OWNER'S MANUAL
Mobile Video System
• Multi-subtitle Languages Function
• Multi-audio Languages Function
• Multi-angle Function
• Parental Control
VDVD-150

2
FEATURES
Compatible with PAL DVD (Video CD)
and NTSC DVD (Video CD)
This player can play discs recorded in
either PAL or NTSC format.
•A single LSI chip now integrates all
major DVD playback circuit functions
including MPEG2 decoder, video D/A
converter, and audio decoders.
•L/R stereo analog audio outputs for
connection to existing head unit aux
inputs. Video output is composite
video.
•Supplied remote handles multi-
function software (multi-language
audio-track/subtitle, multi-angle, multi-
story, etc.), plus all basic functions.
USE THIS PRODUCT
SAFELY
When Driving
Keep the volume level low enough to be
aware of road and traffic conditions.
When Car Washing
Do not expose the product to water or
excessive moisture. This could cause
electrical shorts, fire or other damage.
When Parked
Parking in direct sunlight can produce
very high temperatures inside your
vehicle. Give the interior a chance to
cool down before starting playback.
Use the Proper Power Supply
This product is designed to operate with
a 12 volt DC, negative ground battery
system (the regular system in a North
American car).
Protect the Disc Mechanism
Avoid inserting any foreign objects into
the slot of this player.
Failure to observe this may cause
malfunction due to the precise
mechanism of this unit.
Use Authorized Service Centres
Do not attempt to disassemble or adjust
this precision product. Please refer to
the Service Centre list included with this
product for service assistance.
For Installation
The unit should be installed in a
horizontal position with the front end up
at a convenient angle, but not more than
30°.

3
CONTENTS
Safety Information .............................................................................................4
Disc Notes ..........................................................................................................5
Installation ..........................................................................................................6
Electric Connection ...........................................................................................7
Remote Control..................................................................................................8
Preparing the Remote Control ...........................................................................................9
Loading a DVD/VCD/CD Disc ............................................................................................9
Ejecting a Disc ...................................................................................................................9
Basic Operation................................................................................................10
On-Screen Display Function ............................................................................................11
Multi-audio Language Function .......................................................................................11
Menu Function .................................................................................................................12
Title Menu Function (For DVD only) .................................................................................12
Multi-subtitle Language Function (For DVD only) ............................................................12
Multi-angle Function (For DVD only) ................................................................................12
MP3 Disc Play..................................................................................................................13
Setup .................................................................................................................14
Initial Setup ......................................................................................................................14
General Setup ..................................................................................................................14
Speaker Setup .................................................................................................................16
Audio Setup .....................................................................................................................16
Preferences Setup............................................................................................................17
Defaults Table...................................................................................................................19
Specifications...................................................................................................20

4
CAUTION:
MOBILE DVD PLAYER IS A CLASS I
LASER PRODUCT. HOWEVER THIS
MOBILE DVD PLAYER USES A
VISIBLE/INVISIBLE LASER BEAM WHICH
COULD CAUSE HAZARDOUS
RADIATION EXPOSURE IF DIRECTED.
BE SURE TO OPERATE THE MOBILE
DVD PLAYER CORRECTLY AS
INSTRUCTED.
USE OF CONTROLS OR ADJUSTMENTS
OR PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED
HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
DO NOT OPEN COVERS AND - DO NOT
REPAIR YOURSELF. REFER SERVICING
TO QUALIFIED PERSONNEL.
WARNING:
• TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE
THIS EQUIPMENT TO RAIN OR
MOISTURE.
• TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, AND ANNOYING
INTERFERENCE, USE ONLY THE
RECOMMENDED ACCESSORIES.
• THIS DEVICE IS INTENDED FOR
CONTINUOUS OPERATION.
This product incorporates copyright
protection technology that is protected by
method claims of certain U.S. patents and
other intellectual property rights owned by
Macrovision Corporation and other rights
owners. Use of this copyright protection
technology must be authorized by
Macrovision Corporation, and is intended
for home and other limited viewing uses
only unless otherwise authorized by
Macrovision Corporation. Reverse
engineering or disassembly is prohibited.
SAFETY INFORMATION
Region Management Information
Region Management Information:
This Mobile DVD Player is designed and
manufactured to respond to the Region
Management Information that is recorded
on a DVD disc. If the Region number
described on the DVD disc does not
correspond to the Region number of this
Mobile DVD Player, this Mobile DVD Player
cannot play this disc.

