Stryker 3500-000-150 Manual

2013/07 D.13500-009-001 REV D www.stryker.com
Symmetry®II
Patient and Guest Seating
REF
Whitelettersand
outlinewith
transparent
rectangle
3500
Operations/Maintenance Manual
3500-000-110
3500-000-130
3500-000-150 3500-000-320 3500-000-220 3500-000-520
3500-000-170 3500-000-340 3500-000-190 3500-000-420

www.stryker.com 3500-009-001 REV D 3
Table of Contents
Symbols and Definitions ....................................................................4
Symbols ............................................................................4
Warning/Caution/Note Definition ...........................................................4
Summary of Safety Precautions ..............................................................4
3500-000-110 Highback Chair (18” Seat Height) ..................................................5
Reference P/N: STR3840 ................................................................5
Specifications ........................................................................6
3500-000-130 Highback Chair (21” Seat Height) ..................................................7
Reference P/N: STR3840-21 .............................................................7
Specifications ........................................................................8
3500-000-150 Lowback Chair with Arms (18”) ....................................................9
Reference P/N: STR3841 ................................................................9
Specifications .......................................................................10
3500-000-170 Lowback Chair with Arms (21”) ...................................................11
Reference P/N: STR3841-21.............................................................11
Specifications .......................................................................12
3500-000-220 Lowback Chair witho Arms (18” only) ..............................................13
Reference P/N: STR3842 ...............................................................13
Specifications .......................................................................14
3500-000-320 Highback Flexback Chair (18”) ...................................................15
Reference P/N: STR3843 ...............................................................15
Specifications .......................................................................16
3500-000-340 Highback Flexback Chair (21”) ...................................................17
Reference P/N: STR3843-21 ............................................................17
Specifications .......................................................................18
3500-000-520 Steel Chair .................................................................19
Reference P/N: STR2183 ...............................................................19
Specifications .......................................................................20
3500-000-420 Bariatric Chair ..............................................................21
Reference P/N: STR4125W .............................................................21
Specifications .......................................................................22
3500-000-190 Ottoman....................................................................23
Reference P/N: STR3844 ...............................................................23
Warranty ..............................................................................24
Limited Lifetime Warranty ...............................................................24
One Year Warranty ...................................................................24
To Obtain Parts and Service ............................................................25
Return Authorization...................................................................25
Damaged Merchandise ................................................................25
International Warranty Clause............................................................25

43500-009-001 REV D www.stryker.com
Return To Table of Contents
Symbols and Definitions
SYMBOLS
Warning/Caution: Consult accompanying documentation
Manufacturer
WARNING/CAUTION/NOTE DEFINITION
The words WARNING, CAUTION and NOTE carry special meanings and should be carefully reviewed.
WARNING
Alerts the reader about a situation which, if not avoided, could result in death or serious injury. It may also describe
potential serious adverse reactions and safety hazards.
CAUTION
Alerts the reader of a potentially hazardous situation which, if not avoided, may result in minor or moderate injury to the
user or patient or damage to the equipment or other property. This includes special care necessary for the safe and
effective use of the device and the care necessary to avoid damage to a device that may occur as a result of use or
misuse.
NOTE
Provides special information to make maintenance easier or important instructions clearer.
WARNING
• To avoid the risk of serious injury or product damage, do not stand on chair seat or ottoman.
• To avoid the risk of serious injury or product damage, do not sit on chair arms.
• To avoid the risk of serious injury or product damage, while standing behind the chair, do not lean on chair backrest
or chair arms.
• To avoid the risk of serious injury or product damage, keep all four chair legs on the ground when seated.
• To avoid the risk of serious injury or product damage, do not lay infants or infant carriers in the chair or on the
ottoman.
• Stow the ottoman under the chair when not in use to avoid a tripping hazard.
• Failure to properly clean a contaminated surface will increase the risk of exposure to bloodborne pathogens.
CAUTION
• To avoid the risk of product or floor damage, do not use chairs and/or ottoman if all glides are not present.
• Cleaning products may be harmful to your skin and/or eyes. Use protective gloves and eye protection. Protect the
surrounding area and clothing from exposure to cleaners. Do not inhale or swallow any cleaning agents. Follow
all cleaning product manufacturer’s warnings.
• The use of certain agents can be harmful to the surface appearance and lifespan of fabrics. Check compatibility
of any cleaning product with other surfaces on the furniture, such as painted surfaces or varnish.
• Clean all stains immediately as some stains may become permanent if not removed quickly.
Summary of Safety Precautions

