Stryker 3600-000-110 User manual

Sleeper Chair Seating
Model 3600
2006/07 Manufactured for Stryker Medical www.stryker.com
For parts or technical
assistance call
[phone] (option 2)
Operations\Maintenance Manual
3600-000-220
3600-000-110 3600-000-130

www.stryker.com 2 Manufactured for Stryker Medical
3600-000-220ReclinerBed................................................................3
3600-000-110SleeperChair................................................................4
3600-000-130LoveseatSleeper.............................................................5
Warranty ..............................................................................6
LimitedWarranty.....................................................................6
ServiceContractCoverage .............................................................6
Table of Contents

www.stryker.com 3 Manufactured for Stryker Medical
3600-000-220 Recliner Bed
RETURN TO TABLE OF CONTENTS
Item Stryker P/N Part Description Qty.
1(not serviceable) Arm Frame / Body Upholstered 1
23600-100-002 Seat Frame Upholstered 1
33600-100-003 Headrest Upholstered w/Hinge 1
43600-100-004 Ottoman Frame Upholstered w/Pull Strap 1
53600-100-005 Footboard Upholstered 1
6(not serviceable) Ottoman Pull Strap 1
73600-100-007 Front Rigid Locking Casters 2
83600-100-008 Rear Swivel Casters 2
93600-100-028 #10 x 1-1/2” Flat Phil Tapping Screw Zinc 16
10 (not serviceable) Back Hinge (Pair) KP 11-17 2
11 3600-100-011 Ottoman Support Frame - KP 11-21 (PAIR) 2
12 3600-100-012 Ottoman Support Cross Tube KX 31-53 1
13 3600-100-013 Ottoman Caster RN 25-81 2
14 3600-100-014 Ottoman Caster Bolt RA 21-10 2
15 3600-100-015 Seat Support Frame - KP 11-32 (PAIR) 2
16 3600-100-016 Seat Support Cross Tube KX 31-59 1
17 3600-100-017 Seat Support Bolt RA 21-07 2
18 3600-100-018 Caster Holding Device LF 01-92 2
19 3600-100-019 C-Clip Caster Stop LV 07-63 2
20 3600-100-009 Frame Caster Rail (Right) 1
3600-100-047 Frame Caster Rail (Left) 1
4
9
8
20
17
18
7
19
13
15
16
11
14 12
6
10
1
3
2
5

www.stryker.com 4 Manufactured for Stryker Medical
3600-000-110 Sleeper Chair
RETURN TO TABLE OF CONTENTS
5
7
6
8
12
1
2
3
4
10
11
9
Item Stryker P/N Part Description Qty.
1(not serviceable) Body Upholstered 1
2
3600-100-021 Arms Upholstered, Patient Right, w/Wood Arm Cap 1
3600-100-044 Arms Upholstered, Patient Left, w/Wood Arm Cap 1
3600-100-045 Arms Upholstered, Patient Right 1
3600-100-046 Arms Upholstered, Patient Left 1
3 3600-100-022 Top Arm Finished 2
4 3600-100-023 Seat Cushions Upholstered 1
5 3600-100-024 CAL 129 Inner Spring mattress 1
6 3600-100-025 Classic Sleeper Mechanism - 240968-3548-16D 1
7 3600-100-026 Mattress Retainer - 340849 1
8 3600-100-027 Softech Twin Wheels 3” Locking Casters - SF75116 4
9 3600-100-028 #10 x 1-1/2” Flat Phil Tapping Screw Zinc 16
10 3600-100-029 Wood Leg Finished 4
11 3600-100-030 #10 x 2-1/2” Flat Phil Wood Screw Black 8
12 3600-100-031 Glide 4

