Strong SRT 7511 User manual

Picture similar
www.strong-eu.com
User Manual
Bedienungsanleitung
DIGITALER HD
SATELLITEN RECEIVER
SRT 7511
* Angebot gültig für Neuanmeldungen eines simpli free Pakets. Die simpli more Testphase dauert mindestens 7 Tage
und endet automatisch. Für den Empfang der ORF-Programme ist eine kostenpflichtigeAnmeldung bei ORF DIGITAL
erforderlich. Aktuelle Senderlisten und sonstige Voraussetzungen für TV und Streaming auf simpliTV.at. Änderungen
und Irrtümer vorbehalten.
simpliTV.atHotline: 0800 96 97 98
... und viele mehr!
Geeignet für:
SAT
Auszug aus der simpli more Senderliste.
Jetzt
simplimore
gratis
testen*
Mehr Sender in HD!
Kostenloses simpli free Paket anmelden und simplimore
gratis testen – für noch mehr Sendervielfalt in HD.
Mit dabei: die simpliTV App.

17 Oct 2023 15:50
www.strong-eu.com
Supplied by STRONG Austria
Represented by STRONG Ges.m.b.H.
Teinfaltstraße 8/4. Stock
1010 Vienna, Austria
Email: [e-mail]

1
SIMPLIFIED EU DECLARATION OF CONFORMITY
Hereby, STRONG declares that the SRT 7511 is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address: https://eu.strong-eu.com/downloads/
Subject to alterations. In consequence of continuous research and development technical specications, design and appearance of products may change.
Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio and the double-D symbol are trademarks of Dolby Laboratories. The terms HDMI, HDMI
High-Denition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. ASTRA is a registered
trademark of SES ASTRA, Irdeto is a registered trademark of Irdeto Access B.V. All product names are trademarks or registered trademarks of their respective
owners.
© STRONG 2023. All rights reserved.
Licenses
This product contains one or more programs protected under international and U.S. copyright laws as
unpublished works. They are condential and proprietary to Dolby Laboratories. Their reproduction
or disclosure, in whole or in part, or the production of derivative works therefrom without the express
permission of Dolby Laboratories is prohibited. Copyright 2003-2009 by Dolby Laboratories. All rights
reserved.

2
TABLE OF CONTENTS
1. INTRODUCTION 4
1.1 Safety Instructions 4
1.2 Storage 5
1.3 Equipment Set-up 5
1.4 Accessories 5
1.5 Usage of external USB devices 5
2. YOUR RECEIVER 6
2.1 DEFAULT PIN-CODE: 0000 6
2.2 Front Panel 6
2.3 Side Panel 6
2.4 Rear Panel 6
2.5 Remote Control 7
2.6 Inserting the batteries 8
2.7 Using the remote control 9
3. CONNECTIONS 10
3.1 Connection via HDMI or SCART 10
3.2 Optional connection via DiSEqC 1.0 switch for up to 4 LNBs 10
3.3 Connection to the Internet for RSS feeds and weather forecasts 11
3.4 Extended connections for the home entertainment 11
4. STARTING UP FOR THE FIRST TIME 12
4.1 Language and Video Settings 12
4.2 Antenna Setup 12
4.3 Channel list selection 13
4.4 Regional Channels 13
5. QUICK GUIDE TO USING YOUR RECEIVER 13
6. OPERATION 14
6.1 Changing channels 14
6.1.1 Direct access 14
6.1.2 Channel list 14
6.1.3 Using the CH+/CH- buttons 14
6.1.4 Using the 9button 15
6.2 Info Banner 15
6.3 Selection of audio language 15
6.4 Teletext 15
6.5 Subtitles 15
6.6 Changing the video settings 16
6.7 EPG (Electronic Programme Guide) 16

