Slider20-S Hooklift
Owner’s Manual
Stellar Industries, Inc.
190 State Street
PO Box 169
Garner, IA 50438
800-321-3741
Fax: [phone]
www.stellarindustries.com
Subject to Change without Notification.
© 2021 Stellar Industries, Inc.
Rev 3
PN 89391
Installation • Assembly Drawings • Parts

Page ii | Stellar®Slider20-S Owner’s Manual
Slider Hooklift Manual Revisions
Date of Revision Section Revised Description of Revision

Stellar®Slider20-S Owner’s Manual | Page iii
Table of Contents
Introduction iv
Serial Tag Location ..................................................................................................................................................................................v
Chapter 1 - Specifications........................................................................................................................................................................... 1
Slider20-S Specifications .........................................................................................................................................................................1
Slider20-S Latch Locations for Skid Compatibility ................................................................................................................................2
Slider20-S Latch Locations for Skid Compatibility (cont.)....................................................................................................................3
Slider20-S Latch Locations for Skid Compatibility (cont.)....................................................................................................................4
Slider20-S Grease Zerk Locations ...........................................................................................................................................................4
Chapter 2 - Installation ................................................................................................................................................................................ 5
General Installation .................................................................................................................................................................................5
Installer Notice .....................................................................................................................................................................................5
Torque Data Chart...............................................................................................................................................................................6
Installation Note...................................................................................................................................................................................7
Step 1: Set the hooklift onto the truck frame. ......................................................................................................................................7
Step 2: Drill mounting holes. ...................................................................................................................................................................7
Step 3: Install bumper..............................................................................................................................................................................8
Step 4: Install tie-downs...........................................................................................................................................................................8
Step 5: Install tarper tower (If applicable). ...........................................................................................................................................8
Step 6: Install hydraulic reservoir and valve bank. ..............................................................................................................................8
Reservoir Assembly (2 Section Cable Controls) - PN 94582 ............................................................................................................9
Reservoir Assembly (3 Section Cable Controls) - PN 94606 ..........................................................................................................10
Reservoir Assembly (2 Sectoin Air Controls) - PN 94583.................................................................................................................11
Reservoir Assembly (3 Sectoin Air Controls) - PN 94607.................................................................................................................12
Reservoir Subassembly - PN 86006...................................................................................................................................................13
Valve Bank Parts Drawing.................................................................................................................................................................14
Step 7: Install PTO and pump. ..............................................................................................................................................................15
Face Seal/O-Ring Size Chart................................................................................................................................................................16
Step 8: Route hydraulic hoses..............................................................................................................................................................16
Hose Kit - PN 94576 (Fixed Hook Height Models)............................................................................................................................17
Hose Kit - PN 94575 (Adjustable Hook Height Models)..................................................................................................................18
Power Beyond VDM8 Valve .............................................................................................................................................................19
Step 9: Route Electrical Components.................................................................................................................................................20
Step 10: Install cab and PTO controls..................................................................................................................................................21
Cable Controls...................................................................................................................................................................................21
Air Controls .........................................................................................................................................................................................22
Step 11: Install Hoist Up Light Sensor - PN 83115 .................................................................................................................................23
Step 12: Install mud flaps and fenders. ...............................................................................................................................................23
Step 13A: Apply Hooklift Assembly Decals .........................................................................................................................................24
Step 13B: Apply Chassis Decals ...........................................................................................................................................................25
Step 14: Fill reservoir and activate hydraulic flow. ............................................................................................................................26
Step 15: Operate hooklift. ....................................................................................................................................................................26
Set System Relief Pressure .................................................................................................................................................................26
Chapter 3 - Assembly Drawings ............................................................................................................................................................... 27
Base Assembly - PN 94574 ....................................................................................................................................................................27
Plunger Valve Assembly - PN 86130.....................................................................................................................................................27
Dump Assembly - PN 89235..................................................................................................................................................................29
Outside Latch Assembly - PN 55358 (Optional) .................................................................................................................................30
Inside Latch Assembly - PN 88041 (Optional).....................................................................................................................................31
Secondary & Dump Latch Assembly - PN 94610 ...............................................................................................................................32
Secondary & Dump Latch BOM - PN 94610.......................................................................................................................................33
Main Cylinder Assembly - PN 66826 ....................................................................................................................................................34
Jib Assembly (35.63” Hook Height) - PN 94628...................................................................................................................................35
Jib Assembly (54” Hook Height) - PN 94629........................................................................................................................................36
Jib Assembly (35.63/54” Hook Height) - PN 94630 .............................................................................................................................37
Hose Track - PN 89324 ...........................................................................................................................................................................39
Extension Cylinder Assembly - PN 94627.............................................................................................................................................40
Tilt Cylinder Assembly - PN 54529.........................................................................................................................................................40
Toolbox Assembly - PN 8480 .................................................................................................................................................................41
Toolbox Assembly - PN 10401 ...............................................................................................................................................................41
Toolbox Assembly - PN 10402 ...............................................................................................................................................................41
Optional Tab Alarm Kit - PN 43120.......................................................................................................................................................42
Optional Tab Alarm (cont.) - PN 43120 ...............................................................................................................................................43
Optional Tab Alarm Wire Harness - PN 26291.....................................................................................................................................44
Optional Proximity Switch Wire Harness - PN 26416...........................................................................................................................45

