OPERATING MANUAL
Hausted®Fluoro-Track Fluoroscopy
Capable Stretcher
Model: 493RPCST
(08/30/06) 150830-331

i
Table of Contents Operator Manual 150830-331
A WORD FROM STERIS CORPORATION
This manual contains important information on proper use and maintenance of
the Hausted®Fluoro-Track Fluoroscopy Capable Stretcher Model: 493RPCST.
All personnel involved in the use and maintenance of this equipment mustAll personnel involved in the use and maintenance of this equipment must
All personnel involved in the use and maintenance of this equipment mustAll personnel involved in the use and maintenance of this equipment must
All personnel involved in the use and maintenance of this equipment must
carefully review and comply with the warnings, cautions and instructionscarefully review and comply with the warnings, cautions and instructions
carefully review and comply with the warnings, cautions and instructionscarefully review and comply with the warnings, cautions and instructions
carefully review and comply with the warnings, cautions and instructions
contained in this manual.contained in this manual.
contained in this manual.contained in this manual.
contained in this manual. These instructions are important to protect the
health and safety of personnel operating a Fluoro-Track Stretcher and should
be retained in a conveniently accessible area for quick reference.
Complete instructions for uncrating and connecting utilities, as well as
equipment drawings, have been furnished. If missing, contact STERIS for
replacement copies, giving the serial number and model numbers of the unit.
STERIS carries a complete line of accessories for use with this stretcher. A
STERIS representative will gladly review these with you.
The Hausted Fluoro-Track Fluoroscopy Capable Stretcher Model: 493RPCST
is designed for patient transport, treatment and recovery.
Indications for Use
A thorough preventive maintenance program is essential to safe and proper
unit operation. This manual contains maintenance schedules and proce-
dures which should be followed for satisfactory equipment performance.
You are encouraged to contact STERIS concerning our comprehensive
Annual Maintenance Agreements. Under the terms of these agreements,
preventive maintenance, adjustments, and replacement of worn parts are
done on a scheduled basis to assure equipment performance at peak
capability and to help avoid untimely or costly interruptions. STERIS main-
tains a global staff of well equipped, factory-trained technicians to provide this
service, as well as expert repair services. Please contact your STERIS
representative for details.
Service Information
A listing of the safety precautions to be observed when operating and
servicing this equipment can be found in SECTION 1 of this manual. Do not
operate or service the equipment until you have become familiar with this
information.
Any alteration of this equipment not authorized or performed by STERIS
Engineering Service which could affect its operation will void the warranty,
could adversely affect sterilization efficacy, could violate national, state, and
local regulations, and could jeopardize your insurance coverage.
Advisory
©2006, STERIS Corporation. All rights reserved. Printed in U.S.A.

ii
150830-331 Operator Manual Table of Contents
ECAuthorizedRepresentative
STERIS Limited
STERISHouse
Jays Close
Viables
Basingstoke
Hampshire
RG224AX
UNITEDKINGDOM
Manufacturedby:
STERISCorporation
2720GunterParkEast
Montgomery, AL 36109 • USA
www.steris.com
TEL:[phone]
FAX:[phone]
Equipment not suitable for use
in the presence of a flammable
anesthetic mixture with air or
oxygen or nitrous oxide.
The base language of this document is
ENGLISH. Any translations must be
made from the base language docu-
ment.
STERIS Corporation,
Montgomery, Alabama is an
ISO 13485 certified facility.

