Sound Sation SC-80W-1-W User manual

SC-80W-1-W
HIGH POWER 80W WHITE LED SCANNER LIGHT
Please read this manual carefully and proper take care of this manual
USER MANUAL

2
ENGLISH
Dear customer,
First of all thanks far purchasing a SOUNDSATION® product. Our mission is to satisfy all possible
needs of musical instrument and professional audio and lighting users offering a wide range of
products using the latest technologies.
We hope you will be satised with this item and, if you want to collaborate, we are looking for a
feedback from you about the operation of the product and possible improvements to introduce in
the next future. Go to our website www.soundsationmusic.com and send an e-mail with your
opinion, this will help us to build instruments ever closer to customer’s real requirements.
One last thing: read this manual before using the instrument, an incorrect operation can cause
damages to you and to the unit. Take care!
The SOUNDSATION Team
IMPORTANT SAFETY SYMBOLS
The symbol is used to indicate that some hazardous live terminals
are involved within this apparatus, even under the normal operating
conditions, which may be sufcient to constitute the risk of electric
shock or death.
The symbol is used in the service documentation to indicate that spe-
cic component shall be replaced only by the component specied in
that documentation for safety reasons.
Protective grounding terminal
Alternating current/voltage
Hazardous live terminal
Denotes the apparatus is turned on
Denotes the apparatus is turned off

3
ENGLISH
WARNING: Describes precautions that should be observed to prevent the danger
of injury or death to the operator.
CAUTION: Describes precautions that should be observed to prevent danger of
the apparatus.
IMPORTANT SAFETY INSTRUCTIONS
fRead these instructions
fKeep these instructions
fHeed all warning
fFollow all instructions
Water and Moisture
The apparatus should be protected from moisture and rain and can not be used near
water; for example near a bathtub, a kitchen sink, a swimming pool, etc.
Heat
The apparatus should be located away from heat sources such as radiators, stoves or
other appliances that produce heat.
Ventilation
Do not block areas of ventilation opening. Failure to do could result in re. Always
install according to the manufacturer's instructions.
Object and Liquid Entry
Objects do not fall into and liquids are not spilled into the inside of the apparatus for
safety.
Power Cord and Plug
Protect the power cord from being walked on or pinched particularly at plugs, conve-
nience receptacles, and the point where they exit from the apparatus. Do not defeat the
safety purpose of the polarized or grounding-type plug. A polarized plug has two poles;
a grounding-type plug has two poles and a third grounding terminal. The third prong
is provided for your safety. If the provided plug does not t into your outlet, refer to an
electrician for replacement.
Power Supply
The apparatus should be connected to the power supply only of the type as marked on
the apparatus or described in the manual. Failure to do could result in damage to the
product and possibly the user. Unplug this apparatus during lightning storms or when
unused for long periods of time.

4
ENGLISH
SC-80W-1-W User manual
Fuse
To prevent the risk of re and damaging the unit, please use only of the recommended
fuse type as described in the manual. Before replacing the fuse, make sure the unit
turned off and disconnected from the AC outlet.
Electrical Connection
Improper electrical wiring may invalidate the product warranty.
Cleaning
Clean only with a dry cloth. Do not use any solvents such as benzol or alcohol.
Servicing
Do not implement any servicing other than those means described in the manual. Refer
all servicing to qualied service personnel only. Only use accessories/attachments or
parts recommended by the manufacturer.
WARNING: Please remember the high sound pressure do not only temporar-
ily damage your sense of hearing, but can also cause permanent damage.
Be careful to select a suitable volume.

5
ENGLISH
SC-80W-1-W User manual
TABLE OF CONTENTS
1. PRODUCT SPECIFICATION....................................................................................6
2. LED DISPLAY ..........................................................................................................6
2.1. LED display function..............................................................................................................6
3. CHANNEL MODES ..................................................................................................8
3.1. 1CH Mode .............................................................................................................................8
3.2. 8CH Mode .............................................................................................................................8
3.3. 10CH Mode ...........................................................................................................................9
4. WARRANTY AND SERVICE..................................................................................10
5. WARNING ..............................................................................................................10

6
ENGLISH
SC-80W-1-W User manual
1. PRODUCT SPECIFICATION
fLight source: 1pc of high brightness 80W white LED
fDMX Channel Modes: 1CH, 8CH and 10CH
fColor wheel: 9 color+open
fGobo wheel: 9 gobo+open
fGobo shake effect
fPan: 180°
fTilt: 85°
fControl mode: Sound active, Auto run, DMX and Master/Slave
fVoltage: AC100-240V 50/60Hz
fPower Consumption: 118W
fLight size: 24 x 44 x 16cm
fNet Weight: 4.1kg
2. LED DISPLAY
Item Display Function
Button:
MENU Enter the menu
DOWN Next the menu
UP Previous menu
ENTER Enter the select function
2.1. LED display function
To choose a function, press MENU button, then press UP/DOWN button and press
ENTER button to conrm and edit specic parameters. To exit and go back to main
mode, wait for 10 seconds or press the MENU long time. A complete list of all menus
and sud-menus is as follows:

