UUnniittyy™™ SSlleeeepp--EEeezz™™ RReecclliinneerr
OOppeerraattiioonnss//MMaaiinntteennaannccee MMaannuuaall
3500
EN
FR
3505009001-A 2021/06

SSyymmbboollss
Consult instructions for use
Caution
Catalogue number

Serial number
Distributed by
Manufacturer
 
For US Patents see www.stryker.com/patents
Safe working load
3505009001-A EN

TTaabbllee ooff CCoonntteennttss
Warning/Caution/Note Definition ....................................................................................................................2
Summary of safety precautions ...............................................................................................................2
Introduction ..................................................................................................................................................3
Product description ................................................................................................................................3
Intended use..........................................................................................................................................3
Expected service life...............................................................................................................................3
Specifications ........................................................................................................................................3
Product illustration..................................................................................................................................4
Contact information ................................................................................................................................4
Serial number location............................................................................................................................5
Operation.....................................................................................................................................................6
Locking and unlocking the casters ...........................................................................................................6
Reclining ...............................................................................................................................................6
Lying flat for a sleep surface....................................................................................................................7
Accessories and parts...................................................................................................................................9
Preventive maintenance..............................................................................................................................10
Cleaning with SideKick® wipes ....................................................................................................................11
Cleaning the product...................................................................................................................................12
Service ......................................................................................................................................................13
Caster replacement..............................................................................................................................13
Ottoman cushion replacement...............................................................................................................13
Seat cushion replacement.....................................................................................................................14
Back cushion replacement....................................................................................................................15
Footboard replacement.........................................................................................................................16
Arm cap replacement ...........................................................................................................................16
Recliner assembly ......................................................................................................................................17
3505009001-A 1 EN

WWaarrnniinngg//CCaauuttiioonn//NNoottee DDeeffiinniittiioonn
The words WWAARRNNIINNGG,CCAAUUTTIIOONN, and NNOOTTEE carry special meanings and should be carefully reviewed.
WWAARRNNIINNGG
Alerts the reader about a situation which, if not avoided, could result in death or serious injury. It may also describe
potential serious adverse reactions and safety hazards.
CCAAUUTTIIOONN
Alerts the reader of a potentially hazardous situation which, if not avoided, may result in minor or moderate injury to the
user or patient or damage to the product or other property. This includes special care necessary for the safe and effective
use of the device and the care necessary to avoid damage to a device that may occur as a result of use or misuse.
NNoottee -- Provides special information to make maintenance easier or important instructions clearer.
SSuummmmaarryy ooff ssaaffeettyy pprreeccaauuttiioonnss
CCAAUUTTIIOONN
• Improper usage of the product can cause injury to the patient or operator. Operate the product only as described in this
manual.
• Do not modify the product or any components of the product. Modifying the product can cause unpredictable operation
resulting in injury to patient or operator. Modifying the product also voids its warranty.
• Always confirm stable foot placement and back support or get assistance from another person to avoid the risk of injury
or product damage.
EN 2 3505009001-A

IInnttrroodduuccttiioonn
This manual assists you with the operation or maintenance of your Stryker product. Read this manual before operating or
maintaining this product. Set methods and procedures to educate and train your staff on the safe operation or maintenance
of this product.
CCAAUUTTIIOONN
• Improper usage of the product can cause injury to the patient or operator. Operate the product only as described in this
manual.
• Do not modify the product or any components of the product. Modifying the product can cause unpredictable operation
resulting in injury to patient or operator. Modifying the product also voids its warranty.
NNoottee
• This manual is a permanent part of the product and should remain with the product even if the product is sold.
• Stryker continually seeks advancements in product design and quality. This manual contains the most current product
information available at the time of printing. There may be minor discrepancies between your product and this manual. If
you have any questions, contact Stryker Customer Service or Technical Support at 1-800-327-0770.
PPrroodduucctt ddeessccrriippttiioonn
The SSlleeeepp--EEeezz™ Recliner is a furniture product that functions as a padded seat, capable of reclining. The product is also
capable of lying flat to function as a visitor sleep surface.
IInntteennddeedd uussee
The SSlleeeepp--EEeezz Recliner is intended to be used as furniture within the healthcare setting.
EExxppeecctteedd sseerrvviiccee lliiffee
The SSlleeeepp--EEeezz Recliner has a 10 year expected service life under normal use conditions and with appropriate periodic
maintenance.
SSppeecciiffiiccaattiioonnss
3500-000-691
Safe working load 300 lb 136 kg
Overall length 37.0 in. 940 mm
Overall width 35.0 in. 889 mm
Overall height 35.0 in. 889 mm
Seat depth (minimum) 21.0 in. 533 mm
Seat width (minimum) 27.5 in. 699 mm
Seat height (minimum) 17.5 in. 445 mm
Back width 27.5 in. 699 mm
Back height (minimum) 18.5 in. 470 mm
3505009001-A 3 EN

