Sony DWTB01/E1424 User manual

4-185-238-15 (1)
© 2010 Sony Corporation
Digital Wireless
Transmitter
Operating Instructions
Before operating the unit, please read this manual thoroughly
and retain it for future reference.
DWT-B01 F

2
WARNING
Batteries shall not be exposed to excessive
heat such as sunshine, fire or the like.
If the transmitter develops an abnormally
high temperature, a burning odor or smoke
during use, remove the battery holder and
stop using the transmitter immediately.
Take care not to burn your fingers when
removing the battery holder as the batteries
may be very hot at this time.
For the customers in the U.S.A.
Use of Sony wireless devices is regulated
by the Federal Communications
Commision as described in Part 74 subpart
H of the FCC regulations and users
authorized thereby are required to obtain an
appropriate license.
IMPORTANT NOTE: To comply with the
FCC RF exposure compliance
requirements, no change to the antenna or
the device is permitted,
Any change to the antenna or the device
could result in the device exceeding the RF
exposure requirements and void user’s
authority to operate this device.
This device complies with FCC radiation
exposure limits set forth for uncontrolled
equipment and meets the FCC radio
frequency (RF) Exposure Guidelines in
Supplement C to OET65. This device has
very low levels of RF energy that it is
deemed to comply without testing of
specific absorption radio (SAR).
This equipment has been tested and found
to comply with the limits for a Class B
digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation. This equipment generates,
uses, and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may cause
harmful interference to radio
communications. However, there is no
guarantee that interference will not occur in
a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be
determined by turning the equipment off
and on, the user is encouraged to try to
correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving
antenna.
- Increase the separation between the
equipment and receiver.
- Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced
radio/TV technician for help.
You are cautioned that any changes or
modifications not expressly approved in
this manual could void your authority to
operate this equipment.
All interface cables used to connect
peripherals must be shielded in order to
comply with the limits for a digital device
pursuant to Subpart B of Part 15 of FCC
Rules.
If you have any questions about this
product, you may call;
Sony Customer Information Service Center
1-800-222-7669 or http://www.sony.com/
Declaration of Conformity
Trade Name: SONY
Model: DWT-B01/DWT-B01 (F)
Responsible Party: Sony Electronics
Inc.
Address: 16530 Via Esprillo, San
Diego, CA 92127 U.S.A.
Telephone Number: 858-942-2230
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) this device
may not cause harmful interference,
and (2) this device must accept any
interference received, including
interference that may cause undesired
operation.

3
For the customers in Canada
Operation is subject to the following two
conditions: (1) this device may not cause
interference, and (2) this device must accept
any interference, including interference that
may cause undesired operation of the
device.
The term “IC:” before the radio certification
number only signifies that Industry Canada
technical specifications were met.
Use of Sony wireless devices is regulated
by the Industry Canada as described in their
Radio Standard Specification RSS-123.
A licence is normally required. The local
district office of Industry Canada should
therefore be contacted. When the operation
of the device is within the broadcast band,
the licence is issued on no-interference, no-
protection basis with respect to broadcast
signals.
This Class B digital apparatus complies
with Canadian ICES-003.
This model has an RF module of the
FCC/IC approval built-in.
BUILT IN MODULE RM-215
For the customers in the U.S.A.
You are cautioned that any changes or
modifications not expressly approved in
this manual could void your authority to
operate this equipment.
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) this device
may not cause harmful interference, and (2)
this device must accept any interference
received, including interference that may
cause undesired operation.
For the customers in Canada
Operation is subject to the following two
conditions: (1) this device may not cause
interference, and (2) this device must accept
any interference, including interference that
may cause undesired operation of the
device.
The term “IC:” before the radio certification
number only signifies that Industry Canada
technical specifications were met.
For the customers in Europe
Before operating this unit, please read the
separate R&TTE precautions document.
Voor de klanten in Europa
Lees voordat u het apparaat gaat gebruiken
eerst het aparte document met
waarschuwingen m.b.t. radio- en
telecommunicatieontvangstapparatuur
(R&TTE).
För kunder i Europa
Innan du använder den här enheten ska du
läsa det separata dokumentet om
försiktighetsåtgärder enligt R&TTE-
direktivet.
Para clientes na Europa
Antes de utilizar esta unidade, leia o
documento R&TTE fornecido em separado.
Til europæiske kunder
Læs det separate R&TTE-direktiv om
forholdsregler, inden du betjener enheden.
Asiakkaille Euroopassa
Lue erillinen radio- ja telepäätelaitteita
koskeva varoitusasiakirja (R&TTE) ennen
laitteen käyttöä.
For kunder i Europa
Les det separate R&TTE-dokumentet med
forsiktighetsregler før du bruker denne
enheten.
FCC ID: AK8RM215
IC: 409B-RM215

