Spypoint XCEL 720W User manual

v1.2
In the box Components
Note: Memory cards and additional mounts are sold separately.
1pcs Quick start
guide
INSERTING THE MICROSD CARD
Insert a microSD memory card in the card slot, gold contacts facing the
front of the XCEL. The card is inserted correctly when a click is heard.
REMOVING THE MICROSD CARD
Lightly press the memory card into the camera once to pop it out of the
slot and remove it.
CHARGING THE CAMERA
The camera can be charged with:
A USB power source (e.g. a computer)
To charge the battery:
Connect the camera to a USB power source.
(Charging time: 4 hours)
EXTERNAL POWER SOURCE FOR EXTENDED USE
While using the camera, an external power source can be used to provide
continuous power and allow a longer autonomy period. All of the power
sources shown can be used to power the camera continuously during use.
Getting started
Note: The XCEL mount adaptor is designed to attach securely and
adequately to the anchorage system of the camera and resist
to activities with impact.
CAPTURING VIDEOS + PHOTOS
To Start/Stop video:
Press the Shutter/Select Button, the camera will emit one beep and the
Camera will start recording. Press the Shutter/Select Button again and
the camera will emit one beep to indicate recording has stopped.
To Start/Stop photos:
Press the Down Button to take a picture. The camera will emit a came-
ra shutter sound each time a photo is taken. If in TIME LAPSE, press the
Down Button to stop taking pictures.
PLAYBACK
To enter the Playback menu to view your videos and photos.
Cycle through the camera modes with the Power/Mode Button.
1. Repeatedely press the Up or Down Button
to cycle through video and photo.
2. Press the Shutter/Select Button
to view the selected video or photo.
3. To view your other videos and photos, repeatedely
press the Up/Down Button to cycle through them.
4. To exit, press the Power/Mode Button
INSTALLINGTHE QUICK RELEASE STAND WITH SAFETY RING
TURNING ON THE CAMERA
To turn ON the camera, press the Power/Mode Button.
To turn OFF the camera, press and hold the Power/Mode Button
a few seconds until the screen shuts down.
CYCLE THROUGH THE MODES
You can cycle through the camera modes with the Power/Mode Button
Video/Photo Record Video or capture a single photo.
Playback View recorded video or photo.
Settings Adust camera settings, resolution and more
Note: The camera is compatible with microSD memory cards with capacity up
to 32 GB (not included). See Available accessories section.
1pcs Quick release
stand
1pcs Lithium-ion
Polymer battery
1pcs Lens cleaning
cloth
1pcs USB
cable (22’’)
1pcs Scope
mount
1pcs Leash
1pcs Flat adhesive
mount
Status LED
Lens
Microphone
MicroSD reader
Micro-USB port
Screen
Select/Shutter Button
Power/Mode Button
Up Button
Speaker
Down Button
Battery case
1
2
3
4
5
6
7
8
9
10
11
12
1
2
3
5
6
4
8
12
11
7
10
9
QUICK START GUIDE
XCEL 720W
•TRAIL CAMERAS
•HUNTING TABLET
• ACTION CAMERAS
& ACCESSORIES
User manual, latest rmware
& FAQ available at:
www.support.spypoint.com
 [email protected]
 1-888-779-7646

SETTINGS
Cycle through the camera modes with the Power/Mode Button.
Press the Shutter/Select button to enter the settings menu. Press the
Power/Mode button repeatedly to cycle through options and press the
Shutter/Select button to select the desired option. Use the Up or Down
Button to cycle throught the various options.
Movie Size
720p 30fps
640 VGA 30fps
Date Stamp
On / O
Looping Video
On / O
Enables continuous video recording; overwriting the beginning of
your video to allow for new footage to be captured
Exposure
-2 / -1.7 / -1.3 / -1.0 / -0.7 / -0.3 / 0 / +0.3 / +0.7 / +1.0 / +1.3 / +1.7 / +2
Adjust the amount of light so it feels just bright or dark enough.
Both the shadows and highlights should feel the most natural and
comfortable to look at. Too much light results in a washed out video/
photo (overexposed). Too little light and the video/photo will be too
dark (underexposed).
Photo Resolution
5M/3M/2M/1M
Single Shot
On/O
Bust Photos
On/O
3 photos in 1.5 seconds
Time Lapse
O / 2s / 10s
Continuous Lapse
O / 2 s / 3 s / 5 s / 10 s / 20 s / 30 s / 60 s
Power Frequency
50 Hz / 60 Hz
Language
English, French, German & more
Date & Time
M/DD/YY, D/MM/YY or YY/MM/DD
Sound
Shutter On/O, Start Up 1/2/3/None, Beep On/O, Volume 0/1/2/3
Screen Saver
O / 1 min / 3 min / 5 min
Power Save
O / 1 min / 3 min / 5 min
Format
Yes / No
Reset
Yes / No
Version
Fits any scope within 0.91"
to 1.38" diameter.
#XHD-SCM
Suitable for all firearms equipped
with Picatinny rails.
#XHD-PICATINNY
picatinny mount
scope mount
Suitable for 10 and 12-gauge
shotgun.
#XHD-SGM
SHOTGUN MOUNT
Adjustable, fits medium
to large sized dogs.
#XHD-DOG
dog mount
bow mount
Suitable for all bow models
having an opening for a stabilizer.
#XHD-BM
Fits most sling studs on firearms.
#XHD-SSM
SLING STUD MOUNT
cap mount
The cap clip allows to easily
attach a camera to a cap.
#XHD-CM
DECOY MOUNT
Attach your camera to any
decoy using the clip or the rod.
#XHD-DM
HELMET KIT
Low quick release stand, straight
& 90° extenders, vented helmet
mount and curved adhesive mount.
#XHD-HK
NVG mount
Fits any helmet equipped
with a NVG mounting plate.
#XHD-NVG
Adhesive mounts
Adhesive mounts to attach
to the quick release stand.
Included: 2 curved & 2 flat
adhesive mounts.
#XHD-AM
Ball joint mount + Low
quick release stand kit
Quickly install your camera
in a variety of positions.
#XHD-BJM
Ball joint mount 
Low quick
release stand 
Chest mount
Install the camera to your chest.
#XHD-CHM
head strap mount
Fully adjustable & fits all sizes.
#XHD-HSM
Dual USB Car
charger
12V dual USB ports car adaptor
to charge up to 2 XCEL action
cameras simultaneously.
#XHD-CUSB
LITHIUM-ION
Rechargeable BATTERY
Rechargeable lithium-ion polymer
battery pack. Compatible with
XCEL 720, 1080 & 4K only.
#XHD-BATT2
360° ROLL BAR MOUNT
Fits on any tubular object within
0.79" to 1.38" diameter.
#XHD-360RBM
tripod mount
Attach the camera on any tripod
with ¼-20 threaded insert.
#XHD-TPM
More available on SPYPOINT.com
Additional mounts & accessories
Join the community
Our goal is to design & manufacture
innovative, premium products for the
hunting industry and to cater to all hunters
passionate about the lifestyle that is
hunting. We strive on oering all customers
a positive, user friendly experience that will
have a lasting impression.