Armrest clearance 27.5 in. 699 mm
Arm height (from seat) 9.0 in. 229 mm
Arm height (from floor) 26.2 in. 667 mm
Weight 146 lb 66.4 kg
Stryker reserves the right to change specifications without notice.
PPrroodduucctt iilllluussttrraattiioonn
A
B
C
D
E
F
G
HI
AStrap F Back cushion
B Footboard G Arm cap
C Ottoman cushion H Caster
D Arm I Extension frame
E Seat cushion
CCoonnttaacctt iinnffoorrmmaattiioonn
Contact Stryker Customer Service or Technical Support at: 1-800-327-0770.
Stryker Medical
3800 E. Centre Avenue
EN 4 3505009001-A

Portage, MI 49002
USA
To view your operations or maintenance manual online, see https://techweb.stryker.com/.
Have the serial number (A) of your Stryker product available when calling Stryker Customer Service or Technical Support.
Include the serial number in all written communication.
SSeerriiaall nnuummbbeerr llooccaattiioonn
The serial number for your product is located behind the seat cushion (A).
A
FFiigguurree 11 –– SSeerriiaall nnuummbbeerr llooccaattiioonn
3505009001-A 5 EN

OOppeerraattiioonn
LLoocckkiinngg aanndd uunnlloocckkiinngg tthhee ccaasstteerrss
The locking casters are located at the front of the bench.
To lock the casters, use your foot to push the caster lock (A) down (Figure 2).
To unlock the casters, use your foot to pull the caster lock up.
A
FFiigguurree 22 –– CCaasstteerr lloocckk
RReecclliinniinngg
1. Lock the casters ( Locking and unlocking the casters (page 6)).
2. Pull the strap (A) on the front of the recliner to slide out the extension frame (B) (Figure 3).
3. Pull the strap up and out to raise the ottoman cushion (C) to its upright position.
4. Reverse steps to store away.
EN 6 3505009001-A

A
B
C
FFiigguurree 33 –– RReecclliinnee
LLyyiinngg ffllaatt ffoorr aa sslleeeepp ssuurrffaaccee
1. After you recline ( Reclining (page 6)), pull the strap (A) on the front of the recliner to slide out the extension frame (B)
until it stops (Figure 4).
NNoottee -- The seat cushion should slide out when extended.
2. Grasp the top of the back cushion (C) and fold forward.
3. Reverse steps to store away.
3505009001-A 7 EN

A
C
B
FFiigguurree 44 –– LLyyiinngg ffllaatt
EN 8 3505009001-A

AAcccceessssoorriieess aanndd ppaarrttss
These accessories may be available for use with your product. Confirm availability for your configuration or region. Call
Stryker Customer Service: 1-800-327-0770.
NNaammee PPaarrtt nnuummbbeerr
Arm cap, black 3500-022-690
Arm cap, kalua 3500-023-690
Arm cap , latte 3500-024-690
Arm cap, mocha 3500-025-690
Arm cap, shadow 3500-026-690
Arm cap, toast 3500-027-690
Caster, lock 3500-100-054
Caster, swivel 3500-100-055
Cushion, back, assembly 3500-020-690
Cushion, ottoman 3500-014-690
Cushion, seat 3500-015-690
Foot kick 3500-017-690
Footrest frame kit, stage 3 3500-013-690
Roller frame kit, stage 1 3500-011-690
Screws, back cushion hinge to chair frame 3500-100-151
Screws, caster 3500-100-056
Screws, cushions 3500-100-077
Screws, foot kick 3500-100-056
Seat frame kit, stage 2 3500-012-690
Spacers, foot kick 3500-100-176
3505009001-A 9 EN

