SPEC-D Tuning 2LHP-DEN07-TM User manual

If you experience any difficulties that the instruction did not cover, Please seek local auto shop for advise.
Please wear protection before you work on your vehicle.
An assistant is helpful when removing the front bumper.
Please be careful while working with the bumper or body part to avoid scratching.
Do not make direct contact with the halogen bulb or the wire assembly until the unit has cooled down after use
.
WWW.SPECDTUNING.COM
2007-2010GMCYUKONDENALI PROJECTORHEADLIGHTS
2LHP-DEN07-TM
2LHP-DEN07JM-TM
Handy Remover
¼” Drive Ratchet
¼” Drive Extensions (3 to 6 inches)
10mm Socket
If your Headlight is Halo type, you also need:
Wire Stripper
Wire Crimper
4 Blue Quick Splice Wire Connectors
2 Red Wires (8 inch)
2 Black Wires (8 inch)
INSTALLATION INSTRUCTIONS
TOOLS AND SUPPLIES REQUIRED

1. Open the hood, there are six bolts that needs to be
removed
3. Remove one hidden bolt between the bumper and fender
2. Remove two bolts under wheel well
4. Remove two headlight bolts
WWW.SPECDTUNING.COM
p1
If you experience any difficulties that the instruction did not cover, Please seek local auto shop for advise.
Please wear protection before you work on your vehicle.
An assistant is helpful when removing the front bumper.
Please be careful while working with the bumper or body part to avoid scratching.
Do not make direct contact with the halogen bulb or the wire assembly until the unit has cooled down after use
.
2007-2010
GMCYUKONDENALI PROJECTORHEADLIGHTS
INSTALLATION INSTRUCTIONS
WWW.SPECDTUNING.COM

5. Pull out the headlight a little bit, just enough to see the
wire harness in the back
9. Connect the driving light socket to the LED wire
please make sure that the black wire (negative) and
connects with the black wire
6. Disconnect the connectors from the headlight
7. Remove the harness from the OEM headlight
Please see the “Halo and L.E.D installation instructions”
8. Pull out the driving light bulb
10. Connect all the connectors and harness to new headlight
If your headlights don’t have HALO or L.E.D. You can skip
WWW.SPECDTUNING.COM
If your headlights don’t have HALO or L.E.D. You can skip
p2

11. Connect the connectors with the vehicle
15. Install two bolts under wheel well
12. Put the new headlight into the original spot
13. Install two bolts to fasten the headlight 14. Install one hidden bolt between the bumper and fender
16. Install six bolts for the top front grill
WWW.SPECDTUNING.COM
p3

17. The installation is now complete
please repeat the picture order from 1 to 17 for the
opposite side
WWW.SPECDTUNING.COM
p4
