STM MINI-ROCKETBOX CANNA User manual

MINI-
ROCKETBOX
USER MANUAL
™

MINI-
ROCKETBOX
Sesh Technologies Manufacturing, Inc.
3223 North Market Street, Spokane, WA 99207
Phone: [phone] | Web: www.stmcanna.com
View Training Videos at -https://bit.ly/2TKwmR3
USER MANUAL
™

TABLE OF CONTENTS
Components
Technical Specifications
Getting Started
Break-In Procedure
Suction Cup Mounting
Density Testing
Loading & Unloading Cones
PoweringOnthe Mini-Rocketbox
Good Practices
Using the Mini-Rocketbox
Cleaning & Maintenance
Troubleshooting
Terms of Business
Notes
PAGE 2
PAGE 3
PAGE 4
PAGE 5
PAGE 6
PAGE 6
PAGE 7
PAGE 7
PAGE 8
PAGE 9
PAGE 10
PAGE 11
PAGE 12
PAGE 17
PAGE 1 © JUNE 2020 STM CANNA ™

PAGE 2 © JUNE 2020 STM CANNA ™
COMPONENTS
Top Tray1.
2. Bottom Tray
3. Wing Nuts
4. Loading Box
5. Finishing Base
Top Tray - Meters material into cones
Bottom Tray - Holds the cones
Wing Nuts - Locks tray in place (two)
Loading Box - Holds bottom tray for cone loading
Finishing base - Holds bottom tray for cone unloading
1.
2.
3.
4.
5.
Video: Components - https://bit.ly/3dm3mYk

PAGE 3 © JUNE 2020 STM CANNA ™
MATERIALS
ASSEMBLY
POWER
WEIGHT &
DIMENSIONS
Encased in SAE 304 Stainless Steel
Aluminum & Other Food Grade Components
Designed, Manufactured, & Assembled in the USA
Standard 110V | 0.8 HP Motor | Full-Load 5.2 Amps
5-1/2 ft. Cord Length
Approximately 35 lbs
Machine Dimensions 14" L x 17" H x 10" W
MINI-ROCKETBOX ™
TECHNICAL SPECIFICATIONS
SOFTWARE &
UPGRADES
Manual Control Panel
COMPLIANCE
UL-Listed Components
100% Food Grade (Clean & Safe to Use)
PAPER
COMPATIBILITY
Compatible with Industry Standard King Size 1 gram
(109mm), 1-1/4 (98mm) size for 1/2 gram (84mm) cones
VOLUME
CAPACITY
143 Pre-Roll Joints per Run
OPERATION
Fixed Leveling System
(Cones remain suspended in air inside machine
as to not damage of bend the filters)
WARRANTY &
LIFE CYCLE
1-Year Parts & Labor Warranty
Motor 10 Year Life Cycle

PAGE 4 © JUNE 2020 STM CANNA ™
GETTING STARTED
PREPARING YOUR WORK AREA
The space needed for pre-roll production varies based on volume
needed. See Technical Specifications (page 3) for power requirements
and other details.
RECOMMENDED AREAS FOR A SMOOTH WORKFLOW
Grinding Area - for prepping material going into the Mini-Rocketbox ™
Loading Area - dedicated to loading cones into empty bottom trays
Machine Area - for trained person(s) to operate the Mini-Rocketbox ™
Closing/Packing Area - dedicated to the final process of closing and
packaging cones
SUGGESTED TOOLS & ACCESSORIES
Scoop for placing material on machine to begin cycle
Ballast or secure table to wall or floor for vibration
Food-grade stainless steel tables
One-gallon shop vac (or small vacuum)
Collection Bin for holding the top tray after taking out of machine
Scale to use for density testing
70%+ Isopropyl alcohol spray bottle for cleaning
Sheet pans and sheet pan rack for storage
Microfiber cloth for wiping down machine during cleaning
Stainless steel chopsticks or other tool for closing pre-rolls