iii
Table of Contents Operator Manual 150830-331
TABLE OF CONTENTS
Section Title Page
1 LISTING OF WARNINGS AND CAUTIONS ....................................... 1-1
2 UNPACKING INSTRUCTIONS .......................................................... 2-1
3 OPERATING INSTRUCTIONS ........................................................... 3-1
3.1 Braking and Steering Operation ................................................................................. 3-1
3.1.1 Applying The Brakes ........................................................................................... 3-1
3.1.2 Releasing The Brakes .......................................................................................... 3-1
3.1.3 Applying The Steering Lock/Fifth Wheel ............................................................. 3-1
3.1.4 Releasing the Steering Lock/Fifth Wheel ............................................................ 3-1
3.2 Litter Top Height Adjustment....................................................................................... 3-2
3.2.1 Height Adjustment ............................................................................................... 3-2
3.2.2 Lowering Litter Top .............................................................................................. 3-2
3.2.3 Trendelenburg Adjustment .................................................................................. 3-2
3.2.4 Reverse Trendelenburg Adjustment .................................................................... 3-3
3.3 Retracto Rail Operation............................................................................................... 3-3
3.3.1 Raising the Rail .................................................................................................... 3-3
3.3.2 Half Height ........................................................................................................... 3-3
3.3.3 Lowering the Rail ................................................................................................. 3-3
3.4 Fowler Backrest Operation ......................................................................................... 3-4
3.4.1 Raising the Backrest ............................................................................................ 3-4
3.4.2 Lowering the Backrest ......................................................................................... 3-4
3.5 Sliding Top Operation ................................................................................................. 3-4
4 RECOMMENDED PREVENTIVE MAINTENANCE.............................. 4-1
4.1 Recommended Cleaning Instructions ........................................................................ 4-1
5 OPTIONAL ACCESSORIES ............................................................... 5-1
6 RECOMMENDED REPLACEMENT PARTS ........................................ 6-1

1-1
Listing of Warnings and Cautions Operator Manual 150830-331
The following Safety Precautions must be observed when operating or servicing this Hausted®Fluoro-Track Fluoroscopy
Capable Stretcher Model: 493RPCST . WARNING indicates the potential for personal injury and CAUTION indicates the
potential for damage to equipment. For emphasis, certain Safety Precautions are repeated throughout the manual. Itis
importantto reviewALL SafetyPrecautions beforeoperating or servicingthe unit.
Strictly following these Safety Precautions enhances your ability to safely and effectively utilize the unit and helps the
customer avoid improper maintenance methods which may damage the unit or render it unsafe. It is important to
understand that these Safety Precautions are not exhaustive; customers are encouraged to develop their own safety
policies and procedures to enhance and compliment these Safety Precautions.
WARNING–LACERATION HAZARD:
When cutting bands always use a tool specifically designed for that purpose. This will help to avoid personal
injuries frequently incurred when bands are cut and tension released.
WARNINGS – PERSONAL INJURY:
Do not sit on end – tipping may occur.
The stretcher has a warning label located at the head end stating: Maximum patient weight 226 Kilograms (500
pounds).
Patient entry, egress and transfer should always be done with the brakes locked.
The brakes should always be on and patient side rails up when the patient is not in transport.
Be sure both rails are in the upright locked position before leaving patient.
WARNING – PROPER OPERATION HAZARD:
Floors must be smooth and level to maintain optimum fifth wheel steering. Fifth wheel steering functions can be
influenced by floor irregularities (bumps or dips) greater than 1/2" (13 mm) across the span of the stretcher.
LISTING OF WARNINGS AND CAUTIONS 1

2-1
Unpacking Instructions Operator Manual 150830-331
UNPACKING INSTRUCTIONS 2
IMPORTANT: Report any shipping damage immediately! Inform shipper of
any damages – leave carton intact. Leave the stretcher in the receiving area
until inspection is complete.
Your stretcher has been carefully packaged at our manufacturing plant to
ensure safe shipment to you medical facility. There are several procedures you
must follow to put your new stretcher into service. These procedures only take
a few minutes to complete and are required to ensure proper operation of the
stretcher.
Step 1 – Cut the two metal bands around the shipping carton.
Step 2 – Remove the top half of the carton and cut one side of the bottom half.
Step 3 – Remove the stretcher from the carton. Cut the metal bands from
around the stretcher.
Step 4 – Check to see if all features of the stretcher work properly. If all
features work properly, go to step 5. If any of the features of the
stretcher do not work properly, call STERIS for service.
Step 5 – Clean the stretcher using a mild detergent to remove any dirt
accumulated during shipment.
Step 6 – Place the stretcher into service.
WARNING – LACERATION
HAZARD: When cutting
bandsalwaysuseatoolspe-
cifically designed for that
purpose. This will help to
avoid personal injuries fre-
quently incurred when
bands are cut and tension
released.

