Star Micronics SP2000 Manual

Replacing the interface board
The interface board is an option for the printer SP2000 series.
When replacing the interface board, please use the following procedure.
Interface Board Applicable printer
IFBD-VD02...............RS-232C SP2000 Series
IFBD-VC02 ...............Parallel
Replacement
1. Make sure that the power cord is unplugged.
2. Remove the 2 screws.
3. Remove the interface board unit in the direction of the arrow.
4. When the new board is serial interface board unit, change the setting
of the DIP Switches if necessay, referring to the user's manual of the
printer.
5. Slide the new interface board in until it is firmly seated.
Note:
Insert the interface board so that it connects with the
connector.
6. Secure the interface board using the two screws.
80871110 IFBDSP2000
Screw