3
7. MAIN MENU 16
7.1 Installation 16
7.1.1 Antenna Setup 17
7.1.2 Motor Setting 17
7.1.3 Channel Search 18
7.1.3.1 Edit, add or delete transponders 19
7.1.4 Channel list selection 19
7.1.5 Factory Reset 19
7.2 Channels 20
7.2.1 TV Channel Manager 20
7.2.2 Radio Channel Manager 21
7.2.3 EPG (Electronic Programme Guide) 21
7.2.4 Parental Control 21
7.3 Settings 21
7.3.1 Language 21
7.3.2 System Settings 22
7.3.3 Time Settings 23
7.3.4 Timer 23
7.3.5 Receiver Information 23
7.4 Multimedia 23
7.4.1 Movies 24
7.4.2 Music 24
7.4.3 Pictures 24
7.5 Update 25
7.5.1 USB Software Update 25
7.5.2 OTA Software Update 25
7.5.3 Database backup to USB device 25
7.5.4 Recover database from USB device 25
7.6 CA Menu 26
7.6.1 Service Status 26
7.6.2 Loader Status 26
7.6.3 Product Status 26
7.6.4 Client Status 26
7.6.5 Mailbox 26
7.7 Network 26
7.7.1 RSS (Really Simple Syndication) 26
7.7.2 Weather 26
7.7.3 IP-Setting 27
A.1 TROUBLESHOOTING 27
A.2 TECHNICAL SPECIFICATIONS 28

4
1. INTRODUCTION
1.1 Safety Instructions
Read all of the instructions before operating the device. Keep these instructions well for later use.
Only use attachments/accessories specied or provided by the manufacturer (such as the exclusive
supply adapter, battery etc.).
Please refer to the information on the product enclosure for electrical and safety information before
installing or operating the apparatus.
To reduce the risk of re or electric shock, do not expose this apparatus to rain or moisture.
The ventilation should not be impeded by covering the ventilation openings with items, such as
newspaper, table-cloths, curtains, etc.
The apparatus shall not be exposed to dripping or splashing and no objects lled with liquids, such as
vases, shall be placed on the apparatus.
The mark indicates a risk of electric shock.
To prevent injury, this apparatus must be securely attached to the oor/wall in accordance with the
installation instructions.
Danger of explosion if the battery is incorrectly replaced. Replace only with the same or equivalent types.
The battery (battery or batteries or battery pack) shall not be exposed to excessive heat such as
sunshine, re or the like.
Excessive sound pressure from earphones and headphones can cause hearing loss.
Listening to music at high volume levels and for extended durations can damage one's hearing.
In order to reduce the risk of damage to hearing, one should lower the volume to a safe, comfortable
level, and reduce the amount of time listening at high levels.
The mains plug or appliance coupler is used as disconnect device, it shall remain readily operable.
When not in use and during movement, please take care of the power cord set, e.g. tie up the power
cord set with cable tie or something like that. It shall be free from sharp edges or similar which can
cause abrasion of the power cord set. When put into use again, please make sure the power cord is not
damaged. The absence of a light indication on the apparatus does not mean that it is fully disconnected
from the mains. To disconnect the apparatus completely, the mains plug must be pulled out.
Attention should be drawn to environmental aspects of battery disposal.
No naked ame sources, such as lighted candles, should be placed on the apparatus.
To prevent the spread of re, keep candles or other open ames away from this product at all times.
Equipment with this symbol is a Class II or double insulated electrical appliance. It has been
designed in such a way that it does not require a safety connection to electrical earth.
Precautions
Never try to open the device. It is dangerous to touch the inside of the device due to high voltages
and possible electrical hazards. Opening the device will void the warranty of the product. Refer all
maintenance or servicing to suitably qualied personnel.
When you are connecting cables, be sure that the device is disconnected from the mains supply
voltage. Wait a few seconds after switching o the device before you move the device or disconnect any
equipment.
It is a necessity that you only use an approved extension and compatible wiring that is suitable for the
electrical power consumption of the installed equipment. Please ensure that the electrical power supply
corresponds with the voltage on the electrical identication plate at the back of the device.
Operating Environment
Do not install this equipment in a conned space such as a bookcase or similar unit.
Do not use the set near damp, and cold areas, protect the set from overheating.