www.stryker.com 5 Manufactured for Stryker Medical
3600-000-130 Loveseat Sleeper
RETURN TO TABLE OF CONTENTS
6
8
12
1
2
3
4
10
11
9
5
7
Item Stryker P/N Part Description Qty.
1(not serviceable) Body Upholstered 1
2
3600-100-021 Arms Upholstered, Patient Right, w/Wood Arm Cap 1
3600-100-044 Arms Upholstered, Patient Left, w/Wood Arm Cap 1
3600-100-045 Arms Upholstered, Patient Right 1
3600-100-046 Arms Upholstered, Patient Left 1
3 3600-100-022 Top Arm Finished 2
4 3600-100-035 Seat Cushions Upholstered 2
5 3600-100-036 CAL 129 Inner Spring mattress 1
6 3600-100-037 Big Max Sleeper Mechanism - 241103-2731-713C 1
7 3600-100-038 Mattress Retainer - 340849 1
8 3600-100-027 Softech Twin Wheels 3” Locking Casters - SF75116 4
9 3600-100-028 #10 x 1-1/2” Flat Phil Tapping Screw Zinc 16
10 3600-100-029 Wood Leg Finished 4
11 3600-100-030 #10 x 2-1/2” Flat Phil Wood Screw Black 8
12 3600-100-031 Glide 4

www.stryker.com 6 Manufactured for Stryker Medical
Warranty
LIMITED WARRANTY
Stryker Medical Division, a division of Stryker Corporation, warrants to the original purchaser the Symmetry® II
Sleeper Chair Seating line for a Limited Lifetime Warranty. Stryker’s obligation under this warranty is expressly
limited to supplying replacement parts and labor for, or replacing, at its option, any product which is, in the sole
discretion of Stryker, found to be defective. If requested by Stryker, products or parts for which a warranty claim is
made shall be returned prepaid to the factory. Any improper use or any alteration or repair by others in such manner
as in Stryker’s judgment affects the product materially and adversely shall void this warranty. Any repair of Stryker
products using parts not provided or authorized by Stryker shall void this warranty. No employee or representative
of Stryker is authorized to change this warranty in any way.
The Limited Lifetime Warranty on the Symmetry® II Sleeper Chair Seating line applies to the following components
under normal use and proper care:
10 years on wood structural frame components, wood arms and wood bases
5 years on metal arms, metal bases and metal frames
3 years on Stryker fabric
1 year on foam
This statement constitutes Stryker’s entire warranty with respect to the aforesaid equipment. STRYKER MAKES
NO OTHER WARRANTY OR REPRESENTATION, EITHER EXPRESSED OR IMPLIED, EXCEPT AS SET FORTH
HEREIN. THERE IS NO WARRANTY OF MERCHANTABILITY AND THERE ARE NO WARRANTIES OF FITNESS
FOR ANY PARTICULAR PURPOSE. IN NO EVENT SHALL STRYKER BE LIABLE HEREUNDER FOR INCIDENTAL
OR CONSEQUENTIAL DAMAGES ARISING FROM OR IN ANY MANNER RELATED TO SALES OR USE OF ANY
SUCH EQUIPMENT.
To Obtain Parts and Service
Stryker products are supported by a nationwide network of dedicated Stryker Field Service Representatives. These
representatives are factory trained, available locally, and carry a substantial spare parts inventory to minimize repair
time. Simply call your local representative, or call Stryker Customer Service at (800)327−0770.
SERVICE CONTRACT COVERAGE
Stryker has developed a comprehensive program of service contract options designed to keep your equipment op-
erating at peak performance at the same time it eliminates unexpected costs. We recommend that these programs
be activated before the expiration of the new product warranty to eliminate the potential of additional equipment
upgrade charges.
A SERVICE CONTRACT HELPS TO:
Ensure equipment reliability
Stabilize maintenance budgets
Diminish downtime
Establish documentation for JCAHO
Increase product life
Enhance trade-in value
Address risk management and safety
•
•
•
•
•
•
•
•
•
•
•
RETURN TO TABLE OF CONTENTS

Stryker Medical
3800 E. Centre Ave., Portage, Michigan 49002
[phone] (Option 2)
2006/07 3600-009-001 REV A www.stryker.com
