Mushroom
Installation and Maintenance
Instructions
IMPORTANT: All wiring connections must be made before switching on mains power.
European Conformity
Please retain these instructions for future reference
This product should not be disposed of in your general waste
Class III - Extra Low Voltage
Indoor Use Only
IP20
5 x MSL Star - 14.25VF7.1W (Total) @ 500mA
Mushroom.pdf 1 02/06/2020 09:07:29

Electrical Supply
Installation must be carried out by a qualified electrician in
accordance with BS 7671:2008 Wiring Regulations.
230/240V AC 50/60Hz mains supply to a suitable SELV
LED Driver.
Site conditions: LED equipment is more susceptible to
static damage and overvoltage than previous technology.
Before handling or connecting to the mains supply ensure
that all MSL products are protected from static discharge
and that the mains supply is to regulation. (230V +10
-6%)
Mains cables must be double insulated, strain relieved
and separated from E.L.V output cables.
This unit requires a constant current driver set at 500mA
Max.
Observe polarity:
Positive (+) is marked as RED.
Incorrect supply or reverse polarity can cause irreparable
damage.
All connections must be made before switching on mains.
If the supply is energised prior to making the connections
to the fitting then the resulting surge will damage the LED.
Multiple LEDs should be wired in series, refer to driver
instructions for minimum/maximum load. Power per fitting
is 8W, forward voltage is 15V. Observe volt drop and
ensure total voltage is within drivers maximum voltage.
All lighting equipment is delicate and easily damaged
through misuse or inappropriate installation (mechanical
or electrical). Repairs and replacements may cause
delays and will be chargeable. Contact MSL for support if
required. For full warranty terms & conditions please visit
our website.
The IP rating stated is applicable only when the fitting has
been installed as per these instructions.
The light source contained in this luminaire shall only be
replaced by the manufacturer or his service agent or a
similar qualified person.
Ensure supply driver and connectors are housed indoors
OR in a suitably IP rated enclosure. Cable ends must be
suitably waterproofed. Inspect supply cables before
installation to ensure there is no damage which will allow
water to enter the fitting.
Installation
Check that the ground is suitable for the installation of
this fitting. For hard ground some preparation may be
required for spike installation.
Step 1 Make mains connections to SELV LED driver
and low voltage connections to the fitting.
Step 2 Push the spike on the fitting into the ground
until it stands securely. Do not apply force to
the head when placing in the ground.
Once the fitting is installed take care to ensure that the
cable from the fitting is suitably positioned and
protected from accidental damage.
After opening the sealed portion of the luminaire for
any reason, MSL recommends running the fitting for
15 minutes with the lid open to expel moisture before
closing it up. This will prevent condensation on the
lens and protect the fitting from corrosion.
Care must be taken when handling any ingress
protection seals, glands or "O" rings to ensure they
are kept clean, unblemished and replaced exactly in
their required location and suitably fastened home.
WARNING: Do not look at exposed LED lamps in
operation. Eye injury can result.
Cleaning:
Fully isolate the fitting and allow to cool.
Clean the fitting with a slightly damp lint free cloth
from a mild solution of soap and water. The fitting
must be completely dry before reconnecting power.
Incompatible or abrasive chemicals can damage the
fitting, contact MSL for advice if required.
Mushroom.pdf 2 02/06/2020 09:07:29

From 500mA
LED driver 230/240V Supply
LED Driver
Soft ground
Outdoor Indoor/Dry environment
Mushroom.pdf 3 02/06/2020 09:07:29

WIRING IN SERIES
These connectors can also be supplied in a 4-pole version which allows for series wiring.
Observe polarity:
Positive (+) is marked as RED.
Incorrect supply or reverse polarity can cause irreparable damage.
All connections must be made before switching on mains.
Ensure supply drivers are housed indoors OR in a suitably IP rated enclosure.
TH391 TEETUBE Connector
3Tighten the body section first before sliding the
bung into position and tightening the gland.
1st
2nd
2
Bridge terminals 2 & 3
on the fitting side.
1
4
2
3
4
1
3
2
From LED driver or previous connector
To next fitting/connector
To complete the series
circuit. On the final fitting
Wire +to 1 and - to 4.
4
1
3
2
Suitable for wire 0.5-2.5mm²
