Stamina GYROTRONIC Transformer 2000 User manual

This Product is Produced Exclusively by
2040 N. Alliance, Springfield, MO 65803
Customer Service Number
1 [phone]
www.staminaproducts.com
& Logo and are trademarks of Gyrotonic Sales Corporation.
2003, 03
Owner's Manual
! WARNING !
Exercisecanpresentahealth
risk. Consult a physician
beforebeginninganyexercise
program with this equipment.
If you feel faint or dizzy,
immediately discontinue use
of this equipment. Serious
bodily injury can occur if this
equipment is not assembled
and used correctly. Serious
bodily injury can also occur if
all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
tightened prior to each use.
Followallsafety instructionsin
this manual.
When calling for parts or
service, please specify the
following number.
55-6200
PATENT NO. 4,850,586
OTHER PATENTS PENDING
MADE IN TAIWAN
CAUTION:
Weight on this product should not exceed 300 lbs.
Product May Vary Slightly
From Pictured.

TABLE OF CONTENTS
2
Warm-up and Cool-Down 12
Warranty 13
Product Parts Drawing 14
Parts List 15
Notes 17
Fax/Mail Ordering Form 18
Page Page
Safety Instructions 2
Before You Begin 4
Hardware Illustrations 5
Assembly Instructions 6
Usage Information 9
Conditioning Guidelines 11
Before starting any exercise or conditioning program you should consult with your personal
physician to see if you require a complete physical exam. This is especially important if you
are over the age of 35, have never exercised before, are pregnant, or suffer from any
illness. READ AND FOLLOW THE SAFETY PRECAUTIONS. FAILURE TO FOLLOW
THESE INSTRUCTIONS CAN RESULT IN SERIOUS BODILY INJURY.
SAFETY INSTRUCTIONS
WARNING: To reduce the risk of serious injury, read the following Safety Instructions before
using the .
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
Read all warnings posted on the .
Read this Owner's Manual and follow it carefully before using the .Make sure
that it is properly assembled and tightened before use.
Do not allow children to play on the .Keep children and pets away from the
when it is in use by others. Children should only be allowed to use the product
with adult supervision.
Set up and operate the on a solid level surface. Do not position the
on loose rugs or uneven surfaces.
Inspect the for worn or loose components prior to use.
Tighten/replace any loose or worn components prior to using the .
Whenfoldingor unfoldingthe ,keep allchildrenaway fromthe
and make sure your hands are clear of any folding or pinch point.
Always make sure that the LOCKING PINS(66, 67) are fully inserted.
To prevent tipover, make sure that all four weight plates are in place before using the
.
Consult a physician prior to commencing an exercise program. If, at any time during exercise, you
feel faint, dizzy, or experience pain, stop and consult your physician.
Follow your physician's recommendations in developing your own personal fitness program.
Always choose the workout which best fits your physical strength and flexibility level. Know your
limits and train within them. Always use common sense when exercising.
Do not wear loose or dangling clothing while using the .
Be careful to maintain your balance while using, mounting, dismounting, or assembling the
,loss of balance may result in a fall and serious bodily injury.
The should not be used by persons weighing over 300 pounds.
The should be used by only one person at a time.
The is for consumer use only. It is not for use in public or semipublic facilities.
WARNING:

CALL US FIRSTCALL US FIRST
CALL US FIRSTCALL US FIRST
CALL US FIRST
THANK YOU FOR PURCHASING THE
To help you get started, we have pre-assembled most of your
at the factory with the exception
of those few parts left unassembled for shipping purposes.
Simply follow the few assembly instructions set forth in this manual.
Within a few minutes you will be getting your body into shape and on your
way to achieving a happier and healthier lifestyle.
Should you have any questions,
please call our Customer Service Department toll-free number,
1 [phone]
Monday - Friday, 8:00 A.M. - 5:00 P.M., Central Time.
3

BEFORE YOU BEGIN
THE FOLLOWING TOOLS ARE REQUIRED FOR ASSEMBLY : Phillips Screwdriver
Adjustable Wrench
Rubber Mallet
4
Thank you for choosing the .
We take great pride in producing this quality product
and hope it will provide many hours of quality
exercise to make you feel better, look better and
enjoy life to its fullest.
Yes,it'saprovenfactthataregularexerciseprogram
can improve your physical and mental health. Too
often,ourbusylifestyleslimitourtimeandopportunity
to exercise. The provides a
convenient and simple method to begin your assault
ongettingyourbodyinshapeandachievingahappier
and healthier lifestyle.
Before reading further, please review the drawing
below and familiarize yourself with the parts that are
labeled.
Read this manual carefully before using the
.
AlthoughStamina tries to manufacture itsproducts
with the finest materials and uses the highest
standards of manufacturing, occasionally a part that
does not fit, is the incorrect size, or is otherwise
inappropriate is found. Even with the highest
inspection and quality controls in place these things
will happen occasionally. Please do not return the
product. For your convenience, Stamina has a
Customer Service Department with a toll-free
number. If a part is missing, does not fit, is the
incorrect size, or is otherwise inappropriate, please
call1(800) 375-7520(in theU.S.) between8:00 A.M.
and5:00 P.M.Central Time, Mondaythrough Friday.
Our operators will be able to assist you with your
problem and the parts will be mailed directly to your
house.
Left Rotating Arm
Bench Base Base Stand
Left Base
Base Stand
Weight Plates
Upright Frame
Pulley
Pulley Frame
Hand Straps
Rope
Springs
Pulley Frame
Back
Cushion
Back Cushion
Support
Bench Leg
Right Arm Frame
Right Support Arm
Hand Grip
Handle Knob
Right
Rotating Arm
Cushion

This chart is provided to help identify some of the small parts used in the assembly of this product. This
sheet may not include all the hardware needed to assemble your product. It is intended to be used as a
guide to help simplify your assembly process.
Standard Nut
mm.
in.
INCHES
MILLIMETERS
11/2021/2 31/2 41/2 51/2 61/2
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
6 8 10 12
3/16" 5/16" 1/2"3/8"1/4"
Acorn Nut
Thin Nylock Nut Nylock Nut
Flat WasherLock Washer
Nut CapSpacer
Round Plug Square Plug
Hex Head Bolt
Length
Carriage Bolt
Socket Head Screw Button Head Screw
Round Head Screw Flat Head Screw
Place washers, the end of bolts or screws on the
circlesto checkfor thecorrect size. Usethesmall
scale to check the sizes of bolts and screws.
HARDWARE ILLUSTRATIONS
5
