Stamina Gravity Inversion Table User manual

55-1538
STAMINA PRODUCTS
MADE IN CHINA
Product May Vary Slightly
From Pictured.
CAUTION: 1. Weight on this product should not exceed 300 lbs.
2. Class H equipment: This equipment is for home
use only. It is not for commercial use.
! WARNING !
Exercise can present a health
risk. Consult a physician
beforebeginningany exercise
program with this equipment.
If you feel faint or dizzy,
immediately discontinue use
of this equipment. Serious
bodily injury can occur if this
equipment is not assembled
and used correctly. Serious
bodily injury can also occur if
all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
tightened prior to each use.
Followallsafetyinstructionsin
this manual.
When calling for parts or
service, please specify the
following number.
2005, 12
2040 N. Alliance, Springfield, MO 65803
Customer Service Number
1 [phone]
www.staminaproducts.com
This Product is Produced Exclusively by
2005 Stamina Products, Inc.
Owner's Manual

2
SAFETY INSTRUCTIONS
2
WARNING:
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
Read all warnings posted on the Gravity Inversion Table.
The Gravity Inversion Table should only be used after a thorough review of the Owner's Manual.
We recommend that two people be available for assembly of this product.
Do not use the Gravity Inversion Table alone. Always have a helper available in case assistance is needed
in recovering from the decline position.
Verify that adequate head clearance is available between the user's head and the floor before using this
inversion table. This is especially important for tall users.
Make sure that the PivotArms are assembled using the same hole on both PivotArms. Pay close attention to
Steps 3 and 4 on page 7.
Make sure that the PivotArms are always secured to the pegs on the Main Frame with the Bolts and Washers.
Adjust theNylon Straps to anangle of 15 to 20 degrees and use this setting until you have verified your height
setting and become familiar with the Gravity Inversion Table.
Use the lowest holes in the PivotArms until you become familiar with the Gravity Inversion Table.
You must understand how to recover from the fully inverted position before using the fully inverted position.
Read the RECOVERY FROM LOCKED POSITION section at the bottom of page 12 BEFORE using the fully
inverted position.
Do not allow children to use or play on the Gravity Inversion Table.
Keep small children and pets away from the Gravity Inversion Table at all times.
The Gravity Inversion Table should not be used by persons weighing more than 300 lbs.
The Gravity Inversion Table should not be used by persons over 6 feet 6 inches tall.
It is recommended that you place this exercise equipment on an equipment mat.
Use the Gravity Inversion Table only on a level surface.
Wearappropriateclothing when exercising;do notwearloose clothingthat could becomecaughtin the Gravity
Inversion Table.
Be sure that there is enough room for the bed to rotate completely.
Use the Gravity Inversion Table only as described in the manual.
The safety level of the Gravity Inversion Table can be maintained only if it is examined regularly for damage
and wear.
This equipment is for home use only. It is not for commercial use.
Maintenance Instructions 13
Product Parts Drawing 14
Parts List 15
Warranty 16
Notes 17
Fax/Mail Ordering Form 18
Safety Instructions 2
Before You Begin 4
Hardware Identification Chart 5
Assembly Instructions 6
Operational Instructions 10
Storage 13
TABLE OF CONTENTS Page Page
Extreme obesity
Glaucoma, retinal detachment or conjunctivitis
Pregnancy
Spinal injury, Cerebral Sclerosis, or acutely swollen joints
Middle ear infection
High blood pressure, Hypertension, Recent stroke or Transient ischemic attack
Heart or circulatory disorders for which you are being treated
Hiatus hernia or Ventral hernia
Bone weaknesses including Osteoporosis, Unhealed fractures, Medullary pins, or
Surgically implanted orthopedic supports.
Use of anti-coagulants including Aspirin in high doses.
WARNING: Before using this equipment you should consult with your personal physician to see if inversion
equipment is appropriate for you. Do not use this equipment without your physician's approval. Do not use
this equipment if you have any of the following conditions or ailments:
To reduce the risk of serious injury, read the following safety instructions before
using the Gravity Inversion Table.