4
Για τους πελάτες που διαμένουν
σε χώρες της Ευρώπης
Πριν χρησιμοποιήσετε αυτήν τη
μονάδα, διαβάστε το ξεχωριστ
έγγραφο λήψης προφυλάξεων της
οδηγίας R&TTE.
Pro zákazníky v Evropě
Před použitím tohoto zařízení si
prostudujte bezpečnostní upozornění v
samostatném dokumentu R&TTE.
Klientidele Euroopas
Palun tutvuge enne seadme kasutamist
eraldi dokumendiga mis puudutab R&TTE
direktiivist tulenevaid ettevaatusabinõusid.
Európai ügyfeleinknek
A készülék használatba vétele előtt
szíveskedjék elolvasni a rádió- és
távközlési berendezésekkel kapcsolatos
óvintézkedéseket ismertető R&TTE
dokumentumot.
Dla klientów w Europie
Przed przystąpieniem do korzystania z
tego urządzenia należy przeczytać
oddzielny dokument dotyczący środków
ostrożności wynikających z dyrektywy w
sprawie urządzeń radiowych i
końcowych urządzeń
telekomunikacyjnych oraz wzajemnego
uznawania ich zgodności (dyrektywa
R&TTE).
Pentru clienţii din Europa
Înainte de a utiliza unitatea, vă rugăm să
citiţi documentul separat R&TTE cu
măsuri de precauţie.
Pre zákazníkov v Európe
Pred spustením tohto prístroja si
prečítajte osobitné opatrenia smernice
R&TTE.
Za stranke v Evropi
Pred uporabo te naprave preberite ločen
dokument z varnostnimi ukrepi v zvezi z
R&TTE.

5
Table of Contents
Table of Contents
Features .......................................... 6
Parts Identification ........................ 7
Power Supply ................................. 9
Installing the batteries ............. 9
Setting the Transmission
Channel ........................................ 10
Selecting the group/channel ... 11
Using the Cross Remote .............. 12
Pairing with a receiver ........... 12
Using the Encrypted Transmission
Function ........................................ 14
Using secure key mode
(SECURE KEY) .................... 14
Using password mode
(PASSWORD) ....................... 15
Using a USB Keyboard ............... 16
Basic Menu Operations ............... 17
Setting Menus .............................. 18
Naming of transmitter
(NAME) ................................. 18
Selecting the frequency band
(BAND) ................................. 18
Selecting the group/channel
(GP/CH) ................................. 18
Setting the RF output power
(RF POWER) ........................ 19
Setting the audio input level
(INPUT LEVEL) ................... 19
Low-cut filter setting (LCF) ... 20
Power save setting (POWER
SAVE) ................................... 20
Setting the battery type
(BATTERY TYPE) ............... 20
Displaying the accumulated use
time (TIME) .......................... 20
Setting the encrypted
transmission function
(ENCRYPTION) ....................21
Generating an internal signal
(INTERNAL SG) ...................21
Locking the POWER switch
(POWER SW LOCK) ............21
Cross Remote (RF
REMOTE) ..............................21
Setting the brightness of the
display (BRIGHTNESS) ........22
Automatic dimming of the display
(DIMMER MODE) ................22
Resetting parameters to their
factory settings (FACTORY
PRESET) ................................22
Displaying the software version
(VERSION) ............................22
Attaching With the Soft Case ......23
Removing the clip ..................23
Block Diagram.............................. 24
Troubleshooting ........................... 25
Important Notes on Operation ...27
Notes on using the
transmitter ..............................27
On cleaning ............................27
Specifications ................................28
Carrier Frequencies and Channel
Steps ..............................................30