3-1
Operating Instructions Operator Manual 150830-331
3
OPERATING INSTRUCTIONS
3.1 Braking and
Steering Operation
3.1.1 Applying The Brakes The four wheel central braking system is activated by depressing the red pedal
at any of the four corners of the unit (Figure 3-1). To fully engage the brakes,
the pedal should be pressed to approximately 45º. All four caster wheels
should be locked from swiveling and rotating.
Figure 3-1
WARNING– PROPER
OPERATION HAZARD:
Floorsmustbesmoothand
leveltomaintainoptimum
fifth wheel steering. Fifth
wheel steering functions
canbe influencedbyfloor
irregularities (bumps or
dips)greater than1/2" (13
mm)acrossthespanofthe
stretcher.
3.1.4 Releasing the
Steering Lock/Fifth Wheel
Depress the red pedal at any of the four corners of the unit, until the pedal is in
a horizontal position (Figure 3-2). All four wheels should rotate and swivel freely,
and/or the optional fifth wheel will lift off the floor.
From any corner of the stretcher, depress the green pedal downward into the
locked position. (Figure 3-3). Push the stretcher forward. Either one caster at
the foot end will lock into a non-swivel mode, or the optional fifth wheel will lower
and apply pressure to the floor. This allows straight steering by the attendant.
3.1.3 Applying The
Steering Lock/Fifth Wheel
3.1.2 Releasing The
Brakes
Depress the green pedal at any of the four corners of the unit, until the pedal is
in a horizontal position (Figure 3-2). All four wheels should rotate and swivel
freely.
NOTE: Brakes should always be activated when unit is not in transport”
Figure 3-2 Figure 3-3

3-2
150830-331 Operator Manual Operating Instructions
3.2 Litter Top Height
Adjustment
3.2.1 Height Adjustment Press the pump pedal either at base side (Figure 3-4A) or foot end (Figure 3-4B)
to the floor, then release. Repeat this process until desired height is obtained.
Use smooth strokes on either pump pedal to ensure patient comfort.
3.2.2 Lowering Litter Top
Place the unit at maximum height, see “height adjustment.” Press down on the
release pedal at base side nearest the head end (Figure 3-6A) or right hand
release pedal at foot end (Figure 3-6B) until desired position is obtained then
remove pressure.
Figure 3-4A
Figure 3-5A
Figure 3-6A
Press down on the two release pedals either at base side (Figure 3-5A) or foot
end (Figure 3-5B) at the same time until desired height is obtained.
NOTE: Do Not Stand On Release Pedals.
3.2.3 Trendelenburg
Adjustment
Figure 3-4B
Figure 3-5B
Figure 3-6B

3-3
Operating Instructions Operator Manual 150830-331
3.2.4 Reverse
Trendelenburg Adjustment
Place the unit at maximum height, see “height adjustment.” Press down on the
release pedal at base side nearest the foot end (Figure 3-7A) or left hand pedal
at foot end (Figure 3-7B) until desired position is obtained then remove
pressure.
Figure 3-7A
3.3 Retracto Rail
Operation
3.3.1 Raising the Rail
Figure 3-8
Grasp rail top cap in the middle of the rail (Figure 3-8), and lift.
Figure 3-9
3.3.2 Half Height Grasp the rail (Figure 3-8); lift up on the red trigger under the litter top (Figure
3-9) while lowering the rail. When rail starts to move down release trigger.
Lower rail until it locks into half height position.
3.3.3 Lowering the Rail Grasp the rail (Figure 3-8), lift up on the red trigger under the top (Figure
3-9) while lowering the rail. Hold up on the trigger until the rail is all the
way down.
NOTE: Be sure both rails are in the upright locked position before leaving
patient.
Figure 3-7B

3-4
150830-331 Operator Manual Operating Instructions
Figure 3-10
Figure 3-11
3.4 Fowler Backrest
Operation
3.4.1 Raising the
Backrest
Grasp the fowler backrest tube and the gas spring activating handle (Figure 3-
10), squeeze the handle and the tube together and lift. Once the desired incline
is achieved, release the handle. (Amount of manual lifting required will vary
depending on patient size; the gas springs are intended only to assist you in
lifting the patient).
3.4.2 Lowering the
Backrest
Grasp the fowler backrest tube and the gas spring activating handle (Figure 3-
10). Place your opposite hand on the backrest (Figure 3-11). Squeeze the handle
and the tube together while supporting tube. Adjust incline by either slowly
lowering patient or by pressing the fowler down. (The amount of manual lifting
or supporting required will vary, depending on patient size; the gas springs are
intended only to assist you in lifting or lowering the patient.)
3.5 Sliding Top
Operation
Pull out on red release trigger pin with index finger (Figure 3-12) to unlock red
release handle. While holding release trigger pin outward with the index finger,
at same time grasp the red release handle (Figure 3-13) and lift upward. With
the release handle lifted upward, grasp the stretcher top frame with the other
hand (Figure 3-14) and slide the stretcher top to extend toward the head end
or foot end of the stretcher. When top is in desired position, let go of the release
handle to lock in place. On the release lever side of the stretcher near the head
end, there is a top position label and red indicator to record the precise position
of the stretcher top (Figure 3-15).
NOTE: Return stretcher top to center before moving or transporting patient.
Figure 3-12
Figure 3-13 Figure 3-14 Figure 3-15