www.stryker.com 3500-009-001 REV D 5
Return To Table of Contents
3500-000-110 Highback Chair (18” Seat Height)
Item Stryker P/N Reference P/N Part Description Qty.
1(not serviceable) 17006STR3840 Chair Frame with Glides and Inserts 1
1.1 (not serviceable) 00206STR3840 Chair Frame 1
1.2 3500-100-001 004350019 3/4” Tack Glide, White 4
1.3 (not serviceable) 0043500512 1/4”-20 x 20mm Type D Inst. Nut 4
23500-100-002 16071STR3840 UPH Seat Only 1
33500-100-003 004310164 #12 x 2” Pan Quad TS Zinc 4
4(not serviceable) 16032STR3840 UPH Back Only 1
5(not serviceable) 004310287BLK 1/4”-20 x 1-1/2” Pan Quad M 4
6(not serviceable) 004310612 5/16” ID x 3/4” OD x 1/16” Washer 8
1.2
1.1
1.3
5
6
2
4
3
Note: Back attached to frame
from inside upholstery, using
Loctite®on screw.
1
Reference P/N: STR3840
6

63500-009-001 REV D www.stryker.com
Return To Table of Contents
3500-000-110 Highback Chair (18” Seat Height)
SPECIFICATIONS
DESCRIPTION SPECIFICATIONS
INCHES (MM)
Weight Capacity 300 lbs
CHAIR DIMENSIONS
Length 26 (660)
Width 24 (610)
Height
(Controls at mid-point or
nominal design position)
40.5 (1029)
SEAT
Seat (Type) Plywood & Web
Seat Foam (Type) Ultracell/Slab
Seat Foam Thickness 2.0 (51)
Seat Depth (Min.) 18 (445)
Seat Depth (Max.) --- (0)
Seat Width 21 (553)
Seat Height (Min.) 18 (445)
Seat Height (Max.) --- (0)
BACK
Back Pan (Type) Frame & Web
Back Foam (Type) Regular Slab
Foam Only
Back Foam Thickness 1.5 (38)
Back Width 20.5 (521)
Back Height (Min.) 22-1/2 (584)
ARMRESTS
Armrest (Type) Wooden
Armrest Clearance 19 (483)
Arm Height from Seat (Min.) 8.0 (203)
Arm Height from Floor (Min.) 25.5 (648)
Reference P/N: STR3840

www.stryker.com 3500-009-001 REV D 7
Return To Table of Contents
3500-000-130 Highback Chair (21” Seat Height)
Item Stryker P/N Reference P/N Part Description Qty.
1(not serviceable) 17006STR3840-21 Chair Frame with Glides and Inserts 1
1.1 (not serviceable) 00206STR3840-21 Chair Frame 21” ST HT 1
1.2 3500-100-001 004350019 3/4” Tack Glide, White 4
1.3 (not serviceable) 0043500512 1/4”-20 x 20mm Type D Inst. Nut 4
23500-100-002 16071STR3840 UPH Seat Only 1
33500-100-003 004310164 #12 x 2” Pan Quad TS Zinc 4
4(not serviceable) 16032STR3840 UPH Back Only 1
5(not serviceable) 004310287BLK 1/4”-20 x 1-1/2” Pan Quad M 4
6(not serviceable) 004310612 5/16” ID x 3/4” OD x 1/16” Washer 8
5
6
2
3
4
1.1
1.3
Note: Back attached to frame
from inside upholstery, using
Loctite®on screw.
1.2
1
Reference P/N: STR3840-21
6

