Stannah MIDILIFT CL Instruction Manual

MIDILIFT CL/CLS
USER HANDBOOK
IMPORTANT
Before using your Stannah Midilift CL/CLS platform lift, please
ensure that you read and familiarise yourself with these
instructions.

2
Introduction 3
Safety Instructions 6
Midilift CL/CLS Platform lift 8
Lift Operation 10
Lift Features 13
Emergency Procedure 15
Lift Care 16
CONTENTS

3
Important —please read
Thank you and congratulations on purchasing a Stannah Midilift platform lift.
Before using your lift, you should read this User Handbook to provide an understanding of
the correct and safe use of the lift.
Your platform lift has been installed and UKCA marked in compliance with the Supply of
Machinery (Safety) Regulations 2008 (2008 No. 1597) and complies to the relevant parts
of Lift Standard EN81-41: 2010.
It is important that you arrange for the lift to receive regular inspection and servicing by a
competent person at intervals of at least every six months, after the guarantee period. A
Service Log Card supplied with the lift will be completed after each service visit. Failure to
ensure servicing is carried out could lead to unreliable or unsafe operation.
For all enquiries regarding servicing, please contact your local Stannah Service Branch.
INTRODUCTION
For your records:

4
INTRODUCTION
LIFT SAFETY—YOUR RESPONSIBILITIES
Am I legally obliged to have my lift maintained?
Yes. The general duties imposed by The Health and Safety at Work etc Act 1974 supported
by Provision and Use of Work Equipment Regulations 1998 (PUWER) regulations 5 & 10
mean that you are obliged to keep your lift in safe working order. This means you must
arrange for regular maintenance of your lift.
Am I legally obliged to have my lift Thoroughly Examined?
Yes. Regulation 9 of the Lifting Operations and Lifting Equipment Regulations 1998
(LOLER) requires that a lift undergoes an inspection/thorough examination by a competent
person at regular intervals (twice a year for passenger lifts, once for goods lifts or
according to the lifts’ situation) and applies to all lifts and lifting equipment used at work.
I have a lift in my building. What do I need to do?
You should arrange for the lift to be maintained (regularly serviced and kept in good
repair) and, if the lift is in a place of work, thoroughly examined at intervals in line with
legislation.
What is the difference between ‘Maintenance’ and ‘Thorough Examination’?
Maintenance is the regular servicing of the lift, encompassing the routine adjustment to
components, replacement of worn or damaged parts, topping up of fluids and so on, and
should be carried out by an experienced and competent lift company, such as Stannah Lift
Services Ltd. Maintenance is carried out to ensure the lift runs efficiently and safely.
Thorough Examination is the systematic and detailed visual inspection of the lift and all its
associated equipment and would usually be carried out by a third party, or an appointed
‘competent person’. Thorough Examination provides a good check that maintenance is
being carried out properly. It focuses entirely on the safety of the equipment.
Authoritative guidance on Thorough Examination as required by Lifting Operations and
Lifting Equipment Regulations 1998 (LOLER) can be found in The Guidelines for
Supplementary Testing of In-Service Lifts published by SAFed. Thorough Examination may
also be referred to as Form 54 or F54 inspection –the code given to the form prescribed
by repealed Factories Acts. Although no longer prescribed, the term remains in use. Other
common terms used are: periodic inspection, statutory inspection (because it is required by
law) or insurance inspection (inspections were often on behalf of insurance companies).
Do I have a responsibility for trapped passengers?
Advice on this can be sought from your local Stannah Service Branch.

5
PRODUCT LIFE EXPECTANCY
Product life expectancy depends largely on the environment, usage and the undertaking of
proper scheduled maintenance. Our platform lift products are designed and life tested for
a full life cycle of 10 years without major intervention. In most cases, we would expect our
lifts to last far beyond this, providing they are properly cared for and maintained.
We have a number of platform lifts on our service portfolio that were installed from the late
1990s. The earliest of the platform lifts we’ve installed are approaching 20 years in service.
Actual life expectancy of a lift depends on a number of factors, including:
• The load the lift actually carries on each journey
• The actual lift travel, as this determines the journey time and hence wear on the drive
system
• The number of floors served by the lift
• The level of usage of the lift and whether this changes over time
• The environmental conditions that it operates within
• The quality of the servicing and maintenance
We ensure that spare components are available for at least 10 years following the
installation of any lift but many will be available far beyond this. There are a number of
component parts that may require replacement during its life cycle and you will be advised
of this as part of your lift servicing schedule.
INTRODUCTION

