stellar labs 108-14-32 User manual

108-14-32
Shuttle Hooklift
Owner’s Manual
Stellar Industries, Inc.
190 State Street
PO Box 169
Garner, IA 50438
800-321-3741
Fax: [phone]
www.stellarindustries.com
Subject to Change without Notification.
© 2021 Stellar Industries, Inc.
Rev 2
PN 26504
Installation • Assembly Drawings • Parts

Page ii | Stellar®108-14-32 Shuttle Owner’s Manual
Model 108-14-32 Manual Revisions
Date of Revision Section Revised Description of Revision

Stellar®108-14-32 Shuttle Owner’s Manual | Page iii
Table of Contents
Introduction.............................................................................................................................................................iv
Hooklift Nomenclature........................................................................................................................................... v
Serial Tag Location .................................................................................................................................................vi
Chapter 1 - Specifications.......................................................................................................................................... 1
Model 108-14-32 Shuttle Specifications ............................................................................................................... 1
Acceptable Subframe Dimensions - Model 108-14-32 ...................................................................................... 2
Chapter 2 - Installation ............................................................................................................................................... 3
General Installation ................................................................................................................................................ 3
Installer Notice ..................................................................................................................................................... 3
Torque Data Chart .............................................................................................................................................. 4
Installation Note................................................................................................................................................... 5
Step 1: Set the hooklift onto the truck frame. ..................................................................................................... 5
Step 2: Drill mounting holes. .................................................................................................................................. 6
Step 3: Install bumper............................................................................................................................................. 7
Step 4: Install tie-downs.......................................................................................................................................... 7
Step 5: Install tarper tower (If applicable). .......................................................................................................... 8
Step 6: Install hydraulic reservoir and valve bank. ............................................................................................. 8
Reservoir Assembly with Cable Controls - PN 86463 ....................................................................................... 9
Reservoir Assembly with Air Controls - PN 86467............................................................................................ 10
Reservoir Subassembly - PN 86006................................................................................................................... 11
Valve Bank Parts Drawing.................................................................................................................................... 12
Step 7: Install PTO and pump. ............................................................................................................................. 13
Face Seal/O-Ring Size Chart ............................................................................................................................... 14
Step 8: Route hydraulic hoses. ............................................................................................................................ 14
Hose Kit - PN 98021 ............................................................................................................................................ 15
Power Beyond VDM8 Valve ............................................................................................................................. 16
Step 9: Route Electrical Components ................................................................................................................ 17
Step 10: Install cab and PTO controls................................................................................................................. 18
Cable Controls................................................................................................................................................... 18
Air Controls ......................................................................................................................................................... 19
Step 11: Install Hoist Up Alarm - PN 83115 .......................................................................................................... 20
Step 12: Install mud flaps and fenders. .............................................................................................................. 21
Poly Fender Assembly - PN 6170 ...................................................................................................................... 21
Poly Tandem Fender Assembly - PN 58217..................................................................................................... 22
Steel Tandem Fender Assembly - PN 100617.................................................................................................. 23
Step 13A: Apply Hooklift Assembly Decals ........................................................................................................ 24
Step 13B: Apply Chassis Decals .......................................................................................................................... 25
Step 14: Fill reservoir and activate hydraulic flow............................................................................................. 26
Step 15: Operate hooklift..................................................................................................................................... 26
Set System Relief Pressure................................................................................................................................. 27
Chapter 3 - Assembly Drawings .............................................................................................................................. 29
Base Assembly - PN 93707 ................................................................................................................................... 29
Plunger Valve Assembly - PN 98018.................................................................................................................... 29
Dump Assembly - PN 93710................................................................................................................................. 30
Secondary Assembly - PN 26059......................................................................................................................... 31
Tilt Assembly - PN 93510 ....................................................................................................................................... 32
Main Cylinder - PN 44333..................................................................................................................................... 33
Tilt Cylinder - PN 23456 ......................................................................................................................................... 34
Optional Tab Alarm Kit - PN 43120...................................................................................................................... 35
Optional Tab Alarm Wire Harness - PN 26291 .................................................................................................... 36
Optional Proximity Switch Wire Harness - PN 26416 .......................................................................................... 37