6Features
Features
The DWT-B01 is a digital wireless
transmitter for a UHF synthesized wireless
microphone system to be used for broadcast
or movie production purpose. This
transmitter is suitable for Electronic News
Gathering (ENG) and Electronic Field
Production (EFP).
What is DWX?
DWX refers to Sony’s new digital wireless
microphone system. The DWX series
reflects Sony’s extensive expertise in
professional microphones and sound
design. It represents a successful blend of
Sony know-how, wireless technology
renowned for stability, and cutting-edge
digital audio technology.
In addition to realizing the high sound
quality possible with a digital system, the
DWX series supports multi-channel
simultaneous operation, encrypted
transmission, and metadata transmission for
monitoring the status of multiple
transmitters. Using a main link and a
separate additional link, remote control of
transmitters from the receiver is also
possible. With its many advanced features,
the system has the potential to revolutionize
the workflow of professional applications.
What is WiDIF-HP?
WiDIF-HP (WiDIF: Wireless Digital
Interface Format, HP: High Profile) is a
wireless digital audio interface format
developed by Sony.
It enables highly secure transmission with
high sound quality and low system latency,
and supports simultaneous multi-channel
operation.
What is Cross Remote?
Cross Remote is a system that allows
transmitters to be monitored and controlled
from a receiver and the Wireless Studio
control software installed on a computer
connected to the receiver.
For example, the settings of a transmitter
worn under clothing can be easily changed
over the wireless link.
Wide RF carrier frequency
range
The DWT-B01 transmitter covers an
extremely wide RF carrier frequency range.
Depending on the model, the transmitter
can cover bandwidths between 48-MHz and
72-MHz (e.g., 72-MHz with the CE4248 1))
— much wider than 24-MHz of the analog
wireless microphone system. This
remarkably wide coverage on a single
model offers cost efficiency and operational
convenience, because it allows one
transmitter to be operated in many different
areas.
1) Carrier frequencies differ depending on the
model.
Compact, lightweight, and
rugged design
The DWT-B01 is designed to be extremely
compact and lightweight, essential qualities
for use by artists in fast-moving TV and
outdoor productions.
Switchable mic or line input
level and adjustable
attenuator
For details, see “Setting the audio input level
(INPUT LEVEL)” on page 19.

7
Parts Identification
Selectable RF output power:
1 mW, 10 mW, and 50 mW
For details, see “Setting the RF output power (RF
POWER)” on page 19.
Power sleep mode
For details, see “Power save setting (POWER
SAVE)” on page 20.
Digital low-cut filter
For details, see “Low-cut filter setting (LCF)” on
page 20.
Easy-to-see, full dot-matrix
OLED (Organic Light-Emitting
Diode) Display
The quick response of the OLED display
enables real-time operating conditions to be
displayed clearly and accurately.
Parts
Identification
aAntenna
bAF (audio input level) /PEAK
indicator
Lights up green when the signal input is
stronger than the reference level.
Lights up red when the signal input is 3 dB
below the level at which distortion begins.
cPOWER indicator
Lights up green when the transmitter is
turned on. When the battery is exhausted,
the indicator starts flashing.
dAudio input connector (SMC9-4S)
Connects the output plug from the optional
lavalier microphone.
This connector also accepts the input from
another wired microphone connected
through the supplied microphone cable, or
the audio output from a mixer, etc.

