stellar labs 108-11-32 User manual

108-11-32
Shuttle Hooklift
Owner’s Manual
Stellar Industries, Inc.
190 State Street
PO Box 169
Garner, IA 50438
800-321-3741
Fax: [phone]
www.stellarindustries.com
Subject to Change without Notication.
© 2018 Stellar Industries, Inc.
Rev 1
PN 92397
Installation • Assembly Drawings • Parts

Page ii | Stellar®108-11-32 Shuttle Owner’s Manual
Model 108-11-32 Manual Revisions
Date of Revsion Section Revised Description of Revision

Stellar®108-11-32 Shuttle Owner’s Manual | Page iii
Table of Contents
Introduction ............................................................................................................................................iv
Hooklift Nomenclature .......................................................................................................................... v
Serial Tag Location .................................................................................................................................vi
Chapter 1 - Specications........................................................................................................... 1
Model 108-11-32 Shuttle Specications ............................................................................................... 1
Acceptable Subframe Dimensions - Model 108-11-32 ...................................................................... 2
Chapter 2 - Installation ................................................................................................................ 3
General Installation ................................................................................................................................ 3
Installer Notice ..................................................................................................................................... 3
Torque Data Chart .............................................................................................................................. 4
Installation Note................................................................................................................................... 5
Step 1: Set the hooklift onto the truck frame. ..................................................................................... 5
Step 2: Bolt tie-down castings to mounting plates. ............................................................................ 6
Step 3: Drill mounting holes into frame rail. ......................................................................................... 7
Step 4: Bolt tie-down castings to truck frame. .................................................................................... 7
Step 5: Install bumper. ............................................................................................................................ 8
Step 6: Install tarper tower (If applicable). .......................................................................................... 8
Step 7: Install hydraulic reservoir and valve bank. ............................................................................. 8
Reservoir Assembly with Cable Controls - PN 86463 ....................................................................... 9
Reservoir Assembly with Air Controls - PN 86467 ............................................................................ 10
Valve Bank Parts Drawing ................................................................................................................... 12
Step 8: Install PTO and pump. ............................................................................................................. 13
Face Seal/O-Ring Size Chart ............................................................................................................... 14
Step 9: Route hydraulic hoses. ............................................................................................................ 14
Hose Kit - PN 44338 ............................................................................................................................ 15
Power Beyond VDM8 Valve ............................................................................................................. 16
Step 10: Route Electrical Components .............................................................................................. 17
Step 11: Install cab and PTO controls. ............................................................................................... 18
Cable Controls .................................................................................................................................. 18
Air Controls ......................................................................................................................................... 19
Step 12: Install mud aps and fenders. .............................................................................................. 20
Poly Tandem Fender Assembly - PN 58217 ..................................................................................... 20
Steel Tandem Fender Assembly - PN 46122 ................................................................................... 21
Step 13: Install Hoist Up Alarm - PN 83115 .......................................................................................... 22
Step 14: Apply Decals .......................................................................................................................... 23
Step 15: Fill reservoir and activate hydraulic ow. ........................................................................... 24
Step 16: Operate hooklift. ................................................................................................................... 24
Set System Relief Pressure ................................................................................................................. 25
Chapter 3 - Assembly Drawings ............................................................................................... 27
Base Assembly - PN 92287 ................................................................................................................... 27
Dump Assembly - PN 92333 ................................................................................................................. 28
Secondary Assembly - PN 92339 ........................................................................................................ 29
Tilt Assembly 61.75” - PN 92358 ........................................................................................................... 30
Tilt Assembly 54” - PN 92363 ................................................................................................................ 31
Main Cylinder - PN 19066 .................................................................................................................... 32
Tilt Cylinder - PN 23160 ......................................................................................................................... 33
Rotary Valve - PN 41824 ....................................................................................................................... 34

