Sony UP-CR10L Assembly instructions

Printing
* This may not be necessary in some cases.
Make sure not to forget your prints or memory card.
2-666-587-11
(1)C2005 Sony Corporation
Caution
Before using a memory card, be sure to create a backup copy of
its contents. Sony assumes no liability for lost or damaged data.
Print it!
Print it!
Services
After editing, go to 7
Touch to display the edit menu.
Edit it!
Edit it! For details on how to edit, see Editing Images
Editing Images
Orca_QuickReference 2-666-587-11(1)
Print
Lets you select and print a desired image.
Index Print
Prints an index of all the images on a memory
card at reduced size.
Split Image
Prints multiple photos on a single sheet.
Also handles ID photo size prints.
Border Print
Lets you select and add a border to your photo
before printing.
Basic Operation Guide
Full Mode
Select your language.*
2
Touch the screen.
14Select “Print.” 5
When you finish setting and
editing the image, touch .
78After verifying the number of
prints and the price, touch .9Ask the store clerk to enter
the password.*
Touch or to set the
number of prints.
6
Insert your memory card into the
slot on the front of the printer.
3
Touch the image you want to print.
Displays an enlarged view
of the image.
z For an explanation of this
screen, touch .
Adds a date stamp to all
images.
Do not remove your memory card
until a message appears asking
you to do so.
Printing begins!
Supported Data Formats
JPEG (Exif 2.2.1 Baseline)
TIFF (RGB uncompressed)
BMP (24-bit Windows)
Image size: 6,400 x 4,800 pixels max.
Supported Memory Cards
“Memory Stick” Standard /
“Memory Stick PRO”/
“Memory Stick Duo”
compatible
xD
-
Picture Card SD Card/
MultiMediaCard
CompactFlash card
Microdrive
SmartMedia card

You can edit images taken with a camera for even lovelier
prints. Touch the button of any menu you wish.
Editing Images
If cropping or rotation is performed after red eye reduction, the
corrections for red eye are canceled.
Make sure to perform red eye reduction after cropping or rotation.
Orca_QuickReference 2-666-587-11(1)
The ability to crop images down to
an essential portion and to rotate
them gives you the freedom to
decide an image's composition.
Crop & Rotate
Cropping an Image
Use or to zoom in or out. Then, move the cropping area with
.
Rotating an Image
Each time you touch , the image rotates 90 degrees clockwise. Touch
until the image is oriented as you wish.
When finished editing, touch .
You can reduce the “red eye” effect resulting from flash
photography.
Red Eye Reduction
Use and to position the frame
displayed in the preview screen around the red eye.
1
2Touch .Perform red eye reduction on one eye at a time.
To undo a correction,
touch .
3Verify the results of the correction on the preview screen.
When finished making corrections, touch .
You can process your prints in sepia or black and white to
give them the look of old photographs.
Changes to sepia image.
Sepia / Black&White
After selecting an option, touch .
Changes to black and white image.
You can change an image's color settings, adjusting the
brightness, tint, saturation, and sharpness as you wish.
Select the item you want to adjust, and touch
or to change the color value.
To ensure the desired color adjustment, verify
results in the preview screen while making
adjustments.
When finished adjusting, touch .
Color Adjustment
Closes the edit menu and returns to the
original screen.
Undoes your edits and resets to the
original image.
Editing Images