83500-009-001 REV D www.stryker.com
Return To Table of Contents
SPECIFICATIONS
DESCRIPTION SPECIFICATIONS
INCHES (MM)
Weight Capacity 300 lbs
CHAIR DIMENSIONS
Length 27 (660)
Width 24 (610)
Height
(Controls at mid-point or
nominal design position)
43.5 (110 5)
SEAT
Seat (Type) Plywood & Web
Seat Foam (Type) Ultracell/Slab
Seat Foam Thickness 2.0 (51)
Seat Depth (Min.) 18 (457)
Seat Depth (Max.) --- (0)
Seat Width 21 (553)
Seat Height (Min.) 21 (553)
Seat Height (Max.) --- (0)
BACK
Back Pan (Type) Frame & Web
Back Foam (Type) Regular Slab
Foam Only
Back Foam Thickness 1.5 (38)
Back Width 20.5 (521)
Back Height (Min.) 22.5 (572)
ARMRESTS
Armrest (Type) Wooden
Armrest Clearance 19 (483)
Arm Height from Seat (Min.) 8.0 (203)
Arm Height from Floor (Min.) 29 (737)
3500-000-130 Highback Chair (21” Seat Height)
Reference P/N: STR3840-21

www.stryker.com 3500-009-001 REV D 9
Return To Table of Contents
3500-000-150 Lowback Chair with Arms (18”)
Item Stryker P/N Reference P/N Part Description Qty.
1(not serviceable) 17006STR3840 Chair Frame with Glides and Inserts 1
1.1 (not serviceable) 00206STR3840 Chair Frame 1
1.2 3500-100-001 004350019 3/4” Tack Glide, White 4
1.3 (not serviceable) 0043500512 1/4”-20 x 20mm Type D Inst. Nut 4
23500-100-002 16071STR3840 UPH Seat Only 1
33500-100-003 004310164 #12 x 2” Pan Quad TS Zinc 4
4(not serviceable) 16032STR3841 UPH Back Only 1
5(not serviceable) 004310287BLK 1/4”-20 x 1-1/2” Pan Quad M 4
6(not serviceable) 004310612 5/16” ID x 3/4” OD x 1/16” Washer 8
1.1
1.3
5
6
2
4
3
Note: Back attached to frame
from inside upholstery, using
Loctite®on screw.
1.2
1
Reference P/N: STR3841
6

10 3500-009-001 REV D www.stryker.com
Return To Table of Contents
SPECIFICATIONS
DESCRIPTION SPECIFICATIONS
INCHES (MM)
Weight Capacity 300 lbs
CHAIR DIMENSIONS
Length 26 (660)
Width 24 (610)
Height
(Controls at mid-point or
nominal design position)
34.5 (876)
SEAT
Seat (Type) Plywood & Web
Seat Foam (Type) Ultracell/Slab
Seat Foam Thickness 2.0 (51)
Seat Depth (Min.) 18 (457)
Seat Depth (Max.) --- (0)
Seat Width 21 (553)
Seat Height (Min.) 18 (445)
Seat Height (Max.) --- (0)
BACK
Back Pan (Type) Frame & Web
Back Foam (Type) Regular Slab
Foam Only
Back Foam Thickness 1.5 (38)
Back Width 20.5 (521)
Back Height (Min.) 16-1/2 (432)
ARMRESTS
Armrest (Type) Wooden
Armrest Clearance 19 (483)
Arm Height from Seat (Min.) 8.0 (203)
Arm Height from Floor (Min.) 26 (648)
3500-000-150 Lowback Chair with Arms (18”)
Reference P/N: STR3841

www.stryker.com 3500-009-001 REV D 11
Return To Table of Contents
3500-000-170 Lowback Chair with Arms (21”)
Item Stryker P/N Reference P/N Part Description Qty.
1(not serviceable) 17006STR3840-21 Chair Frame with Glides and Inserts 1
1.1 (not serviceable) 00206STR3840-21 Chair Frame 1
1.2 3500-100-001 004350019 3/4” Tack Glide, White 4
1.3 (not serviceable) 0043500512 1/4”-20 x 20mm Type D Inst. Nut 4
23500-100-002 16071STR3840 UPH Seat Only 1
33500-100-003 004310164 #12 x 2” Pan Quad TS Zinc 4
4(not serviceable) 16032STR3841 UPH Back Only 1
5(not serviceable) 004310287BLK 1/4”-20 x 1-1/2” Pan Quad M 4
6(not serviceable) 004310612 5/16” ID x 3/4” OD x 1/16” Washer 8
1.1
1.3
5
6
2
4
3
Note: Back attached to frame
from inside upholstery, using
Loctite®on screw.
1.2
1
Reference P/N: STR3841-21
6