6
SAFETY INSTRUCTIONS
• The lift must not be overloaded. The maximum rated load is displayed in the cabin, on
the operating panel.
• A Midilift may be used for the occasional transportation of light goods e.g. stationery,
luggage etc., subject to lift/building owner carrying out a risk assessment.
• Like all vertical platform lifts, the Midilift is not designed to move large numbers of
people quickly and frequently. The maximum recommended usage, or duty rating, for
the Midilift is:
Midilift CL 385kg 30 starts per hour
315kg 35 starts per hour
250kg 40 starts per hour
Midlift CLS 400kg 30 starts per hour
325kg 35 starts per hour
250kg 40 starts per hour
• The emission sound pressure level of lift users is not expected to exceed 63dB(A).
• Children should not be allowed to tamper or play with the lift.
• The lift shall not be used for fire fighting or evacuation during fire.
• Check that the doors are free from obstruction when opening.
• If the cabin does not have cabin doors they will be replaced by photoelectric barriers
covering the entire surface of the door. The barriers will stop the movement of the
platform if they detect any object that crosses it. If the obstacle is cleared, it’s necessary
to press and hold the required floor button again on the lift cabin for the cabin to
move.
• DO NOT SMOKE inside the cabin.
• A ‘Lock Release’ key will have been left by our installers, it is for use by trained lift
engineers only—do not attempt to use it yourself.
• Daily checks should be carried out by a person who is competent to do so to ensure
that:
• landing doors cannot be opened when the platform is not at the same level and
• the platform cannot travel without the doors closed and locked.
• If the lift is unused for an extended period of time it should be switched off when
positioned at the lower level. Ensure that all doors are securely locked.
• You should not attempt to dismantle or remove any parts of the platform lift. Such work
should be entrusted only to competent personnel with the relevant expert knowledge
and training.

7
THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK

8
MIDILIFT CL PLATFORM LIF T
The Midilift CL is a platform lift with a full height
cabin and hinged door. It can be in a structure or
wall-mounted.
A Midilift CL platform lift is intended primarily for
the transportation of people.
It has a hydraulic drive with a separate cabinet.
• Rated load: from 250 kg to 385 kg.
• If the rated load is exceeded in the cabin, the
equipment has a pressure switch that will
prevent the movement of the lift.
• The transmission ratio is 2:1 with pulley and
cables to transmit the movement of the piston
to the cabin.
• The lift has a backpack chassis that supports
the cabin.
• The chassis and therefore the cabin are moved
by two vertical guides in the form of a "T".
• The cabin can have cabin bus doors or
electronic safety barriers.
• The cabin roof is practicable and can be used
for the maintenance of the final stop (only by
qualified lift personnel).
• Nominal speed: 0.15 m/s.

9
MID ILIFT CLS PLATFORM LIFT
The Midilift CLS is a platform lift with a fully en-
closed cabin and sliding car & landing door. It
can be in a structure or wall-mounted.
A Midilift CLS platform lift is intended primarily for
the transportation of people.
It has a hydraulic drive with a separate cabinet.
• Rated load: from 250 kg to 400 kg.
• If the rated load is exceeded in the cabin, the
equipment has a pressure switch that will
prevent the movement of the installation.
• The transmission ratio is 2:1 with pulley and
cables to transmit the movement of the piston
to the cabin.
• The lift has a backpack chassis that supports
the cabin.
• The chassis and therefore the cabin are moved
by two vertical guides in the form of a "T".
• The cabin and landing have automatic sliding
doors.
• The cabin roof is practicable and can be used
for the maintenance of the final stop (only by
qualified lift personnel).
• Nominal speed: 0.15 m/s.