8Parts Identification
To connect a microphone
e+ or – button
Selects functions or values shown on the
display.
Holding down the – button while switching
on the transmitter activates the pairing
operation for the wireless remote control
function.
fPOWER switch
Turns the transmitter ON or OFF.
gBattery compartment
Accommodates two LR6 (size AA) alkaline
batteries.
For details on how to insert the batteries, see
“Power Supply” on page 9.
hSET button
Adjusts displayed function settings and
enters the value.
Holding down the SET button while
switching on the power turns the transmitter
on without sending a signal.
iUSB connector (Micro USB)
Use this connector to connect an optional
USB keyboard to carry out menu functions
using key operations. By connecting the
digital wireless receiver to this connector
with the supplied USB cable, you can
exchange the encryption key for encrypted
transmission function.
jDisplay section
ARF transmission indication
Indicates the current transmission status.
:Currently transmitting
—: Transmission stopped
BRF (radio frequency) transmission
power indication
Indicates the current transmission power
setting. You can change the setting with the
RF transmission power setting function.
H: transmitting at 50 mW
M: transmitting at 10 mW
L: transmitting at 1 mW
CAudio input level meter
Indicates the input signal level.
DReference level gauge
Indicates the reference input level. When
the attenuation is 0 dB with INPUT LEVEL
set to MIC, –58 dBu (–60 dBV) is indicated.
When LINE is selected for INPUT LEVEL,
+4 dBu is indicated.
EPeak indicator
Warns of excessive input by lighting up
when the signal is 3 dB below the level at
which distortion begins.
Microphone (optional)
To secure the microphone cable
connection, be sure to turn and lock
the connector cover.

9
Power Supply
FPOWER switch lock indicator
Indicates that the POWER switch is locked,
preventing the transmitter from being
accidentally turned off or on.
For details, see “Locking the POWER switch
(POWER SW LOCK)” on page 21.
GCross Remote condition indication
Indicates the signal transmission condition
of the wireless remote control function (4
levels).
: Good transmission
: Somewhat good transmission
: Somewhat poor transmission
: Poor transmission
: Unable to communicate with paired
receiver
When the wireless remote control function
is off, this indication does not appear.
HBattery indication
Shows the battery condition.
For details, see “Battery indication” on page 9.
IMenu display section
The status of 17 different functions are
displayed here. To select the function, press
the + or – button repeatedly.
For details, See “Setting Menus” on page 18.
Power Supply
The transmitter can operate on two LR6
(size AA) alkaline batteries continuously
for about 5 hours at 25°C (77°F).
Installing the batteries
1Squeeze the battery-holder tabs inward
(in the direction of the arrows) and
slide out the battery holder.
2Insert new batteries, making sure the
polarities are correct, and then return
the battery holder to its original
position.
Battery indication
The power status is indicated by eight level
indications.
Replace both batteries when the battery
indication starts to flash.

10 Setting the Transmission Channel
Be sure to check the expiration date printed
date on the new batteries before using them.
• When BATTERY TYPE is set to
TYPE1, the power status is indicated
based on the use of new LR6 (size AA)
Sony Alkaline batteries. An incorrect
indication may result when a different
kind of batteries, a different brand of
batteries or old batteries are used. If you
plan to use other kind of batteries than
alkaline, set the BATTERY TYPE
function according to the type of batteries
to be used.
• If you plan to use the transmitter for a
long period of time, it is recommended
that you replace the batteries with brand
new ones.
For details on BATTERY TYPE setting, see “Setting
the battery type (BATTERY TYPE)” on page 20.
Setting the
Transmission
Channel
The transmitter provides groups of
interference-free channels. When using
multiple microphones and transmitters at
the same time (simultaneous multi-channel
operations) within the same area, selecting
the same group and using a channel within
that group can prevent signal interference.
To set the transmission channel on the
transmitter, first you select the group and
channel using the RF indicator and
scanning functions on the receiver. Next
you set the group and channel parameters to
match the setting on the receiver.
• Certain transmission channels cannot be
used with the wireless remote control
function.
• “(INCOMPATIBLE WITH RF
REMOTE)” will slide across the display
during group/channel selection for
transmission channels that cannot be
used with the wireless remote control
function.
• When a transmission channel that cannot
be used with the wireless remote control
function is selected, “RESTRICTED BY
GP/CH SETTING” appears on the RF
REMOTE screen and the wireless remote
control function cannot be used. When
using the wireless remote control
function, select transmission channels for
which “(INCOMPATIBLE WITH RF
REMOTE)” does not appear during
group/channel selection.
Notes
Notes

