Stryker InTouch FL27 series User manual

InTouch™ Critical
Care Bed
Model FL27 (2131/2141)
Maintenance Manual
2012/04 C.1 2131-409-002 REV C www.stryker.com
For Parts or Technical Assistance:
USA: 1-800-327-0770 (option 2)
Canada: 1-888-233-6888
Version 2.4

Return To Table of Contents
www.stryker.com 2131-409-002 REV C 3
Table of Contents
Symbols ................................................................................6
Introduction .............................................................................7
Intended Use .........................................................................7
Brief Product Description and Intended Use Statement ..........................................7
Product Illustration .....................................................................8
Specifications ........................................................................9
Warning / Caution / Note Definition........................................................10
Summary of Safety Precautions .............................................................11
Optional Zoom®Drive System (Model 2141) .................................................13
Static Discharge Precautions ...............................................................14
Setup Procedures........................................................................15
Optional XPRT Therapy Mattress .........................................................16
Optional PositionPRO™ Repositioning Mattress option ........................................16
Optional Zoom® Drive System (Model 2141).................................................17
Maintenance Menu Guide ..................................................................18
Configuration Screen ..................................................................19
Bed Calibration ...................................................................19
Preventative Maintenance ..................................................................32
Checklist ...........................................................................32
Cleaning...............................................................................33
Troubleshooting Guide ....................................................................35
Scale Troubleshooting .................................................................41
Maintenance Error Messages ...............................................................42
Error Handling .......................................................................42
Error Messages ......................................................................42
Quick Reference Replacement Parts List ......................................................45
Quick Reference Replacement Parts List ......................................................46
CPU/Power Board - QDF75-0110 ............................................................47
Software Configuration for CPU/Power Board SW1 ...............................................48
Fuse Specification ....................................................................49
Bed Electrical Diagram ....................................................................51
Service Information.......................................................................66
Bed lift Actuator (Head) Removal and Replacement - (Base).....................................66
Bed lift Actuator (Foot) Removal and Replacement - (Base) .....................................67
Fowler Actuator Removal and Replacement - (Litter) ..........................................68
Gatch Actuator Removal and Replacement - (Litter) ...........................................69
Foot Actuator Removal and Replacement - (Litter) ............................................70
Zoom® Drive Actuator Removal and Replacement (2141 Model Only) - (Base) .......................71
CPU / Power Board Removal and Replacement - (Litter)........................................72
Load Cell (Head End) Removal and Replacement - (Litter)......................................73
Load Cell (Foot End) Removal and Replacement - (Litter) ......................................74
Display Removal and Replacement - (Footboard) .............................................75
Brake Control Board Removal and Replacement - (Footboard) ...................................76
Function Selection/LED Board Removal and Replacement - (Footboard) ...........................77
Touch Screen Removal and Replacement - (Footboard) ........................................78

4 2131-409-002 REV C www.stryker.com
Table of Contents
Service Information (Continued)
Battery Removal and Replacement - (Foot Board).............................................79
Brake / Neutral / Drive Potentiometer Removal and Replacement - QDF27-2024 ......................80
Battery Removal and Replacement - (Litter) .................................................81
Fowler Angle Sensor Removal and Replacement - (Litter) ......................................82
Gatch Angle Sensor Removal and Replacement - (Litter) .......................................83
Foot Angle Sensor Removal and Replacement - (Litter) ........................................84
Base Angle Sensor Removal and Replacement - (Base) ........................................85
Trend Angle Sensor Removal and Replacement - (Litter) .......................................86
Headwall Communication Board Removal and Replacement - (Litter) ..............................87
Base Assembly, Hood .....................................................................88
Base Assembly, Brake ....................................................................91
Base Assembly, Caster Lock (2131 Model Only) .................................................94
Base Assembly, Caster Non-Lock (2141 Model Only)..............................................96
Angle Sensor Assembly - 27-2477............................................................98
Base Assembly, Electrical..................................................................99
Base Assembly, ZOOM® .................................................................105
Base Assembly, ZOOM®Drive (2141 Model Only) ...............................................106
Bed Labeling ..........................................................................108
Lift Assembly ..........................................................................112
Spring Assembly........................................................................116
Litter Assembly.........................................................................118
Litter Assembly, Interior Frame .............................................................123
Litter Assembly with Serial Cable ...........................................................126
Litter Assembly, Upper Frame ..............................................................128
Litter Assembly, Foot End .................................................................13 0
Litter Assembly, Electrical.................................................................13 5
120V Electric System ....................................................................142
120V Straight Plug - OL250053.............................................................143
Optional 120V 90 Degree Plug - OL250055....................................................144
Litter Assembly, Foot End, w/out Mattress Connector - OL270165 ...................................145
Litter Assembly, Foot End, with Mattress Connector - OL270166 ....................................146
Litter Assembly, Optional Dual 120V Outlet ....................................................148
Optional 100V Electric System .............................................................150
Optional 200V Electric System .............................................................151
Optional 220V Electric System .............................................................15 2
Optional 240V Electric System .............................................................15 3
CPR Assembly, Mechanical ...............................................................154
Handle Assembly (Model 2131 Only).........................................................159
Handle Assembly (ZOOM® Model 2141 Only) ..................................................160
ZOOM® Assembly .......................................................................162
Optional No Head End Control Panel.........................................................163
Optional Head End Control Panel Assembly ...................................................164
Head End Siderail Mounting Assembly .......................................................166
Standard Siderail Assembly, Head End, Right ..................................................167