10
Landing button Installed on the landing operating panel. Used to call the lift.
Car button Use to select floor of travel in the cabin. Depending on the lift
model it will either have automatic one touch control or con-
stant pressure operation (see model variations on pg. 8 & 9).
• For automatic one touch control - press once for operation
• For constant pressure (hold to run) - press and hold for
operation. If the user stops pressing the button the lift will
stop until re-pressed.
Car alarm
button (yellow)
In the event of emergency or difficulty, help can be alerted by
continuously pressing the yellow alarm button.
Emergency
STOP button
(red)
Press to STOP the lift in emergencies
Once activated the lift will not receive any calls, from either
car or landing buttons. To deactivate the emergency stop
button, turn it by following the arrows marked on the button.
Car keyswitch FOR USE BY AUTHORISED PERSONNEL ONLY
LIF T OPERATION
LIFT OPERATION USE AT-A-GLANCE
KEYSWITCH OPERATION (OPTION)
Isolating the whole lift
If fitted, a keyswitch can be used to isolate the lift. By turning the
keyswitch to the ‘Off’ position the whole lift can be isolated to stop it
being used.
Isolating at the landing level
If the keyswitch has an ‘Off’ position then this can be used to only isolate the button
at that landing. This option means that the lift can be only be accessed by those with
the key.
Resuming normal lift operation
Turn the keyswitch to ‘On’ to enable use of the lift again and allow five seconds for
the lift to reset.

11
LIF T OPERATION
SAFE LOADING AND UNLOADING
When entering or exiting the cabin users must pay attention to avoid snagging clothes,
jewellery, bags, packages etc with landing doors. Users should not stop on the entrance
door threshold.
SAFE LANDING ACCESS
Access to the cabin entrance must be kept clear at all times. Avoid placing obstacles such
as dangerous steps or objects at the landing entrance as their presence can cause risks to
users.
LIFT OPERATION FROM THE LANDING
• Press the landing button (typically located in the frame of the door). Users only
need to press the button once to call the lift car.
• As the button is pressed, the light around it will illuminate acknowledging its
activation.
• The doors will open either automatically or manually (depending on model)
when the lift car is located on the floor level where the user is located
For CL models, please note:
• If the lift is at the same level, the door will unlock allowing the user to manually
open the door and enter the lift car.
• If the lift is at a different level, the button will remain illuminated and the lift will be
called to the landing that the button is pressed.
• When the platform arrives, the door will unlock allowing the user to manually open the
door and enter the lift.
Please note the faceplates may differ slightly from the picture.
LIFT OPERATION FROM THE CABIN (CL MODEL)
• When the lift door is closed and locked, the lift is ready to move.
• Standing in front of the car operating panel, press the button for the level that you wish
to travel to.
• The button will illuminate.
• During lift travel, be aware of moving parts around you and ensure that any loose items
and passengers are away from any open sides of the lift cabin.
• Upon reaching the destination floor, the door will unlock for five seconds giving the
opportunity to exit the lift.
• If the door should lock again simply press the floor button relating to the floor you are
at and it will unlock again.

12
LIF T OPERATION
LIFT OPERATION FROM THE CABIN (CLS MODEL)
• When the lift door is closed and locked, the lift is ready to move.
• Operate the button of the level that you wish to travel to.
• The call button will remain illuminated.
• Be aware of moving parts around you and ensure that any loose items and passengers
are away from the cabin doors.
• Once the lift arrives at the required destination the doors will automatically open.
EMERGENCY LIFT ALARM
In the event of experiencing difficulty in the lift, help can be alerted by continuously
pressing the yellow alarm button. This action will ring the intercom handset elsewhere
in the building, when answered, two-way communication is possible and the button
can be released. **
** Intercom is the standard communication supplied with the lift. In some situations an
automatic dialling system may be in place. If so, instructions are provided on the console
and over the speaker. The system will dial predetermined phone numbers to put you in
contact with someone able to assist trapped passengers.
IN THE EVENT OF POWER LOSS TO THE LIFT
During power loss the lift will revert to a battery back up supply fitted on the lift. This battery
will maintain the power to the emergency lighting, buttons, digital display and door
locking. If fully charged it will do this for one hour.
During power loss the lift can only travel in the down direction.
In the event of power failure during use:
• Place a call to the lowest landing.
• The door will unlock and the user can exit the lift.
• Turn the landing keyswitch to the ‘Off’ position until power is reinstated.