Page iv | Stellar®Slider20-S Owner’s Manual
Introduction
A copy of this manual is provided with every hooklift and can be found in the hard plastic
manual case that is installed on the chassis. A copy of this manual shall remain with the
hooklift at all times.
Throughout the manual, three signal words will be used to bring attention to important
items:
A NOTICE signal word indicates a practice not related to physical injury.
A WARNING signal word indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
A DANGER signal word indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
Information contained within this manual does not cover operation, maintenance, or trou-
bleshooting. Please refer to the General Slider Hooklift Manual for details on these items.
This manual is not binding. Stellar Industries, Inc. reserves the right to change, at any time,
any or all of the items, components, and parts deemed necessary for product improve-
ment or commercial/production purposes. This right is kept with no requirement or obliga-
tion for immediate mandatory updating of this manual.
In closing:
If more information is required or technical assistance is needed, or if you feel that any part
of this manual is unclear or incorrect, please contact the Stellar Customer Service Depart-
ment by phone at 800-321-3741 or email at [email protected].
WARNING
NOTICE
DANGER
For Technical Questions, Information, Parts, or Warranty, Call Toll-Free at
800-321-3741
Hours: Monday - Friday, 8:00 a.m. - 5:00 p.m. CST
Or email at the following addresses:
Technical Questions, and Information [email protected]
Order Parts [email protected]
Warranty Information [email protected]

Stellar®Slider20-S Owner’s Manual | Page v
The serial tag should be located on the right side (passenger side) of the base assembly:
FOR SERVICE ON THIS EQUIPMENT
CONTACT:
STELLAR INDUSTRIES, INC.
190 STATESTREET, GARNER, IA 50438
641-923-3741
800-321-3741
4214
®
35234
ProudlyDesigned
andManufactured
inthe USA by
MODELNO. SERIALNO.
DATE
MADEIN THE U.S.A. BY STELLAR INDUSTRIES, INC. PNC5942
THEFOLLOWING U.S. OR FOREIGN PATENTSMAY APPLY:
U.S.PATENTS
6,749,389 6,558,104 5,427,495
5,108,247 6,065,942 5,082,417
CANADIANPATENTS
6,749,389
5,108,247
WARNING
25627 - Rev B
Moving parts can crush
and cut.
Keep hands and arms
clear when operating
equipment.
Crush Hazard
DANGER
Electrocution Hazard
Death or serious injury will result from
inadequate clearance if hooklift, load,
or vehicle becomes electrically
charged.
• Maintain safe clearance from high
voltage power sources.
• Never approach vehicle or load if
equipment is near a high voltage
power source.
55832 - RevA
Serial Tag Location
MODEL NO. SERIAL NO.
DATE
MADE IN THE U.S.A. BY STELLAR INDUSTRIES, INC.
PN C5942
®
PATENT INFORMATION
http://www.stellarindustries.com/ip

Page vi | Stellar®Slider20-S Owner’s Manual
This page intentionally left blank.