12 3500-009-001 REV D www.stryker.com
Return To Table of Contents
SPECIFICATIONS
DESCRIPTION SPECIFICATIONS
INCHES (MM)
Weight Capacity 300 lbs
CHAIR DIMENSIONS
Length 26 (660)
Width 24 (610)
Height
(Controls at mid-point or
nominal design position)
37. 5 (953)
SEAT
Seat (Type) Plywood & Web
Seat Foam (Type) Ultracell/Slab
Seat Foam Thickness 2.0 (51)
Seat Depth (Min.) 18 (457)
Seat Depth (Max.) --- (0)
Seat Width 21 (553)
Seat Height (Min.) 21 (533)
Seat Height (Max.) --- (0)
BACK
Back Pan (Type) Frame & Web
Back Foam (Type) Regular Slab
Foam Only
Back Foam Thickness 1.5 (38)
Back Width 20.5 (521)
Back Height (Min.) 16-1/2 (432)
ARMRESTS
Armrest (Type) Wooden
Armrest Clearance 19 (483)
Arm Height from Seat (Min.) 8.0 (203)
Arm Height from Floor (Min.) 29 (737)
3500-000-170 Lowback Chair with Arms (21”)
Reference P/N: STR3841-21

www.stryker.com 3500-009-001 REV D 13
Return To Table of Contents
3500-000-220 Lowback Chair witho Arms (18” only)
Item Stryker P/N Reference P/N Part Description Qty.
1(not serviceable) 17006STR3842 Chair Frame with Glides and Inserts 1
1.1 (not serviceable) 00206STR3842 Chair Frame 1
1.2 3500-100-001 004350019 3/4” Tack Glide, White 4
1.3 (not serviceable) 0043500512 1/4”-20 x 20mm Type D Inst. Nut 4
23500-100-002 16071STR3840 UPH Seat Only 1
33500-100-003 004310164 #12 x 2” Pan Quad TS Zinc 4
4(not serviceable) 16032STR3841 UPH Back Only 1
5(not serviceable) 004310287BLK 1/4”-20 x 1-1/2” Pan Quad M 4
6(not serviceable) 004310612 5/16” ID x 3/4” OD x 1/16” Washer 8
1.1
1.3
5
6
2
4
3
Note: Back attached to frame
from inside upholstery, using
Loctite®on screw.
1.2
1
Reference P/N: STR3842
6

14 3500-009-001 REV D www.stryker.com
Return To Table of Contents
SPECIFICATIONS
DESCRIPTION SPECIFICATIONS
INCHES (MM)
Weight Capacity 300 lbs
CHAIR DIMENSIONS
Length 26 (660)
Width 22.5 (572)
Height
(Controls at mid-point or
nominal design position)
34.5 (876)
SEAT
Seat (Type) Plywood & Web
Seat Foam (Type) Ultracell/Slab
Seat Foam Thickness 2.0 (51)
Seat Depth (Min.) 18 (457)
Seat Depth (Max.) --- (0)
Seat Width 21 (553)
Seat Height (Min.) 18 (445)
Seat Height (Max.) --- (0)
BACK
Back Pan (Type) Frame & Web
Back Foam (Type) Regular Slab
Foam Only
Back Foam Thickness 1.5 (38)
Back Width 20.5 (521)
Back Height (Min.) 17 (432)
3500-000-220 Lowback Chair witho Arms (18” only)
Reference P/N: STR3842