PPrreevveennttiivvee mmaaiinntteennaannccee
Remove product from service before you perform the preventive maintenance inspection. Check all items listed during
annual preventive maintenance for all Stryker Medical products. You may need to perform preventive maintenance checks
more often based on your level of product usage. Service only by qualified personnel.
Inspect the following items:
All fasteners are secure
All casters are secure
All casters roll and swivel freely
Front casters lock
No debris in casters
Back, arms, seat, and foot section are not damaged
Foot and seat sections slide out and stop freely
Product serial number:
Completed by:
Date:
EN 10 3505009001-A

CClleeaanniinngg wwiitthh SSiiddeeKKiicckk®® wwiippeess
For the United States only. Call Stryker Customer Service: 1-800-327-0770 to confirm availability for your configuration or
region.
Stryker’s preferred wipes (2060-000-001 6'' x 10'' or 2060-000-002 9'' x 12'') include the following active ingredients:
• n-Alkyl (60% C14, 30% C16, 5% C12, 5% C18) dimethyl benzyl ammonium chloride - 0.154%
• n-Alkyl (68% C12, 32% C14) dimethyl ethylbenzyl ammonium chloride - 0.154%
• Isopropanol - 21.000%
Non-active ingredient: Ethylene Glycol Monobutyl Ether – < 3%
NNoottee -- For safety information, read the product label.
Follow these steps to clean the external product surface using SSiiddeeKKiicckk wipes. SSiiddeeKKiicckk wipes are not approved to
disinfect your product.
1. Rub with a fresh, clean SSiiddeeKKiicckk wipe to remove all visible soils. Repeat as necessary until the product is clean.
NNoottee -- Use as many wipes as necessary.
2. Allow the external product surface to air dry before you return the product to service.
3505009001-A 11 EN

CClleeaanniinngg tthhee pprroodduucctt
Recommended cleaners:
• Quaternary solutions (active ingredient – ammonium chloride) that contain less than 3% glycol ether
• Chlorinated bleach solution (1 part bleach solution to 100 parts water, 520 ppm available chlorine solution)
• Isopropyl alcohol (active ingredient ≤ 21%)
Recommended cleaning method:
1. Follow the cleaning solution manufacturer’s dilution recommendations.
2. Hand wash all surfaces of the product with a cleaning solution.
3. Avoid oversaturation. Do not allow the product to stay wet longer than the chemical manufacturer’s guidelines for
cleaning.
4. Dry the product.
5. Verify proper operation before you return the product to service.
EN 12 3505009001-A

SSeerrvviiccee
CCaasstteerr rreeppllaacceemmeenntt
TToooollss rreeqquuiirreedd::
• #3 Phillips screwdriver
• Blanket or equivalent
PPrroocceedduurree::
1. Pull the recliner away from the wall.
2. Lay a blanket, or equivalent, on the floor behind the recliner.
3. Using two hands, lift up on the bottom of the recliner to flip the recliner onto its back.
CCAAUUTTIIOONN -- Always confirm stable foot placement and back support or get assistance from another person to avoid the
risk of injury or product damage.
4. Using a #3 Phillips screwdriver, remove the four screws that secure the caster to the recliner frame and remove the
caster. Save the screws.
5. Reverse steps to reinstall.
6. Verify proper operation before you return the product to service.
OOttttoommaann ccuusshhiioonn rreeppllaacceemmeenntt
TToooollss rreeqquuiirreedd::
• #3 Phillips screwdriver
PPrroocceedduurree::
1. Pull the strap (A) on the front of the recliner to slide out the extension frame (B) (Figure 5).
2. Pull the strap up and out to raise the ottoman cushion (C) to its upright position.
3. Using a #3 Phillips screwdriver, reach through the extension frame to remove the four screws that secure the ottoman
cushion to the extension frame. Save the screws.
4. Remove the ottoman cushion.
5. Reverse steps to reinstall.
6. Verify proper operation before you return the product to service.
3505009001-A 13 EN