Page iv | Stellar®108-14-32 Shuttle Owner’s Manual
Introduction
A copy of this manual is provided with every hooklift and can be found in the hard plastic
manual case that is installed on the chassis. A copy of this manual shall remain with the
hooklift at all times.
Throughout the manual, three signal words will be used to bring attention to important
items:
A NOTICE signal word indicates a practice not related to physical injury.
A WARNING signal word indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
A DANGER signal word indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
Information contained within this manual does not cover operation, maintenance, or trou-
bleshooting. Please refer to the General Shuttle Hooklift Manual for details on these items.
This manual is not binding. Stellar Industries, Inc. reserves the right to change, at any time,
any or all of the items, components, and parts deemed necessary for product improve-
ment or commercial/production purposes. This right is kept with no requirement or obliga-
tion for immediate mandatory updating of this manual.
In closing:
If more information is required or technical assistance is needed, or if you feel that any part
of this manual is unclear or incorrect, please contact the Stellar Customer Service Depart-
ment by phone at 800-321-3741 or email at [email protected].
WARNING
NOTICE
DANGER
For Technical Questions, Information, Parts, or Warranty, Call Toll-Free at
800-321-3741
Hours: Monday - Friday, 8:00 a.m. - 5:00 p.m. CST
Or email at the following addresses:
Technical Questions, and Information [email protected]
Order Parts [email protected]
Warranty Information [email protected]

Stellar®108-14-32 Shuttle Owner’s Manual | Page v
Hooklift Nomenclature
The Stellar®Shuttle is a hydraulic, body-loading device when mounted on a truck chassis. It
can handle a multitude of bodies ranging from flatbeds to recycling containers and dump
bodies.
The Shuttle consists of four basic parts: the base, dump, secondary, and tilt sections. Please
take the time to familiarize yourself with the various components. Knowing the proper ter-
minology is necessary to get the full benefit of this manual.
HOOKLIFT
BASE
DUMP
SECONDARY
TILT

Page vi | Stellar®108-14-32 Shuttle Owner’s Manual
The serial tag should be located on the right side (passenger side) of the base assembly:
FOR SERVICE ON THIS EQUIPMENT
CONTACT:
STELLAR INDUSTRIES, INC.
190 STATE STREET,GARNER, IA 50438
641-923-3741
800-321-3741
4214
35234
Proudly Designed
and Manufactured
in the USA by
DANGER
Electrocution Hazard
Death or serious injury will result from
inadequate clearance if hooklift, load,
or vehicle becomes electrically
charged.
• Maintain safe clearance from high
voltagepower sources.
• Never approach vehicle or load if
equipmentis near a high voltage
powersource.
55832 - RevA
MODELNO.SERIALNO.
DATE
MADE IN THE U.S.A. BY STELLAR INDUSTRIES, INC.
PN C5942
®
PATENTINFORMAT ION
http://www.stellarindustries.com/ip
WARNING
25627 - Rev B
Moving parts can crush
and cut.
Keep hands and arms
clear when operating
equipment.
Crush Hazard
Serial Tag Location
MODEL NO. SERIAL NO.
DATE
MADE IN THE U.S.A. BY STELLAR INDUSTRIES, INC.
PN C5942
®
PATENT INFORMATION
http://www.stellarindustries.com/ip