Page iv | Stellar®108-11-32 Shuttle Owner’s Manual
Introduction
A copy of this manual is provided with every hooklift and can be found in the hard plastic
manual case that is installed on the chassis. A copy of this manual shall remain with the
hooklift at all times.
Throughout the manual, three signal words will be used to bring attention to important
items:
A NOTICE signal word indicates a practice not related to physical injury.
A WARNING signal word indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
A DANGER signal word indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
Information contained within this manual does not cover operation, maintenance, or trou-
bleshooting. Please refer to the General Shuttle Hooklift Manual for details on these items.
This manual is not binding. Stellar Industries, Inc. reserves the right to change, at any time,
any or all of the items, components, and parts deemed necessary for product improve-
ment or commercial/production purposes. This right is kept with no requirement or obliga-
tion for immediate mandatory updating of this manual.
In closing:
If more information is required or technical assistance is needed, or if you feel that any part
of this manual is unclear or incorrect, please contact the Stellar Customer Service Depart-
ment by phone at 800-321-3741 or email at [email protected].
WARNING
NOTICE
DANGER
For Technical Questions, Information, Parts, or Warranty, Call Toll-Free at
800-321-3741
Hours: Monday - Friday, 8:00 a.m. - 5:00 p.m. CST
Or email at the following addresses:
Technical Questions, and Information [email protected]
Order Parts [email protected]
Warranty Information [email protected]

Stellar®108-11-32 Shuttle Owner’s Manual | Page v
Hooklift Nomenclature
The Stellar® Shuttle is a hydraulic, body-loading device when mounted on a truck chassis. It
can handle a multitude of bodies ranging from atbeds to recycling containers and dump
bodies.
The Shuttle consists of four basic parts: the base, dump, secondary, and tilt sections. Please
take the time to familiarize yourself with the various components. Knowing the proper ter-
minology is necessary to get the full benet of this manual.
HOOKLIFT
BASE
DUMP
SECONDARY
TILT

Page vi | Stellar®108-11-32 Shuttle Owner’s Manual
The serial tag should be located on the right side (passenger side) of the base assembly:
FOR SERVICE ON THIS EQUIPMENT
CONTACT:
STELLAR INDUSTRIES, INC.
190 STATESTREET, GARNER, IA 50438
641-923-3741
800-321-3741
4214
®
35234
ProudlyDesigned
andManufactured
inthe USA by
MODELNO. SERIALNO.
DATE
MADEIN THE U.S.A. BY STELLAR INDUSTRIES, INC. PNC5942
THEFOLLOWING U.S. OR FOREIGN PATENTSMAY APPLY:
U.S.PATENTS
6,749,389 6,558,104 5,427,495
5,108,247 6,065,942 5,082,417
CANADIANPATENTS
6,749,389
5,108,247
WARNING
25627 - Rev B
Moving parts can crush
and cut.
Keep hands and arms
clear when operating
equipment.
Crush Hazard
DANGER
Electrocution Hazard
Death or serious injury will result from
inadequate clearance if hooklift, load,
or vehicle becomes electrically
charged.
• Maintain safe clearance from high
voltagepower sources.
• Never approach vehicle or load if
equipmentis near a high voltage
powersource.
55832 - RevA
Serial Tag Location
MODEL NO. SERIAL NO.
DATE
MADE IN THE U.S.A. BY STELLAR INDUSTRIES, INC.
PN C5942
®
PATENT INFORMATION
http://www.stellarindustries.com/ip

Stellar®108-11-32 Shuttle Owner’s Manual | Page 1
A
G
E
I
D
H
C
L
J
D
K
Chapter 1 - Specications
Model 108-11-32 Shuttle Specications
Model 108-11-32 Shuttle
Lifting/Dumping Capacity 32,000 lbs (14,515 kg)
ADump Angle 46°
BLowest hook Height 41.75” (106 cm)
CEffective Length 125.81” (320 cm)
DTruck Frame Height 41” (104 cm)
EHooklift Height 52.31” (132.87 cm)
GHooklift Length 138.69” (353 cm)
HHooklift Center of Gravity 55.5” (141 cm)
IChassis Cab to Axle 108” to 120” (274.3 to 304.8 cm)
JMax Height When Loading 145” (369 cm)
KLongest Body to Dump 180” (457 cm)
LMax Height when Dumping 196” (498 cm)
Operating Pressure 4200 psi
Hydraulic Flow Not to exceed 24 GPM
Shipping Weight 3,160 lbs (1,434 kg)
Hook Height 61.75” (156.85 cm)
Shipping Dimensions (LxHxW) 140” x 84” x 51”
Minimum Truck GVWR 34,000
RBM 1,600,000
Load Angle w/Shortest Body Length 36°
Recommended Body Lengths* 11’ to 14’ (3.35 to 4.26 m)
Recommended Flatbed Body Lengths** to 16’ (4.87 m)
* Assumes 3ft. overhang from center of rear roller pin.
* Assumes 5ft. overhang from center of rear roller pin - May require bumper and latch options.