5
DISC NOTES
Disc formats supported by this player
DVD
12 cm disc
(Single-sided disc only)
Video CD
12 cm disc
CD
12 cm disc
MP3
12 cm disc
Discs which cannot be played with this
player
• DVD-ROM
• DVD-R/DVD-RAM
• CDV
• CD-G
Handling and Cleaning
• Dirt, dust, scratches and warping disc
will cause misoperation.
• Do not place stickers or make
scratches on discs.
• Do not warp discs.
•Adisc should always be kept in its
case when not in use to prevent from
damaging.
• Do not place discs in the following
places:
1. Direct sunlight
2. Dirty, dusty and damp areas
3. Near car heaters
4. On the seats or dashboard
Disc Cleaning
Use a dry soft cloth to wipe the surface.
If the disc is quite dirty, use a soft cloth
slightly moisturised with isopropyl (rubbing)
alcohol. Never use solvents such as
benzine, thinner or conventional record
cleaners as they may mar the surface of
the disc.
Note:
A disc may become somewhat scratched
(although not enough to make it unusable)
depending on your handle it and conditions
in the usage environment.
V
I
D
E
O
Note these scratches are not an indication
of any problem with the player.
Preparing New Discs with Rough Spots
A new disc may have rough edges on its
inside and outside edges. If a disc with
rough edges is used, the proper setting will
not be performed and the player will not
play the disc. Therefore, remove the rough
edges in advance by using a ball point pen
or pencil as shown on the right. To remove
the rough edges, press the side of the pen
or pencil against the inside and outside
edges of the disc.
Rough spots
on inside edge
Ball point pen
or pencil
Rough spots on
outside edge
Label side up
Do not touch
the underside
of the disc
Do not bend
Wipe the disc from center
toward the outside edge

6
INSTALLATION
Note:
1. First remove the two screws that locket the unit core, then attach the brackets on
both sides of unit with screws (M4x6), last install the unit with screws (M5x25).
2. When fix the unit, you can slide the screw (M5x25) to left side or right side to meet
your needed position. In the figure above, select 1 and 3 position to fix the bracket,
and you can also select 2 and 4 position to fix the bracket.
12
34
1
2
3
4
SCREW
M4x5
SCREW
M4x5
SCREW
M5x25
SCREWS LOCKED THE UNIT
CORE

7
ELECTRIC CONNECTION
DC 12 V IN DC 1 V OUT
+
_
+RRMOTE DIGITAL
AUDIO
A/V OUT
L/R VIDEO
DVD PLAYER
AC/DC
ADAPTOR
(OPTIONAL)
YELLOW
RED
WHITE
VIDEO OUT
AUDIO R OUT
AUDIO L OUT
REMOTE CONTROL RECEIVER
CIGARETTE LIGHTER
(OPTIONAL)

8
REMOTE CONTROL
11
12
13
14
15
16
17
18
19
21
22
1
2
3
4
5
6
7
8
9
10
20
1. GOTO Disc search button, cooperatively used with numeric buttons
2. DISPLAY Display statistical disc information during playback
3. EJECT Press it to eject the disc.
4. SUBTITLE Changing of the SUBTITLE Language on multi-subtitle
language DVD disc
5. AUDIO Changing of the AUDIO soundtrack on multi-audio soundtrack
DVD disc. Changing of the sound mode of the VCD/CD disc
6. ZOOM Press it to zoom the picture in scale x 1.5,
7. TITLE Display the TITLE M=Menu that is stored in DVD disc
changing between PBC ON and PBC OFF on the VCD disc
8. / Press to start forward rapidly & to reverse rapidly
9. / / / Cursor buttons in MENU Mode.
10. SETUP Display the SETUP menu
11. Press it to stop playback
12. Press once to pause a play, press again to resume continuous
playback
13. POWER Press POWER to turn the unit ON or OFF
14. MUTE Press it to eliminate the sound immediate
15. SLOW Changing for slow forward/reverse playback motion
16. ANGLE Changing of the view angle on multi-angle DVD disc
17. A-B Press it to repeat between two selected sports on DVD or VCD
disc.
18. REPEAT Switch the Repeat mode of DVD/VCD/CD disc
19. / Press to skip to the next track & press to skip back one
track
20. ENTER Confirm the Track/Chapter selected with the number key or
selected with the cursor buttons on TV screen
21. 0 - 9 Numeric buttons
22. +10 Press it to select 10th digits