11
Setting the Transmission Channel
Selecting the group/
channel
• Before doing this procedure, use the
BAND function (see page 18) to set the
transmitter to the bandwidth of the
receiver you are using.
• The setting for this function cannot be
changed during actual signal
transmission.
Set the transmitter group (GP) and channel
(CH) as follows:
For details on groups and channels, refer to “Sony
Digital Wireless Microphone System Frequency
Lists” on the supplied CD-ROM.
For details on menu operation, see “Basic Menu
Operations” on page 17.
1Turn off the power, and then while
holding down the SET button, turn the
power on.
The signal transmission stops.
2Press the + or – button repeatedly until
the GP/CH indication is displayed.
3Hold down the SET button until the
item to be set flashes.
4Press the + or – button repeatedly to
select a group.
5Press the SET button to enter the
group.
The channel indication starts flashing.
6Press the + or – button repeatedly to
select a channel.
7Press the SET button to enter the
channel.
To start signal transmission with the
selected channel, turn off the power and
then turn it on again.
To set the group/channel
using the pairing mode of the
Cross Remote
When the transmitter is paired with the
receiver, the transmission channel of the
transmitter is set to the receiving channel on
the receiver automatically.
For details, see“Pairing with a receiver” on
page 12.
Notes
Note

12 Using the Cross Remote
Using the Cross
Remote
This transmitter is equipped with a wireless
remote control function that can be used to
set the parameters (low-cut filter,
attenuation operation, power save mode,
etc.) of the transmitter through the receiver
or other devices. This function makes it
easier to operate and manage the
microphone system while in the field.
This wireless control is 2.4 GHz
IEEE802.15.4 compliant and has no effect
on the RF band of digital wireless audio.
This function is activated when pairing is
established between the transmitter and the
receiver using the RF REMOTE function.
Pairing must be done first before the
wireless remote control function can be
used.
If “RESTRICTED BY GP/CH SETTING”
appears on the RF REMOTE screen, the
wireless remote control function cannot be
used. To use the wireless remote control
function, select a different transmission
channel.
For details on how to change the transmission
channel, see “Setting the Transmission Channel” on
page 10.
Pairing with a receiver
Pairing links the transmitter with the
receiver which the wireless remote control
function is to be used.
When the transmitter has been paired with a
receiver through the receiver operation,
turning on the transmitter while holding
down the – button establishes the pairing
immediately.
To carry out pairing through menu
operations on the transmitter, do the
following.
1Set the receiver to be used for
controlling the transmitter to pairing
mode.
For details, refer to the operating instructions
supplied with the receiver.
2Press the + or – button repeatedly until
the RF REMOTE indication is
displayed.
3Hold down the SET button until the
item to be set flashes.
4Press the + or – button repeatedly to
select PAIRING.
5Press the SET button to enter.
The transmitter sends a pairing request
to the receiver which is on pairing
mode.
Before established pairing, if you press
any operation key on the transmitter,
pairing mode will be cancelled.
When pairing has been established, the
wireless remote control condition level
(indicated by ) goes up, RF
REMOTE turns on, and the remote
control function becomes operative.
To use the Cross Remote with
a previous pairing
In the RF REMOTE indication, select ON.
• When you set RF REMOTE to ON, the
transmitter will communicate with the
receiver to which it was previously
paired. To use the wireless remote
control function with another receiver,
you must perform the pairing procedure
for that receiver.
Note
Notes

13
Using the Cross Remote
• Multiple transmitters cannot be paired
with the same receiver.
• If you reset all parameters by using the
FACTORY PRESET function (see page
22), the pairing setting of the transmitter
is also cleared.
The following transmitter settings
can be done from the remote control:
• Transmitter name setting
• Frequency band/group/channel selection
• RF transmission power setting
• MIC/LINE setting and attenuator setting
for audio input level
• Low-cut filter setting
• Power save setting
• Resetting accumulated use time
• Internal signal setting
• POWER switch lock setting
For details on menu operation, see “Setting Menus”
on page 18.
To perform remote control, the receiver must be
equipped with a control function for the setting you
want to control. For details, refer to the operating
instructions supplied with the receiver.
To cancel the Cross Remote
In the RF REMOTE indication, select OFF.
Notes on the Cross Remote
The wireless remote control function on the
transmitter uses the 2.4-GHz band and may
thus be subject to interference from other
devices.
• When pairing fails (“Pairing fail” is
displayed), successful communication
between the transmitter and the receiver
has not occurred within a given amount
of time. Pairing may be harder to do
when another receiver is engaged in
pairing nearby.
• When it becomes hard to use the remote
control, the remote control may be
improved by switching the wireless
remote control function off, then on again
in the RF REMOTE display, then re-
pairing with the transmitter (change to a
channel with less interference).