Page 2 | Stellar®108-11-32 Shuttle Owner’s Manual
Acceptable Subframe Dimensions - Model 108-11-32

Stellar®108-11-32 Shuttle Owner’s Manual | Page 3
Chapter 2 - Installation
Installer Notice
According to Federal Law (49 cfr part 571), each nal-stage manufacturer shall complete the vehi-
cle in such a manner that it conforms to the standards in effect on the date of manufacture of the
incomplete vehicle, the date of nal completion, or a date between those two dates. This require-
ment shall, however, be superseded by any conicting provisions of a standard that applies by its
terms to vehicles manufactured in two or more stages.
Therefore, the installer of Stellar® Hooklifts is considered one of the manufacturers of the vehicle.
As such a manufacturer, the installer is responsible for compliance with all applicable federal and
state regulations. They are required to certify that the vehicle is in compliance with the Federal
Motor Vehicle Safety Standards and other regulations issued under the National Trafc and Motor
Vehicle Safety Act.
Please reference the Code of Federal Regulations, title 49 - Transportation, Volume 5 (400-999), for
further information, or visit http://www.gpoaccess.gov/nara/index.html for the full text of Code of
Federal Regulations.
General Installation
This chapter is designed to serve as a general guide for the installation of a Stellar®Shuttle
108-14-40 Hooklift. Each installation is considered unique so certain portions of this chap-
ter may or may not apply to your direct application. If a question should arise during the
installation process, please contact Stellar Customer Service at [phone].
PTO and Pump installation instructions are provided by the corresponding manufacturers.
For more information on which PTO and Pump t your application, please contact your
local Stellar Distributor or Stellar Customer Service.
Do not install this hooklift on a chassis not capable of handling the loads
imposed on it. Failure to do so may result in serious injury or death.
Do not weld or drill holes into the side wall of the base tubes.
Hooklift Mounting and Assembly
Study names and locations of the parts and familiarize yourself with the hooklift before
starting the assembly . Reading the step-by-step instructions that follow will be helpful.
Assembly
Select an area for assembly that will be large enough to accommodate the completed
unit. The surface of the work area should be as level as possible. Use the proper hand
tools to ensure proper bolt tightness. Refer to the torque data chart in this chapter for the
recommended torque values for different sizes of bolts.
Model Number
Know the model number of the Stellar® Hooklift being mounted. Use this model number
whenever referring to the assembly or parts listing pages. The number is stamped on the
name plate which is located on the front frame member.
WARNING
NOTICE

Page 4 | Stellar®108-11-32 Shuttle Owner’s Manual
When using the torque data in the
chart, the following rules should be
observed:
• Bolt manufacturer’s particular
specications should be consulted
when provided.
• Flat washers of equal strength
must be used.
• All torque measurements are giv-
en in foot-pounds. To convert to
inch-pounds, multiply by 12.
• Torque values specied are for
bolts with residual oils or no special
lubricants applied. If special lubri-
cants of high stress ability, such as
Never-Seez compound graphite
and oil, molybdenum disulphite,
colloidal copper or white lead are applied, multiply the torque values in the charts by the
factor .90. The use of Loctite does not affect the torque values listed above.
• Torque values for socket-head capscrews are the same as for Grade 8 capscrews.
• Do not use these values if a different torque value or tightening procedure is given for
a specic application. Torque values listed are for general use only. Check tightness of
fasteners periodically.
• Sheer bolts are designed to fail under predetermined loads. Always replace shear bolts
with identical grade.
• Fasteners should be replaced with the same or higher grade. If higher grade fasteners
are used, these should only be tightened to the strength of the original.
• Tighten plastic insert or crimped steel-type lock nuts to approximately 110 percent of the
dry torque values shown in the chart below, applied to the nut, not to the bolt head.
Tighten toothed or serrated-type lock nuts to the full torque value. Note: “Lubricated”
means coated with a lubricant such as engine oil, or fasteners with phosphate and oil
coatings. “Dry” means plain or zinc plated without lubrication. Tighten lubricated bolts
to approximately 80% of dry bolts.
Size Bolt DIA Plain Plated Plain Plated Plated
(DIA-TPI) (Inches) (Ft-Lb) (Ft-Lb) (Ft-Lb) (Ft-Lb) (Ft-Lb)
5/16-18 0.3125 17 13 25 18 22
3/8-16 0.3750 31 23 44 33 39
7/16-14 0.4375 49 37 70 52 63
1/2-13 0.5000 75 57 105 80 96
9/16-12 0.5625 110 82 155 115 139
5/8-11 0.6250 150 115 220 160 192
3/4-10 0.7500 265 200 375 280 340
7/8-9 0.8750 395 295 605 455 549
1-8 1.000 590 445 910 680 823
1 1/8-7 1.1250 795 595 1290 965 1167
1 1/4-7 1.2500 1120 840 1815 1360 1646
1 3/8-6 1.3750 1470 1100 2380 1780 2158
1 1/2-6 1.500 1950 1460 3160 2370 2865
GRADE 5 GRADE 8 GRADE 9
Torque Data Chart