5
Keep away from direct sunlight.
Do not use the set near dust place.
Do not attach candle to accessible opening area, to avoid ammable foreign material from entering the
device.
WEEE Directive
WEEE
Correct Disposal of this product. This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of
material resources. To return your used device, please use the return and collection systems or contact the
retailer where the product was purchased. They can take this product for environmental safe recycling.
1.2 Storage
Your device has been carefully checked and packed before shipping. When unpacking it, make sure that
all the parts are included and keep the packaging away from children. We recommend that you keep
the carton during the warranty period, to keep your device perfectly protected in the event of repair or
warranty.
1.3 Equipment Set-up
We recommend you to consult a professional installer to set up your equipment. Otherwise, please follow
the instructions below:
Refer to the user manual of your TV and your antenna.
Make sure that the SCART/HDMI cable and outdoor components are in a good condition and the SCART/
HDMI connections are well shielded and from good quality.
This user manual provides complete instructions for installing and using this receiver. The following symbols
will serve as follows.
WARNING Indicates warning information.
NOTE Indicates any other additional important or helpful information.
MENU Represents a button on the remote control or the receiver.
Move to Represents a menu item within a screen.
1.4 Accessories
Installation instructions
1x remote control unit
2x batteries (AAA type)
1x power adapter 12 V DC, 1,5 A
WARNING: The batteries should not be recharged, disassembled, electrically short-circuited, be mixed
or used with other types of batteries. If rechargeable accumulators instead of batteries are
going to be used, we recommend using (e.g. NiMH) types with low self-discharge to ensure
long time operation of remote control.
1.5 Usage of external USB devices
It is recommended to use USB 2.0 or higher storage devices. If your device is not compatible to USB 2.0
specications, multimedia functions or software update might not work properly.
If you are going to use external USB HDD (Hard Disk Drive) please consider that it might be the case
that the power specications exceed the supported output of your receiver (5 V/500 mA). If so, please
connect your USB HDD to an according external power adapter.
STRONG cannot guarantee compatibility with all types of USB storage devices.

6
It is advised not to store important information on USB storage devices used with the receiver. Always
make backups of data on your USB storage device before using it with this receiver. STRONG will not take
responsibility for any loss of information or circumstances caused by loss of information.
For a proper performance with this receiver your USB device must be formatted to FAT32.
STRONG cannot guarantee the playback of all les although extensions are listed, as it depends on the
used le size, codec, bit rate and resolution.
2. YOUR RECEIVER
2.1 DEFAULT PIN-CODE: 0000
2.2 Front Panel
Fig. 1
1. Indicator LED GREEN indicates that the receiver is currently ON, RED indicates that the receiver is
currently in Standby mode.
2. IR Sensor Receives the RCU commands.
2.3 Side Panel
Fig.2
USB: To connect your USB storage device for multimedia functions or software update.
2.4 Rear Panel
Fig. 3
SAT IN
Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation.
2 3 4 5 6 7
1. SAT IN To connect to the LNB of your satellite antenna for reception of satellite broadcast
signal.
1 2

7
2. Ethernet To connect to to your home network via switch, router or modem.
3. S/PDIF (coax.) To connect to a digital amplier or home theatre set.
4. HDMI To connect to the HDMI input of your TV set using a good quality HDMI cable.
5. IR To connect the separately available IR extender.
6. TV SCART To optionally connect to your TV set using a SCART cable.
7. Power adapter To connect to the original included main power adapter (Input 100 ~240V 50~60Hz/
Output 12 V DC ).
2.5 Remote Control
Fig. 4
1
3
4
7
6
9
11
11
16
18
20
21
22
25
27
28
30
22
23
25
26
28
29
12
13
12
15
17
19
10
5
8
2
1. qSwitches the receiver On/Standby
2. !Mutes audio output of the receiver in every mode incl. videotext, the symbol will not
be shown within menu mode
3. 0~9 Channel selection or value input

8
4. TV/R Toggles between TV and RADIO mode
5. No function
6. FAV Opens the favourite list selection if previously congured
7. 9Opens the recently watched channel list or switches between the two last previously
watched channels*
8. AUDIO Opens the list of audio languages
9. INFO Shows the actual channel information (2x event info, 3x technical info)
10. EPG Opens the EPG (Electronic Programme Guide) in TV mode
11. pq Menu O: Change channel to next/previous. Menu On: Moves the cursor up/down
12. tu Menu O: Decreases/increases the volume level. Menu On: Change settings and
navigation in menu
13. OK Menu O: Displays the current channel list. Menu On: Opens the highlighted setting
or for conrmation. In Videotext mode: Changing the transparency in 3 stages
14. MENU Opens the main menu; Within the menu switches to TV mode
15. One step back from each menu or to cancel actions
16. VOL+/VOL- Increases/decreases the volume in all modes (with TV picture in BG/Videotext)
17. P+/P- Scroll page wise in all lists
18. LIST Opens the satellite list in TV mode. In EPG and Timer mode it opens the Timer list
19. CH+/CH- Channel up/down
20. OPT Opens the settings for TV format, aspect ratio and resolution
21. TEXT Opens the videotext if available
22. SUB Shows the list of DVB-subtitles if available
23. Gives direct access to mails from your broadcaster
24. 2In Multimedia mode: To pause the playback of a le
25. 5 6 In Multimedia mode: Fast rewind/Fast forward
26. 4No function
27. uIn Multimedia mode: Starts the playback of a selected le (Preview)
28. 7 8 In Multimedia mode: During playback to jump to the previous / next le
29. 3In Multimedia mode: Stops the playback of the selected le
30. RED In menu for specic functions
31. GREEN In menu for specic functions
32. YELLOW In menu for specic functions
33. BLUE In menu for specic functions
*Depending on the System setting Recent channel list settings; allows you to call the channel list with up to 30 recently watched channels
2.6 Inserting the batteries
Fig. 5
1. 3.
2.
Remove the battery cover from the remote control and put 2x AAA size batteries inside the compartment.
The diagram inside the battery compartment shows the correct way to install the batteries.
1. Open the cover 2. Install batteries 3. Close the cover