9
REMOTE CONTROL
Preparing the Remote Control
Inserting the Batteries
1. Remove the battery holder as the
direction indicated by the arrow.
2. Put the battery properly with the {+}
sign up as illustrated
3. Insert the battery holder. Push in the
holder to the original position
Using the Remote Control
Face the remote control towards the
player front face IR mark (remote control
signal receiver).
Operation angle: About ±30 degree in
each the direction of the front of the IR
mark.
To prevent damage to the unit, be sure
to follow the connection diagram
(page 7).
Loading a DVD/VCD/CD Disc
1. Turn the ignition on the accessory
position.
2. Press the POWER button (1).
3. Insert the disc with printed side facing
up into the disc slot (2).
4. The player starts playback
automatically.
Ejecting a Disc
Press (EJECT) button (3) to eject the disc.
12 3

BASIC OPERATION
10
Stopping Play
- Brief press the (Stop) button to stop
the unit playback, when press the
(Play) button it can continuous normal
playback.
-Press (Stop) button twice, it will stop
the playback and go back to initial
Track/Chapter.
Rapid Forward/Rapid Reverse
Press FF & REW during play.
Each time the button is pressed, the speed
of rapid forward/reverse changes according
to the disc as follow.
DVD:
VCD/CD:
MP3:
Skipping Track
Press / on the remote handset or
front panel during playback.
Press to skip to next track, and to
back one track.
Note: For some VCD 2.0 dics
(PBC-playback control), and
buttons may be unavailable.
Slow Motion Play
Press slow button during playback.
Each time the button is pressed, the slow mode
changes according to the disc as follow.
DVD:
VCD:
Note: For VCD, in any slow mode, press
ENTER button to return to normal
playback.
Normal Playback 2X 4X 6X 8X
Normal Playback 1X 2X 3X 4X
Pause (still picture)
Pressing during playback will stop play
temporary. Return to normal playback,
press once again.
Repeat
Press the REPEAT button to select repeat
mode as follow.
DVD:
Press the REPEAT button to select repeat
mode as follow.
VCD/CD:
Press the REPEAT button to select repeat
mode as follow.
1.
Continuously repeat at the current chapter/
track, when selected REP-ONE mode.
2.
Select REP-ALL mode to continuously
repeat all chapter/track on the current disc.
3. When the player finish playback the current
disc last chapter/track, it will stop display
the elapsed time. When selected REPEAT
OFF mode (REP-ONE & REP-ALL
disappear at the screen display).
4. REPEAT feature does not support
VCD2.0 (with PBC ON).
Reset
Reset button is placed on the front panel
and must be activated with a ball point pen
or thin metal object. Reset button is to be
activated for the following reasons:
• Initial installation of the unit when all
wiring is completed.
•
All the function buttons do not operate.
• Error symbol on the display.
Remote Sensor (IR)
Point the remote handset to the remote sensor.
Receive the signal from remote handset.
Turning the player on/off
Press the (POWER) button on front of
panel or press (POWER) button on
remote control to turn the player on or off.
Normal Playback SF 2X SF 4X SF 8X
SR 8X SR 4X SR 2X
CHAPTER REPEAT ON TITLE REPEAT ON
REPEAT OFF
REP-ONE REP-ALL REPEAT OFF
Normal Playback SF 1X SF 2X
Step BWD SF 3X
Normal Playback 2X
Press ENTER Button

BASIC OPERATION
(2) Press DISPLAY for the second time:
(3) Press DISPLAY for the third time:
(4) Press DISPLAY for the fourth time:
(5) Press DISPLAY for the fifth time:
The message on the screen will be cleared.
MP3:
Each time DISPLAY is pressed, the message
displayed on screen changes as follows:
Multi-audio Language Function
DVD:
Press AUDIO during playback.
Each time the button is pressed, number
of the audio soundtrack language changes
on sequential order.
Notes:
- The language number is different
according to the disc.
- Some disc only contain one language
soundtrack.
- When no different language
soundtrack are recorded will be
display at screen left top corner.
VCD:
Press AUDIO during playback.
It is possible to switch the sound between
monaural and stereo sound.
On-Screen Display Function
Press the DISPLAY button during playback
to display the contents of the current disc
on the screen.
Example:
DVD:
(1) Press DISPLAY for the first time:
Title Number, Total Title Number, Chapter
Number, Total Chapter Number of this Title
of the disc currently being played will be
shown on the screen, along with the
elapsed time.
(2) Press DISPLAY for the second time:
(3) Press DISPLAY for the third time:
(4) Press DISPLAY for the fourth time:
(5) Press DISPLAY for the fifth time:
The message on the screen will be cleared.
Video CD/SVCD/CD:
(1) Press DISPLAY for the first time:
TITLE 01/03 CHAPTER 002/025
00:02:25
CHAPTER REMAIN
00:01:39
CHAPTER ELAPSED
00:00:24
TITLE REMAIN
01:46:58
SINGLE ELAPSED 00:00:25
TRACK 01
SINGLE REMAIN 00:03:15
TRACK 01
TOTAL ELAPSED 00:00:25
TRACK 01
TOTAL REMAIN 00:40:35
TRACK 01
CHAPTER ELAPSED CHAPTER REMAIN
LEFT VOCAL RIGHT VOCAL MONO LEFT
STEREO MONO RIGHT
11