Stellar®108-11-32 Shuttle Owner’s Manual | Page 5
• Visually inspect the truck and look for any potential issues. For example: Clearance
problems, cross members extending too high, insufcient room in front of the hooklift for
tarpers, exhaust manifolds, etc., or insufcient room in the rear to allow for bumper se-
lection. Note: Stellar Industries recommends allowing 12” behind the start of clear truck
frame for installation of a tarping system.
• Be sure to square the hooklift on the truck frame to allow for proper measurement. The
front of the hooklift needs to be at least 2.50” behind the cab or any equipment mount-
ed behind the cab.
Step 1: Set the hooklift onto the truck frame.
Every hooklift installation is unique. However, certain guidelines exist that apply to every
model. Listed below is a general set of chronlological steps that may be followed when
installing a Stellar Hooklift. If any questions arise during the installation process, feel free to
contact your local dealer or Stellar Customer Service at 800-321-3741.
Installation Note
.41 11.49
2.50
8.32

Page 6 | Stellar®108-11-32 Shuttle Owner’s Manual
Step 2: Bolt tie-down castings to mounting plates.
1. Place and weld a tie down channel (PN 79246) on both sides of the base, within 2” of
the front plate.
2. Place a second set in the approximate position shown in the corresponding mounting
diagram below. The top of the lower channel should be ush with the top of the chassis
frame rail.
3. Place a tie down channel (PN D0143) on both sides of the base, underneath the tabs at
the rear. Drill an 11/16” hole in each of the rear tabs, using the channels as a guide. Bolt
the channels to the tab using 5/8” bolts, washers and nuts.
DETAIL
A
SCALE 1 : 1
0
1
.2
5
TYP
4
.2
5
TYP
2
DETAIL
B
SCALE 1 : 15
3
(
.25
)
W
=.
38
TYP
4
4
7
7
10
1
2
11
8
9
0
4
7
7
10
1
2
6
8
11
8
9
ITEM PART DESCRIPTION QTY.
179246 TIE DOWN 40,000# PC BLACK
4
21440 TIE DOWN, 40000#
4
380043 PLATE 0.50X8.00X16.00 W/HOLE 4
412169
CAP SCR 1.00-8X3.50 HHGR8
4
6 C1025 CAP SCR 0.63-11X2.00 HHGR8 ZY
4
76538 WASHER 1.00 SAE FLAT YELLOW GR8
32
8 C5902 WASHER 0.63 SAE FLAT YELLOW GR8
8
924868 NUT 0.63-11 HHGR8 NYLOCK ZY
4
10 6294 NUT 1.00 HHGR8 NYLOC
16
11 D0143 TIE DOWN CHANNEL
2
A
B
DETAIL A
SCALE 1 : 10
1
.25
TYP 4
.25
TYP 2
DETAIL B
SCALE 1 : 15
3
(.25)
W=.38
TYP 4