THANK YOU FOR PURCHASING THE
Gravity Inversion Table
To help you get started, we have pre-assembled most of your
Gravity Inversion Table at the factory with the exception
of those few parts left unassembled for shipping purposes.
Simply follow the few assembly instructions set forth in this manual.
Within a few minutes you will be getting your body into shape and on your
way to achieving a happier and healthier lifestyle.
Should you have any questions,
please call our Customer Service Department toll-free number,
1 [phone]
Monday - Friday, 8:00 A.M. - 5:00 P.M., Central Time.
CALL US FIRST
3

Thank you for choosing the Gravity Inversion
Table. We take great pride in producing this quality
productand hopeit willprovidemanyhoursofquality
exerciseto makeyoufeelbetter,lookbetter andenjoy
life to its fullest.
Yes, it's a proven fact that a regular exercise
program can improve your physical and mental
health. Too often, our busy lifestyles limit our time
andopportunitytoexercise. The Gravity Inversion
Table provides a convenient and simple method to
beginyourassault on gettingyour body in shapeand
achieving a happier and healthier lifestyle.
Before reading further, please review the drawing
below and familiarize yourself with the parts that are
labeled.
For your benefit, read this manual carefully before
using the Gravity Inversion Table.
BEFORE YOU BEGIN
4
Pivot Arm
Bumper
Footrest
Heel Holder
Height
Adjustment Beam
Front Frame
Main Frame
Buckle Strap
Hand Grip
Rear Frame
Although Stamina tries to manufacture its products
with the finest materials and uses the highest
standards of manufacturing, occasionally a part that
does not fit, is the incorrect size, or is otherwise
inappropriate is found. Even with the highest
inspection and quality controls in place these things
will happen occasionally. Please do not return the
product. For your convenience, Stamina has a
Customer Service Department with a toll-free
number. If a part is missing, does not fit, is the
incorrect size, or is otherwise inappropriate, please
call1(800) 375-7520 (in the U.S.)between8:00A.M.
and 5:00 P.M. Central Time, Monday through Friday.
Our operators will be able to assist you with your
problem and the parts will be mailed directly to your
house.
Adjustment Knob
Endcap Stand
THE FOLLOWING TOOLS ARE INCLUDED FOR ASSEMBLY : Wrench
CombinationWrench
Protective Cover
Nylon Bed
Protective Cover

5
Part No. and Description Qty
HARDWARE IDENTIFICATION CHAT
Place washers, the end of bolts or screws on the circles to check for the
correct size. Use the small scale to check the sizes of bolts and screws.
This chart is provided to help identify the hardware used in the assembly process.
After unpacking the unit, open the hardware bag and make sure that you have the following items:
length
length
mm.
in.
INCHES
MILLIMETERS
11/2021/2 31/2 41/2 51/2 61/2
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
6 8 10 12
3/16" 5/16" 1/2"3/8"1/4"
NOTICE: The length of all kinds of screws and bolts are not included
themselves head, except the flat head screws and bolts.
42 Nylock Nut (M6 x 1) 2
38 Bolt, Round Head (M6 x 1 x 10mm) 2
40 Bolt, Hex Head (M6 x 1 x 47mm) 2
44 Larger Washer (M6) 2
45 Washer (M6) 4
1. Some of the hardware items listed may be attached to other parts.
2. Bolt length is measured from the bottom of the bolt head to the end of the bolt.
NOTE:

ASSEMBLY INSTRUCTIONS
Place all parts from the box in a cleared area and position them on the floor in front of you. Remove all
packing materials from your area and place them back into the box. Do not dispose of the packing materials
until assembly is completed. Read each step carefully before beginning. If you are missing a part please
call our toll-free number for assistance 1 [phone] or e-mail us at:
[e-mail]
6
STEP 1
Unfoldthe BASEASSEMBLYto an upright position by moving the FRONT FRAME(1)away from REAR
FRAME(2). Then push down on the middle of the two FOLDING LINKAGES(3) until they are fully
locked down.
STEP 2
Slide one PROTECTIVE COVER(23) onto each side of the BASE ASSEMBLY, and pull the covers
down until the bottom of the covers are slightly lower than the FOLDING LINKAGES(3). Secure the
PROTECTIVE COVERS(23) to the FOLDING LINKAGES(3) with the SECURING STRAPS on the
bottom of the covers.
NOTE: WhenthePROTECTIVE COVERS(23) areassembledcorrectly, the FOLDING LINKAGES(3)
should not be visible. Refer to the illustration.

ASSEMBLY INSTRUCTIONS
7
STEP 3
Slidethebottom of the two PIVOTARMS(5)intothebracketslocatedat each sideoftheMAIN FRAME(4).
Align the desired hole on the arm with the peg on the bracket, and insert the peg into the hole to lock the
PIVOT ARMS(5) in position. Then secure the PIVOT ARMS(5) on the pegs with ROUND HEAD
BOLTS(M6 x 10mm)(38) and LARGE WASHERS(M6)(44).
PIVOT ARM ADJUSTMENT:
There are three adjustment holes on the PIVOT ARMS(5) allowing you to position the MAIN FRAME(4)
at three different heights. The lowest hole will allow the least amount of inversion angle. The top hole will
allow the greatest amount of inversion angle.
CAUTION:
STEP 4
Attach the MAIN FRAME(4) onto the REAR FRAME(2)by sliding the slots in the ends of the two PIVOT
ARMS(5) into the slots on the REAR FRAME(2).
Use the lowest holes in the PIVOT ARMS(5) until you become familiar with the Gravity
Inversion Table.
Both PIVOT ARMS(5) must be adjusted to the same hole. Trying to adjust the PIVOT
ARMS(5) to different positions could cause damage to the machine, and injury to the user.
1.
2.
SLOTS

ASSEMBLY INSTRUCTIONS
8
STEP 5
Attach the FOOTREST(8) onto the HEIGHT ADJUSTMENT BEAM(6) with the ADJUSTMENT
KNOB(9).
NOTE:
STEP 6: Insert the PAD TUBE(10) through the hole on the HEIGHT ADJUSTMENT BEAM(6) and
secure with HEX BOLT(M6 x 47mm)(40), NYLOCK NUT(M6)(42), and WASHERS(M6)(45). Place
a HEEL HOLDER BRACKET(11) onto a HEEL HOLDER(12), then slide them onto PAD TUBE(10)
together. Slide another set of HEEL HOLDER BRACKET(11) and HEEL HOLDER(12) over the other
end of the PAD TUBE(10).
STEP 7: Attach the ADJUSTABLE INSTEP FRAME(7) to the HEIGHT ADJUSTMENT BEAM(6)
bypullingtheSMALL SPRING PIN(15)and sliding theADJUSTABLE INSTEPFRAME(7) completely
into the HEIGHT ADJUSTMENT BEAM(6). Place a WASHER(M6)(45) onto the HEX BOLT
(M6x 47mm)(40), then insertthebolt thehalfwaythroughthesquaretube on theHEIGHTADJUSTMENT
BEAM(6), slide the bolt through the ring at the bottom of the SPRING(13), slide the bolt through the
square tube and secure with NYLOCK NUT(M6)(42) and WASHER(M6)(45). Press the SQUARE
PLUG(35) into the HEIGHT ADJUSTMENT BEAM(6). Install a HEEL HOLDER BRACKET(11)
and HEEL HOLDER(12) onto both sides of the ADJUSTABLE INSTEP FRAME(7).
The four adjustment holes in the FOOTREST(8) allow the FOOTREST(8) to be attached in four
different positions. Start with one of the center positions and adjust if necessary. Use the outer
position if users are taller than average. Use the inner position if users are shorter than average.