Making an Index Print
Printing a Split Image
Making a Border Print
* This may not be necessary in some cases.
Make sure not to forget your prints or memory card.
* This may not be necessary in some cases.
Make sure not to forget your prints or memory card.
* This may not be necessary in some cases.
Make sure not to forget your prints or memory card.
To reselect an image,
touch .
Orca_QuickReference 2-666-587-11(1)
Edit it!
Edit it!
Edit it!
Edit it!
Select your language.*
2
Insert your memory card into the slot
on the front of the printer.
3
4 Select “Split Image.”
After verifying the number
of prints and the price,
touch .
9Ask the store clerk to
enter the password.*
10
Select a layout for
the split image.
57
6
Select your language.*
2
Touch the screen.
14Select “Index Print.” After verifying the number
of prints and the price,
touch .
5Ask the store clerk to
enter the password.*
6
Select your language.*
2
Insert your memory card into the
slot on the front of the printer.
3
4Select “Border Print.”
Select a border and
touch .
5
Touch the image
you want to print.
6
7Touch or to set the
number of prints.
After verifying the number of
prints and the price, touch .
9
When you finish setting and
editing the image, touch .
8
Insert your memory card
into the slot on the front
of the printer.
3
Touch the screen.
1
Set the number of prints
and touch .
8
Touch the screen.
1
Ask the store clerk to enter
the password.*
10
Printing begins!
Printing begins!
Printing begins!
When the layout allows you to
assign multiple images, repeat
6and 7.
Touch the frame you
want to assign the
image to.
Do not remove your memory card until a
message appears asking you to do so.
Touch to display the
edit menu.
Select the image
and touch .
Touch to display the
edit menu.
Do not remove your memory card until a
message appears asking you to do so.
Prints an index of all the
images on a memory card at
reduced size.
For details on how to edit,
see
Do not remove your memory card until a
message appears asking you to do so.
For details on
how to edit, see
Editing Images
Editing Images
Editing Images
Editing Images
z For an explanation of this
screen, touch .
z For an explanation of this screen,
touch .

For Store Clerks
Maintenance Guide
3
123
45
2
1
689
10
Orca_QuickReference 2-666-587-11(1)
Replacing the Paper Roll
Open the side door. Remove the ribbon
cartridge.
Insert the new ribbon
cartridge.
Close the side door.
Open the front door. Press the paper holder
release button, and
remove the paper holder.
Remove the paper roll from
the paper holder.
Insert the paper core into
the new paper roll. 7
Pull the paper core out of
the old paper roll.
Close the paper holder. Insert the paper holder into
the printer.
Insert the paper roll into the
paper holder with the arrow
on the label pointing inward,
and then remove the label.
Close the front door.
Replacing the Ribbon Cartridge and Paper Roll
Clear out any paper scraps that have
built up in the paper holder.
For Store Clerks
Make sure to fully remove all labels from
the paper roll.
*
4
Replacing the Ribbon Cartridge
zImmediately after printing, the thermal head inside
the unit will be hot. When loading a cartridge,
do not insert your hand into the ribbon cartridge
access opening, to prevent the risk of burns.
zAlways use a designated print pack.
zBe sure to replace both the ribbon cartridge and
the paper roll as a set.
zDo not touch the printing surface of the
paper roll or the ink on the ribbon cartridge.
Fingerprints and other pollutants can lead to
reduced print quality.
Precautions
Open the paper holder
completely by pressing
the button at the top.

Orca_QuickReference 2-666-587-11(1)
Troubleshooting
A mounted memory card does not contain any data.
tInsert a memory card that contains image data.
Data has been recorded on a memory card in a format that the unit
does not recognize.
t Be sure to store image data in a format that the unit can recognize.
The memory card may not be properly inserted.
tMake sure that the memory card is fully inserted.
The memory card may not be inserted in the correct direction.
tSet the memory card in the direction shown on the operation screen.
Image data cannot be read.
Symptom Cause/ Remedy
Display not on or difficult to see. Depending on the display angle, the display may not be visible or
may be difficult to see.
tThe display angle can be adjusted. Adjust the angle of the display to
improve the display appearance.
There is a white margin on the printed image.
The print position may not be correct.
tAdjust the print position on the administration screen.
Paper roll was loaded, but “no paper”
message appears.
Paper roll may not have been loaded correctly.
tEnsure that paper roll is loaded correctly.
Ribbon cartridge was loaded, but “no
ribbon cartridge” message appears.
Ribbon cartridge may not have been loaded correctly.
tEnsure that ribbon cartridge is loaded correctly.
Out of paper message appears, but
there is still paper in the unit.
This is not a defect. Some spare paper will be left over.
tRemove the leftover paper and load a new ribbon cartridge and paper
roll.
Power does not switch on.
The power cord may not be connected.
tMake sure that the power cord is connected.
The on/standby button may not have been pressed correctly.
tMake sure that the on/standby button has been fully depressed.
The unit does not switch to standby.
The unit may still be doing processing.
tWait a few moments for the unit to stop processing.
An abnormal condition may have caused the unit to stop
responding.
tDisconnect the power cord from the power outlet.Then reconnect
the power cord, and press the on/standby button.
Cannot load paper roll.
Are you trying to load 2UPC-C13, C15 while adaptors are
mounted in the paper holder?
tRemove the adaptors and then load the paper roll.