14 Using the Encrypted Transmission Function
Using the
Encrypted
Transmission
Function
To prevent hacking of the signal, the
transmitter scrambles the signal during
transmission. To use this function, select
one of the following encrypted transmission
modes:
Secure key mode: An encryption key
that is automatically generated by the
transmitter is used by both the transmitter
and receiver in this one-to-one encrypted
transmission method.
Password mode: You choose a
password of up to eight characters that can
be set for multiple transmitters and
receivers. This enables encrypted
transmission within a group.
Make sure the same mode is set on the
transmitter and receiver.
Using secure key mode
(SECURE KEY)
Use this mode for one-to-one encrypted
transmission between one transmitter and
one receiver.
An encryption key that cannot be read from
the outside is automatically generated by
the transmitter. This key is transmitted to
the receiver through a USB connection or
the RF REMOTE function, enabling
encrypted transmission to take place.
The encryption key used by the transmitter
and receiver is newly generated for each
key transmission, resulting in highly secure
communication.
The encryption key used between the
transmitter and the receiver is saved when
the power is turned off, so the encrypted
transmission can be resumed the next time
the power is turned on.
1Preparing the transmitter (this unit)
1Hold down the SET button until
the item to be set flashes in
ENCRYPTION indication on the
transmitter.
2Press the + or – button repeatedly
to select SECURE KEY, and then
press the SET button.
2Preparing the receiver
Select SECURE KEY on the receiver
that receives the encryption key.
For details on receiver operations, refer to the
operating instructions supplied with the
receiver.
3Exchanging the encryption key
On the receiver, select USB or
REMOTE (wireless remote) as the
method for encryption key exchange.
When the RF REMOTE function is
off, REMOTE cannot be selected.
When the receiver does not support
encryption key exchange through USB
connection, select REMOTE.
When you select USB:
Connect the transmitter to the receiver
with the supplied USB cable and USB
adapter cable.
Note
Note

15
Using the Encrypted Transmission Function
For details on receiver operations, refer to the
operating instructions supplied with the
receiver.
When you select REMOTE:
The transmitter searches for a receiver
that it has been paired with. After the
transmitter detects the receiver, the
transmitter exchanges the encryption
key with receiver and encrypted
transmission begins.
Using password mode
(PASSWORD)
Set this mode when multiple transmitters
are paired with multiple receivers for
encrypted transmission.
If both transmitters and receivers are set
with the same user-designated password,
the audio signal can be decoded. This mode
is useful when multiple transmitters and
receivers are used as a single group, or
when the audio signal from one transmitter
is received by multiple receivers at the same
time.
1Hold down the SET button until the
item to be set flashes in the
ENCRYPTION indication on the
transmitter.
2Press the + or – button repeatedly to
select PASSWORD, and then press the
SET button.
3Input a password of up to eight
characters on the transmitter.
To enter a password, use the procedure
described in “Naming of transmitter (NAME)”
on page 18.
4Set the encrypted transmission
function setting on the receiver to
PASSWORD.
5Set the same password that was set on
the transmitter.
For details on receiver operations, refer to the
operating instructions supplied with the
receiver.
It is recommended that you change the
password periodically.
USB cable (supplied)
USB adapter
cable
(supplied)
Note