Thanks for being a valuable and loyal client of STM. Our goal is to bring
our customers the very best in product quality and customer service. We
deeply value your feedback as this is how we consider what to improve
and or update in our existing products.
Please be advised that the Mini-Rocketbox ™ has a direct funneling
system into your selected pre-rolls when used properly.
What this means is that contaminate free material being funneled from
the top trays into your pre-rolls will remain contaminate free through
the direct filling process. The Top Tray funnels are directly inserted into
the openings of your pre-roll cones and do not allow anything other than
what is being fed onto the Top Tray.
After you have set up your Mini-Rocketbox ™ , proceed to run
multiple cycles (at least 5 per set of trays for 2 minutes each cycle).
Run the machine 1 minute on medium and 1 minute on high with
each of your tray systems and watch for debris in between the trays
and in the bottom of the shaker box.
Visual inspection should always remain part of the operation of your
Mini-Rocketbox ™ .
PAGE 5 © JUNE 2020 STM CANNA ™
BREAK-IN PROCEDURE
Do not reclaim any material that has fallen
past the trays and into the shaker box.

The Mini-Rocketbox ™ has a powerful suction cup located on the
bottom of the unit. The suction cup is used to keep the machine secure
and stable during operation. Onlyuse the Mini-Rocketbox ™ on a level,
flat surface such as a stainless steel table. This is important for the
overall success of your process.
PAGE 6 © JUNE 2020 STM CANNA ™
SUCTION CUP MOUNTING
DENSITY TESTING
It's good practice to perform density testing for each strain
so consistent weights and results are achieved.
MOUNT & REMOVE SUCTION CUP
Use the unit on a solid, flat surface such as a stainless steel table.
STEP 1:
STEP 2:
STEP 3:
Clean surface with alcohol. Place unit on table.
Press white button on suction cup continuously until the
button stays depressed to the red line.
STEP 4:
To remove suction cup, pry away rubber edge of the cup.
Tare a 10ml beaker on a scale.
STEP 1:
STEP 2:
STEP 3:
Fill a 10ml beaker full of ground up material.
Vibrate it in the Mini-Rocketbox for about 30-60 seconds.
STEP 4:
Either fill again up to the 10ml mark or remove material
until it's at the 10ml level (vibrate again if adding more).
STEP 5:
Weight the beaker and move the decimal to the left one spot.
Video: Density Information -https://bit.ly/2z5xbNJ

PAGE 7 © JUNE 2020 STM CANNA ™
LOADING/UNLOADING CONES
Load cones into bottom tray.
STEP 1:
STEP 2:
STEP 3:
Carefully and evenly, add top tray using
guide pins on bottom tray.
LOADING CONES
UNLOADING CONES
POWERING ON MINI-ROCKETBOX
Plug three-prong cord into a standard 110v/20amp wall outlet.
Press the orange button to the ON position.
STEP 1:
STEP 2:
TURNING ON THE MINI-ROCKETBOX ™
Place bottom tray in loading box.
Remove trays and place into machine.
STEP 4:
Secure tray in place with 2 wing nuts.
STEP 5:
Power OFF the Mini-Rocketbox ™ .
Remove 2 wing nuts.
Lift tray out with handles.
STEP 1:
STEP 2:
STEP 3:
Set straight down onto finishing base.
STEP 4:
Remove cones and close.
STEP 5:
Video: Loading Cones - https://bit.ly/2L5Wkee
Video: Closing Cones -https://bit.ly/2xk5gcB

Make sure to use high-quality cones such as Hara, Raw, or
Elements. Visit stmcanna.com/store to purchase cones exclusively
for the Mini-Rocketbox ™ .
Please refer to Density Chart for desired weight and results. It is
recommended to first test various grinds using the 'sample' presets
on the touch screen prior to adjusting settings. You can find the
Density chart and information here -bit.ly/2z5xbNJ
For best results, material should not be ground too finely (like
powder) or too coarse. 4.5mm - 5.5mm is typically the optimal
particle size for pre-rolls.
Mix product well before placing onto machine. Remove any visible
seeds and stems in advance.
PAGE 8 © JUNE 2020 STM CANNA ™
0.5g (84mm) - BOTTOM TRAY
Industry standard 84mm
1g (109mm) - BOTTOM TRAY
Industry standard 109mm King Size
0.7g (98mm) - BOTTOM TRAY
Industry standard 98mm
Please be aware that the following cone sizes are not compatible: "Reefer",
"98MM Regular", "Slim", "Cigarette/Tube", "Fatboy", or "Party Size". More
information in the STM Client Portal.
Video: Paper Selection -https://bit.ly/2W6OMOr
GOOD PRACTICES