Stellar®Slider20-S Owner’s Manual | Page 1
L
K
A
G
J
EB
C
C
D
H
I
Chapter 1 - Specifications
35.63” (905mm) Fixed Hook Height 54” (1,372mm) Fixed Hook Height 35.63” (905mm) to 54” (1,372mm) Hydraulic Adjustable
Lifting Capacity 20,000 lbs (9,072 kg) 20,000 lbs (9,072 kg) 20,000 lbs (9,072 kg)
Dumping Capacity 20,000 lbs (9,072 kg) 20,000 lbs (9,072 kg) 20,000 lbs (9,072 kg)
A Dump Angle 60º 60º 60º
B Lowest Hook Height 28.5” (724 mm) 8.63” (219 mm) 8.63” or 28.5” (219 mm or 724 mm)
C Effective Length 112.50” to 142.50” (2,858 mm to 3,620
mm)
112.50” to 142.50” (2,858 mm to 3,620
mm) 112.50” to 142.50” (2,858 mm to 3,620 mm)
D Truck Frame Height 40” (1,016 mm) 40” (1,016 mm) 40” (1,016 mm)
E Hooklift Height 51.88” (1,318 mm) 51.88” (1,318 mm) 51.88” (1,318 mm)
G Hooklift Length 152.13” (3,865 mm) 152.13” (3,865 mm) 152.13” (3,865 mm)
H Hooklift Center of Gravity 70” (1,778 mm) 68” (1,727 mm) 67.75” (1,721 mm)
I Chassis Cab to Axle 108” to 120” (2,743 mm to 3,048
mm)***
108” to 120” (2,743 mm to 3,048
mm)*** 108” to 120” (2,743 mm to 3,048 mm)***
J Max. Height When Loading 129” (3,276 mm) 142.6” (3,622 mm) 129” to 142.6” (3,276 mm to 3,622 mm)
K Longest Body When Dumping 15’ 15’ 15’
L Max. Height When Dumping 196” (4,979 mm) 206.50” (5,245 mm) 196” to 206.50” (4,979 mm to 5,245 mm)
Maximum Operating Pressure 4,200 psi (29 MPa) 4,200 psi (29 MPa) 4,200 psi (29 MPa)
Hydraulic Flow 24 gpm (91 lpm) 24 gpm (91 lpm) 24 gpm (91 lpm)
Shipping Weight 2,800 lbs (1,270 kg) 2,880 lbs (1,305 kg) 2,910 lbs (1,320 kg)
Shipping Dimensions (LxWxH) 152.13” x 46” x 58” 152.13” x 46” x 76” 152.13” x 46” x (58-76”)
Minimum Truck GVWR 25,000 lbs (11,340 kg) 25,000 lbs (11,340 kg) 25,000 lbs (11,340 kg)
Load Angle w/Shortest Body Length 60º 55º 55º
Recommended Container Lengths* 10’ to 14’ (4,267 mm to 4,877 mm) 10’ to 14’ (4,267 mm to 4,877 mm) 10’ to 14’ (4,267 mm to 4,877 mm)
Recommended Flatbed Lengths** Up to 16’ (4,877 mm) Up to 16’ (4,877 mm) Up to 16’ (4,877 mm)
*Assumes 3 ft. overhang from center of
rear roller pin (Bumper typically 12” from
center of roller pin)
**Assumes 5 ft. overhang from center of
rear roller pin (May require bumper and
latch options)
***Weight Distribution Required
Slider20-S Specifications

Page 2 | Stellar®Slider20-S Owner’s Manual
Slider20-S Latch Locations for Skid Compatibility

Stellar®Slider20-S Owner’s Manual | Page 3
Slider20-S Latch Locations for Skid Compatibility (cont.)