12
MONO LEFT MONO RIGHT STEREO
Multi-angle Function
(For DVD only)
Press ANGLE during playback.
Each time the button is pressed, number
of the angle changes in sequential order.
Notes:
- The angle number is different
according to the disc.
- The function only work for discs
having scenes recorded at different
angles.
- When no different angle are recorded,
will be displayed at screen left top
corner.
BASIC OPERATION
CD:
Press AUDIO during playback.
It is possible to switch the sound between
monaural and stereo sound.
TITLE Menu Function
DVD
If the DVD has multiple titles recorded on
the disc. It can select preferred title from
the title menu to start playback.
1. Press TITLE during playback.
The title menu is display.
2. Press the cursor button shown in TV
screen, select preferred title by the
cursor button and confirmed by
ENTER key.
VCD:
Press TITLE button while the disc is
playing, you can switch between “PBC on”
and “PBC off” mode.
Multi-subtitle Language Function
(For DVD only)
Press SUBTITLE during playback.
Each time the button is pressed, number
of the subtitle language changes in
sequential order.
Notes:
- The language number is different
according to the disc.
- Some discs only contain one subtitle
language.
- When no different subtitle language
are recorded, will be displayed at
screen left top corner.

13
MP3 Disc Play
MP3 disc is playing as the format of
FOLDER.
For example:
Use / / / buttons to select the item or
folder, then press ENTER button.
When select PLAY MODE, press the
REPEAT button repeatedly to select three
kinds of play mode.
REP-ONE:
Play the same song over and over again.
FOLDER REPEAT:
Play all songs in the current directory in
sequence, over and over again.
DISC REPEAT:
Play all songs in the disc over and over
again.
In the playback, use or to skip an
item ahead or back.
: Rapid reverse, : Rapid advance
Note: The FOLDER cannot be selected
during playing. It can be selected after
(Stop) button is pressed.
ROOT ROOT 0
MP3 MUSIC 1
SKY
MP3 HEAR YOUR
FOLDER
Mp3 PLAYER
PLAY MODE
BASIC OPERATION

14
SET UP
INITIAL SETUP
SETUP MENU --- MAIN PAGE
1. Press SETUP in the stop mode.
(Press the stop button twice to ensure
the player under STOP mode.)
2. The initial SETUP menu is displayed.
3. Select the preferred item by using the
/ buttons.
4. Press ENTER buttons.
a. GENERAL SETUP
This setup page includes all the
item of TV display & audio output
feature. The detail please refer to
GENERAL SETUP MENU.
b. SPEAKER SETUP
This is to activate the audio output
from DOLBY AC3 5.1 DOWNMIX
to 2 channel mode. Please refer to
SPEAKER SETUP MENU.
c. AUDIO SETUP
This setup page includes all the
items for AUDIO. Please refer to
AUDIO SETUP MENU.
d. PREFERENCE SETUP
This setup page includes all the
configuration of support feature.
The detail please refer to
PREFERENCES SETUP MENU.
GENERAL SETUP
--- GENERAL PAGE ---
TV display setup
This is to select the appropriate TV
aspect (4:3 or 16:9) according to the
connected TV set.
Normal/PS (For 4:3 TV)
Played back in the PAN & SCAN style.
(If connected to wide-screen TV, the left
and right edges are cut off.)
Normal/LB (For 4:3 TV)
Played back in letterbox style.
(If connected to wide-screen TV, black
bands appear at top and bottom of the
screen.)
Wide (For 16:9 TV)
Select when a wide-screen TV set is
connected.
Video Material
Normal
TV Screen
Pan Scan Letter-box
4:3 Wide (16:9)
4:3
16:9
GENERAL SETUP
SPEAKER SETUP
AUDIO SETUP
PREFERENCES
EXIT SETUP
TV DISPLAY
PIC MODE
ANGLE MARK
OSD LANG
CAPTIONS
SCR SAVER
MAIN PAGE
NORMAL/PS
NORMAL/LB
WIDE