9
NOTE: The batteries must not be recharged, disassembled, electrically short-circuited, be mixed or
used with other types of batteries.
2.7 Using the remote control
Fig. 6
To use the remote control, point it towards the front of the digital receiver. The remote control has a range of
up to 7 metres from the receiver, if properly aligned towards the IR eye on the front panel.
The remote control will not operate if its path is blocked.
NOTE: Sunlight or very bright light might decrease the sensitivity of the remote control.

10
3. CONNECTIONS
3.1 Connection via HDMI or SCART
Fig. 7
SAT IN
Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation.
a) Connect the LNB of your satellite antenna to the SAT IN connector of your receiver using a good quality
coaxial cable and suitable ‘F-connector’ plugs.
b) Connect one end of a good quality HDMI cable to the HDMI connector of your receiver and the other end
to the HDMI input of your TV set.
c) Plug the power adapter jack to the receiver and the other end to a suitable wall outlet.
Optional: Connect one end of a good quality Scart cable to the TV SCART of your receiver and the other end
to the SCART input of your TV set.
3.2 Optional connection via DiSEqC 1.0 switch for up to 4 LNBs
Fig. 8
SAT IN
Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and the double-D symbol are tradem

11
a) Connect the LNBs of your xed antenna to the desired inputs of a DiSEqC 1.0 switch using a good quality
coaxial cable and suitable ‘F-connectors’.
b) Connect the output or “to receiver” of the DiSEqC 1.0 switch to the SAT IN connector on your receiver
using a good quality coaxial cable and suitable ‘F-connectors’.
c) Plug the power adapter jack to the receiver and the other end to a suitable wall outlet.
3.3 Connection to the Internet for RSS feeds and weather forecasts
Fig. 9
SAT IN
Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and the double-D symbol are trademarks
To use RSS feeds and weather forecast, the receiver must be connected to the Internet. Connect the
Ethernet (RJ-45) connector at least with a class CAT5E cable to your router/switch/Extender or similar
applicable equipment, which provides access to the Internet.
3.4 Extended connections for the home entertainment
Fig. 10
SAT IN
Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation.

