Stanley 4V360H User manual

4V360H Multi - Line Laser
RedBeam:STHT77521-1, STHT77522-1, STHT77523-1
Green Beam: STHT77524-1, STHT77525-1, STHT77526-1
Please read these instructions before operating the product.
www.2helpU.com
DOC100270398
GB
NL
GR
I
FIN
HU
BG
LV
D
DK
CZ
ES
NO
SK
RO
LT
F
SE
RU
PT
PL
SI
EE
TR
HR

2
Figures
X1
1
X2
2
X1
1
X2
2
X1
1
X2
2
X3
3
1
2
3
4
5
1
Ⓐ
Ⓑ

3
>25% <25%
>4º
Blink
Ⓒ
Ⓓ
①
①
②

4
Figures
+
x4
-
5/8"-11 ①
Ⓔ
Ⓕ
②

5
Ⓖ
Ⓗ
5/8"-11

6
GB
D1
D1
2
D2
D1
D1
2
Ⓘ
P1
P3
P1
P2
P1P2
P4
P4
P1
D3P2
P3
D4
D2
P1
P3
P2
1.
4.
2.
3.
5.
D
2
P
1
P
3
P
2
P
4
Ⓙ
D1
D1
2
D1
2
5.
D1
D1
P1
D1
2
D1
2
D1
2
D1
2
P2
P1
P3
P2
P4
D1
D1
2
D1
2
P1
P3
P2
P1
1.
4.
2.
3.

7
GB
P1
P4
D2
P1
P3
P2
D1
L
2 x L
P1
P4
P3
P2
D1
L
2 x L
Ⓚ
1.
2.
3.

8
GB Contents
• User Safety
• Keypad, Modes, and LED
• Battery Safety
• Installing AA Batteries
• End of Life
• Declaration of Conformity
• Ease of Use
• Accuracy Check and Calibration
• Using Laser Accessories
• Maintenance and Care
• Warranty
• Specications
User Safety
The denitions below describe the level of severity for
each signal word. Please read the manual and pay
attention to these symbols.
DANGER: Indicates an imminently
hazardous situation which, if not avoided, will
result in death or serious injury.
 WARNING: Indicates a potentially
hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION: Indicates a potentially hazardous
situation which, if not avoided, may result in
minor or moderate injury.
NOTICE:Indicates a practice not related to personal
injury which, if not avoided, may result in property
damage.
If you have any questions or comments about this
or any Stanley tool, go to http://www.2helpU.com.
WARNING:
Read and understand all instructions.
Failure to follow the warnings and instructions
in this manual may result in serious personal
injury.
SAVE THESE INSTRUCTIONS
WARNING:
The following labels are placed on the laser
tool to inform you of the laser class for your
convenience and safety.
Made in China
www.STANLEYTOOLS.com
www.stanleylasers.com
STHT77521-1 / STHT77522-1
STHT77523-1
Made in China
www.STANLEYTOOLS.com
www.stanleylasers.com
STHT77524-1 / STHT77525-1
STHT77526-1
WARNING: To reduce the risk of
injury, user must read instruction
manual.
WARNING: LASER RADIATION. DO
NOT STARE INTO BEAM. Class 2
Laser Product.
CAUTION:
While the laser tool is in operation, be careful
not to expose your eyes to the emitting laser
beam.
CAUTION:
Glasses are supplied in some of the laser tool
kits. These are NOT certied safety glasses.
These glasses are ONLY used to enhance the
visibility of the beam in brighter environments
or at greater distances from laser source.
WARNING:
Laser Radiation Exposure. Do not disassemble
or modify the laser level. There are no user
serviceable parts inside. Serious eye injury
could result.
• Do not operate the laser in explosive
atmospheres, such as in the presence of
ammable liquids, gases, or dust. This tool may
create sparks which may ignite the dust or fumes.
• Do not use optical tools such as a telescope or
transit to view the laser beam. Serious eye injury
could result.

