Sony SELP-18200 User manual

11x Zoom for a Wide Range of Subjects
The SELP18200 oers a wide 18mm to 200mm zoom range (35 mm equivalent: 27mm to 300mm):
wide to super telephoto in a single versatile lens. Expansive landscapes, dynamic snapshots with
normal human perspective, engaging medium-telephoto portraits with beautifully defocused
backgrounds, and super telephoto sports and wildlife … this exible lens comfortably covers all of
these subjects and situations.
Smooth, quiet focusing motor
The SELP18200 incorporates a newly developed internal linear motor that achieves an
exceptionally smooth and quiet focus operation. The result is an almost noiseless, smooth high-
speed focusing operation that is essential for high-quality movie capture.
Powered zoom for enhanced visual expression
In addition to variable speed zoom the SELP18200 supports constant speed zooming for slow,
smooth zoom eects that can enhance cinematographic expression but are dicult to achieve
manually. Zoom can be controlled directly from camcorders that feature built-in zoom levers,
as well as from the built-in zoom lever on the lens. Since power for the internal zoom drive
mechanism is supplied by the camera, no additional battery is required.
Optical SteadyShot image stabilization with Active Mode
Optical image stabilizations (Optical SteadyShot) allows for sharp images to be shot using
shutter speeds as much as 4 stops slower than would normally be possible when shooting hand-
held. Advantageous for general photography, but is particularly eective when combined
with the Anti Motion Blur and Hand-held Twilight modes provided in the NEX-series Handycam
camcorders, and it makes dicult indoor shots that retain the mood of the ambient lighting
possible without the need to increase ISO sensitivity, delivering top-quality images with minimal
noise.
Premium-class optical performance
This high-quality lens design features 5 aspheric surfaces and unreserved application of
advanced technology developed for the Alpha-series E-mount lenses in order to deliver images
of superlative clarity and presence. This compact lens aords rst-class contrast and sharpness
from the image center right out to the edges.
Circular aperture
The SELP18200 incorporates the same type of circular aperture that is a popular feature in other
Alpha E-mount lenses. This 7-blade aperture is designed to maintain a circular shape from
maximum aperture to two stops down, yielding smooth, natural defocusing with a beautiful
circular rendering of point light sources.
Metal exterior for a rened feel
The exterior of the lens barrel is made of aluminum alloy for elegant, high-quality appearance
and feel that ideally balance the unit’s compact dimensions. Metal construction also provides
maximum durability in combination with the metal lens mount.
Specications
Optics/Lens
Aperture Circular
Aperture (Max.) F3.5 - F6.3
Aperture (Min.) F22 – F40
Focal Length (35mm equivalent) 27mm – 300mm
SELP-18200 Alpha E-mount PZ18-200mm F3.5-6.3 OSS

Filter Diameter 67mm
Lens Groups-Elements 12 groups, 17 elements (5 aspheric surfaces, 1 ED-glass element)
Minimum Focus Distance 1 (W) - 1 8 in (T) (0.3m (W) - 0.5 m (T))
Aperture Blade 7 blades (Circular aperture)
Dimensions (Max. Diameter x Length) 3-3/4" x 4" (93.2 x 99mm)
Direct Manual Focus Yes
Exterior Finish Metal
Focus Ring in AF Mode No Rotation
Internal Motor Yes (Stepping motor)
Lens Weight 22.9 oz (649g)
Low Noise During Movie Capture Excellent
Maximum Magnication 0.35x (APS-C)
Mount Material Metal
Non-rotating Focusing Ring No rotation
Weights and Measurements
Dimensions (Approx.) 22.9 oz (649g)
Weight (Approx.) 3-3/4" x 4" (93.2 x 99mm)
Weight(Approx) (Main unit only) 3-3/4" x 4" (93.2 x 99mm)
Accessories
Supplied Accessories Lens cap
Lens rear cap