Stellar®108-14-32 Shuttle Owner’s Manual | Page 1
A
G
E
I
D
H
C
L
J
B
K
Chapter 1 - Specifications
Model 108-14-32 Shuttle Specifications
Model 108-14-32 Shuttle
Lifting/Dumping Capacity 32,000 lbs (14,515 kg)
ADump Angle 57°
BLowest hook Height 49” (125 cm)
CEffective Length 144” (366 cm)
DTruck Frame Height 41” (104 cm)
EHooklift Height 52.31” (132.87 cm)
GHooklift Length 156” (396 cm)
HHooklift Center of Gravity 67” (170 cm)
IChassis Cab to Axle 122” to 128” (310 to 325 cm)
JMax Height When Loading 156” (396 cm)
KLongest Body to Dump 204” (518 cm)
LMax Height when Dumping 214” (544 cm)
Operating Pressure 4200 psi
Hydraulic Flow Not to exceed 24 GPM
Shipping Weight 3,600 lbs (1,633 kg)
Hook Height 61.75” (156.85 cm)
Shipping Dimensions (LxHxW) 156” x 83” x 49”
Minimum Truck GVWR 32,000
RBM 1,600,000
Load Angle w/Shortest Body Length 41°
Recommended Body Lengths* 12’ to 15’ (3.66 to 4.57 m)
Recommended Flatbed Body Lengths** to 17’ (5.18 m)
* Assumes 3ft. overhang from center of rear roller pin.
* Assumes 5ft. overhang from center of rear roller pin - May require bumper and latch options.

Page 2 | Stellar®108-14-32 Shuttle Owner’s Manual
Acceptable Subframe Dimensions - Model 108-14-32

Stellar®108-14-32 Shuttle Owner’s Manual | Page 3
Chapter 2 - Installation
Installer Notice
According to Federal Law (49 cfr part 571), each final-stage manufacturer shall complete the vehi-
cle in such a manner that it conforms to the standards in effect on the date of manufacture of the
incomplete vehicle, the date of final completion, or a date between those two dates. This require-
ment shall, however, be superseded by any conflicting provisions of a standard that applies by its
terms to vehicles manufactured in two or more stages.
Therefore, the installer of Stellar®Hooklifts is considered one of the manufacturers of the vehicle.
As such a manufacturer, the installer is responsible for compliance with all applicable federal and
state regulations. They are required to certify that the vehicle is in compliance with the Federal
Motor Vehicle Safety Standards and other regulations issued under the National Traffic and Motor
Vehicle Safety Act.
Please reference the Code of Federal Regulations, title 49 - Transportation, Volume 5 (400-999), for
further information, or visit http://www.gpoaccess.gov/nara/index.html for the full text of Code of
Federal Regulations.
General Installation
This chapter is designed to serve as a general guide for the installation of a Stellar®Shuttle
108-14-32 Hooklift. Each installation is considered unique so certain portions of this chap-
ter may or may not apply to your direct application. If a question should arise during the
installation process, please contact Stellar Customer Service at [phone].
PTO and Pump installation instructions are provided by the corresponding manufacturers.
For more information on which PTO and Pump fit your application, please contact your
local Stellar Distributor or Stellar Customer Service.
Do not install this hooklift on a chassis not capable of handling the loads
imposed on it. Failure to do so may result in serious injury or death.
Do not weld or drill holes into the side wall of the base tubes.
Hooklift Mounting and Assembly
Study names and locations of the parts and familiarize yourself with the hooklift before
starting the assembly . Reading the step-by-step instructions that follow will be helpful.
Assembly
Select an area for assembly that will be large enough to accommodate the completed
unit. The surface of the work area should be as level as possible. Use the proper hand
tools to ensure proper bolt tightness. Refer to the torque data chart in this chapter for the
recommended torque values for different sizes of bolts.
Model Number
Know the model number of the Stellar®Hooklift being mounted. Use this model number
whenever referring to the assembly or parts listing pages. The number is stamped on the
name plate which is located on the front frame member.
WARNING
NOTICE