USING THE MINI-ROCKETBOX
PAGE 9 © JUNE 2020 STM CANNA ™
How to use the Mini-Rocketbox ™
Load tray into machine, tighten wing nuts, then power ON.
STEP 1:
Turn knob to around Medium setting.
Add material onto top tray, filling and spreading evenly
to all cones.
The total average run time is 40 seconds. If material drops
further, add more. Top tray cones should be filled to the top.
Turn dial to HIGH for full power final pack for the last 10-15
seconds. May require a little longer for light, fluffy strains.
Turn power OFF.
Remove wing nuts and washers.
Set tray straight down and evenly on finishing base.
Remove top tray. Reclaim any material on top tray to reuse.
Remove cones and close with preferred method (video on page 7 )
STEP 2:
STEP 3:
STEP 4:
STEP 5:
STEP 6:
STEP 7:
STEP 8:
STEP 9:
STEP 10:
Video: Full Operation of Mini - https://bit.ly/2SH7mKZ

PAGE 10 © JUNE 2020 STM CANNA ™
CLEANING & MAINTENANCE
Each tray may be separated and cleaned using regular soap and
water and rinsing off, removing all residue. Be sure to dry
thoroughly as calcium from water can remain on tray.
To clean stainless steel, use isopropyl alcohol and a soft cloth. Wet
the rag with the isopropyl alcohol and wipe down all areas
thoroughly.
If there is any material left inside which is deemed unusable, scoop
out or vacuum the material and discard.
Clean as often as needed or required. Set the Mini-Rocketbox ™ on
regular cleaning schedule, dependent on use and materials.
WARNING: Do not remove plastic cones from top or bottom
tray, you may risk voiding your warranty
Video: Cleaning the Mini - https://bit.ly/2WvjXSD

TROUBLESHOOTING
PAGE 11 © JUNE 2020 STM CANNA ™
Mini-Rocketbox ™ will not power on
Make sure power button cord is plugged in and power outlet is functional.
Next, make sure orange button is in the ON position. If the unit will still
not power on, please contact Client Services at [phone] or by e-
mail at [e-mail]
Suction cup loses pressure
Make sure surface area is flat and clean. Prep and clean with isopropyl
alcohol first. Place Mini-Rocketbox ™ on clean, flat table and press white
button continuously to make sure suction cup is fully pressurized for the
best hold.
Can I purchase cones from STM?
Yes, please visit stmcanna.com/store to purchase cones exclusively for the
Rocketbox ™ product line and STM clients.
NOTE: Please visit the STM Client Portal - http://bit.ly/2mrR0sA
to view all Frequently Asked Questions.
Top tray is clogging during filling stage
It's important to dust material lightly onto the top tray to prevent clogging.
If the top tray clogs, a paper clip or a chop stick may be used to unclog
material.

PAGE 12 © JUNE 2020 STM CANNA ™
TERMS OF BUSINESS
All STM systems carry a non-transferable, limited one-year warranty
against defects in workmanship and/or materials.
Who is covered?
Please note that results with STM processing equipment vary widely and
depend on a myriad of factors, including but not limited to: correct grind
size, age of material, quality of material, moisture content, strain,
temperature, correct sized cone usage, quality of cones used, skill of the
operator, and more. Our quoted weight ranges for flower and trim are all
general averages that have been reported to us by our customers, however
your material may behave differently. We take no responsibility for your
results, only for the working functionality of our products. If you have any
questions or concerns regarding this disclaimer, please do not hesitate to
contact us.
What voids the warranty?
Abuse, misuse, improper installation and modifications.
Custom applications.
No proof of purchase at the time of warranty. Claimant must provide
proof of purchase, warranty card, and a warranty authorization number
(RMA) obtained from STM.
Finishes such as plating or painted surfaces with discoloration or rust
due to inclement weather conditions, exposure to salt, exposure to
chemicals, or lack of maintenance by the customer are not covered.
International grey-market product purchased through a
dealer/distributor not authorized for your country will not be supported
by this warranty.
Electrical parts are not covered under warranty.

