Speco O2VLB2 User manual

Owner’s Manual
Full HD IP Bullet Camera
O2VLB2
Version 1.0

i
Welcome
Thank you for purchasing this network camera!
This owner’s manual is designed to be a reference tool for your system.
Please read this manual carefully before operating the unit and retain it for future reference.
Should you require any technical assistance, please contact Speco Technologies Technical Support.

ii
Im ortant Safeguards and Warnings
1
.
..
.
Electrical safety
All installation and operation here should conform to local electrical safety codes.
se a certified/listed 12VDC Class 2 power supply only.
Please note: Do not connect two ower su lying sources to the device at the same time; it may result in
device damage! The roduct must be grounded to reduce the risk of electric shock.
Improper handling and/or installation could run the risk of fire or electrical shock.
2
.
..
.
Trans ortation security
Heavy stress, violent vibration or exposure to water is not allowed during transportation, storage and
installation.
3
.
..
.
Installation
Do not apply power to the camera before completing installation.
Please install the proper power cut-off device during the installation connection.
Always follow the instructions in this guide.
4
.
..
.
Qualified ersonnel
This camera should be installed by qualified personnel only.
All the examination and repair work should be done by qualified personnel.
Any unauthorized changes or modifications could void the warranty.
5
.
..
.
Environment
This product should be installed in a cool, dry place away from direct sunlight and heat sources.
Do not install the product in extreme temperature conditions.
Do not expose the camera to electromagnetic radiation. Otherwise it may result in CMOS sensor failure.
Do not block any ventilation openings.
Do not allow water and liquid intrusion into the camera.
6. Maintenance
Please shut down the device and then unplug the power cable before you begin any maintenance work.
Do not touch the CMOS sensor optic component. You can use a blower to clean the dust on the lens surface.
Always use the dry soft cloth to clean the device. If there is too much dust, use a cloth dampened with a small
quantity of neutral detergent. Finally use the dry cloth to clean the device.
Please use a professional optical cleaning method to clean the enclosure. Improper enclosure cleaning (such as
using cloth) may result in poor IR functionality and/or IR reflection.

iii
7. Accessories
Before installation, please open the package and check that all the components are included.
Contact your distributor immediately if something is broken/missing in your package.
Accessory Name Amount
Network Camera nit 1
Quick Start Guide 1
Installation Accessories Bag 1
CD 1

iv
Table of Contents
1
General Introduction ................................................................................................................ 1
1.1
Overview .................................................................................................................... 1
1.2
Specifications .............................................................................................................. 1
1.2.1
Performance ........................................................................................................ 1
2
Physical Specifications .............................................................................................................. 2
2.1
Cable .......................................................................................................................... 2
2.2
Dimensions ................................................................................................................. 3
3
Device Installation .................................................................................................................... 5
4
IP Scanner ................................................................................................................................ 7
4.1
Overview .................................................................................................................... 7
4.2
Operation ................................................................................................................... 7
5
Web Operation......................................................................................................................... 8
5.1
Login and Main Interface ............................................................................................ 8
6
FAQ .......................................................................................................................................... 9
Appendix Toxic or Hazardous Materials or Elements ..................................................................... 10

1
1General Introduction
1.1 Overview
This Speco device is a multi-codec (H.264, MJPEG) IP camera that integrates the traditional camera and network
video technology. It enables real time transmission of synchronized video of full HD resolution.
Built-in IR LEDs allows for a suitable image in low light environments. IP66 compliant housing allows for
outdoor installations. Built-in PoE (power over Ethernet) reduces wiring that’s required during installation.
1.2 S ecifications
1.2.1 Performance
Camera
Image Sensor Progressive scan 1/3-inch CMOS
Day/Night Mode IR-cut filter
Gain Control Fixed/Auto
White Balance Manual/Auto
BLC On/Off
Electronic Shutter
Manual/Auto/Low noise/Low motion blur
Range: 1/3 to 1/100000.
Video Com ression H.264/H.264B/H.264H/MJPEG
Su orted
Resolutions
Main stream
: 1920x
1080
/ 1280x720
@30fps
Sub stream: 704x576 / 704x480 @ 30fps
Video Bit Rate
VBR/CBR supported
H.264H: 16Kbps-8192Kbps
MJPEG: adjustable
Video Fli Mirror and flip
Privacy Mask Supports max 4 privacy mask zones
Video Information Channel title, time title, motion detection, tampering.
Lens 3.6mm fixed
Network
Ethernet 10/100 Base-T
Network Protocol HTTP
,
TCP
,
ARP
,
RTSP
,
RTP
,
DP
,
RTCP
,
SMTP
,
FTP
,
DHCP
,
DNS
,
DDNS
,
PPPOE
,
IPv4/v6
,
QoS
,
PnP
,
NTP
,
HTTPS
,
Bonjour
User Access Max 20 users
Security ser ID & password protection, IP address filtering, HTTPS, user access log
O eration & Unit
IR Range 65’ (depending on scene reflection)
Power PoE (802.3af), 12VDC
Power
Consum tion 6W max
O erating
Tem erature -22F ~ 140F
O erating Humidity
≤95%
Dimensions 2.6” (diam) x 6.1” (L)
Unit Weight 1.4 lbs.