13
The following provides an overview of the features on your cabin platform lift.
AUTOMATIC DOORS (CLS MODEL)
On the first operation, i.e. after lift power on, the automatic door will open and close very
slowly. This function allows the system to learn its surroundings and calibrate its stopping
positions. Following this automatic calibration the door will open and close at normal speed.
If the door meets any obstruction during subsequent operations the door will stop, reclose
and open at the slow speed.
Door open and unlocking times can be adjusted if required. Please speak to your lift
engineer if the doors require adjustment.
COMMUNICATION DEVICES
INTERCOM - The intercom is supplied on the standard product and allows the user to
connect with someone within the building in the event of an emergency. The alarm button
on the lift console ‘rings’ the handset that is placed in a suitable location in the building.
Once the handset receiver is picked up, and a 2 way conversation can take place.
AUTODIALLER (OPTION) - When the alarm is pressed the autodialler will automatically
phone out to the programmed emergency numbers. The autodialler is situated on the
control panel. If requested, the autodialler can be installed with an induction loop for the
hard of hearing. Phone number changes have to be performed by a lift engineer.
TELEPHONE (OPTION) - A dedicated phone line will be situated on the cabin control panel,
enabling the user to phone out in an emergency.
Note: With all communication systems it remains the responsibility of the building owner to
ensure effective measures are in place to deal with the possible outcome of users being
trapped inside the lift. i.e. Who could be using the lift? Could it be out of normal hours? Are
the systems regularly tested? Etc...
DIGITAL DISPLAY OPERATION (OPTION)
The digital display will visually indicate lift operation, floor numbers and arrows to the user.
In the unlikely event of the lift obtaining a fault, the display may be used to present fault
codes to aid fault finding for the engineer. If these are observed please make a note of them
to communicate to the engineer upon arrival.
FIRE ALARM SHUT DOWN
Some buildings have a lift interface for the fire alarm system. When activated, the lift will
automatically travel to the lower/designated floor should a fire alarm occur, all calls will be
disabled and the car door open button will still operate allowing users to exit the lift.
LIF T FEAT URES

14
OVERLOAD CONDITION
The lift will have a maximum load rating stated. If the load limit is exceeded, the alarm
buzzer and light signal is activated. The lift remains stationary as long as the buzzer
remains active. Once the excess load is eliminated, the cabin will be operational again.
ROOF FAN (OPTION)
Where required, a fan can be can be fitted into the roof, drawing in fresh air to increase
circulation in hot climates.
SAFETY EDGES (CL MODEL)
The cabin lift has safety edges fitted to protect the user from moving parts of the lift.
The protection is provided by two different methods:
Light curtain protection
This is provided by sensors fitted on the vertical plane of the lift entrances. If interrupted
during travel, the lift will stop moving until the obstruction is cleared.
Mechanical safety edge
This is provided by a metal strip at the bottom and top of the lift entrance. If depressed
during lift travel the lift will stop moving until the obstruction is cleared.
LIFT FEATURES

15
EMERGENCY PROCEDURE
EMERGENCY RELEASING PASSENGERS
The instructions for performing a rescue if a person is trapped in a cabin depend on the
situation, where either the user can rescue themself or require competent and trained
personnel to carry out the rescue.
RESCUE FROM INSIDE THE CABIN (only with the automatic rescue option)
In the case of a power outage, the cabin emergency light will switch on. The lift will detect
the power outage, enable automatic rescue, activate the emergency batteries and take the
cabin to the next lower floor, allowing the user to leave the cabin.
RESCUE FROM OUTSIDE THE CABIN
If the user is trapped inside the cabin and there is no automatic rescue option.
• If the entrapment is caused by a power outage, the emergency light button in the cabin
will turn on. The user must press the yellow alarm button to notify others of the situation
through the equipped communication device. This is so they can come to their aid and
try to operate the lift using the landing buttons. If the lift is not working, the person out-
side must contact qualified lift personnel to perform an emergency rescue.
• If fitted with an autodialler the user will raise the alarm through a phone line or
communication system (using the same yellow button) to raise the alarm.
RESCUE BY AUTHORISED PERSONNEL
If the user is trapped between two floors and rescue has not been possible from outside,
the authorised personnel must refer to the rescue instructions located in the control cabinet.
The rescue must be performed in the following steps:
• Switch OFF the lift mains electrical supply.
• The cabin must be brought to the level of the floor closest to the stopping position.
• If it’s necessary to lower the cabin, press the Emergency Button, which opens the valve
and makes it possible to lower the cabin at a very slow speed; hold it down until the
door zone LED lights up.
• If it’s necessary to raise the cabin, operate the pump by hand until the door zone LED
lights up.
• Use the triangle key to open the door that matches the position of the cabin.
• Be aware of the risk of falling through to the shaft under the cabin protection apron
when the passenger exits the cabin.
• If there is a cabin door, open manually.
• Once the process is finished, close the door again. Immediately notify the Service
Branch, leaving the main switch switched off until the appliance is operational again.
USE OF THE EMERGENCY KEY IS RESTRICTED TO COMPETENT PERSONNEL

