Legend Bedside Stand, 1-Drawer/1-Door - Model 4400-500-000
19.4
18.5
30.5
18.0
ASSEMBLY METHOD
The Stryker Med/Surg Beside Stand is constructed using
a locking cam and dowel pin arrangement.
To dismantle the unit, use a #2 Phillips screwdriver
to unlock each cam by rotating the cam in a counter-
clockwise direction.
UNLOCK
LOCK
NOTE:
The product serial number label is located
on the back of the unit.
D
G
E
F
B
C
A
6
4
1
9
3
16
7
8
5
11
12
13
14
15
Reference Table
on Back
Reference Table
on Back

24400-500-900 REV E www.stryker.com
3800 E. Centre Ave., Portage, MI 49002
[phone] Option 2
Legend Bedside Stand, 1-Drawer/1-Door - Model 4400-500-000
Bedside Stand Common Components
Item Part Number Part Name Qty.
1 4400-508-100 Case (see Case Assembly Table) 1
3 3150-001-200 Caster 4
4 3100-052-733 Dowel Pin 6
5 3100-052-732 Cam 6
6 0020-013-000 Wood Screw 4
7 4400-500-205 L-Bracket 3
8 3100-052-731 Drawer Guide (set of 2) 1
9 4400-111-302 Hinge 2
11 3100-052-737 Plastic Vent 1
12 4400-009-100 Cleaning / Serial Number Label 1
13 4400-111-309 Shelf Pin 4
14 4400-500-207 Adjustable Shelf 1
15 3100-200-108 Drawer Liner 1
16 0020-021-000 Wood Screw 28
Standard Configuration
Part Number Part Name Qty.
4400-500-219 Drawer Front 1
Door Option
Part Number Part Name Qty.
8100-503-001 Right Side Hinges 1
8100-503-002 Left Side Hinges 1
Top Panel Option
Part Number Part Name Qty.
3100-200-110 Legend Top 1
Key Lock Option
Part Number Part Name Qty.
4400-500-300 Lock 1
4400-500-221 Drawer Front 1
Slam Lock Option
Part Number Part Name Qty.
4400-500-301 Lock 1
4400-500-222 Drawer Front 1
Hardware Option
Part Number Part Name Qty.
4400-500-208 Brass Pull 2
4400-500-209 Chrome Pull 2
(1) Case Assembly
Item Part Number Part Name Qty.
A 4400-508-118 Bottom Panel 1
B 4400-500-201 Back Panel 1
C 4400-508-116 Right SIde Panel 1
D 4400-508-117 Left Side Panel 1
E 3100-052-733 Dowel Pin 16
F 3100-052-732 Cam 16
G 4400-500-204
4400-500-224
4400-500-223
Brace (No Lock)
Brace (Slam Lock)
Brace (Key Lock)
1
1
1
DISINFECTION PROCEDURE
The Center for Disease Control recommends a 1:4 mixture of bleach and water for disinfection. Thoroughly rinse the
solution from the product surface. If other hospital-grade cleaning agents are used, follow the instructions provided by
the cleaning solution’s manufacturer. Wipe the surface with a soft, dry cloth to remove any moisture.
WARRANTY
Stryker warrants this product for one (1) year under normal use and proper care. For one year from date of shipment,
Stryker will repair or, at our option, replace defective merchandise free of charge (parts, labor, and shipping included).
Note: LIFETIME warranty on metal drawer frames and glides.