www.stryker.com 3500-009-001 REV D 15
Return To Table of Contents
Item Stryker P/N Reference P/N Part Description Qty.
13500-100-038 17006STR3843 Chair Frame with Glide and Brackets 1
1.1 3500-100-039 00206STR3843 Chair Frame 1
1.2 3500-100-001 004350019 3/4” Tack Glide, White 4
1.3 3500-100-040 00437C70032 281 Seat Bracket 90 Degree 4
1.4 3500-100-041 004310147 #12 x 3/4” Pan Quad Screw 8
23500-100-050 16071STR3843 UPH Seat Only 1
33500-100-003 04310164 #12 x 2” Pan Quad TS Zinc 4
43500-100-042 004310266BLK 1/4”-20 x 7/8” Truss Quadrex ZCBLK 4
53500-100-043 16032STR3843 UPH Back withBU 1
6(not serviceable) 004310612 5/16” ID x 3/4” OD x 1/16” Washer 4
73500-100-045 004320007BLK 5/16” Split Lock Washer BLK 3
83500-100-046 004310334 5/16”-18 x 1” Hex Bolt BLK Z GR2 3
93500-100-047 004310612BLK 5/16” ID x 3/4” OD x 1/16” Washer BLK 2
10 3500-100-044 004378944 8944 3” Omega Bracket BLK 1
8
7
97
5
3500-000-320 Highback Flexback Chair (18”)
3
2
4
1.4
1.3
1.2
1.1
Reference P/N: STR3843
10
6

16 3500-009-001 REV D www.stryker.com
Return To Table of Contents
SPECIFICATIONS
DESCRIPTION SPECIFICATIONS
INCHES (MM)
Weight Capacity 300 lbs
CHAIR DIMENSIONS
Length 26 (660)
Width 24 (610)
Height
(Controls at mid-point or
nominal design position)
40.5 (1029)
SEAT
Seat (Type) Plywood & Web
Seat Foam (Type) Ultracell/Slab
Seat Foam Thickness 2.0 (51)
Seat Depth (Min.) 18 (457)
Seat Depth (Max.) --- (0)
Seat Width 21 (553)
Seat Height (Min.) 18 (445)
Seat Height (Max.) --- (0)
BACK
Back Pan (Type) Frame & Web
Back Foam (Type) Regular Slab
Foam Only
Back Foam Thickness 1.5 (38)
Back Width 20.5 (521)
Back Height (Min.) 22-1/2 (584)
ARMRESTS
Armrest (Type) Wooden
Armrest Clearance 19 (483)
Arm Height from Seat (Min.) 8.0 (203)
Arm Height from Floor (Min.) 26 (648)
FRAME
Frame (Type) Wood
MISCELLANEOUS
Unit Weight (lbs (kgs)) 22 (10.0)
Carton Count 1-PER
3500-000-320 Highback Flexback Chair (18”)
Reference P/N: STR3843

www.stryker.com 3500-009-001 REV D 17
Return To Table of Contents
3500-000-340 Highback Flexback Chair (21”)
Item Stryker P/N Reference P/N Part Description Qty.
13500-100-048 17006STR3843-21 Chair Frame with Glide and Brackets 1
1.1 3500-100-049 00206STR3843-21 Chair Frame 1
1.2 3500-100-001 004350019 3/4” Tack Glide, White 4
1.3 3500-100-040 00437C70032 281 Seat Bracket 90 Degree 4
1.4 3500-100-041 004310147 #12 x 3/4” Pan Quad Screw 8
23500-100-050 16071STR3843 UPH Seat Only 1
33500-100-003 04310164 #12 x 2” Pan Quad TS Zinc 4
43500-100-042 004310266BLK 1/4”-20 x 7/8” Truss Quadrex ZCBLK 4
53500-100-043 16032STR3843 UPH Back withBU 1
6(not serviceable) 004310612 5/16” ID x 3/4” OD x 1/16” Washer 4
73500-100-045 004320007BLK 5/16” Split Lock Washer BLK 3
83500-100-046 004310334 5/16”-18 x 1” Hex Bolt BLK Z GR2 3
93500-100-047 004310612BLK 5/16” ID x 3/4” OD x 1/16” Washer BLK 2
10 3500-100-044 004378944 8944 3” Omega Bracket BLK 1
8
7
97
5
2
4
1.4
1.3
1.2
1.1
Reference P/N: STR3843-21
10
3
6