4-1
Recommended Preventive Maintenance Operator Manual 150830-331
4
RECOMMENDED PREVENTIVE MAINTENANCE
For more details information, please contact:
STERIS Corporation at:
1-800-333-8828
1234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567
8
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567
8
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567
8
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567
8
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567
8
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567
8
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567
8
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567
8
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567
8
1234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678
Material
Lubricating oil, light-duty
grease, wax stick lubricant.
Schedule
3 Months
Proper size wrench and screw-
driver.
3 MonthsInspect all fasteners to ensure proper fit,
position and tightness (including nuts,
bolts, etc.).
Procedure
Lubricate all moving and sliding parts
and hinge points.
>!< Never Lubricate Gas Spring, Motor and Mech-Lock Shafts >!<
!!
Metal File, proper color paint
(specify color when ordering)
3 MonthsInspect all surfaces and remove any
user developed sharp or burred areas.
Apply touch-up where required.
Component
Pads
4.1 Recommended
Cleaning
Instructions
Schedule
After Each Use
Cleaning Agent
Routine Hospital Grade
Disinfectants, Soap
and Water
Routine hospital grade
disinfectants, soap and
water
Routine hospital grade
disinfectants, soap and
water
Cleaning Procedure
Wipe with Damp Cloth To remove
any foreign materials
Wipe with damp cloth to remove
any foreign materials
Special Notes
• Use only medium strength cleaners
• Do not steam clean or pressure wash
NOTE:Steamcleaningandpressurewashingofstretcherisnotrecommended
and can void warranty
Stretcher
Accessories
Lubricate pivot points after cleaning
Lubricate pivot points after washing
After each use
After each use
Wipe with a damp cloth to remove
any foreign materials or pressure
wash

5-1
Optional Accessories Operator Manual 150830-331
5
OPTIONAL ACCESSORIES
00001200 Patient safety strap with buckle (Qty. 1)
00001400 Patient safety strap with Velcro (Qty. 1)
00001800 IV Pole - telescoping, removable, stainless steel, 27" x 54" (69 cm x 137 cm)
00005400 Lateral x-ray cassette holder, holds cassettes up to 14"-17" (36 cm- 43 cm)
00006B00 Head/Footboard, stationary
00007B00 Head/Footboard, with extension
000E1700 IV Pole, fixed height, removable, stainless, 42" (107 cm)
000N4500 Monitor shelf - removable, folding
00CR6B00 Head/Footboard with chart holder, stationary
00CR7B00 Head/Footboard with chart holder and extension
00N16A00 Heel stirrups with mounting adapters (pair)
00N16C00 Knee crutch stirrups with mounting- adapters (pair)
00N16E00 Knee crutch and heel stirrups with mounting adapters (pair)
03165460 Mattress, 2" x 24-1/2" x 76" (5cm x 62cm x 193cm) conductive foam
03165560 Mattress, 3" x 24-1/2" x 76" (8cm x 62cm x 193cm) conductive foam
06189360 PressureCare mattress 4" x 24-1/2" x 76" (10cm x 62cm x 193cm)
conductive foam
06536600 Universal patient tray
06576500 Footboard with monitor shelf and chart holder
06589700 Mobile IV stand attachment
06883600 Footboard with monitor shelf, chart holder, and extension
06892160 Enhanced PressureCare mattress 5" x 24 1/2" x 76" (13cm x 62cm x
193cm) with Fusion II material, hunter green
06920000 Slick Patient Transfer System 4" x 24-1/2" x 76" (10cm x 62cm x 193cm)
The Slick 2 part system consists of transfer mattress, and base
mattress.
06925700 Paper roll holder
07562600 Patient protecting side rail covers, padded (pair)
07565600 Push handles, self-storing (pair)
07633400 Armboard with 1" pad and surgical mounting adapter
12845000 Vertical oxygen tank holder
12877000 IV Pole, telescoping with cable attachment
12884000 Drainage bag hooks (pair)
13193400 Burgundy color bumpers and striping for department identification
13193500 Teal color bumpers and striping for department identification
13193600 Plum color bumpers and striping for department identification
13317000 Under fowler utility tray (stainless steel)