Stellar®108-11-32 Shuttle Owner’s Manual | Page 7
Step 4: Bolt tie-down castings to truck frame.
Step 3: Drill mounting holes into frame rail.
Using 1” bolts, washers and nuts secure the front tie down channels to the truck frame.
Using 5/8” bolts, washers and nuts secure the rear tie down channels to the truck frame.
5
7
7
10
2
9
8
8
6
11
0
5
7
7
10
2
9
8
8
611
ITEM PART DESCRIPTION QTY.
21440 TIE DOWN, 40000#
4
55199
CAP SCR 1.00X8X3.00 HHGR8 ZY
12
6 C1025 CAP SCR 0.63-11X2.00 HHGR8 ZY
4
76538 WASHER 1.00 SAE FLAT YELLOW GR8
32
8 C5902 WASHER 0.63 SAE FLAT YELLOW GR8
8
924868 NUT 0.63-11 HHGR8 NYLOCK ZY
4
10 6294
NUT 1.00 HHGR8 NYLOC
16
11 D0143 TIE DOWN CHANNEL
2
1. Place two shear plates (PN 80043) on each side of the base in the approximate loca-
tions shown in the corresponding mounting diagram below. The top of the plates should
be approximately even with the bottom of the base tube.
2. Weld all tie down channels and shear plates to the base of the hooklift.
3. Using the channels as a guide, drill four (4) 1-1/16” holes and two (2) 11/16” holes
through the truck frame.
4. Drill two (2) 1-1/16” holes through each of the shear plates, and the truck frame.
NO
TE:
-L
OC
ATE A
S
C
L
OS
E T
O
FR
O
NT PIN P
O
INT A
S
P
OSS
IBL
E
-MU
S
T BE IN FR
O
NT
O
F FR
O
NT
S
ADDL
E
FR
O
NT PIN P
O
IN
T
FR
O
NT
S
ADDLE
NO
TE:
-
L
OC
ATE BEL
O
W FR
O
NT D
U
MP RE
S
T
NO
TE:
-L
OC
ATE BEL
O
W REAR DUMP RE
S
T
FR
O
NT DUMP RE
ST
REAR DUMP RE
ST
NOTE:
-LOCATE AS CLOSE TO FRONT PIN POINT AS POSSIBLE
-MUST BE IN FRONT OF FRONT SADDLE
FRONT PIN POINT
FRONT SADDLE
NOTE:
-LOCATE BELOW FRONT DUMP REST
NOTE:
-LOCATE BELOW REAR DUMP REST
FRONT DUMP REST
REAR DUMP REST
FOR THE FRONT 4 MOUNTS DRILL 1-1/16" MOUNTING HOLES THROUGH THE TRUCK FRAME AS SHOWN
FOR THE REAR MOUNT DRILL 11/16" MOUNTING HOLES THROUGH THE TRUCK FRAME AS SHOWN
DETAIL
A
SCALE 1 : 1
0
1
.2
5
TYP
4
.2
5
TYP
2
DETAIL
B
SCALE 1 : 15
3
(
.25
)
W
=.
38
TYP
4
4
7
7
10
1
2
11
8
9
0
4
7
7
10
1
2
6
8
11
8
9
ITEM PART DESCRIPTION
QTY.
179246 TIE DOWN 40,000# PC BLACK
4
21440 TIE DOWN, 40000#
4
380043 PLATE 0.50X8.00X16.00 W/HOLE 4
412169
CAP SCR 1.00-8X3.50 HHGR8
4
6 C1025 CAP SCR 0.63-11X2.00 HHGR8 ZY
4
76538 WASHER 1.00 SAE FLAT YELLOW GR8
32
8 C5902 WASHER 0.63 SAE FLAT YELLOW GR8
8
924868 NUT 0.63-11 HHGR8 NYLOCK ZY
4
10 6294 NUT 1.00 HHGR8 NYLOC
16
11 D0143 TIE DOWN CHANNEL
2
A
B
DETAIL A
SCALE 1 : 10
1
.25
TYP 4
.25
TYP 2
DETAIL B
SCALE 1 : 15
3
(.25)
W=.38
TYP 4

Page 8 | Stellar®108-11-32 Shuttle Owner’s Manual
Mounting Kit - PN 16898
ITEM PART DESCRIPTION QTY.
179246 TIE DOWN 40,000# PC BLACK
4
21440 TIE DOWN, 40000#
4
380043 PLATE 0.50X8.00X16.00 W/HOLE 4
412169
CAP SCR 1.00-8X3.50 HHGR8
4
55199 CAP SCR 1.00X8X3.00 HHGR8 ZY
12
6 C1025 CAP SCR 0.63-11X2.00 HHGR8 ZY
4
76538 WASHER 1.00 SAE FLAT YELLOW GR8
32
8 C5902 WASHER 0.63 SAE FLAT YELLOW GR8
8
924868 NUT 0.63-11 HHGR8 NYLOCK ZY
4
10 6294 NUT 1.00 HHGR8 NYLOC
16
11 D0143 TIE DOWN CHANNEL
2
6
8
9
10
7
7
5
3
4
7
10
5
7
WELD HER
E
2
0
0
6
8
9
10
7
7
5
3
4
7
10
5
7
WELD HERE
1
2
PN 16898
•See NHTSA (National Highway Truck Saftey Administration) Regulations for acceptable
placement.
• Modify the truck frame as necessary so that it ends 2” from the rear of the hooklift.
Step 5: Install bumper.
2.00
See brand specic installation instructions.
• Before drilling and bolting to the frame, conrm adequate room for cable routing be-
tween in-cab controls and the valve bank. Note: The top of the reservoir should not be
above the truck frame. Refer to the Reservoir Assembly Drawings for details.
Step 6: Install tarper tower (If applicable).
Step 7: Install hydraulic reservoir and valve bank.