7
ENGLISH
SC-80W-1-W User manual

8
ENGLISH
SC-80W-1-W User manual
3. CHANNEL MODES
3.1. 1CH Mode
Channel Number Function
1CH 000-007 No Function
008-255 Sound control
3.2. 8CH Mode
Channel Number Function
CH1 000-255 The X axis positioning
CH2 000-255 The Y axis positioning
CH3 (LED
open)
000-127 Color change
128-193 The rainbow effect is clockwise, from fast to slow
194-225 The rainbow effect is counterclockwise, slow to fast
CH4 (Gobo)
000-005 Spot
006-011 Gobo1
012-017 Gobo2
018-023 Gobo3
024-029 Gobo4
030-035 Gobo5
036-041 Gobo6
042-047 Gobo7
048-053 Gobo8
054-063 Gobo9
064-069 Spot shake effect
070-127 Gobo shake effect
128-189 The rainbow effect is clockwise, from fast to slow
190-193 Stop
CH4 194-225 The rainbow effect is counterclockwise, slow to fast
CH5
000-007 No Function
008-015 Dimming
016-131 Strobe from low to fast
132-139 Dimming
140-181 Strobe from low to fast
182-189 Dimming
190-255 Strobe from low to fast
CH6 000-255 Dimming 0-100%
CH7 000-255 The speed of X Y,from fast slow
CH8 000-238 No Function
239-255 Sound control

9
ENGLISH
SC-80W-1-W User manual
3.3. 10CH Mode
Channel Number Function
CH1 000-255 The X axis positioning
CH2 000-255 The X axis ne-tuning
CH3 000-255 The Y axis positioning
CH4 000-255 The Y axis ne-tuning
CH5
000-127 Color change
128-193 The rainbow effect is clockwise, from fast to slow
194-255 The rainbow effect is counterclockwise, slow to fast
CH6
000-005 Spot
006-011 Gobo1
012-017 Gobo2
018-023 Gobo3
024-029 Gobo4
030-035 Gobo5
6CH
036-041 Gobo6
042-047 Gobo7
048-053 Gobo8
054-063 Gobo9
064-069 Spot shake effect
070-127 Gobo shake effect
128-189 The rainbow effect is clockwise, from fast to slow
190-193 Stop
194-225 The rainbow effect is counterclockwise, slow to fast
7CH
000-007 No Function
008-015 Dimming
016-131 Strobe from low to fast
132-139 Dimming
140-181 Strobe from low to fast
182-189 Dimming
190-255 Strobe from low to fast
8CH 0-255 Dimming 0-100%
9CH 0-255 The speed of X Y,from fast slow
10CH 000-238 No Function
239-255 Sound control

10
ENGLISH
SC-80W-1-W User manual
4. WARRANTY AND SERVICE
All SOUNDSATION products feature a limited two-year warranty. This two-year warranty is specif-
ic to the date of purchase as shown on your purchase receipt.
The following cases/components are not covered from the above warranty:
• Any accessories supplied with the product
• Improper use
• Fault due to wear and tear
• Any modication of the product effected by the user or a third party
SOUNDSATION shall satisfy the warranty obligations by remedying any material or manufacturing
faults free of charge at SOUNDSATION’s discretion either by repair or by exchanging individual
parts or the entire appliance. Any defective parts removed from a product during the course of a
warranty claim shall become the property of SOUNDSATION.
While under warranty period, defective products may be returned to your local SOUNDSATION
dealer together with original proof of purchase. To avoid any damages in transit, please use the
original packaging if available. Alternatively you can send the product to SOUNDSATION SER-
VICE CENTER – Via Enzo Ferrari , 10 – 62017 Porto Recanati - Italy . In order to send a product
to service center you need an RMA number. Shipping charges have to be covered by the owner of
the product.
For further information please visit www.soundsationmusic.com
5. WARNING
PLEASE READ CAREFULLY – EU and EEA (Norway, Iceland and Liechtenstein) only
This symbol indicates that this product is not to be disposed of with your household waste, accord-
ing to the WEEE Directive (2202/96/EC) and your national law.
This product should be handed over to a designated collection point, e.g., on an authorized one-
for-one basis when you buy a new similar product or to an authorized collection site for recycling
waste electrical and electronic equipment (WEEE).
Improper handling of this type of waste could have a possible negative impact on the environment
and human health due to potentially hazardous substances that are generally associated with
EEE. At the same time, your cooperation in the correct disposal of this product will contribute to
the effective usage of natural resources.
For more information about where you can drop off your waste equipment for recycling, please
contact your local city ofce, waste authority, approved WEEE scheme or your household waste
disposal service.