Page 4 | Stellar®108-14-32 Shuttle Owner’s Manual
When using the torque data in the
chart, the following rules should be
observed:
• Bolt manufacturer’s particular
specifications should be consulted
when provided.
• Flat washers of equal strength
must be used.
• All torque measurements are giv-
en in foot-pounds. To convert to
inch-pounds, multiply by 12.
• Torque values specified are for
bolts with residual oils or no special
lubricants applied. If special lubri-
cants of high stress ability, such as
Never-Seez compound graphite
and oil, molybdenum disulphite,
colloidal copper or white lead are applied, multiply the torque values in the charts by the
factor .90. The use of Loctite does not affect the torque values listed above.
• Torque values for socket-head capscrews are the same as for Grade 8 capscrews.
• Do not use these values if a different torque value or tightening procedure is given for
a specific application. Torque values listed are for general use only. Check tightness of
fasteners periodically.
• Sheer bolts are designed to fail under predetermined loads. Always replace shear bolts
with identical grade.
• Fasteners should be replaced with the same or higher grade. If higher grade fasteners
are used, these should only be tightened to the strength of the original.
• Tighten plastic insert or crimped steel-type lock nuts to approximately 110 percent of the
dry torque values shown in the chart below, applied to the nut, not to the bolt head.
Tighten toothed or serrated-type lock nuts to the full torque value. Note: “Lubricated”
means coated with a lubricant such as engine oil, or fasteners with phosphate and oil
coatings. “Dry” means plain or zinc plated without lubrication. Tighten lubricated bolts
to approximately 80% of dry bolts.
Size Bolt DIA Plain Plated Plain Plated Plated
(DIA-TPI) (Inches) (Ft-Lb) (Ft-Lb) (Ft-Lb) (Ft-Lb) (Ft-Lb)
5/16-18 0.3125 17 13 25 18 22
3/8-16 0.3750 31 23 44 33 39
7/16-14 0.4375 49 37 70 52 63
1/2-13 0.5000 75 57 105 80 96
9/16-12 0.5625 110 82 155 115 139
5/8-11 0.6250 150 115 220 160 192
3/4-10 0.7500 265 200 375 280 340
7/8-9 0.8750 395 295 605 455 549
1-8 1.000 590 445 910 680 823
1 1/8-7 1.1250 795 595 1290 965 1167
1 1/4-7 1.2500 1120 840 1815 1360 1646
1 3/8-6 1.3750 1470 1100 2380 1780 2158
1 1/2-6 1.500 1950 1460 3160 2370 2865
GRADE 5 GRADE 8 GRADE 9
Torque Data Chart

Stellar®108-14-32 Shuttle Owner’s Manual | Page 5
• Visually inspect the truck and look for any potential issues. For example: Clearance
problems, cross members extending too high, insufficient room in front of the hooklift for
tarpers, exhaust manifolds, etc., or insufficient room in the rear to allow for bumper se-
lection. Note: Stellar Industries recommends allowing 12” behind the start of clear truck
frame for installation of a tarping system.
• Be sure to square the hooklift on the truck frame to allow for proper measurement. The
front of the hooklift needs to be at least 2.50” behind the cab or any equipment mount-
ed behind the cab.
Step 1: Set the hooklift onto the truck frame.
Every hooklift installation is unique. However, certain guidelines exist that apply to every
model. Listed below is a general set of chronological steps that may be followed when
installing a Stellar Hooklift. If any questions arise during the installation process, feel free to
contact your local dealer or Stellar Customer Service at 800-321-3741.
Installation Note
2.50
4.94

Page 6 | Stellar®108-14-32 Shuttle Owner’s Manual
• When positioning mounts to frame, tie-down castings are bolted to the underside of
each tie down plate located on the outside of the main rails of the base. The tie-down
plate closest to the front of the base requires one mount on each side of the pin. This
is the only time two tie down castings are required per a single tie-down plate. The tie-
down plates are designed with multiple slots to offer more flexibility in mounting locations.
Additional holes may not be added to the tie-down plates.
• Using the tie-down castings as a guide, drill 11/16” holes through the truck frame as
shown.
Step 2: Drill mounting holes.
NOTE: FOR THE FRONT MOUNT AT LEAST THREE BOLTS ARE REQUIRED TO ANGLE THE LOADER TO THE MOUNT AND TWO BOLTS
TO MOUNT THE ANGLE TO THE TRUCK FRAME.
NOTE:
1. MULTIPLE HOLES ARE PREDRILLED ON THE BASE MOUNTING FLATS, ADDITIONAL HOLES MAY NOT BE ADDED.
2. ONLY THE FRONT ANGLE MOUNT REQUIRES 4 BOLTS TO INSTALL THE ANGLE MOUNT TO THE TRUCK FRAME AND
4 BOLTS TO INSTALL THE HOOK TO THE ANGLE MOUNT.
3. THE REAR 3 ANGLE MOUNTS REQUIRE 2 BOLTS EACH TO INSTALL THE ANGLE MOUNT TO THE TRUCK AND THE
HOOKLIFT TO THE ANGLE MOUNT.