15
SET UP
--- GENERAL PAGE ---
PIC mode setup
Select AUTO, the player PIC mode will
depend on DVD disc.
Select HI-RES format for best image
resolution.
Select N-FLICKER format on format on
image or picture under noise affect.
--- GENERAL PAGE ---
ANGLE MARK display setup
If it is set to ON, when the multi-angle
DVD disc is playing, (the angle mark)
will appears on the screen; if is set to
OFF, the mark will not appear.
--- GENERAL PAGE ---
OSD LANG type setup
Select the preferred OSD language by
using the / buttons.
--- GENERAL PAGE ---
CAPTIONS setup
Activate the CAPTIONS feature by
selecting ON. And release this feature
by selecting OFF.
TV DISPLAY
PIC MODE
ANGLE MARK
OSD LANG
CAPTIONS
SCR SAVER
MAIN PAGE
AUTO
HI-RES
N-FLICKER
TV DISPLAY
PIC MODE
ANGLE MARK
OSD LANG
CAPTIONS
SCR SAVER
MAIN PAGE
ENGLISH
TV DISPLAY
PIC MODE
ANGLE MARK
OSD LANG
CAPTIONS
SCR SAVER
MAIN PAGE
ON
OFF
TV DISPLAY
PIC MODE
ANGLE MARK
OSD LANG
CAPTIONS
SCR SAVER
MAIN PAGE
ON
OFF

16
--- GENERAL PAGE ---
SCR SAVER setup
Select the SCR SAVER output ON/OFF.
SPEAKER SETUP
--- SPEAKER SETUP PAGE ---
This is to activate the audio output from
DOLBY AC3 5.1 DOWNMIX to 2 channel
mode. Select the preferred SPEAKER
connection by using the cursor buttons.
• Select the LT/RT to activate the Dolby
surround compatible output.
• Select the STEREO to activate simple
stereo mode.
AUDIO SETUP
--- AUDIO SETUP ---
AUDIO OUT
This is to activate the audio output from
ANALOG mode to SPDIF/RAW mode to
SPDIF/PCM mode.
--- AUDIO SETUP ---
OP MODE
There are two operating modes for the
Dolby Digital decoder: LINE OUT and
RF REMOD.
TV DISPLAY
PIC MODE
ANGLE MARK
OSD LANG
CAPTIONS
SCR SAVER
MAIN PAGE
ON
OFF
AUDIO OUT
OP MODE
LPCM OUTPUT
DYNAMIC
MAIN PAGE
ANALOG
SPDIF/RAW
SPDIF/PCM
AUDIO OUT
OP MODE
LPCM OUTPUT
DYNAMIC
MAIN PAGE
LINE OUT
RF REMOD
DOWNMIX
MAIN PAGE
LT/RT
STEREO
SET UP

17
PREFERENCES SETUP
--- PREFERENCES PAGE ---
TV type setup
This player can play discs recorded in
either PAL or NTSC format.
Select NTSC format, when you
connected to NTSC TV.
Select PAL format, when you connected
to PAL TV.
Select AUTO format, the player TV output
format will according to the DVD disc
format.
--- PREFERENCES PAGE ---
AUDIO language setup
Select the preferred AUDIO soundtrack
by using the cursor buttons.
--- AUDIO SETUP ---
Dynamic Range Control
Select DRC and adjust the dynamic
range of a Dobly Digital encoded
program. There are 8 steps between full
compression and off compression.
--- AUDIO SETUP ---
LPCM OUTPUT
Select the LPCM OUTPUT between
LPCM 48K and LPCM 96K.
AUDIO OUT
OP MODE
LPCM OUTPUT
DYNAMIC
MAIN PAGE
FULL
6/8
4/8
2/8
OFF
AUDIO OUT
OP MODE
LPCM OUTPUT
DYNAMIC
MAIN PAGE
LPCM 48K
LPCM 96K
TV TYPE
AUDIO
SUBTITLE
DISC MENU
PARENTAL
PASSWORD
DEFAULTS
MP3 PLAYER
MAIN PAGE
AUTO
NTSC
PAL
TV TYPE
AUDIO
SUBTITLE
DISC MENU
PARENTAL
PASSWORD
DEFAULTS
MP3 PLAYER
MAIN PAGE
ENGLISH
FRENCH
SPANISH
CHINESE
JAPANESE
SET UP