Stellar®108-11-32 Shuttle Owner’s Manual | Page 9
11
1
18
3
2
4
14
17
13
13
8
19
21
NOTE: ITEMS NOT SHOWN 25941 - DECAL LOADER VB VDM8 HOSE LOCATION X 1 42971 - DECAL OIL FILTER CHANGE X 1
ITEM
PART
DESCRIPTION
QTY.
186006
RSRVR ASM 25GAL K MODEL W/ TANK TOP FILTER
1
27353
FTG 32-32 MP-MP HEX NIPPLE STRAIGHT
1
3
C4750
VALVE BALL 2.00
1
4
C4730
FTG 32-32 MP-HB STRAIGHT
1
524611 VB 2-SECTION VDM8
1
60521
WASHER 0.25 LOCK
3
70339
CAP SCR 0.25-20X2.50 HHGR5
3
860395
FTG 16-20 MFS-MAORB 90
1
9
C2252
FTG 8-10 MFS-MORB STRAIGHT
2
10 16152
FTG 10-10 MFS-MORB STRAIGHT
2
11 27119
HOSE 0.75(78C-12-JC-JC-12-12-12-120)
1
12 10094
GAUGE OIL LF 2.5" 0-5000 BM
1
13 c4819
HOSE CLAMP 2.00
2
14 17766
HOSE SUCT 2.00 10FT
1
15 25630
FTG 10-4 MORB-FP STRAIGHT
1
16
d1435
FTG 12-10 MFS-MORB STRAIGHT
1
17 c4903
FTG 12-12 MFS-FFSS 90
1
18 83959
MNT KIT RSRVR 25G
1
19 86168
HOSE 0.75(300PSI)-16FFSS SHORT-12FFSS 90 SHORT-7.75CL
1
20
C2142
FTG 12-12 MFS-MORB STRAIGHT
1
21
C6327
FILTER STRAINER 35GAL TF-2030
1
PN 86463
Reservoir Assembly with Cable Controls - PN 86463

Page 10 | Stellar®108-11-32 Shuttle Owner’s Manual
10
18
3
2
4
13
16
1
12
12
19
8
21
NOTE: ITEMS NOT SHOWN 25941 - DECAL LOADER VB VDM8 HOSE LOCATION X 1 42971 - DECAL OIL FILTER CHANGE X 1
ITEM
PART
DESCRIPTION
QTY.
186006
RSRVR ASM 25GAL K MODEL W/ TANK TOP FILTER
1
27353
FTG 32-32 MP-MP HEX NIPPLE STRAIGHT
1
3
C4750
VALVE BALL 2.00
1
4
C4730
FTG 32-32 MP-HB STRAIGHT
1
525940
VB 2-SECTION VDM8 W/AIR ACTUATORS
1
60521
WASHER 0.25 LOCK
3
70339
CAP SCR 0.25-20X2.50 HHGR5
3
860395
FTG 16-20 MFS-MAORB 90
1
9
C2252
FTG 8-10 MFS-MORB STRAIGHT
2
10 27119
HOSE 0.75(78C-12-JC-JC-12-12-12-120)
1
11 10094
GAUGE OIL LF 2.5" 0-5000 BM
1
12 c4819
HOSE CLAMP 2.00
2
13 17766
HOSE SUCT 2.00 10FT
1
14 25630
FTG 10-4 MORB-FP STRAIGHT
1
15
d1435
FTG 12-10 MFS-MORB STRAIGHT
1
16 c4903
FTG 12-12 MFS-FFSS 90
1
17 16152
FTG 10-10 MFS-MORB STRAIGHT
2
18 83959
MNT KIT RSRVR 25G
1
19 86168
HOSE 0.75(300PSI)-16FFSS SHORT-12FFSS
90 SHORT-7.75CL
1
20
C2142
FTG 12-12 MFS-MORB STRAIGHT
1
21
C6327
FILTER STRAINER 35GAL TF-2030
1
PN 86467
Reservoir Assembly with Air Controls - PN 86467