6-1
Recommended Replacement Parts Operator Manual 150830-331
6
RECOMMENDED REPLACEMENT PARTS

6-2
150830-331 Operator Manual Recommended Replacement Parts
Figure 6-1. Retracto Rail Assemblies
3
1
4
10
18
13 9
11
17
15
14
2
12
6
5
7
8
13

6-3
Recommended Replacement Parts Operator Manual 150830-331
S
V
CDESCRIPTION
FIG. &
ITEM
NO.
PART
NUMBER UNITS PER
ASSEMBLY
6-1- RETRACTO RAIL ASSEMBLIES ............................................... X
1 075057 ASSEMBLY, Top Cap -Right ....................................................... 1
2 075056 ASSEMBLY, Top Cap -Left.......................................................... 1
3 068886 RIVET, Cherry - Female End ....................................................... 1
4 068886 RIVET, Cherry - Male End ........................................................... 1
5 068882 LEG, Offset .................................................................................. 10
6 035137 ROCKER...................................................................................... 12
7 035138 SPACER ...................................................................................... 12
8 035122 SCREW, Hex Head Cap, 1/4-20 x 1-5/8" Long ........................... 12
9 062038 SCREW, Buton Hed Socket, 1/4-20 x 3/4" Long ......................... 2
10 068883 LEG, Lock .................................................................................... 2
11 065432 PLATE, Lock - Left....................................................................... 1
12 065433 PLATE, Lock - Right .................................................................... 1
13 075269 CAP, Red Vinyl ............................................................................ 2
14 068198 SUPPORT, Retracto Rail Plate.................................................... 2
15 031325 SCREW, Flat Head Socket, 1/4-20 x 1/2" Long .......................... 2
16 066617 BOLT, Shoulder, 5/16 x 1-1/4" Long............................................ 2
17 031055 NUT, Lock, 1/4-20........................................................................ 16
18 031186 RIVET, Stop ................................................................................. 2

6-4
150830-331 Operator Manual Recommended Replacement Parts
Figure 6-2. Model RPC – Fluoro Track Assembly
40
37
139
42
52
41
47
48 25
26
34
24
29 49
30
23
36
44
635
28 32
31
13
33
62
10 916
12 8
15
1
61
38
59
45
43
56
57
58
46 55
51
49 53
11
13
14
54
17 19
18
17
3
521
2
4
60
22
20
27