Page 4 | Stellar®Slider20-S Owner’s Manual
Slider20-S Latch Locations for Skid Compatibility (cont.)
Slider26
QTY. (2)
QTY. (2) QTY. (2)
QTY. (1)
QTY. (2)
QTY. (2)
QTY. (2) BOTH ENDS OF
SLIDE CYLINDER
QTY. (2)
QTY. (2)
QTY. 2
Note: Grease After Every 100 Cycles.
Slider20-S Grease Zerk Locations

Stellar®Slider20-S Owner’s Manual | Page 5
Chapter 2 - Installation
Installer Notice
According to Federal Law (49 cfr part 571), each final-stage manufacturer shall complete the vehi-
cle in such a manner that it conforms to the standards in effect on the date of manufacture of the
incomplete vehicle, the date of final completion, or a date between those two dates. This require-
ment shall, however, be superseded by any conflicting provisions of a standard that applies by its
terms to vehicles manufactured in two or more stages.
Therefore, the installer of Stellar®Hooklifts is considered one of the manufacturers of the vehicle.
As such a manufacturer, the installer is responsible for compliance with all applicable federal and
state regulations. They are required to certify that the vehicle is in compliance with the Federal
Motor Vehicle Safety Standards and other regulations issued under the National Traffic and Motor
Vehicle Safety Act.
Please reference the Code of Federal Regulations, title 49 - Transportation, Volume 5 (400-999), for
further information, or visit http://www.gpoaccess.gov/nara/index.html for the full text of Code of
Federal Regulations.
General Installation
This chapter is designed to serve as a general guide for the installation of a Stellar®Slider20S
Hooklift. Each installation is considered unique so certain portions of this chapter may or
may not apply to your direct application. If a question should arise during the installation
process, please contact Stellar Customer Service at [phone].
PTO and Pump installation instructions are provided by the corresponding manufacturers.
For more information on which PTO and Pump fit your application, please contact your
local Stellar Distributor or Stellar Customer Service.
Do not install this hooklift on a chassis not capable of handling the loads
imposed on it. Failure to do so may result in serious injury or death.
Do not weld or drill holes into the side wall of the base tubes.
Hooklift Mounting and Assembly
Study names and locations of the parts and familiarize yourself with the hooklift before
starting the assembly . Reading the step-by-step instructions that follow will be helpful.
Assembly
Select an area for assembly that will be large enough to accommodate the completed
unit. The surface of the work area should be as level as possible. Use the proper hand
tools to ensure proper bolt tightness. Refer to the torque data chart in this chapter for the
recommended torque values for different sizes of bolts.
Model Number
Know the model number of the Stellar®Hooklift being mounted. Use this model number
whenever referring to the assembly or parts listing pages. The number is stamped on the
name plate which is located on the front frame member.
WARNING
NOTICE

