Stryker Highpointe 4400-700-000 User manual

www.stryker.com 4400-700-900 REV E 1
Highpointe Bedside Stand, 1-Drawer/1-Door - Model 4400-700-000
19.4
18.50
31.0
18.0
ASSEMBLY METHOD
The Stryker Med/Surg Beside Stand is constructed using
a locking cam and dowel pin arrangement.
To dismantle the unit, use a #2 Phillips screwdriver
to unlock each cam by rotating the cam in a counter-
clockwise direction.
UNLOCK
LOCK
NOTE:
The product serial number label is located
on the back of the unit.
C
E
G
A
B
F
D
9
14 13
1
3
6
7
2
4
5
11
8
12
10
15
16
17
Reference
Table
on Back

24400-700-900 REV E www.stryker.com
3800 E. Centre Ave., Portage, MI 49002
[phone] Option 2
Highpointe Bedside Stand, 1-Drawer/1-Door - Model 4400-700-000
Bedside Stand Common Components
Item Part Number Part Name Qty.
1 4400-500-500 Case (see Case Assembly Table) 1
2 3100-200-110 Highpointe Top Panel 1
3 3150-052-734 Caster 4
4 3100-052-733 Dowel Pin 6
5 3100-052-732 Cam 6
6 0020-013-000 Wood Screw 48
7 4400-500-205 L-Bracket 3
8 3100-052-737 Plastic Vent 1
9 4400-600-203 Drawer Frame 1
10 3100-052-743 Rivet 6
11 4400-600-204 Drawer Slides 1
12 4400-111-302 Hinge 2
13 4400-111-309 Shelf Pin 4
14 4400-500-207 Adjustable Shelf 1
15 4400-009-100 Cleaning / Serial Number Label 1
16 3100-200-208 Drawer Liner 1
17 4400-700-209 HIghpoine Door 1
Standard Configuration
Part Number Part Name Qty.
4400-700-208 Drawer Front 1
Key Lock Option
Part Number Part Name Qty.
4400-500-300 Lock 1
4400-700-210 Drawer Front 1
Slam Lock Option
Part Number Part Name Qty.
4400-500-301 Lock 1
4400-700-211 Drawer Front 1
Hardware Option
Part Number Part Name Qty.
4400-700-201 Brass Pull 2
4400-700-202 Chrome Pull 2
(1) Case Assembly
Item Part Number Part Name Qty.
A 4400-500-218 Bottom Panel 1
B 4400-500-201 Back Panel 1
C 4400-500-216 Right SIde Panel 1
D 4400-500-217 Left Side Panel 1
E 3100-052-733 Dowel Pin 16
F 3100-052-732 Cam 16
G 4400-500-204
4400-500-224
4400-500-223
Brace (No Lock)
Brace (Slam Lock)
Brace (Key Lock)
1
1
1
DISINFECTION PROCEDURE
The Center for Disease Control recommends a 1:4 mixture of bleach and water for disinfection. Thoroughly rinse the
solution from the product surface. If other hospital-grade cleaning agents are used, follow the instructions provided by
the cleaning solution’s manufacturer. Wipe the surface with a soft, dry cloth to remove any moisture.
WARRANTY
Stryker warrants this product for one (1) year under normal use and proper care. For one year from date of shipment,
Stryker will repair or, at our option, replace defective merchandise free of charge (parts, labor, and shipping included).
Note: LIFETIME warranty on metal drawer frames and glides.
