC
EC-MIC(A7)
12
A1/A3
(PLUG IN POWER)
1(R) 2(L)
LRL
AUX 1 L L
to AC outlet
VISCA RS-422 cable
(prepared by using the RS-422
connector plug supplied with the
Camera Unit)
Converter (RS-422yRS-232C)
(not supplied)
to VISCA RS-422
to CAMERA CONTROL
(VISCA) MAIN (or SUB)
VISCA RS-232C cable
PCSA-CHG90 Camera Unit