Stellar®108-14-32 Shuttle Owner’s Manual | Page 7
•See NHTSA (National Highway Truck Safety Administration) Regulations for acceptable
placement.
• Modify the truck frame as necessary so that it ends 2” from the rear of the hooklift.
Step 3: Install bumper.
2.00
Note: See torque chart at beginning of chapter:
Step 4: Install tie-downs.
ITEM PART DESCRIPTION QTY.
1 57081PC ANGLE 4.00X6.00X.50WX22.00 SLOTS 2
2
57079PC ANGLE FORMED 4.00X4.00X0.50X12.88 SLOTS 2
35199
CAP SCR 1.00X8X3.00 HHGR8 ZY 40
46538
WASHER 1.00 SAE FLAT YELLOW GR8 80
56294
NUT 1.00 HHGR8 NYLOC 40
8
57733PC ANGLE 4.00X6.00X.50WX11.00 SLOTS 4
PN 57080
3
3
4
4
8
1
4
4
3
3
4
4
5
5
4
5
5
4
2

Page 8 | Stellar®108-14-32 Shuttle Owner’s Manual
Mounting Kit - PN 16898
ITEM PART DESCRIPTION QTY.
179246 TIE DOWN 40,000# PC BLACK
4
21440 TIE DOWN, 40000#
4
380043 PLATE 0.50X8.00X16.00 W/HOLE 4
412169
CAP SCR 1.00-8X3.50 HHGR8
4
55199 CAP SCR 1.00X8X3.00 HHGR8 ZY
12
6 C1025 CAP SCR 0.63-11X2.00 HHGR8 ZY
4
76538 WASHER 1.00 SAE FLAT YELLOW GR8
32
8 C5902 WASHER 0.63 SAE FLAT YELLOW GR8
8
924868 NUT 0.63-11 HHGR8 NYLOCK ZY
4
10 6294 NUT 1.00 HHGR8 NYLOC
16
11 D0143 TIE DOWN CHANNEL
2
6
8
9
10
7
7
5
3
4
7
10
5
7
WELD HER
E
2
0
0
6
8
9
10
7
7
5
3
4
7
10
5
7
WELD HERE
1
2
PN 16898
See brand specific installation instructions.
• Before drilling and bolting to the frame, confirm adequate room for cable routing be-
tween in-cab controls and the valve bank. Note: The top of the reservoir should not be
above the truck frame. Refer to the Reservoir Assembly Drawings for details.
Step 5: Install tarper tower (If applicable).
Step 6: Install hydraulic reservoir and valve bank.

