Stamina inSTRIDE CYCLE XL User manual

WARNING: Weight limit is not applicable if product is used properly. This unit
is not designed to support a user's weight. To reduce the risk of
serious injury, please read all safety instructions before using.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
SAFETY INSTRUCTIONS
Product May Vary
Slightly From Pictured.
Read this Owner's Manual and follow it carefully before using the inSTRIDE CYCLE XL.
Do not stand up on the inSTRIDE CYCLE XL.
Keep children away from the inSTRIDE CYCLE XL. Do not allow children to use or
play around the inSTRIDE CYCLE XL. Keep children and pets away from the
inSTRIDE CYCLE XL when it is in use.
Set up and operate the inSTRIDE CYCLE XL on a solid level surface or table.Do
not position the inSTRIDE CYCLE XL on loose rugs or uneven surfaces.
Inspect the inSTRIDE CYCLE XL for damaged or loose components prior to use.
Tighten/replace any loose or worn components prior to using the inSTRIDE CYCLE XL.
The surface of the crank housing may become hot during use, so allow it to cool
before moving.
Consult a physician prior to commencing an exercise program. If, at any time during
exercise, you feel faint, dizzy, or experience pain, stop and consult your physician.
Always choose the workout which best fits your physical strength and flexibility
level. Know your limits and train within them. Always use common sense when
exercising.
Do not wear loose or dangling clothing while using the inSTRIDE CYCLE XL.
Never exercise with bare feet or socks.Always wear appropriate footwear.
The inSTRIDE CYCLE XL should be used by only one person at a time.
The inSTRIDE CYCLE XL is for consumer use only. It is not for use in public or
semipublic facilities.
Safety Instructions
Customer Service
Operation
Warranty
When calling for parts or
service, please specify the
following model number:
15 -0120A
MADE IN CHINA
2009 Stamina Products, Inc.
This Product is Produced Exclusively by
2009, 12
2040 N. Alliance, Springfield, MO 65803
Customer Service Number
1 [phone]
[e-mail]
www.staminaproducts.com

ASSEMBLY & OPERATIONAL INSTRUCTIONS
STEP 1:
STEP 2:
STEP 3:
NOTE:
2
Insert the STABILIZERS(2) into both ends of the MAIN FRAME(1) and secure
withBUTTONHEADBOLTS(M8x1.25x12mm)(16)andARCWASHERS(M8)(17).
DO NOT TIGHTEN COMPLETELY.
AdjusttheSTANDCAPS(3), set the inSTRIDE CYCLE XL onthefloorand tighten
the bolts.
Bolt the T KNOB(14) into the hub on the MAIN FRAME(1).
Slide the TIMER(18) onto the plate on the MAIN FRAME(1).
There are two adjustment holes on each side of the PEDALSTRAPS(12). Select
the adjustment holes which allow your feet to be easily removed from the
PEDALS(11).
Thesurfaceofthecrankhousingmaybecome
hot during use, so allow it to cool before
moving. Read the cautions posted on the
inSTRIDE CYCLE XL.
CAUTION:
Caution Decal
(both sides)

LOAD ADJUSTMENT
ASSEMBLY & OPERATIONAL INSTRUCTIONS
3
USING THE ELECTRONIC TIMER
To time your workout, begin by pressing and holding the
button on the face of the timer until zeros are displayed.
Release the button.
Start the timer by pressing and releasing the button. Now
you are ready to begin your workout.
To stop or pause the timer, press and release the timer button. This freezes the workout
time. To resume your workout without losing the time displayed before stopping or
pausing, press and release the button again.
When you complete your workout, press and release the timer button. The timer will
automatically turn off after being in stop or pause mode for 4 minutes.
NOTE: Even after the timer automatically turns off, the time that was displayed prior to
shutoffwillremaininmemory.To resumeyour workout withoutlosingthetimedisplayed
before stopping, press and release the timer button. To clear the time and start a new
workout, start again at step 1.
TIMER Function:
BATTERY:
The electronic timer displays minutes and
seconds up to 99.59.
1.
2.
3.
4.
The electronic timer operates with a 3v CR2032 mercury battery. Replace the
battery when you see inconsistencies in the display.
MAINTENANCE
The safety and integrity designed into the inSTRIDE CYCLE XL can only be maintained
when the inSTRIDE CYCLE XL is regularly examined for damage and wear. Special
attention should be given to the following:
1.
2.
3.
4.
Alightoil isapplied tothe pedalsofyour inSTRIDE CYCLE XL beforeshipping.Reapply
oil if the pedals begin squeaking.
Verify that all nuts and bolts are properly tightened.
Use only Stamina Products components for maintenance and repair. For replacement
parts, contact us at [e-mail] or call 1-800-375-7520.
Keep your inSTRIDE CYCLE XL clean by wiping with an absorbent cloth after use.
To increase the intensity of your workout, turn the T KNOB(14) clockwise. To decrease
the resistance, turn the T KNOB(14) counterclockwise.

Product Parts Drawing and Parts List
FRONT
BACK
1
2
3
4
5
6
7
8
9
11
12
Part No. and Description Qty Part No. and Description Qty
13
14
15
16
17
18
19
20
21
22
23
4
Main Frame 1
Stabilizer 2
Stand Cap (50.8mm) 4
Crank 1
Bottom Brake Block 1
Top Brake Block 1
Press Plate 1
Hub Cap 2
Nylon Washer (M12) 2
Pedal 2
Pedal Strap 2
Push Nut (1/2") 2
T Knob 1
Screw, Round Head (M4 x 12mm) 8
Bolt, Button Head (M8 x 1.25 x 12mm) 6
Arc Washer (M8) 6
Timer 1
Allen Wrench (6mm) 1
Owner's Manual 1
Workout Manual 1
E Clip (1/2") 2
Caution Decal 2
Products shipped to the manufacturer must be in the original shipping carton with freight
prepaid. All expenses for repairing or replacing the product, including the cost of shipping
it back to the original purchaser, will be covered by the manufacturer. This warranty gives
you specific legal rights, and you may have other rights which vary from state to state.
If the product should, for any reason, become defective within 90 days of purchase, the
manufacturerwillreplace theproductonce it isreturnedto themanufacturer. This warranty
does not apply to any damage caused by accident, return transit, alteration, abuse, or
misuse. There are no other warranties other than those expressly set forth herein.
This product is warranted to be free from defects in material and workmanship and to be in
perfect working order at the time of purchase. This warranty applies to personal, family or
household use. This warranty does not apply to use in athletic clubs, health clubs, spas,
gymnasiums, exercise facilities, and other public or semipublic facilities.
LIMITED WARRANTY