Page 6 | Stellar®Slider20-S Owner’s Manual
When using the torque data in the
chart, the following rules should be
observed:
• Bolt manufacturer’s particular
specifications should be consulted
when provided.
• Flat washers of equal strength
must be used.
• All torque measurements are giv-
en in foot-pounds. To convert to
inch-pounds, multiply by 12.
• Torque values specified are for
bolts with residual oils or no special
lubricants applied. If special lubri-
cants of high stress ability, such as
Never-Seez compound graphite
and oil, molybdenum disulphite,
colloidal copper or white lead are applied, multiply the torque values in the charts by the
factor .90. The use of Loctite does not affect the torque values listed above.
• Torque values for socket-head capscrews are the same as for Grade 8 capscrews.
• Do not use these values if a different torque value or tightening procedure is given for
a specific application. Torque values listed are for general use only. Check tightness of
fasteners periodically.
• Sheer bolts are designed to fail under predetermined loads. Always replace shear bolts
with identical grade.
• Fasteners should be replaced with the same or higher grade. If higher grade fasteners
are used, these should only be tightened to the strength of the original.
• Tighten plastic insert or crimped steel-type lock nuts to approximately 110 percent of the
dry torque values shown in the chart below, applied to the nut, not to the bolt head.
Tighten toothed or serrated-type lock nuts to the full torque value. Note: “Lubricated”
means coated with a lubricant such as engine oil, or fasteners with phosphate and oil
coatings. “Dry” means plain or zinc plated without lubrication. Tighten lubricated bolts
to approximately 80% of dry bolts.
Size Bolt DIA Plain Plated Plain Plated Plated
(DIA-TPI) (Inches) (Ft-Lb) (Ft-Lb) (Ft-Lb) (Ft-Lb) (Ft-Lb)
5/16-18 0.3125 17 13 25 18 22
3/8-16 0.3750 31 23 44 33 39
7/16-14 0.4375 49 37 70 52 63
1/2-13 0.5000 75 57 105 80 96
9/16-12 0.5625 110 82 155 115 139
5/8-11 0.6250 150 115 220 160 192
3/4-10 0.7500 265 200 375 280 340
7/8-9 0.8750 395 295 605 455 549
1-8 1.000 590 445 910 680 823
1 1/8-7 1.1250 795 595 1290 965 1167
1 1/4-7 1.2500 1120 840 1815 1360 1646
1 3/8-6 1.3750 1470 1100 2380 1780 2158
1 1/2-6 1.500 1950 1460 3160 2370 2865
GRADE 5 GRADE 8 GRADE 9
Torque Data Chart

Stellar®Slider20-S Owner’s Manual | Page 7
• When positioning mounts to frame, tie-down castings are bolted to the underside of
each tie down plate located on the outside of the main rails of the base. The tie-down
plate closest to the front of the base requires one mount on each side of the pin. This
is the only time two tie down castings are required per a single tie-down plate. The tie-
down plates are designed with multiple slots to offer more flexibility in mounting locations.
Additional holes may not be added to the tie-down plates.
• Using the tie-down castings as a guide, drill 11/16” holes through the truck frame as
shown.
Step 2: Drill mounting holes.
• Visually inspect the truck and look for any potential issues. For example: Clearance
problems, cross members extending too high, insufficient room in front of the Slider for
tarpers, exhaust manifolds, etc., or insufficient room in the rear to allow for bumper se-
lection. Note: Stellar Industries recommends allowing 12” behind the start of clear truck
frame for installation of a tarping system.
• Be sure to square the Slider on the truck frame to allow for proper measurement. The
front of the hooklift needs to be at least 2.50” behind the cab or any equipment mount-
ed behind the cab. Note: On some Slider models, the jib may extend beyond the front
of the base.
Step 1: Set the hooklift onto the truck frame.
Every hooklift installation is unique. However, certain guidelines exist that apply to every
model. Listed below is a general set of chronological steps that may be followed when
installing a Stellar Hooklift. If any questions arise during the installation process, feel free to
contact your local dealer or Stellar Customer Service at 800-321-3741.
Installation Note
0
3.00
15.00 53.50 88.00
148.12
Note: These are approximent measurements from the front of the hooklift base. Specific applications may vary.

Page 8 | Stellar®Slider20-S Owner’s Manual
Note: See torque chart at beginning of chapter:
Step 4: Install tie-downs.
3
42
12
423
2
ITEM PART DESCRIPTION QTY.
1 D0143 TIE-DOWN CASTING 10
2
C5902 WASHER 0.63 SAE FLAT YELLOW GR8 40
3
C1025 CAP SCR 0.63-11X2.00 HHGR8 ZY 20
424868
NUT 0.63-11 HHGR8 NYLOCK ZY 20
PN 54848
• See NHTSA (National Highway
Truck Safety Administration) Regu-
lations for acceptable placement.
• Modify the truck frame as neces-
sary so that it ends 2” from the rear
of the hooklift.
Step 3: Install bumper.
2.00
• Before drilling and bolting to the frame, confirm adequate room for cable routing be-
tween in-cab controls and the valve bank. Note: The top of the reservoir should not be
above the truck frame.
Step 6: Install hydraulic reservoir and valve bank.
See brand specific installation instructions.
Step 5: Install tarper tower (If applicable).