6-5
Recommended Replacement Parts Operator Manual 150830-331
S
V
CDESCRIPTION
FIG. &
ITEM
NO.
PART
NUMBER UNITS PER
ASSEMBLY
6-2- MODEL RPC – FLUORO TRACK ASSEMBLY.......................... X
1 069353 WELDMENT, Horizon Fluoro Top ............................................... 1
2 061195 BHCS, 1/4-20 x 5/8" Long............................................................ 2
3 031055 NUT, Lock 1/4-20 ......................................................................... 22
4 067316 GUARD, Release Handle ............................................................ 1
5 067316 ASSEMBLY, Release Handle ...................................................... 1
6 061344 RING, Snap.................................................................................. 2
7 031118 PIN, Spring................................................................................... 4
8 068108 BRACKET, Mechlock ................................................................... 2
9 031104 SCREW, Set, 1/4-20 x 3/8" Long ................................................. 4
10 031325 SCREW, Button Head Cap, 1/4-20 x 1/2" Long ......................... 14
11 067311 MECHLOCK................................................................................. 2
12 067315 CABLE, Long ............................................................................... 1
13 062641 RING, Snap.................................................................................. 2
14 067314 CABLE, Short............................................................................... 1
15 067312 ASSEMBLY, Cable Anchor.......................................................... 1
16 067326 ACTUATOR, Release .................................................................. 1
17 065605 PIN, Spring, 1/8" x 1/2" Long ....................................................... 2
18 067351 CAP, Release Handle .................................................................. 1
19 067339 PLUNGER, Release .................................................................... 1
20 035235 SPRING, Plunger ......................................................................... 1
21 067349 PIN, Release Trigger ................................................................... 1
22 067350 CAP, Trigger Pin .......................................................................... 1
23 065561 BOLT, Shoulder, 5/16 x 1" Long .................................................. 2
24 068099 CLEVIS ........................................................................................ 2
25 068102 ACTIVATOR, Trigger ................................................................... 2
26 068100 ACTIVATOR, Fixed...................................................................... 2
27 068110 SPRING, Fowler Gas ................................................................... 2
28 068103 CABLE, Pneumatic Fowler .......................................................... 2
29 068090 FOWLER, Pneumatic................................................................... 1
30 068097 ANCHOR, Cable – Left Hand ...................................................... 1
31 031057 NUT, Lock, 5/16-18...................................................................... 2
32 062037 BOLT, Shoulder, 1/2" x 2" Long................................................... 2
33 052044 STOP, Doorman Wire .................................................................. 2
34 052041 SCREW, Set , #10-32 x .250" Long............................................. 2
35 068098 ANCHOR, Cable – Right Hand .................................................... 1
36 068093 WELDMENT, Fowler Release ..................................................... 1
37 066615 RIVET, Pop, .125" x .563"/.625" BSP-410................................... 2
38 067320 LABEL, Table Position ................................................................. 1
39 067348 TOP, Fowler ................................................................................. 1
40 067352 RIVET, Pop, 3/16"........................................................................ 8
41 067310 TOP, Foot End ............................................................................. 1
42 052046 CLIP, Cable.................................................................................. 2
43 069362 TUBE, Roller – Head ................................................................... 2
44 069097 STABILIZER, Shaft ...................................................................... 2
45 031115 SCREW, Hex Head Cap, 1/4-20 x 2-1/4" Long ........................... 2
46 068464 COLLAR, Shaft, 3/4" .................................................................... 4
47 000848 PLATFORM.................................................................................. 6
48 000849 TIE, Cable .................................................................................... 6
49 062128 SCREW, Button Head Cap, 1/4-20 x 1-1/4" Long ...................... 10
50 031054 NUT ,1/4-20 ................................................................................. 2
51 069361 HEAD, Stop Tube ........................................................................ 2
52 068114 RIVET, Drive ................................................................................ 10
continued on next page

6-7
Recommended Replacement Parts Operator Manual 150830-331
S
V
CDESCRIPTION
FIG. &
ITEM
NO.
PART
NUMBER UNITS PER
ASSEMBLY
6-2- MODEL RPC – FLUORO TRACK ASSEMBLY (CONTINUED) . X
53 068469 CROSSTUBE............................................................................... 2
54 069363 ASSEMBLY, Roller Head, Left..................................................... 2
55 069364 ASSEMBLY, Roller Head, Right Pointer...................................... 1
56 069365 ASSEMBLY, Roller Foot, Left ...................................................... 1
57 069366 ASSEMBLY, Roller Foot, Right.................................................... 1
58 069360 TUBE, Stop Foot .......................................................................... 2
59 069369 BUSHING, Roller .312" ................................................................ 2
60 067332 LABEL, Table Lock ...................................................................... 1
61 065728 SUPPORT, Fowler ....................................................................... 2
62 035122 SCREW, Hex Head Cap, 1/4-20 X 1-5/8" Long.......................... 12

6-8
150830-331 Operator Manual Recommended Replacement Parts
Figure 6-3. Horizon Fluoro Base Assembly
53
56
12
51
25
29
24
28 22
21
23
14
34
31
54
52
57 59
41
58
27
35
48
33
35
47
60
45
19
20
40
39
37
12
10
36
45 17
7
96
44
15
64
11
13
32
4
5
8
9
2
27
1
49 50 66
34
38
42 25
24
62
39
31
13
3
51
23
29
28
26
10
62
43
33
63
16
21
30
20
21
20
37
45
63
67
46
15
46
NOTE:
1. Unless otherwise specified:
For all moving and sliding locations - apply petroleum jelly lubricant.
Apply oil to Items 24, 27, 41 & 47.
Apply Never-Seize to Item 42.
2. For all threaded areas (which do not have a built in thread locking mechanism), apply removable
thread locker to male threads. Apply permanent thread locker to threads of Item 64.
64
65