16 Using a USB Keyboard
Using a USB
Keyboard
Connecting an optional USB keyboard to
the transmitter allows you to perform menu
operations and enter your name and
password for the encrypted transmission
function from the keyboard.
A Micro USB connector is used on the
transmitter. For this reason, use the supplied
USB adapter cable.
Menu operations with a USB
keyboard
You can use a USB keyboard to perform the
same menu operations that you do on the
transmitter.
The transmitter buttons correspond to the
following keys on a USB keyboard:
To enter a text
With a USB keyboard, you can enter names
and passwords for encrypted transmissions.
Characters that can be entered from
a USB keyboard: (space), 0, 1, 2, 3, 4, 5,
6, 7, 8, 9, A, B, C, D, E, F, G, H, I, J, K, L,
M, N, O, P, Q, R, S, T, U, V, W, X, Y, Z, !,
#, &, $, @, +, -, =, _, (, ), [, ]
(Passwords may consist of the numbers 0 to
9 and letters A to Z only.)
Special key: Backspace (BS) and Delete
(DEL) keys.
• The number keys on the keyboard cannot
be used.
• This transmitter is compatible with
English-language keyboards only.
• USB keyboards with multiple functions,
such as USB hub and pointing device,
cannot be used.
• Power to the connected keyboard is
supplied by the USB connector on the
transmitter. The power rating is 100 mA.
Keyboards that consume more power
than that cannot be used.
• Do not leave the transmitter connected to
the keyboard when not in use. If you do,
the batteries in the transmitter will be
drained more quickly.
• Text editing should be done with the
alphabet, BS, DEL, and Enter keys.
Buttons on the
transmitter
USB keyboard
SET ENTER
+R
–r
USB adapter cable (supplied)
Notes

17
Basic Menu Operations
Basic Menu
Operations
1Press the + or – button repeatedly until
the function to be set appears.
2Hold down the SET button until the
item to be set flashes.
3Press the + or – button to change the
setting.
4Press the SET button to enter the
setting.
Types of menu:
• NAME (transmitter name) setting
• BAND (frequency band) selection
• GP/CH (group/channel) selection
• RF POWER (RF transmission power)
setting
• INPUT LEVEL (audio input level)
setting
• LCF (low-cut filter) setting
• POWER SAVE setting
• BATTERY TYPE (battery type) setting
• TIME (accumulated use time) indication
• ENCRYPTION (encrypted transmission
function) setting
• INTERNAL SG (internal signal
generator) function
• POWER SW LOCK (POWER switch
lock) function
• RF REMOTE (wireless remote control)
function
• BRIGHTNESS (display brightness)
setting
• DIMMER MODE (automatic dimming
of the display) setting
• FACTORY PRESET (factory setting)
function
• VERSION (software version) indication
Function name
Item to be set

18 Setting Menus
Setting Menus
The functions and parameters of the settings
menu are explained here. Underlined items
are the factory setting.
Naming of transmitter
(NAME)
You can specify a transmitter name of up to
16 characters. The factory setting for the
transmitter name is the model name and
serial number. The transmitter name is sent
to the receiver as metadata and is used by
the receiver to distinguish between different
transmitters.
+: The first press on the + button displays
the character set. You can then use the + and
– buttons to select the desired character.
And then, pressing the SET button adds the
selected character to the end of the current
name.
– : Deletes the last character in the current
name.
SET: Enters the character or edited name.
You cannot insert or delete a character in
the middle of the name.
Using wireless remote control, this function
can be controlled from the receiver and
other devices.
For details on wireless remote control function, see
“Using the Cross Remote” on page 12.
To edit with a keyboard
You can enter data from an optional
keyboard connected to the USB connector.
For details, see “Using a USB Keyboard” on
page 16.
Selecting the frequency
band (BAND)
Match the frequency range on this
transmitter to that of the Sony digital
wireless receiver.
See “Carrier Frequencies and Channel
Steps” on page 30 for differences in
frequency ranges that can be set for optional
receivers combined with this transmitter.
For details about the frequency range of each band,
refer to “Sony Digital Wireless Microphone System
Frequency Lists” on the supplied CD-ROM.
Using wireless remote control, this function
can be controlled from the receiver and
other devices.
For details on wireless remote control function, see
“Using the Cross Remote” on page 12.
• The setting for this function cannot be
changed during actual signal
transmission. To change the setting, turn
off the transmitter first. Then, while
holding down the SET button, turn the
power on. Then change the setting after
the signal transmission has stopped.
• Be sure to select the group/channel right
after selecting the frequency band. To
start signal transmission with the selected
frequency band/group/channel, turn off
the power and then turn it on again.
Selecting the group/
channel (GP/CH)
See “Carrier Frequencies and Channel
Steps” on page 30 for factory settings.
For details, see “Selecting the group/channel” on
page 11.
Note
Notes