Stellar®Slider20-S Owner’s Manual | Page 9
16
10
17
2
3
4
12
13
12
1
18
8
20
NOTE: ITEMS NOT SHOWN 25941 - DECAL LOADER VB VDM8 HOSE LOCATION X 1 42971 - DECAL OIL FILTER CHANGE X 1 35408 - PORT RELIEF VDM8 2715 PSI
ITEM
PART
DESCRIPTION
QTY
186006
RSRVR ASM 25GAL K MODEL W/ TANK
TOP FILTER
1
27353
FTG 32-32 MP-MP HEX NIPPLE STRAIGHT
1
3
C4750
VALVE BALL 2.00
1
4
C4730
FTG 32-32 MP-HB STRAIGHT
1
591222
VB 2-SECT VDM8 C4-C4-4200MRV-(2-A- 3000-B-2500)-LCHA-ZNCT
1
60521
WASHER 0.25 LOCK
3
70339
CAP SCR 0.25-20X2.50 HHGR5
3
860395
FTG 16-20 MFS-MAORB 90
1
9
C2252
FTG 8-10 MFS-MORB STRAIGHT
4
10 27119
HOSE 0.75(78C-12-JC-JC-12-12-12-120)
1
11 10094
GAUGE OIL LF 2.5" 0-5000 BM
1
12
C4819 HOSE CLAMP 2.00
2
13 17766
HOSE SUCT 2.00 10FT
1
14 25630
FTG 10-4 MORB-FP STRAIGHT
1
15
d1435
FTG 12-10 MFS-MORB STRAIGHT
1
16 c4903
FTG 12-12 MFS-FFSS 90
1
17 83959
MNT KIT RSRVR 25G
1
18 86168
HOSE 0.75(300PSI)-16FFSS SHORT-12FFSS 90 SHORT-8.50CL
1
19
C2142
FTG 12-12 MFS-MORB STRAIGHT
1
20
C6327
FILTER STRAINER 35GAL TF-2030
1
PN 94582
NOTE: INSTALL PORT RELIEF 35408 HERE
NOTE: 26183 - PORT RELIEF VDM8 3000 PSI
NOTE: 26182 - PORT RELIEF VDM8 2500 PSI
7
6
15
11
14
9
NOTE: PLUG SIDE #12 PORT
5
19
Reservoir Assembly (2 Section Cable Controls) - PN 94582

Page 10 | Stellar®Slider20-S Owner’s Manual
8
18
3
2
4
11
14
10
10
1
19
7
21
NOTE: ITEMS NOT SHOWN 25941 - DECAL LOADER VB VDM8 HOSE LOCATION X 1 42971 - DECAL OIL FILTER CHANGE X 1
35408 - PORT RELIEF VDM8 2715 PSI X 1 26182 - PORT RELIEF VDM8 2500 PSI X 2
ITEM
PART
DESCRIPTION
QTY.
186006
RSRVR ASM 25GAL K MODEL W/ TANK TOP FILTER
1
27353
FTG 32-32 MP-MP HEX NIPPLE STRAIGHT
1
3
C4750
VALVE BALL 2.00
1
4
C4730
FTG 32-32 MP-HB STRAIGHT
1
591223
VB 3-SECT VDM8 C4-C4-C4-4200MRV-(2- A-3000-B-2500)-LCHA-ZNCT
1
60521
WASHER 0.25 LOCK
3
760395
FTG 16-20 MFS-MAORB 90
1
827119
HOSE 0.75(78C-12-JC-JC-12-12-12-120)
1
910094
GAUGE OIL LF 2.5" 0-5000 BM
1
10
C4819 HOSE CLAMP 2.00
2
11 17766
HOSE SUCT 2.00 10FT
1
12 25630
FTG 10-4 MORB-FP STRAIGHT
1
13
d1435
FTG 12-10 MFS-MORB STRAIGHT
1
14 c4903
FTG 12-12 MFS-FFSS 90
1
15 0339
CAP SCR 0.25-20X2.50 HHGR5
3
16
C1855
FTG 6-10 MFS-MORB STRAIGHT
2
17
C2252
FTG 8-10 MFS-MORB STRAIGHT
4
18 83959
MNT KIT RSRVR 25G
1
19 86168
HOSE 0.75(300PSI)-16FFSS SHORT-12FFSS
90 SHORT-8.50CL
1
20
C2142
FTG 12-12 MFS-MORB STRAIGHT
1
21
C6327
FILTER STRAINER 35GAL TF-2030
1
PN 94606
NOTE: INSTALL PORT RELIEF 35408 HERE.
NOTE: INSTALL PORT RELIEF 26182 HERE.
NOTE: 26183 - PORT RELIEF VDM8 3000 PSI
NOTE: 26182 - PORT RELIEF VDM8 2500 PSI
12
9
13 17
15
6
NOTE: PLUG SIDE #12 PORT
5
20
16
Reservoir Assembly (3 Section Cable Controls) - PN 94606