2
2Physical S ecifications
2.1 Cable
Refer to the following figure for cable information.
Figure 2-1 Cable
Please refer to the following sheet for detailed information.
No.
Port Name
Function Connection Note
1 LAN Network port Ethernet port
Connect to standard Ethernet cable for power and data
2 DC 12V Power input port
DC jack Power port. Input DC 12V.

3
2.2 Dimensions
Please refer to the following figure for dimension information. The unit is in mm. See Figure 2-3 to Figure 2-6.
Figure 2-3
Figure 2-4

4
Figure 2-5
Figure 2-6

5
3Device Installation
Im ortant
Please make sure the installation surface can su ort a minimum of 3 times the weight of the camera.
Figure 3-1 Device installation 1
Please see Figure 3-1 and Figure 3-2.
Ste 1
Put installation template on the designated surface where you will install the device (wall or ceiling).
Ste 2
Drill holes according to position of the holes on the installation template.
Ste 3
Open accessories bag, take out the expansion bolts and insert them into the drilled holes.
Ste 4
Take out the screws. Tighten the 4 screws to fix the device on the installation surface (wall or ceiling). The sun
shield can be adjusted. Tighten the screws on the sun shield when finished.
Ste 5
Connect all applicable wiring properly.

6
Figure 3-2 Device installation 2
Ste 6
se Philip’s head screw (in accessories bag) to loosen adjusting screw.
Ste 7
Adjust the device to point to the desired angle.
Ste 8
se Philip’s head screw to tighten the screws.

4IP Scanner
4.1 Overview
IP Scanner can search
for the device on the local network.
Please note
that only devices that are on the same subnet can be discovered
4.2 O eration
Open up IP Scanner.
Figure 4-1
In the device list, you can view the
IP add
applicable device and double click to open up the web viewer.
for the device on the local network.
that only devices that are on the same subnet can be discovered
.
IP add
ress, model number, and MAC address
of each device
applicable device and double click to open up the web viewer.
Figure 4-1 IP Scanner
of each device
. Select the

5Web O eration
This device supports viewing
and management via
5.1
Login and Main Interface
Open the browser
and input network camera address in the address bar
See Figure 5- 1.
The login interface is shown as below. See
Please input your user name and password.
Default user name is
admin
and password is
Note: For security ur oses
, lease
After
logging in, follow directions to install applicable plugins
and management via
a web browser on a PC.
Login and Main Interface
and input network camera address in the address bar
or double click the device in IP Scanner
Figure 5- 1 IP address
The login interface is shown as below. See
Figure 5- 2.
Please input your user name and password.
and password is
1234
.
, lease
change the assword after initial login.
Figure 5- 2 Web login
logging in, follow directions to install applicable plugins
.
or double click the device in IP Scanner
.
Input your IP
address
here

9
6FAQ
Bug
Water leakage has
occurred.
Removal of the front or rear cap may result in water leakage.
The glass front cap has sustained heavy push or strike.
The waterproof plug of the rear cap has loosened.
IR video is poor.
If there is not enough power, the IR LEDs may not function properly.
The object is out of the IR distance range of current device.
Cannot log in to the
web viewer.
The Active X control is blocked.
The graphics card version needs to be dx8.1 or higher.
Network connection error has occurred.
Invalid network setup.
Invalid user name or password.
Settings updates After modifying important camera settings, please reboot the device to
make sure the new settings are applied.

10
A endix Toxic or Hazardous Materials or Elements
Com onent
Name
Toxic or Hazardous Materials or Elements
Pb Hg Cd Cr VI PBB PBDE
Circuit Board
Component ○ ○ ○ ○ ○ ○
Device Case
○
○ ○ ○ ○ ○
Wire and Cable
○
○ ○ ○ ○ ○
Packing
Components ○ ○ ○ ○ ○ ○
Accessories ○ ○ ○ ○ ○ ○
O: Indicates that the concentration of the hazardous substance in all homogeneous materials in the parts is
below the relevant threshold of the SJ/T11363-2006 standard.
X: Indicates that the concentration of the hazardous substance of at least one of all homogeneous materials in
the parts is above the relevant threshold of the SJ/T11363-2006 standard. During the environmental-friendly
use period (EF P) period, the toxic or hazardous substance or elements contained in products will not leak or
mutate so that the use of these (substances or elements) will not result in any severe environmental pollution,
any bodily injury or damage to any assets. The consumer is not authorized to process such kind of substances
or elements, please return to the corresponding local authorities to process according to your local government
statutes.
Note
This user’s manual is for reference only. Slight difference may be found in user interface.
All the designs and software here are subject to change without rior written notice.
All trademarks and registered trademarks mentioned are the ro erties of their res ective
owners.
Please visit our website at s ecotech.com or contact customer service for more information.