19
Setting Menus
Using wireless remote control, this function
can be controlled from the receiver and
other devices.
For details on wireless remote control function, see
“Using the Cross Remote” on page 12.
Setting the RF output
power (RF POWER)
You can set the RF output power.
1 mW (LOW): transmitted by 1 mW
10 mW (MID):transmitted by 10 mW
50 mW (HIGH): transmitted by 50 mW
• The setting for this function cannot be
changed during actual signal
transmission. To change the setting, turn
off the transmitter first. Then, while
holding down the SET button, turn the
power on. And then, change the setting
after the signal transmission has stopped.
• To start signal transmission with the
selected RF output power setting, turn off
the power and then turn it on again.
Using wireless remote control, this function
can be controlled from the receiver and
other devices.
For details on wireless remote control function, see
“Using the Cross Remote” on page 12.
Setting the audio input
level (INPUT LEVEL)
You can set the input level to the analog
head amp.
Select LINE or MIC, depending on the
audio source connected to the audio input
connecter.
When MIC is selected, ATT (attenuation
level) will flash next. With the microphone
connected, speak into the microphone as
you monitor the input level meter and press
the + or – button repeatedly to select the
appropriate attenuation level.
The reference levels for the various settings
are as follows:
MIC/LINE settings and attenuator settings for the audio input level can be changed from the
receiver and other devices via the wireless remote control function.
For details on wireless remote control function, see “Using the Cross Remote” on page 12.
Notes
Input Attenuation
(dB)
Reference input
level (dB)
Maximum input
level (dBu)
Headroom (dB)
MIC 0–58 –22 36
3–55 –19
6–52 –16
9–49 –13
3 dB step 3 dB step 3 dB step
45 –13 +23
48 –10 +24 34
LINE –+4 +24 20

20 Setting Menus
Low-cut filter setting (LCF)
The frequency of the low-cut filter can be
set.
OFF: Turns off the low-cut filter.
20 30 40 50 60 70 80 90 100
120 140 160 180 200 220 (Hz):
Low-cut filter is set according to the
selected frequency.
Using wireless remote control, this function
can be controlled from the receiver and
other devices.
For details on wireless remote control function, see
“Using the Cross Remote” on page 12.
Power save setting (POWER
SAVE)
To conserve power, this setting allows you
to put all transmitter functions to sleep.
ACTIVE: The transmitter operates
normally.
SLEEP: The sleep function is on. During
sleep, the POWER indicator flashes at 2-
second intervals.
To change back to normal
operation
During sleep, press the SET, +, or – button.
You can also use the wireless remote
control to change the receiver back to
normal operation.
For details on wireless remote control function, see
“Using the Cross Remote” on page 12.
Setting the battery type
(BATTERY TYPE)
Set this item according to the type of
batteries you use to obtain accurate battery
power status indication.
TYPE1: The power status is indicated
based on characteristics of new LR6 (size
AA) Sony Alkaline batteries. Select this for
LR6 (size AA) alkaline batteries.
TYPE2: Select this for rechargeable
nickel-metal-hydride batteries.
TYPE3: Select this for lithium batteries.
The characteristics of batteries change
according to battery type and
environmental conditions. It is
recommended that you learn the
characteristics of batteries you use before
using them.
Displaying the
accumulated use time (TIME)
You can display the accumulated battery
use time as a rough estimate of total
transmitter usage.
The factory setting is “00:00”.
To reset the accumulated time
indication
1Hold down the SET button until the
time indication flashes.
2Press the – button so “00:00 RESET”
appears, and then press the SET
button.
Using wireless remote control, this function
can be controlled from the receiver and
other devices.
For details on wireless remote control function, see
“Using the Cross Remote” on page 12.
Note