18 3500-009-001 REV D www.stryker.com
Return To Table of Contents
SPECIFICATIONS
DESCRIPTION SPECIFICATIONS
INCHES (MM)
Weight Capacity 300 lbs
CHAIR DIMENSIONS
Length 27 (660)
Width 24 (610)
Height
(Controls at mid-point or
nominal design position)
43.5 (110 5)
SEAT
Seat (Type) Plywood & Web
Seat Foam (Type) Ultracell/Slab
Seat Foam Thickness 2.0 (51)
Seat Depth (Min.) 18 (457)
Seat Depth (Max.) --- (0)
Seat Width 21 (553)
Seat Height (Min.) 21 (553)
Seat Height (Max.) --- (0)
BACK
Back Pan (Type) Frame & Web
Back Foam (Type) Regular Slab
Foam Only
Back Foam Thickness 1.5 (38)
Back Width 20.5 (521)
Back Height (Min.) 23 (584)
ARMRESTS
Armrest (Type) Wooden
Armrest Clearance 19 (483)
Arm Height from Seat (Min.) 8.0 (203)
Arm Height from Floor (Min.) 29 (737)
FRAME
Frame (Type) Wood
MISCELLANEOUS
Unit Weight (lbs (kgs)) 22 (10.0)
Carton Count 1-PER
3500-000-340 Highback Flexback Chair (21”)
Reference P/N: STR3843-21

www.stryker.com 3500-009-001 REV D 19
Return To Table of Contents
3500-000-520 Steel Chair
Item Stryker P/N Reference P/N Part Description Qty.
13500-100-024 182352183 Arm and Frame Assembled 1
1.1 (not serviceable) 004062183BLK 4 Leg Metal Frame 1” Round Tube 1
1.1.1 3500-100-026 0100022171 Split Plastic Sleeve 4
1.1.2 3500-100-027 010050027 1” OD Round CLSR/GLD 14/18G 4
1.2 (not serviceable) 170032171 2171 Arm Assembly Only BLK PR
1.2.1 (not serviceable) 010 032171 2171 Plastic Arms BLK PR
1.2.2 (not serviceable) 004310610 1/4”-20 16 GA Tube Connector 4
1.2.3 (not serviceable) 004310097Q #8 x 5/8” Pan QD L.RT WS BLK 4
23500-100-033 16071STR2183 2171 UPH Seat withUC Foam 1
33500-100-034 004310282BLK 1/4”-20 x 1-1/4” FLT QD BLK 4
43500-100-035 008062171T-A 2171 Seat Bottom Tray ECN 1
53500-100-036 16032STR2183 Upholstery Back Only 1
63500-100-037 004310276 1/4”-20 x 5/8” TRS QD MS SR B 4
1.2
4
1
52
1.2.1
1.2.3
1.1.1
1.2.2
1.1.2
6
3
Reference P/N: STR2183

20 3500-009-001 REV D www.stryker.com
Return To Table of Contents
SPECIFICATIONS
DESCRIPTION SPECIFICATIONS
INCHES (MM)
Weight Capacity 300 lbs
CHAIR DIMENSIONS
Length 20 (508)
Width 23 (584)
Height
(Controls at mid-point or
nominal design position)
32 (813)
SEAT
Seat (Type) Plywood
Seat Foam (Type) Ultracell
Seat Foam Thickness 2.0 (51)
Seat Depth (Min.) 17. 5 (445)
Seat Depth (Max.) --- (0)
Seat Width 18 (457)
Seat Height (Min.) 18 (457)
Seat Height (Max.) --- (0)
BACK
Back Pan (Type) Plywood
Back Foam (Type) Slab
Back Foam Thickness 1.25 (32)
Back Width 17. 5 (445)
Back Height (Min.) 14 (356)
ARMRESTS
Armrest (Type) Plastic
Armrest Clearance 19.5 (495)
Arm Height from Seat (Min.) 8.0 (203)
Arm Height from Floor (Min.) 26 (660)
FRAME
Frame (Type) 1” Round Tubing
Thickness/Guage 16 Guage
MISCELLANEOUS
Unit Weight (lbs (kgs)) 14 (6.4)
Com Yardage (yds (m)) 1.0 (0.9)
Carton Count 2-PER
Cubage 13.25. (0.35)
Shipment Weight
(lbs (kgs)) 46 (20.9)
3500-000-520 Steel Chair
REFERENCE P/N: STR2183