12
Connecting to a Digital Audio Amplier with S/PDIF
By connecting your receiver to a digital amplier or home theatre system, you can enjoy the best possible
sound quality and multi-channel audio (depending on broadcast). Connect your Digital Audio Amplier or
home theatre system with a suitable cinch cable to the S/PDIF connector on the back of the receiver
Connecting to a digital audio amplier and TV using HDMI
If you want to connect your home theater, amplier or AV receiver using HDMI, connect one end of a high-
quality HDMI cable to the HDMI connector on your receiver and the other end to the HDMI input on your
digital audio device.
The HDMI output of the digital audio device is then connected to the TV with another high-quality HDMI
cable. Select the appropriate input on your digital audio device as well as on the TV to use high quality
audio and video signals.
4. STARTING UP FOR THE FIRST TIME
Ensure that your satellite signal is of good quality and that all connections are properly setup. In case of
diculties or questions, please ask your local dealer or service hotline for assistance. It is recommended to
follow the First Time Installation gradually. It will guide you through the basic installation and setup process.
You can enjoy digital HD broadcasts within just a few minutes. To enjoy the complete range of channels
and to watch your preferred scrambled services, please register with the enclosed registration form at ORF-
DIGITAL-DIREKT.
If you have further questions about your registration, you can directly contact the ORF-DIGITAL-Service-
Hotline [phone]). Please have your Device-ID (Gerätenummer) ready.
4.1 Language and Video Settings
After connecting your receiver for the rst time, the OSD Language, Aspect Ratio, Aspect Conversion and
HDMI Resolution menus will be shown. Change your language with tu and use pq to select the other
settings. For these settings, you can also use OK to show a list of available settings. Adjust the Aspect Ratio
according to your TV (4:3 for an analogue CTV set and 16:9 for your new at screen / HD TV) and select the
Conversion of your preference.
For HDMI Resolution the default setting 720p is recommended, but many TVs already support higher
resolutions. Therefore, you can choose 1080p.
NOTE: If you select an HDMI resolution which is not supported by your TV, the receiver will switch to
the previous setting automatically after ~10 sec. If you can see the displayed message, please
conrm the selected resolution by pressing OK.
During any stage of the First Time Installation, you can press BLUE Next to go to the next step or YELLOW
Previous to get back to the previous step.
4.2 Antenna Setup
This receiver is already adjusted for reception of Astra 19.2 satellite with the correct settings. Per default it
is setup for DiSEqC port 1, but you can use the setting as well if you are not connected to any switch. You
only need to change these settings if you are not connected to Astra 19.2 or this satellite is not connected to
port 1 of your DiSEqC switch. To adjust your antenna settings for the Satellite, LNB Power, LNB Type, LNB Freq,
DiSEqC 1.0 and Transponder correctly, use the tu and pq buttons.
For user convenience which have a multi dish installation, the Auto DiSEqC Scan* function is supported,
which can be activated by pressing the GREEN button.
For further details and information about the settings, see chapter 7.1.1 Antenna Setup.
In the First Time Installation, it is possible to adjust the settings for up to 4 satellite positions. To proceed
within the First Time Installation, use the BLUE Next button to follow the steps.

13
*This new function can recognise available satellites in the persisting antenna installation. The predened satellites are: Astra 19.2E, Astra 23.5E, Astra 28.2E,
HotBird 13.0E and Eutelsat 9.0E.
4.3 Channel list selection
In this menu, you can choose your channel list by pressing pq.
You can choose between ORF List, simpliTV List, Family List and Young Spirit, depending on your preferences
and subscription (an overview about the dierent channels can be found on our website www.strong-eu.
com).
In the ORF List you can nd mainly Austrian ORF HD channels, respectively the most popular and preferred
German and Austrian Free-To-Air TV channels in SD and HD.
The simpliTV List includes all ORF HD, Austrian private HD channels and those available with an additional
simpliTV SAT HD subscription. Additionally, it provides quick access to popular German and international
Free-to-Air channels. The simpliTV List will be maintained by the broadcaster. Individual changes can be
made if channels have been moved to favourite lists.
The Family list and Young Spirit provides a mixed selection of Austrian and German HD channels, but in
dierent sequences.
To continue with the rst-time installation, press the BLUE Next key.
4.4 Regional Channels
Use pq to decide which ORF2 HD channel should be placed at the 2nd position of the selected channel
list. Press OK to conrm.
After your regional channel is set, press the BLUE Next button to nish the rst-time installation. Your
receiver will execute the respective search and afterwards switches automatically to the 1st channel of your
selected list.
Details for a channel search can be found in the chapter 7.1.3 Channel search.
5. QUICK GUIDE TO USING YOUR RECEIVER
We at STRONG understand that you eagerly anticipate enjoying your new HD receiver. We do, however,
recommend reading the full manual to get the best performance of your STRONG HD receiver.
To switch your receiver ON or to Standby, use the qbutton on the remote control. Choose a channel with
pq or the CH+/CH- buttons. Alternatively, you can choose the channel number with the 0~9 buttons on
the remote control or press OK in viewing mode to display the channel list. The volume can be adjusted with
tu or the VOL+/VOL- buttons. The usage of VOL+/VOL- and !is possible in ALL menus which present
a TV picture in the background and can be used in the videotext mode additionally. P+/P- enables you to
scroll page wise in all lists, which allows you to select channels or other items as conveniently as possible.
To open the channel and programme* information, press the INFO button in viewing mode. In this state
it is possible to use tu to display channel and programme information about other channels without
switching channels, but however in this mode you can also switch to the selected channel by pressing OK.
Press INFO twice to display detailed programme information of the current or next programme. For the
current programme information use tu to change between the current and next event information. In the
respective programme information you can use P+/P- to scroll if applicable. If you press the button a third
time, technical details of this channel will be displayed. Press INFO or to close the information.
*Programme information are displayed in case of availability. Availability depends on the broadcast.