PAGE 13 © JUNE 2020 STM CANNA ™
Extent of Warranty
Any STM system properly returned to STM will be repaired or replaced by
STM. STM is not responsible for any other expense incurred by the
customer under the terms of this limited warranty, nor is STM responsible
for any damages either consequential, incidental, special, contingent or
otherwise; or expenses or injury arising directly or indirectly from the use of
the STM system purchased. Any system returned to STM must be sent at
the customers expense along with the proof of purchase and warranty
authorization (RMA). STM reserves the right to determine whether the
terms of the warranty, set out above, have been properly followed. In the
event that the terms are not followed this warranty is void.
STM is the sole determiner of abuse, misuse, installation errors and
modifications - should any of these be found, this warranty is void. The
duration of any and all implied warranties are limited to the duration of the
express warranty. All incidental or consequential damages are hearby
excluded. The warranty gives you specific legal rights and you may have
other rights, which vary from state to state. Some states do not allow the
exclusion or limitation of incidental or consequential damages or limitations
on how long an implied warranty lasts, so the above limitations and
exclusions may not apply to you. Warranty only applies to original owner of
the machine. Warranties cannot be transferred.
For international customers, please contact your client services
representatives regarding warranties.
TERMS OF BUSINESS

PAGE 14 © JUNE 2020 STM CANNA ™
TERMS OF BUSINESS
If You Have a Problem:
If you have a problem, or are missing a part, please double-check this
trouble shooting guide first:
1. Reference your instruction sheet and double-check all instructions
2. Always take time to examine problems in detail.
3. When all else fails, call our technical support line at [phone]:
The technical line is open 9:00am - 3:00pm, Monday through Friday,
Pacific Time.
Please have the following information handy: Name of Company the
purchase was made under, Date of Purchase, and Serial number.
Terms:
All orders will be shipped COD (Cash on Delivery) unless other
arrangements have been made. STM reserves the right to specify collection
by certified check, money order, or company check. Personal checks are
not accepted.
Shipping:
All orders are FOB Spokane, Washington. Orders received will fall in line
and be serviced accordingly where the shipment date may be sooner than
originally quoted. We will ship by the most reasonable means based on the
volume of the order, unless otherwise specified.

PAGE 15 © JUNE 2020 STM CANNA ™
TERMS OF BUSINESS
Special Orders
All special-order items must be paid in full before the order is placed. These
items are non-returnable and no refund will be given. All special-order
items will also take a longer period of time for the customer to receive,
which will be quoted at the time of payment.
Liability
The purchaser of any parts releases the manufacturer of those parts and
STM from all liabilities pertaining to use of the parts. The purchaser
recognizes that any alteration or modifications to any STM system may
increase the risk of accident and/or injury and may also render the machine
inoperable.
Returns
No Refunds/Exchanges: We do not accept returns or exchanges unless the
item purchased is defective. All items that we ship are insured; if an item
arrives damaged from shipping,we will work closely with you to get your
replacement parts as soon as possible.We may also request pictures or
other identifying information to establish the damage that was caused by
the shipping carrier. If you receive an item you believe is defective, please
contact us with details of the product at [phone] or email:
[e-mail].

PAGE 16 © JUNE 2020 STM CANNA ™
We may ask you for pictures, video, descriptions, and other identifying
information to make a determination. If you are unable to provide adequate
documentation requested, your return request will be denied. If your item
is deemed defective, which is solely at STM ’ s discretion, we will issue you an
RMA # which you will need to place in and on the package. After receiving
your RMA #, you may send the item to:
Sesh Technologies Manufacturing
3223 North Market St.
Spokane, WA 99207
Upon receipt of the returned product, we will fully examine it and notify
you via e-mail, within a reasonable period of time, whether you are entitled
to a replacement as a result of the defect. If you are entitled to a
replacement, we will replace the product at no additional cost to you.
Claims
Since ownership of product transfers at the FOB point, claims for
damaged, lost, or short shipments must be made at the time of receipt.
Technical Questions
See your local dealer or contact Technical Support directly at (509) 204-
3164 or email to [e-mail].
TERMS OF BUSINESS

NOTES
PAGE 17 © JUNE 2020 STM CANNA ™