9
GB
• Do not place the laser in a position which may
cause anyone to intentionally or unintentionally
stare into the laser beam. Serious eye injury
could result.
• Do not position the laser near a reective
surface which may reect the laser beam toward
anyone’s eyes. Serious eye injury could result.
• Store an idle laser out of reach of children and
other untrained persons. Lasers are dangerous in
the hands of untrained users.
• Turn the laser off when it is not in use. Leaving
the laser on increases the risk of staring into the
laser beam.
• Do not modify the laser in any way. Modifying
the tool may result in hazardous laser radiation
exposure.
• Do not operate the laser around children or
allow children to operate the laser. Serious eye
injury may result.
• Do not remove or deface warning labels. If labels
are removed, the user or others may inadvertently
expose themselves to radiation.
• Position the laser securely on a level surface. If
the laser falls, damage to the laser or serious injury
could result.
Personal Safety
• Stay alert, watch what you are doing, and use
common sense when operating the laser. Do not
use the laser when you are tired or under the
inuence of drugs, alcohol, or medication. A moment
of inattention while operating the laser may result in
serious personal injury.
• Use personal protective equipment. Always wear
eye protection. Depending on the work conditions,
wearing protective equipment such as a dust
mask, non-skid safety shoes, hard hat, and hearing
protection will reduce personal injury.
Tool Use and Care
• Do not use the laser if the Power button does
not turn the laser on or off. Any tool that cannot be
controlled with the switch is dangerous and must
be repaired.
• Follow instructions in the Maintenance and Care
section of this manual. Use of unauthorised parts or
failure to follow Maintenance and Care instructions
may create a risk of electric shock or injury.
Keypad, Modes, and LED
Keypad and Laser Modes (Figure Ⓒ)
Power ON / OFF key
Pendulum Lock Switch (Figure Ⓓ)
Pendulum lock off / Self-leveling on
Pendulum lock on / Self-leveling off
ALWAYS slide the pendulum lock switch to the
LOCKED position when the laser is not in use.
(Figure Ⓓ①)
Modes
Laser Beam Available Modes.
• See Figures Ⓑ and Ⓒ for beam conguration.
Self-Leveling
• The pendulum lock on the laser tool needs to be
switched to the UNLOCKED position to enable
self‑leveling when placed in a position < 4°.
Out of Level
• If the laser has been tilted > 4° then it cannot
self‑level and the laser beam will ash.
Keypad - Pulse Mode (Figure Ⓒ②)
Pulse mode ON / OFF key
Press to activate Pulse mode, LED on.
Press again, Pulse mode off, LED off.

10
GB Keypad - Battery LED (Figure Ⓒ①)
Battery level indicator LED.
LED ON-CONTINUOUS RED
Battery Life > 25%
LED ON-FLASHING RED
Battery Life < 25%
Battery Safety
Always insert batteries correctly with
regard to polarity (+ and –), as marked on
the battery and the equipment. Do not mix
old and new batteries. Replace all batteries
at the same time with new batteries of the
same brand and type.
WARNING:
Batteries can explode, or leak, and can
cause injury or re.To reduce this risk:
• Carefully follow all instructions and warnings on the
battery label and package.
• Do not mix battery chemistries.
• Do not dispose of batteries in re.
• Keep batteries out of reach of children.
• Remove batteries if the device will not be used for
several months.
• Do not short battery terminals.
• Do not charge disposable batteries.
• Remove dead batteries immediately and dispose of
per local codes.
Installing AA Batteries
Battery Installation/Removal FigureⒺ
Laser Tool
• Open battery compartment cover by pressing and
sliding out.
• Install / Remove batteries. Orient batteries correctly
when placing into laser tool (Figure Ⓔ).
• Close and lock battery compartment cover by
sliding in until securely closed.
End of Life
DO NOT dispose of this product with household waste.
ALWAYS dispose of batteries per local code.
PLEASE RECYCLE in line with local provisions for
the collection and disposal of electrical and electronic
waste under the WEEE Directive.
Declaration of Conformity
Stanley Tools declares that the CE Mark has been
applied to this product in accordance with the CE
Marking Directive 93/68/EEC.
This product conforms with IEC/EN60825‑1:2014.
Ease of Use
Level / Point Transfer
• Using the horizontal laser beam, establish a
horizontal reference plane.
• Position the desired object(s) until they are aligned
with the horizontal reference plane to ensure
object(s) are level.
Square
• Using either of the vertical laser beams that cross
the horizontal laser beams, establish a point where
the 2 beams cross.
• Position the desired object(s) until they are aligned
with both the vertical and horizontal laser beams to
ensure object(s) are square.
Pulse Mode (Figure Ⓒ②)
• Setting laser tool to pulse mode allows use with
optional laser detectors.