14
NOTE: 5 min after switching the receiver into Standby it will enter the deep sleep mode. Within this
time the receiver is able to start up quickly. Starting up from deep sleep takes approx. 35
seconds.
6. OPERATION
In viewing mode, several features are available to make watching TV a true pleasure. This chapter describes
these features. Please also read chapter 7.0 to get familiar with the menu of your new receiver.
6.1 Changing channels
Your new receiver is equipped with three ways to change channels.
1. Via direct access
2. Via the channel list
3. Via the CH+/CH- or pq buttons
4. Via using the 9button
6.1.1 Direct access
To gain direct access to a certain channel, simply input its number with the 0~9 buttons on the remote
control. Channel numbers can be up to four digits long. Entering a number with less than four digits is
possible. After entering the channel number just wait a few seconds or press OK and your receiver will
switch to the selected channel.
NOTE: When using the simpliTV List some channel numbers may not be assigned or present in the list.
Channels which have been searched manually or been added personally (e.g. when you had
installed another list before installing the simpliTV List) will be assigned from channel number
400 onwards.
6.1.2 Channel list
Press OK in viewing mode to display the channel list. In the header section the corresponding name of the
selected channel list will be displayed. Use pq inside the channel list to highlight your channel of choice
and press OK to switch to the highlighted channel.
The channel list is equipped with a lter function to make it easier to nd your favourite channels. While in
the channel list, press RED. An alphabet banner will now be displayed. Use pq or P+/P- to select the rst
letter or number of the channel you wish to lter for and press OK or tto change to the ltered list. All
channels, beginning with the chosen letter, will now be listed at the left side (ascending order by channel
number). Then use the buttons as usually to select the desired channel. Afterwards the normal channel list
is displayed again. To quickly switch between your preferred channels, use the 9button to display the list of
Recently watched channels.
The following buttons are available in the channel list and in viewing mode:
TV/R: Toggles between TV and radio channels, in channel list changes the list mode.
LIST: Opens the satellite list selection in viewing and list mode in case there is more than 1 satellite
installed.
FAV: Displays the favourite list selection in both modes. Details about creating favourite lists can be
found in chapter 7.2.1 TV Channel Manager.
To return to the original respectively to the previous channel list /mode use TV/R or LIST.
6.1.3 Using the CH+/CH- buttons
CH+ or pwill switch to a higher channel.
CH- or qwill switch a lower channel.

15
6.1.4 Using the 9button
In order to quickly switch between your most preferred channels, use 9to view the list of Recently watched
channels. This list contains up to 30 recently watched channels. As this list is temporary it will be recreated
each time after you switch on your receiver. In the Settings System Settings menu, the Recent channel list
option can also be set to O, in this case pressing the 9button switches between the 2 last watched
channels.
6.2 Info Banner
Any time during viewing mode you can press the INFO button to get info about the current channel and
programme*.
In this state, it is possible to use tu to display channel and programme information about other channels
without switching channels, but however in this mode you can also switch to the selected channel
by pressing OK. Press INFO twice to display detailed programme information of the current or next
programme. For the current programme information use tu to change between the current and next
event information. In the respective programme information, you can use P+/P- to scroll if applicable. If you
press the button a third time, technical details of this channel will be displayed. The technical information
might help you in case of reception or similar problems to see if the channel provides Audio/Video PIDs and
if the signal is of sucient quality and strength additionally you can nd the Device-ID (Gerätenummer) in
this screen. Press INFO or to close the information.
Settings for the display duration can be set in menu 7.3.2 System Settings.
*Programme information are displayed in case of availability. Availability depends on the broadcast.
6.3 Selection of audio language
Some channels support a choice of dierent audio formats and/or languages. To select another audio
language, press AUDIO in the viewing mode. A list with the available audio languages will be displayed.
Press pq to select an audio language or mode and conrm with OK. It is also possible to select another
audio mode with tu. To conrm your settings press OK to apply.
6.4 Teletext
Your receiver includes a fully featured Teletext. To access Teletext, press the TEXT button in viewing mode
and enter the page number of choice with the 0~9 buttons. You can use pq tu like described on screen
for selection and scrolling through Teletext pages. If you would like to change the transparency of the
Videotext, press OK. In this mode the usage of VOL+/VOL- and !is supported as well. If subpages are
available at the current page, use tu to select and with P+/P- you can scroll fast through the pages +100/-
100. Press or TEXT to quit.
6.5 Subtitles
Some channels support a choice of dierent DVB subtitle languages. Press the SUB button in viewing mode
to display a list of available subtitle languages. Use the pq buttons for selection and conrm with OK. To
leave this menu use .
NOTE: DVB subtitles on Astra 19.2 are currently available on dierent German channels: Das Erste
HD, ZDF HD, 3sat HD, arteHD, WDR HD and other popular channels. If you switch the Subtitles
Display to On, the according subtitles will be displayed automatically in case of availability
for this channel/movie. When the setting is O subtitles can be temporary opened. Further
information about subtitles can be found on the broadcaster’s own videotext pages or
websites.

