Mini Module
Installation and Maintenance
Instructions
IMPORTANT: All wiring connections must be made before switching on mains power.
European Conformity
Please retain these instructions for future reference
This product should not be disposed of in your general waste
Class III - Extra Low Voltage
IP65 Protected against low power jets of water.
MSL Type S 2.85VF1.4W @ 500mA
Mini Module.pdf 1 11/12/2019 17:27:43

Electrical Supply
Installation must be carried out by a qualified electrician in
accordance with BS 7671:2008 Wiring Regulations.
230/240V AC 50/60Hz mains supply to a suitable SELV
LED Driver.
Site conditions: LED equipment is more susceptible to
static damage and overvoltage than previous technology.
Before handling or connecting to the mains supply ensure
that all MSL products are protected from static discharge
and that the mains supply is to regulation. (230V +10
-6%)
Mains cables must be double insulated, strain relieved
and separated from E.L.V output cables.
This unit requires a constant current driver. 500mA Max.
Observe polarity:
Positive (+) is marked as RED.
Incorrect supply or reverse polarity can cause irreparable
damage.
All connections must be made before switching on mains.
If the supply is energised prior to making the connections
to the fitting then the resulting surge will damage the LED.
Multiple LEDs should be wired in series, refer to driver
instructions for minimum/maximum load.
All lighting equipment is delicate and easily damaged
through misuse or inappropriate installation (mechanical
or electrical). Repairs and replacements may cause
delays and will be chargeable. Contact MSL for support if
required. For full warranty terms & conditions please visit
our website.
The IP rating stated is applicable only when the fitting has
been installed as per these instructions.
The light source contained in this luminaire shall only be
replaced by the manufacturer or his service agent or a
similar qualified person.
The entire dimming control circuit source must be of SELV
insulation class.
Ensure supply driver and connectors are housed indoors
OR in a suitably IP rated enclosure.
Installation
Check that the mounting surface is suitable for the
installation of this fitting.
Step 1 Make mains connections to SELV LED driver
and extra low voltage connections to the
fitting.
Step 2 Secure the fitting to the mounting surface
using the appropriate fixings method;
1 Secure using M3 fixing only if the magnet
is not fitted.
2 Secure using magnet to suitable magnetic
surface.
3 Secure to a suitable surface using silicone
or similar.
After opening the sealed portion of the luminaire for
any reason, MSL recommends running the fitting for
15 minutes with the lid open to expel moisture before
closing it up. This will prevent condensation on the
lens and protect the fitting from corrosion.
WARNING: Do not look at exposed LED lamps in
operation. Eye injury can result.
Cleaning:
Fully isolate the fitting and allow to cool.
Clean the fitting with a slightly damp lint free cloth
from a mild solution of soap and water. The fitting
must be completely dry before reconnecting power.
Incompatible or abrasive chemicals can damage the
fitting, contact MSL for advice if required.
Mini Module.pdf 2 11/12/2019 17:27:43

1
2
3
magnetic surface
Silicon or similar
Suitable fixing
Bezel
Optic
Retaining collar
Body
OPTIC CHANGE
To change the optic unscrew the front bezel, remove the
black lens retaining collar and let the optic drop out.
Repeat the process in reverse to fit the new optic.
Warning - Failure to tighten the bezel fully may result in
premature failure of fitting.
After opening the sealed portion of the luminaire for any
reason, MSL recommends running the fitting for 15
minutes with the lid open to expel moisture before closing
it up. This will prevent condensation on the lens and
protect the fitting from corrosion.
WARNING: Do not look at exposed LED lamps in
operation. Eye injury can result.
Ø17mm
Mini Module.pdf 3 11/12/2019 17:27:43

Series Wiring
SUPPLY
Installation must be carried out by a qualified electrician in
accordance with BS 7671:2008 Wiring Regulations.
230/240V AC 50/60Hz mains supply.
Mains cables must be double insulated and strain relieved.
Observe polarity:
Positive (+) is marked as RED.
Incorrect supply or reverse polarity can cause irreparable damage.
All connections must be made before switching on mains.
Ensure supply driver and connectors are housed indoors OR in a
suitable IP rated enclosure.
Ensure LEDs are connected in ‘series’ as shown below to the LED
drivers.
Mains
Output +
-
LED
Driver
LED
LED
LED
LED
Use suitable
connectors