ASSEMBLY INSTRUCTIONS
9
1.
2.
STEP 8
Install the HEIGHT ADJUSTMENT BEAM(6) into MAIN FRAME(4) by pulling the LARGE SPRING
PIN(18) on the MAIN FRAME(4) and inserting the HEIGHT ADJUSTMENT BEAM(6) as shown. For
added safety, thread the LOCKING KNOB(19) into back side of the MAIN FRAME(4).
WARNING:
STEP 9
Attach the NYLON STRAP(27) onto the BUCKLE on the end of the BUCKLE STRAP(28) by inserting
the end of the strap up through the bottom of the buckle, as shown in the illustration 1.
STEP 10
Hook the end of the NYLON STRAP(27) onto the loop on the back of the MAIN FRAME(4). Hook the
end of the BUCKLE STRAP(28) onto the loop on the FRONT FRAME(1).
NOTE:
A.
C.
B.
BUCKLE
Do not use the Gravity Inversion Tableuntil you have verified your height setting. Failure
to use the proper height setting can result in difficulty recovering from the decline position.
See HEIGHT ADJUSTMENT instructions on page 10.
The NYLON STRAPS are used to control the decline angle of the Gravity Inversion Table.
For a steeper decline angle, lengthen the straps. For a lessor decline angle, shorten the straps.
Make sure these NYLON STRAPS are tight in the buckle and check the declineangle before
using the Gravity Inversion Table.

OPERATIONAL INSTRUCTIONS
10
GENERAL PRECAUTIONS
UsethelowestholesinthePIVOT ARMS(5) untilyou becomefamiliarwith the Gravity Inversion Table.
Do not use the Gravity Inversion Table alone. Always have a helper available in case assistance is
needed in recovering from the decline position.
Make sure that the HEEL HOLDERS(12) are holding your feet securely.
Make sure that the HEIGHT ADJUSTMENT BEAM(6) is properly set for your height.
Make sure that the HEIGHT ADJUSTMENT BEAM(6) is held securely by both the LARGE SPRING
PIN(18) and the LOCKING KNOB(19).
Make sure that there is enough room for the bed to rotate completely.
1.
2.
3.
4.
5.
6.
THE HANDLEBARS
For added convenience, and safety, a set of HANDLEBARS has been added to the Gravity Inversion
Table.These HANDLEBARS are located at the top of the REAR FRAME(2). The HANDLEBARS are to
help you return to the upright position from any degree of inversion. If you wish to return to the upright
position, and the bed is moving too slowly, or not moving at all, simply grab the HANDLEBARS and pull on
them until you return to the upright position.
HEIGHT ADJUSTMENT
The Gravity Inversion Table is a very sensitive balance device. It responds to very slight changes in
weight distribution. It is very important to make sure that the height adjustment is adjusted properly. Use
the following procedure to set the height adjustment and balance the Gravity Inversion Table.
Adjust the NYLON STRAPS to restrict
movement to approximately 15 degrees
beyond the horizontal position. The
nylon straps should not allow the Gravity
Inversion Table togointothefull inversion
position while you are setting the height
adjustment.
Loosen the LOCKING KNOB(19) under
the MAIN FRAME(4).
PulltheLARGESPRING PIN(18)anduse
the SCALE DECAL(16) to set the
HEIGHT ADJUSTMENT BEAM(6).
Tighten the LOCKING KNOB(19).
Mount the machine.
Lock your ankles into the HEEL
HOLDERS(12).
Lie back with your hands at your sides.
Slowly raise your hands to your chest.
If your feet are higher than your head,
dismount and try a taller setting. If you do
not rotate to a position close to level,
dismount and try a shorter setting.
3.
4.
5.
1.
2.
6.
7.
8.
9.
The Gravity Inversion Table should return to the upright position when your hands are below
your waist. If it does not, use a taller setting.
Verify that adequate head clearance is available between the user's head and the floor before
using this inversion table. This is especially important for tall users.
NOTE:1.
2.
Handlebars