Stellar®Slider20-S Owner’s Manual | Page 11
7
17
3
2
4
10
13
9
9
18
6
1
20
NOTE: ITEMS NOT SHOWN 25941 - DECAL LOADER VB VDM8 HOSE LOCATION X 1 42971 - DECAL OIL FILTER CHANGE X 1 35408 - PORT RELIEF VDM8 2715 PSI
ITEM
PART
DESCRIPTION
QTY.
186006
RSRVR ASM 25GAL K MODEL W/ TANK TOP FILTER
1
27353
FTG 32-32 MP-MP HEX NIPPLE STRAIGHT
1
3
C4750
VALVE BALL 2.00
1
4
C4730
FTG 32-32 MP-HB STRAIGHT
1
50521
WASHER 0.25 LOCK
3
660395
FTG 16-20 MFS-MAORB 90
1
727119
HOSE 0.75(78C-12-JC-JC-12-12-12-120)
1
810094
GAUGE OIL LF 2.5" 0-5000 BM
1
9
C4819 HOSE CLAMP 2.00
2
10 17766
HOSE SUCT 2.00 10FT
1
11 25630
FTG 10-4 MORB-FP STRAIGHT
1
12
d1435
FTG 12-10 MFS-MORB STRAIGHT
1
13 c4903
FTG 12-12 MFS-FFSS 90
1
14 0339
CAP SCR 0.25-20X2.50 HHGR5
3
15 91224
VB 2-SECT VDM8 PAC4-PAC4-4200MRV- (2-A-3000-B-2500)-LCHA-ZNCT
1
16
C2252
FTG 8-10 MFS-MORB STRAIGHT
4
17 83959
MNT KIT RSRVR 25G
1
18 86168
HOSE 0.75(300PSI)-16FFSS SHORT-12FFSS 90 SHORT-8.50CL
1
19
C2142
FTG 12-12 MFS-MORB STRAIGHT
1
20
C6327
FILTER STRAINER 35GAL TF-2030
1
PN 94583
NOTE: INSTALL PORT RELIEF 35408 HERE
NOTE: 26183 - PORT RELIEF VDM8 3000 PSI
NOTE: 26182 - PORT RELIEF VDM8 2500 PSI
11
8
12
14
5
NOTE: PLUG SIDE #12 PORT
15
16
19
Reservoir Assembly (2 Sectoin Air Controls) - PN 94583