6-9
Recommended Replacement Parts Operator Manual 150830-331
S
V
CDESCRIPTION
FIG. &
ITEM
NO.
PART
NUMBER UNITS PER
ASSEMBLY
6-3 HORIZON FLUORO BASE ASSEMBLY .................................... X
1 068553 ASSEMBLY, Base Frame ............................................................ 1
2 062672 CASTER, Tente, Brake................................................................ 3
3 062671 CASTER, Tente, Swivel Lock ...................................................... 1
4 062659 PLATE, Caster Dolt Lock ............................................................. 4
5 062685 SCREW, Hex Head Cap, M8 x 1.25 X 12.00" Lg. ....................... 8
6 065041 BOLT Eye, 5/16-18 ...................................................................... 4
7 031058 NUT, Free Thread, 5/16............................................................... 4
8 031080 WASHER, Flat, 5/16 .................................................................... 6
9 031057 NUT, Lock, 5/16-18...................................................................... 1
10 052041 SCREW, Socket Set, #10-52 x 1/4" Lg........................................ 5
11 068551 ROD, Hex Brake .......................................................................... 2
12 066507 ASSEMBLY, Left Brake Pedal ..................................................... 2
13 066508 ASSEMBLY, Right Brake Pedal .................................................. 2
14 069478 PLATE, Jack Mounting Reinforcement........................................ 4
15 011422 COLLAR, Worm ........................................................................... 8
16 068207 JACK Hydraulic, Foot End ........................................................... 1
17 068209 JACK Hydraulic, Head End.......................................................... 1
18 035122 SCREW, Hex Head Cap, 1/4-20 x 1 5/8" Lg. .............................. 4
19 031337 SCREW, Hex Head Cap, 1/4-20 x 3/4" Lg. ................................. 4
20 031076 WASHER, Flat, USS, 1/4"............................................................ 10
21 031055 NUT, Lock, 1/4-20........................................................................ 14
22 066617 BOLT, Shoulder, 5/16" x 1-1/4" Lg. ............................................. 1
23 075242 LINK, Horizon Long Jack, End Control ........................................ 1
24 068455 NYLINER, 5/16" ........................................................................... 8
25 068371 PEDAL, To Link Connector.......................................................... 2
26 068345 ASSEMBLY, Pump Pedal ............................................................ 1
27 068126 NYLINER, 1/2" ............................................................................. 8
28 068379 BAR, Pump Pedal Hinge.............................................................. 2
29 031102 SCREW, Knurled Point Set, 1/4-20 x 1/4" Lg. ............................. 4
30 068355 ANGLE, Verticle Guide ................................................................ 1
31 069417 CUP, Rue, 5/16" .......................................................................... 3
32 065418 NYLINER, Type 7, 1/4" ................................................................ 2
33 031006 SCREW, Hex Head Cap, 1/4-20 x 1-1/2" Lg. .............................. 2
34 031321 SCREW, Hex Head Cap, 1/4-20 x 2" Lg. .................................... 9
35 031054 NUT, Free Thread, 1/4-20 ........................................................... 5
36 066705 BUMPER, Stop ............................................................................ 1
37 068374 LINK, Head End Release............................................................. 1
38 068375 LINK, Foot End Release .............................................................. 1
39 068378 COLLAR, Stop ............................................................................. 8
40 068128 SPRING, Long, 1-17/32".............................................................. 4
41 051308 NYLINER, 3/4" ............................................................................. 4
42 069481 BRACKET, Axle Bearing.............................................................. 2
43 068377 PLATE, Push ............................................................................... 2
44 068890 SCREW, Hex Head Cap, #10-32 x 1/2" Lg. ................................ 1
45 068380 TAPE, Teflon, 3/4" x 1-1/2" .......................................................... 4
46 068381 TAPE, Teflon, 1 2" x 3/4" ............................................................. 2
47 068530 WASHER, Nylon Shoulder .......................................................... 2
48 031371 GRIPRING, .250 .......................................................................... 2
49 062378 CHAIN, Anti-Static ....................................................................... 1
50 031416 SCREW, Self Tapping, Type A, #10-32 x 1/2" Lg. ...................... 1
51 035115 WASHER, Nylon, 5/16"................................................................ 3
continued on next page