16
6.6 Changing the video settings
Press the OPT button in viewing mode to change settings like HDMI Resolution, Aspect Ratio and Aspect
Conversion or to have a look on the current settings. To select use pq and to change use tu. After all
settings have been made, press to quit.
NOTE: If you select an HDMI resolution which isn’t supported by your TV, the receiver will
automatically switch to the previous settings after ~10 sec. If you can see the displayed
message, please conrm the selected resolution by pressing OK.
6.7 EPG (Electronic Programme Guide)
The Electronic Programme Guide (EPG) provides an information overview on the current television
programme. The information is provided by the respective broadcaster and may not be available for all
channels.
Therein you will nd programmes information and overviews and you can also programme a timer (for
viewing or with your VCR).
To open, press the EPG button in TV mode. By default, the Grid EPG is set, which gives you a better overview
of the current programme on several dierent channels. On the left you will see the channel list, on the right
the events preview with the event information for the next hours. The corresponding short information
about the selected event is displayed in the upper right of the screen with the start and end of the event.
Use the pq buttons to select the desired channel, then press OK to switch to the channel and load its
information. If you press OK again on you will directly switch to TV mode. Use uto highlight a particular
event of the selected channel. Press INFO to display detailed information and press to close it again. Press
the BLUE button to go 6 hours forwards and press the YELLOW button to go 6h backwards (not further than
to current time). To go directly to the current time use the GREEN button. The RED button allows you to
book a timer for a selected event and with LIST you can open the timer list.
For details on editing timers, see chapter 7.3.4 Timer, the function is identical.
Use the EPG button to switch to Single EPG.
Single EPG
In this form of the EPG, you always see the list of information for the selected channel on the right where
you can use pq to select an event. The corresponding event description is located in the lower area. To
go to the next or previous day, use the BLUE and YELLOW buttons, to return to the current contents use
the GREEN button. The remaining functions stay as described above. To switch to the Grid EPG use the EPG
button and to leave the menu use or press OK for a 2nd time on the selected channel.
NOTE: Availability of EPG data depends on broadcast and can be displayed for up to 7 days. If you are
opening the EPG just after the receiver was switched on or you change to another transponder,
we recommend to wait for a short moment in order to collect the data.
7. MAIN MENU
Press MENU in viewing mode to display the main menu. All important settings and features of your
receiver can be operated from there. It consists of the following sub-menus: Installation, Channels, Settings,
Multimedia, Update, CA Menu and Network
Use tu to select a sub-menu and pq to choose an option. Press OK to open the chosen submenu.
7.1 Installation
Press MENU and select Installation with tu. The following sub-menus are available: Antenna Setup, Motor
Setting, Channel Search and Factory Reset.