Page 12 | Stellar®Slider20-S Owner’s Manual
9
18
3
2
4
12
15
11
11
7
19
1
21
NOTE: ITEMS NOT SHOWN 25941 - DECAL LOADER VB VDM8 HOSE LOCATION X 1 42971 - DECAL OIL FILTER CHANGE X 1 35408 - PORT RELIEF VDM8 2715 PSI X 1 26182 - PORT RELIEF VDM8 2500 PSI X2
ITEM
PART
DESCRIPTION
QTY.
186006
RSRVR ASM 25GAL K MODEL W/ TANK
TOP FILTER
1
27353
FTG 32-32 MP-MP HEX NIPPLE STRAIGHT
1
3
C4750
VALVE BALL 2.00
1
4
C4730
FTG 32-32 MP-HB STRAIGHT
1
591225
VB 3-SECT VDM8 PAC4-PAC4-PAC4-
4200MRV-(2-A-3000-B-2500)-LCHA-ZNCT
1
60521
WASHER 0.25 LOCK
3
760395
FTG 16-20 MFS-MAORB 90
1
8
C1855
FTG 6-10 MFS-MORB STRAIGHT
2
927119
HOSE 0.75(78C-12-JC-JC-12-12-12-120)
1
10 10094
GAUGE OIL LF 2.5" 0-5000 BM
1
11 c4819
HOSE CLAMP 2.00
2
12 17766
HOSE SUCT 2.00 10FT
1
13 25630
FTG 10-4 MORB-FP STRAIGHT
1
14
d1435
FTG 12-10 MFS-MORB STRAIGHT
1
15 c4903
FTG 12-12 MFS-FFSS 90
1
16 0339
CAP SCR 0.25-20X2.50 HHGR5
3
17
C2252
FTG 8-10 MFS-MORB STRAIGHT
4
18 83959
MNT KIT RSRVR 25G
1
19 86168
HOSE 0.75(300PSI)-16FFSS SHORT-12FFSS
90 SHORT-8.50CL
1
20
C2142
FTG 12-12 MFS-MORB STRAIGHT
1
21
C6327
FILTER STRAINER 35GAL TF-2030
1
PN 94607
NOTE: INSTALL PORT RELIEF 35408 HERE.
NOTE: INSTALL PORT RELIEF 26182 HERE.
NOTE: 26182 - PORT RELIEF VDM8 2500 PSI
NOTE: 26183 - PORT RELIEF VDM8 3000 PSI
17
14
10
13
6
16
NOTE: PLUG SIDE #12 PORT
5
20
8
Reservoir Assembly (3 Sectoin Air Controls) - PN 94607

Stellar®Slider20-S Owner’s Manual | Page 13
Reservoir Subassembly - PN 86006
9
10
7
8
6
3
2
5
1
4
11
NOTE: REPLACEMENT OIL FILTER - PN 86010
ITEM PART DESCRIPTION QTY
1 C2126 MAGNETIC PLUG DRAIN 3/4" 1
2 15463
THERMO SIGHT GAUGE ZINGA SG-O5-A-T-N 1
3 73278
CAP FILL 1PSI ZINGA THREADED 1
4 13002
DECAL HYD OIL SPECIFICATION MOBIL 1
5 86007
RSRVR 25GAL K MODEL W/ TANK TOP FILTER 1
6 66656
FILTER PIPE TANK TOP 1
7 85928
FILTER TANK TOP 20 FORB 1
8 58396
GASKET RG-11 TANK TOP FILTER 1
9 0335
CAP SCR 0.38-16X1.25 HHGR5 4
10
C6353 WASHER 0.38 SAE FLAT YELLOW GR8 4
11
C4845 PLUG 0.75 NPT SQ HD BLK 1
PN 86006
NOTE: REPLACEMENT GASKET
UNDER FILTER CAP - PN 109546

Page 14 | Stellar®Slider20-S Owner’s Manual
Valve Bank Parts Drawing
SPOOL SPRING KIT
WITH COVER PN 43776
AIR ACTUATOR
PN 26566
HANDLE ASM - OUTSIDE
CTRLS WITH HANDLE PN 30381
SPOOL RETAINER
PN 61522
MAIN RELIEF VALVE
PN 28510
HANDLE
PN 26130
SPOOL SEAL KIT
PN 29683