18
--- PREFERENCES PAGE ---
SUBTITLE language setup
Select the preferred SUBTITLE language
by using the cursor buttons.
--- PREFERENCES PAGE ---
DISC MENU language setup
Select the preferred DISC MENU
language by using the cursor buttons.
--- PREFERENCES PAGE ---
PARENTAL
Select suitable parental guidance by the
cursor buttons and conformed by
pressing ENTER button.
--- PREFERENCES PAGE ---
PASSWORD
Select the change and press ENTER
button. Type the old password (The initial
factory code is 3308) and key in 4
characters password now you want to
use, and retype again to confirm key in
correctly.
TV TYPE
AUDIO
SUBTITLE
DISC MENU
PARENTAL
PASSWORD
DEFAULTS
MP3 PLAYER
MAIN PAGE
ENGLISH
FRENCH
SPANISH
CHINESE
JAPANESE
TV TYPE
AUDIO
SUBTITLE
DISC MENU
PARENTAL
PASSWORD
DEFAULTS
MP3 PLAYER
MAIN PAGE
1 G
2
3 PG
4 PG 13
5
6 PG-R
7 NC-17
8 ADULT
NO_PARENTAL
CHANGE
TV TYPE
AUDIO
SUBTITLE
DISC MENU
PARENTAL
PASSWORD
DEFAULTS
MP3 PLAYER
MAIN PAGE
SET UP
TV TYPE
AUDIO
SUBTITLE
DISC MENU
PARENTAL
PASSWORD
DEFAULTS
MP3 PLAYER
MAIN PAGE
ENGLISH
FRENCH
SPANISH
CHINESE
JAPANESE

19
General Setup TV Display Normal/PS
PIC Mode AUTO
Angle Mark ON
OSD Language English
Captions OFF
SCR Saver OFF
Speaker Setup Downmix Stereo
Audio Setup Audio Out Analog
OP Mode Line Out
Dynamic
LPCM Output LPCM 96K
Preferences TV Type AUTO
Audio English
Subtitle English
DISC Menu English
Parental 6 PG-R
Password 3308
Smart NAV With Menu
--- PREFERENCES PAGE ---
DEFAULTS
Select reset to become factory initial
setting.
--- PREFERENCES PAGE ---
Mp3 PLAYER
In this item, you can select NO MENU
mode or WITH MENU mode.
RESET
TV TYPE
AUDIO
SUBTITLE
DISC MENU
PARENTAL
PASSWORD
DEFAULTS
MP3 PLAYER
MAIN PAGE
NO MENU
WITH MENU
TV TYPE
AUDIO
SUBTITLE
DISC MENU
PARENTAL
PASSWORD
DEFAULTS
MP3 PLAYER
MAIN PAGE
DEFAULTS TABLE
SET UP

20
SPECIFICATIONS
Supply Voltage : 12V DC (11V-15V), test voltage 14.4V, negative ground
Current Consumption : Less than 2A
Signal System : Compositive video 1.0Vp-p 75Ω
Discs Played : (1) DVD-VIDEO Disc
5” (12 cm) single-sided, single-layer
5” (12 cm) single-sided, double-layer
(2) Compact Disc (CD-DA, VIDEO CD)
5” (12cm) disc
Audio Output Level : 600Ω(2 ch 2.0 Vrms)
Audio Signal Output
Characteristics : (1) Frequency Response 20 Hz - 20 KHz
: (2) S/N Ratio 90 dB (JIS)
: (3) Wow and Flutter Below measurable limits
Note:
Specifications and design are subject to modification, without notice, due to improvements
in technology.
This product incorporates copyright protection technology that is protected by
method claims of certain U.S. patents and other intellectual property rights
owned by Macrovision Corporation and other rights owners. Use of this copyright
protection technology must be authorized by Macrovision Corporation, and is
intended for home and other limited viewing uses only unless otherwise
authorized by Macrovision Corporation. Reverse engineering or disassembly is
prohibited.
88-V2350-14