16
LIF T CARE
The following lift care procedures carried out regularly will help to keep your lift in good
condition:
• Paint finishes and panels should be cleaned with a damp soft cloth and mild detergent.
Ensure that excess water is squeezed out prior to cleaning. Pressure washers should not
to be used.
• Vinyl skin plate and laminate boards should be cleaned with a soft cloth using a
furniture polish aerosol.
• Stainless steel components should be cleaned with a soft cloth, using baby oil or a
propriety stainless steel cleaner and then wiped off with a dry, lint-free cloth.
• Mirrors should be cleaned with a soft cloth and any glass cleaning fluid.
• Flooring should be cleaned with a damp cloth and mild detergent. Ensure that excess
water is squeezed out prior to cleaning.
• Never leave objects resting against the doors, door frames or car finishes.
• For outdoor installations and coastal high saline environments, the servicing frequency
remains the same. However additional monthly routine care must be introduced, this
can be undertaken by either the lift owner, or service company, and includes:
- Completing one full cycle of the lift operation.
- Cleaning of paint work with a damp soft cloth and mild detergent.
- Removal of any debris or leaves in the lift car, structure or surrounding enclosure.
- Inspection and reporting of any vandalism or misuse which has resulted in damage
to the protective surface.

17
NOTE S

18
NOTE S

19
Our Guarantee
Stannah Lifts Ltd is pleased to guarantee our materials and workmanship, and provide a
maintenance and breakdown service, supplied by our sister company Stannah Lift
Services, for a period of 24 months from installation completion and handover of the
lift, as follows:
• We’ll provide regular planned maintenance visits at the frequency agreed in the
contract, subject to suitable access to the lift within normal working hours.
• We’ll provide a full breakdown service within normal working hours, unless caused by
misuse, abuse, accidental damage or other matters outside of our control, in which
case it will be chargeable. Normal working hours are Monday to Thursday 8.00am to
4.45pm, Friday 8.00am to 3.45pm. Evening and weekend breakdowns will be
charged at a premium rate, unless included in the service contract.
• Should any defect in workmanship or material become evident within such period or
in any part delivered under this contract, we undertake to repair or replace the
defective part, as soon as possible during normal working hours.
• Our guarantee doesn’t cover repairs, replacements or adjustment which may be
required as a result of ordinary wear and tear, wilful or accidental damage, misuse,
neglect or any other cause beyond our control.
• Lifting platforms must be regularly serviced by a technically competent Lift Engineer.
For the external option, we require that at least four service visits are carried out at
regular intervals annually to preserve the warranty. Claims cannot be accepted for
corrosion that occurs as a result of misuse, neglect, unauthorised alterations or
improperly repaired paintwork.
• The contact details of your nearest Service Branch is on the ‘Completion Notice’ and
a full list of service branches is on our website www.stannahlifts.co.uk.
The guarantee is subject to the following conditions:
• The lift has been formally handed over and the ‘Completion Notice’ is signed.
• All outstanding monies have been paid to us.
• No other lift company has worked on the lift, e.g. carrying out a maintenance visit,
attending a breakdown or attempting a repair.
• Stannah isn’t prevented from carrying out planned maintenance for any reason
outside of our control, including but not limited to, the safety of our employees
engaged in activities under this warranty.
• The lift well and machine room / space must be accessible, free from damp, properly
ventilated and maintained.
Stannah reserve the right to change the terms of any warranty provided subject to any
such change being notified to the beneficiary in writing.
WAR RANTY GUAR ANTEE

www.stannahlifts.co.uk
NOTE
Whilst every effort has been used to ensure the clarity and
accuracy of this Handbook, we cannot be held responsible
for damage or injury resulting from negligence or misuse of
this lift equipment.
We are continually developing and improving the Midilift range and we therefore reserve the
right to alter or amend the specification without prior notice.
Stannah Lifts Ltd
Telephone: [phone]
Email: [email protected]
Midilift CL/CLS UM—Jul23