Stellar®108-11-32 Shuttle Owner’s Manual | Page 11
Step 7: Install hydraulic reservoir and valve bank continued...
2 Section Valve Bank w/ Cable Controls
2 Section Valve Bank w/ Air Controls
NOTE: INSTALL PORT RELIEF HERE WHEN PN'S
FROM THE FOLLOWING LIST ARE USED.
TILT ASM'S:
83048 USES PORT RELIEF 69172
85778 USES PORT RELIEF 26184
NOTE: INSTALL PORT RELIEF HERE WHEN PN'S
FROM THE FOLLOWING LIST ARE USED.
DUMP ASM'S
56861
47056
45730
55839

Page 12 | Stellar®108-11-32 Shuttle Owner’s Manual
Valve Bank Parts Drawing
SPOOL SPRING KIT
WITH COVER PN 43776
AIR ACTUATOR
PN 26566
HANDLE ASM - OUTSIDE
CTRLS WITH HANDLE PN 30381
SPOOL RETAINER
PN 61522
MAIN RELIEF VALVE
PN 28510
HANDLE
PN 26130
SPOOL SEAL KIT
PN 29683

Stellar®108-11-32 Shuttle Owner’s Manual | Page 13
Step 8: Install PTO and pump.
• Before installing the pump to the PTO, always check the direction of the PTO output shaft
to determine which direction the hydraulic pump needs to rotate to operate the equip-
ment. If this is not determined prior to installing the hydraulic pump, the hydraulic pump
may rotate in the incorrect direction and damage the front shaft seal.
PTO Direction of Rotation Tip:
Viewed by standing at the rear of the vehicle, looking forward at the PTO shaft, with the
PTO shaft pointing toward the rear of the vehicle:
Remember that the PTO is specied by looking from the rear of the truck to the front of the
truck. The driven equipment (pump) is specied by looking from the front of the truck to
the rear of the truck.
• Use the brand specic PTO/Pump installation instructions. If the directions are not quite
clear, contact Stellar®Customer Service or consult with a hydraulic specialty house or
company prior to installation.
PTO
DRIVEN
EQUIPMENT
(PUMP)
DRIVEN
EQUIPMENT
(PUMP)
TRANSMISSION
TRANSMISSION
From rear of truck,
PTO shaft rotates
opposite engine/
clockwise.
From front of truck,
pump shaft rotates
counterclockwise.
From front of truck,
pump shaft rotates
clockwise.
From rear of truck,
PTO shaft rotates with
engine/counterclockwise.
PTO
P.T.O. Driven E
q
ui
p
ment
Rotates Opposite Engine
(looks "clockwise)
Driven equipment must rotate
counterclockwise (also called left-hand
rotation, "A" for anti-clockwise or C.C.W. for
counter clockwise).
Rotates With Engine
(looks "counterclockwise")
Driven equipment must rotate clockwise
(also called right-hand rotation or "C" for
clockwise).

Page 14 | Stellar®108-11-32 Shuttle Owner’s Manual
1. Route hose line from the reservoir to the pump (See hose kit drawing for details).
2. Route hose line from the pump to the valve bank (See hose kit drawing for details).
3. Route hose line from the valve bank to the reservoir (See hose kit drawing for details).
4. Route hose line from the valve bank and the hooklift (See hose kit drawing for details).
Note: If using the Power Beyond feature for additional function, see “Power Beyond VDM8
Valve” later in this chapter for further details.
Notes on hose line routing:
• Protect these lines with hose wrap when necessary.
• Keep these lines away from sharp edges.
• Keep these lines away from the exhaust or other temperature extreme items.
• Keep these lines away from the driveshaft or other moving items.
Step 9: Route hydraulic hoses.
Face Seal (A)
Stellar®PN
Hose
Size
Fitting
Size Stellar®PN
O-ring Boss (B)
#4 C2027 D1245
#6 C2028 D1246
#8 C2029 D1247
#10 32223 D1248
#12 D1244 D1249
#161”
3/4”
5/8”
1/2”
3/8”
1/4”
D1250
B
A
Face Seal/O-Ring Size Chart