17
7.1.1 Antenna Setup
In this menu, you can change and adapt settings for the antenna(s) and their transponders. Use the tu
buttons to change settings, and use pq to select an item, or press OK to list the settings. For the default
setting of DiSEqC 1.0, you can set the parameters for up to 4 satellite positions Port 1-4.
Satellite Press OK to open the list of available satellites. Select the desired satellite with
pq or P+/P- and conrm with OK.
LNB Power If necessary, you can change the LNB voltage using the tu buttons.
LNB Type Select the desired LNB type using the tu buttons if you are not using a universal
LNB. Available are: C Band and User dened.
LNB Freq Displays the corresponding values for the LNB type. 4 adjustments are possible.
22 KHz Tone Not congurable at Universal LNB Type.
DiSEqC 1.0 If DiSEqC 1.0 is used, up to 4 positions can be linked to satellites.
DiSEqC 1.1 If DiSEqC 1.1 is used, up to 16 positions can be linked to satellites.
Transponder Press OK to open the list of available transponders for the selected satellite to
check the reception or select for channel search on it.
If Transponder is highlighted, the channel search can be started on this TP by using the RED Search button
or just press OK, the GREEN Auto DiSEqC Search* button allows you to search for available satellites in the
existing antenna installation.
*This function can nd available satellites within the already persisting installation. The precongured satellites are: Astra 19.2E, Astra 23.5E, Astra 28.2E, HotBird
13.0E and Eutelsat 9.0E.
7.1.2 Motor Setting
If you are using DiSEqC 1.2 or USALS, you can install satellites which are received by a motorised dish. For the
correct installation and positioning of your motor, we recommend the support/advice of a professional and
experienced installer. Here you can congure the motor type and set the motor position for a satellite that
you want to receive.
Satellite Press OK to open the list of available satellites and select one by using the pq or
P+/P- buttons, then press OK again for conrmation.
Transponder Press OK to open the list of available transponders if you like to set a specic
transponder for the selected satellite.
DiSEqC Motor Choose between DiSEqC 1.2 and USALS or O. Per default it is O because of pre-
dened setup for DiSEqC 1.0.
DiSEqC 1.2 selection
Move step-wise Press tu to move your antenna east or west. Move carefully until you see
that both signal beams have an acceptable reception level. When you nd the
selected satellite, press and select Yes to save the position.
Move continuously Use this function to move quickly to a desired position by holding down the tor
ukey, depending on the direction in which you want to move the antenna. Also,
be very careful with it, so you do not bump into obstacles.
Limit Press OK to open this sub-menu, which allows you to set the mechanical limits for
your motor. This is only necessary if your antenna is mounted which means, that a
wall, a tree or similar physical blockages could interfere with a free movement of
the antenna or motor.
Save to this position You can store this position between 0 and 63, OK can be used again as described
above.

18
Save / Recalculation With Save and Recalculate, you can set whether the position should be saved or a
new calculation should be made after setting this position.
Go to position Press OK to move the motor to the centre position. This is only necessary for the rst
time to set the antenna correctly. Then you can also select a number of a position you
already have stored or check the antenna position.
USALS selection
Congure the motor position by using the USALS function. Enter your geographic location. The motor is
able to calculate all available satellite positions, preconditioned this function is also supported by the motor.
Use pq to select the Antenna Position sub-menu.
Antenna position: Press OK to open the submenu. Use the 0~9 buttons to enter the degree of
longitude. Next, select East or West, then 0~9 to enter the latitude. Finally, specify
North or South. Finally, select Save and press OK to conrm your entries.
Go to position Press OK to move the motor to the desired satellite position. After computation, you
can also select other satellites, go to Satellite and select the desired one from the list.
NOTE: For detailed information about correct geographic values of your location, visit
websites such as dishpointer.com, itouchmap.com, or other reliable sources such as
professional journals.
7.1.3 Channel Search
In this menu, you can perform an automatic, network or transponder search. You can also search for
channels on all installed satellites. Use the pq buttons to highlight the desired item and use tu to
change the settings.
Satellite: Here you will nd a list of satellites, only select a satellite/s which is available in your
installation or have been congured previously.
If this option is marked, the name and position can be changed using the RED
Rename Satellite button. To do this use pq and tu, on the shown keyboard, to
navigate.
Transponder: Use the tu buttons to switch between the transponders of the selected satellite.
You can also press OK to list them. Use pq or P+/P- to scroll through the list.
Conrm your selection with OK. Press the RED button to Edit TP, the GREEN to Add TP
or YELLOW to Delete Current TP. Details can be found in chapter 7.1.3.1 Edit, add or
delete transponders
Channel type Use tu to select the channels you’d like to search for: All, only Free-to-air or
Encrypted channels.
Scan mode TV & Radio searches for TV and radio channels, TV only for TV channels and radio only
for radio channels.
Search for Use tu to select the search type to be performed. You can choose between the
following options:
One Satellite: Searching on the selected satellite.
Selected Satellites: Search for all installed satellites. * This option displays a menu for selecting the
installed satellites. After selection, please use the RED Search key to continue the
search.
NIT Table: NIT Scan on the selected satellite.
simpliTV List: With this option you can install the simpliTV list at a later stage. In this case, previously
installed or available channels are kept and will be integrated in the simpliTV list. TV
or radio channels which are not included in the simpliTV list are listed starting with