Stellar®108-14-32 Shuttle Owner’s Manual | Page 9
Reservoir Assembly with Cable Controls - PN 86463
11
1
18
3
2
4
14
17
13
13
8
19
21
NOTE: ITEMS NOT SHOWN
25941 - DECAL LOADER VB VDM8 HOSE LOCATION X 1
42971 - DECAL OIL FILTER CHANGE X 1
ITEM PART DESCRIPTION QTY.
186006
RSRVR ASM 25GAL K MODEL W/ TANK
TOP FILTER
1
27353
FTG 32-32 MP-MP HEX NIPPLE STRAIGHT
1
3 C4750 VALVE BALL 2.00
1
4 C4730 FTG 32-32 MP-HB STRAIGHT
1
524611 VB 2-SECTION VDM8
1
60521 WASHER 0.25 LOCK
3
70339 CAP SCR 0.25-20X2.50 HHGR5
3
860395 FTG 16-20 MFS-MAORB 90 1
9
C2252 FTG 8-10 MFS-MORB STRAIGHT
2
10 16152 FTG 10-10 MFS-MORB STRAIGHT
2
11 27119 HOSE 0.75(78C-12-JC-JC-12-12-12-120)
1
12 10094 GAUGE OIL LF 2.5" 0-5000 BM
1
13 c4819 HOSE CLAMP 2.00
2
14 17766 HOSE SUCT 2.00 10FT
1
15 25630 FTG 10-4 MORB-FP STRAIGHT
1
16 d1435 FTG 12-10 MFS-MORB STRAIGHT
1
17 c4903 FTG 12-12 MFS-FFSS 90
1
18 83959 MNT KIT RSRVR 25G
1
19 86168
HOSE 0.75(300PSI)-16FFSS SHORT-12FFSS
90 SHORT-7.75CL
1
20
C2142 FTG 12-12 MFS-MORB STRAIGHT 1
21
C6327 FILTER STRAINER 35GAL TF-2030 1
PN 86463

Page 10 | Stellar®108-14-32 Shuttle Owner’s Manual
Reservoir Assembly with Air Controls - PN 86467
10
18
3
2
4
13
16
1
12
12
19
8
21
NOTE: ITEMS NOT SHOWN
25941 - DECAL LOADER VB VDM8 HOSE LOCATION X 1
42971 - DECAL OIL FILTER CHANGE X 1
ITEM PART DESCRIPTION QTY.
186006
RSRVR ASM 25GAL K MODEL W/ TANK
TOP FILTER
1
27353
FTG 32-32 MP-MP HEX NIPPLE STRAIGHT
1
3 C4750 VALVE BALL 2.00
1
4 C4730 FTG 32-32 MP-HB STRAIGHT
1
525940 VB 2-SECTION VDM8 W/AIR ACTUATORS
1
60521 WASHER 0.25 LOCK
3
70339 CAP SCR 0.25-20X2.50 HHGR5
3
860395 FTG 16-20 MFS-MAORB 90 1
9
C2252 FTG 8-10 MFS-MORB STRAIGHT
2
10 27119 HOSE 0.75(78C-12-JC-JC-12-12-12-120)
1
11 10094 GAUGE OIL LF 2.5" 0-5000 BM
1
12 c4819 HOSE CLAMP 2.00
2
13 17766 HOSE SUCT 2.00 10FT
1
14 25630 FTG 10-4 MORB-FP STRAIGHT
1
15 d1435 FTG 12-10 MFS-MORB STRAIGHT
1
16 c4903 FTG 12-12 MFS-FFSS 90
1
17 16152 FTG 10-10 MFS-MORB STRAIGHT
2
18 83959 MNT KIT RSRVR 25G
1
19 86168
HOSE 0.75(300PSI)-16FFSS SHORT-12FFSS
90 SHORT-7.75CL
1
20
C2142 FTG 12-12 MFS-MORB STRAIGHT 1
21
C6327 FILTER STRAINER 35GAL TF-2030 1
PN 86467

Stellar®108-14-32 Shuttle Owner’s Manual | Page 11
Reservoir Subassembly - PN 86006
9
10
7
8
6
3
2
5
1
4
11
NOTE: REPLACEMENT OIL FILTER - PN 86010
ITEM PART DESCRIPTION QTY
1 C2126 MAGNETIC PLUG DRAIN 3/4" 1
2 15463
THERMO SIGHT GAUGE ZINGA SG-O5-A-T-N 1
3 73278
CAP FILL 1PSI ZINGA THREADED 1
4 13002
DECAL HYD OIL SPECIFICATION MOBIL 1
5 86007
RSRVR 25GAL K MODEL W/ TANK TOP FILTER 1
6 66656
FILTER PIPE TANK TOP 1
7 85928
FILTER TANK TOP 20 FORB 1
8 58396
GASKET RG-11 TANK TOP FILTER 1
9 0335
CAP SCR 0.38-16X1.25 HHGR5 4
10
C6353 WASHER 0.38 SAE FLAT YELLOW GR8 4
11
C4845 PLUG 0.75 NPT SQ HD BLK 1
PN 86006
NOTE: REPLACEMENT GASKET
UNDER FILTER CAP - PN 109546