A
B
C
FFiigguurree 55 –– OOttttoommaann ccuusshhiioonn rreeppllaacceemmeenntt
SSeeaatt ccuusshhiioonn rreeppllaacceemmeenntt
TToooollss rreeqquuiirreedd::
• #3 Phillips screwdriver
PPrroocceedduurree::
1. Pull the strap (A) on the front of the recliner to slide out the extension frame (B) (Figure 6).
2. Pull the strap up and out to raise the ottoman cushion (C) to its upright position.
3. Pull the strap to slide out the extension frame until it stops.
NNoottee -- The seat cushion should slide out when extended.
4. Using a #3 Phillips screwdriver, reach through the seat frame (F) to remove the four screws that secure the seat cushion
(D) to the seat frame. Save the screws.
5. Remove the cushion.
6. Reverse steps to reinstall.
7. Verify proper operation before you return the product to service.
EN 14 3505009001-A

A
C
B
D
E
F
FFiigguurree 66 –– SSeeaatt ccuusshhiioonn rreeppllaacceemmeenntt
BBaacckk ccuusshhiioonn rreeppllaacceemmeenntt
TToooollss rreeqquuiirreedd::
• #3 Phillips screwdriver
PPrroocceedduurree::
1. Pull the strap (A) on the front of the recliner to slide out the extension frame (B) (Figure 6).
2. Pull the strap up and out to raise the ottoman cushion (C) to its upright position.
3. Pull the strap to slide out the extension frame until it stops.
NNoottee -- The seat cushion should slide out when extended.
4. Using a #3 Phillips screwdriver, reach through the seat frame (F) to remove the two bottom screws (one on each side)
that secure the back cushion hinge mechanism to the recliner frame. Save the screws.
5. Grasp the top of the back cushion (E) and fold forward.
6. Using a #3 Phillips screwdriver, remove the two top screws (one on each side) that secure the back cushion hinge
mechanism to the recliner frame. Save the screws.
7. Remove the back cushion assembly.
8. Reverse steps to reinstall.
NNoottee
• The left and right stampings on the hinges are a directional reference as you look at the front of the chair. The hinges
have two screw holes on each side. Reinstall the screws through the inner holes.
• Use caution when you slide the hinges down to install the new back cushion assembly to avoid the risk of damage to
the fabric.
9. Verify proper operation before you return the product to service.
3505009001-A 15 EN

FFoooottbbooaarrdd rreeppllaacceemmeenntt
TToooollss rreeqquuiirreedd::
• #3 Phillips screwdriver
PPrroocceedduurree::
1. Pull the strap (A) on the front of the recliner to slide out the extension frame (B) (Figure 5).
2. Pull the strap up and out to raise the ottoman cushion (C) to its upright position.
3. Using a #3 Phillips screwdriver, reach through the extension frame to remove the four screws that secure the footboard
to the extension frame. Save the screws.
4. Remove the footboard.
5. Reverse steps to reinstall.
6. Verify proper operation before you return the product to service.
AArrmm ccaapp rreeppllaacceemmeenntt
TToooollss rreeqquuiirreedd::
• Rubber hammer
• Large flat screwdriver
PPrroocceedduurree::
1. Using a rubber hammer, hit the back of the arm cap (A) toward the front of the recliner until it stops moving forward
(Figure 7).
NNoottee -- Use caution when you hit the arm cap to avoid the risk of damage to the fabric.
2. Position a large flat screwdriver between the arm cap and arm to pull up on the arm cap and loosen the arm cap from
the recliner. Remove and discard the arm cap.
3. Align the new arm cap bolts with the holes at the front of the arm slots.
4. Using a rubber hammer, hit the arm cap down until it is tight to the arm.
5. Using a rubber hammer, hit the arm cap toward the back of the recliner until it stops moving back.
NNoottee -- Use caution when you hit the arm cap to avoid the risk of damage to the fabric.
6. Verify proper operation before you return the product to service.
A
FFiigguurree 77 –– AArrmm ccaapp
EN 16 3505009001-A