Page 12 | Stellar®108-14-32 Shuttle Owner’s Manual
Valve Bank Parts Drawing
SPOOL SPRING KIT
WITH COVER PN 43776
AIR ACTUATOR
PN 26566
HANDLE ASM - OUTSIDE
CTRLS WITH HANDLE PN 30381
SPOOL RETAINER
PN 61522
MAIN RELIEF VALVE
PN 28510
HANDLE
PN 26130
SPOOL SEAL KIT
PN 29683

Stellar®108-14-32 Shuttle Owner’s Manual | Page 13
Step 7: Install PTO and pump.
• Before installing the pump to the PTO, always check the direction of the PTO output shaft
to determine which direction the hydraulic pump needs to rotate to operate the equip-
ment. If this is not determined prior to installing the hydraulic pump, the hydraulic pump
may rotate in the incorrect direction and damage the front shaft seal.
PTO Direction of Rotation Tip:
Viewed by standing at the rear of the vehicle, looking forward at the PTO shaft, with the
PTO shaft pointing toward the rear of the vehicle:
Remember that the PTO is specified by looking from the rear of the truck to the front of the
truck. The driven equipment (pump) is specified by looking from the front of the truck to
the rear of the truck.
• Use the brand specific PTO/Pump installation instructions. If the directions are not quite
clear, contact Stellar®Customer Service or consult with a hydraulic specialty house or
company prior to installation.
PTO
DRIVEN
EQUIPMENT
(PUMP)
DRIVEN
EQUIPMENT
(PUMP)
TRANSMISSION
TRANSMISSION
From rear of truck,
PTO shaft rotates
opposite engine/
clockwise.
From front of truck,
pump shaft rotates
counterclockwise.
From front of truck,
pump shaft rotates
clockwise.
From rear of truck,
PTO shaft rotates with
engine/counterclockwise.
PTO
P.T.O. Driven E
q
ui
p
ment
Rotates Opposite Engine
(looks "clockwise)
Driven equipment must rotate
counterclockwise (also called left-hand
rotation, "A" for anti-clockwise or C.C.W. for
counter clockwise).
Rotates With Engine
(looks "counterclockwise")
Driven equipment must rotate clockwise
(also called right-hand rotation or "C" for
clockwise).

Page 14 | Stellar®108-14-32 Shuttle Owner’s Manual
1. Route hose line from the reservoir to the pump (See hose kit drawing for details).
2. Route hose line from the pump to the valve bank (See hose kit drawing for details).
3. Route hose line from the valve bank to the reservoir (See hose kit drawing for details).
4. Route hose line from the valve bank and the hooklift (See hose kit drawing for details).
Note: If using the Power Beyond feature for additional function, see “Power Beyond VDM8
Valve” later in this chapter for further details.
Notes on hose line routing:
• Protect these lines with hose wrap when necessary.
• Keep these lines away from sharp edges.
• Keep these lines away from the exhaust or other temperature extreme items.
• Keep these lines away from the driveshaft or other moving items.
Step 8: Route hydraulic hoses.
Face Seal (A)
Stellar®PN
Hose
Size
Fitting
Size Stellar®PN
O-ring Boss (B)
#4 C2027 D1245
#6 C2028 D1246
#8 C2029 D1247
#10 32223 D1248
#12 D1244 D1249
#161”
3/4”
5/8”
1/2”
3/8”
1/4”
D1250
B
A
Face Seal/O-Ring Size Chart