www.stryker.com 2131-409-002 REV C 5
Table of Contents
Assembly Drawings (Continued)
Standard Siderail Assembly, Head End, Left ................................................... 171
Standard Siderail Assembly, Labeling ........................................................ 17 5
Optional Siderail Ass’y, HE, without Speaker/without NC ..........................................17 6
Optional Siderail Ass’y, HE, with Speaker/without NC.............................................17 7
Optional Siderail Ass’y, HE, with Speaker/iAudio ................................................ 178
Optional Siderail Ass’y, HE, with Speaker/with NC ............................................... 17 9
Optional Siderail Ass’y, HE, with iAudio - OL270164 .............................................180
Optional Siderail Ass’y, HE, with Speaker/with NC/with iAudio ......................................182
Foot End Siderail Mounting Assembly ........................................................184
Standard Siderail Assembly, Foot End, Right - Common...........................................185
Standard Siderail Assembly, Foot End, Left - Common............................................188
Optional Siderail Assembly with iBed ........................................................192
Headboard and Footboard Assembly .........................................................193
Standard Footboard Assembly - Common .....................................................194
Footboard Assembly without iBed ...........................................................196
Footboard USB Assembly ................................................................202
Optional Bed Accessories.................................................................203
Notes ................................................................................204
Bed Extender - FA64234..................................................................205
Bed Extender, Position Pro Mattress - DM64196 ................................................206
Bed Extender, XPRT Mattress - DM64197 .....................................................206
Line Management System Assembly - FA64210.................................................207
I.V. Pole Assembly, Permanent - FA64221/FA64238 ..............................................208
I.V. Pole Ass’y, Dual Head End, Permanent - FA64202 ............................................209
Monitor Tray Assembly - FA64214 ...........................................................211
Upright Oxygen Bottle Holder Assembly - FA64187 ..............................................212
Right-Fit Oxygen Bottle Holder Assembly - FA64203 ............................................. 213
Pendant Assembly with Motion Control - FA64209 ..............................................215
Pendant Assembly with Motion Control/NC - FA64226 ...........................................216
Pendant Assembly with Motion Control/Smart TV - FA64195 ....................................... 217
Pendant Assembly with Motion Control/NC/Smart TV - FA64225....................................218
Pendant Clip Assembly - FA64186 ..........................................................219
Traction Sleeve Assembly, 4” x 1/2” - FA64215 .................................................220
Traction Sleeve Assembly, 4” x 3/4” - FA64216 .................................................221
Traction Sleeve Assembly, 8” x 1/2” - FA64217 .................................................222
Traction Sleeve Assembly, 8” x 3/4” - FA64218 .................................................223
Traction Sleeve Assembly, 6-1/2” x 3/4” - FA64219 ..............................................224
Wall Saver Cable Assembly - FA64208 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 225
X-Ray Cassette Holder Assembly - FA64205 ...................................................227
Warranty .............................................................................229
Recycling Passports .....................................................................231

Return To Table of Contents
6 2131-409-002 REV C www.stryker.com
Type B Equipment: equipment providing a particular degree of protection against electric shock,
particularly regarding allowable leakage current and reliability of the protective earth connection.
Class 1 Equipment: equipment in which protection against electric shock does not rely on BASIC
INSULATION only, but which includes an additional safety precaution in that means are provided for the
connection of the EQUIPMENT to the protective earth conductor in the fixed wiring of the installation in
such a way that ACCESSIBLE METAL PARTS cannot become live in the event of a failure of the BASIC
INSULATION.
Mode of Operation: Continuous
Protection from liquid splash
IPX4
Alternating Current
1.6 SYMBOLS
10A 250V
~
Safe Working Load Symbol
Medical Equipment approved by the Canadian Standards Association with Respect to Electric Shock,
Fire, Mechanical and Other Specified Hazards.
Potential Equalization Symbol
Protective Earth Terminal
Dangerous Voltage Symbol
Fuse Rating for Beds with the 120V~ Electric System
Symbols
Warning/Caution, consult accompanying documentation
1.6 SYMBOLS
6.3A 250V
Fuse Rating for Beds with the 200V~ or 220V~ or 240V~ Electric System
In accordance with European Directive 2002/96/EC on Waste Electrical and Electronic Equipment, this
symbol indicates that the product must not be disposed of as unsorted municipal waste, but should be
collected separately. Refer to your local distributor for return and/or collection systems available in your
country.

Return To Table of Contents
www.stryker.com 2131-409-002 REV C 7
INTENDED USE
This manual is designed to assist you with the maintenance of the Stryker InTouch™ Critical Care Bed, Model FL27
(2131/2141). Carefully read this manual thoroughly before using the equipment or beginning maintenance on it. To ensure
safe operation of this equipment, it is recommended that methods and procedures be established for educating and
training staff on the safe operation of this bed.
This Maintenance Manual is an integral part of the bed and should be included if the bed is sold or transferred.
BRIEF PRODUCT DESCRIPTION AND INTENDED USE STATEMENT
Intended Medical Indications: In-touch is an AC-powered adjustable hospital bed designed to position patients for proce-
dures, therapy, and recovery in healthcare environment, transport patients between bays and procedural rooms, provide
patient security, measure and display patient weight, allow patients to alert caregiver when the patient requires emer-
gency assistance or any assistance to improve comfort levels, and monitor patient position to alert caregiver of a deliber-
ate exit or potential fall. The bed has thirty-nine prerecorded clinical phrases in 24 languages and offers music therapy.
Intended Patient Population: The intended patient population is acute-care human patients. The safe working load (i.e.
the sum of the patient, the mattress, and accessory weight) for InTouch is 550lbs (250kg). This bed is not intended for
use with patients 35 inches or less and/or patients that weigh less than 50 pounds.
Intended Part of the body: InTouch is intended to support a patient. It is intended to be used with a sleep surface. The
Frame can come in contact with human skin but a patient should never be on the frame without a support surface.
Intended user profile: InTouch is intended for use in Acute Care settings. These settings may include critical care, step
down, progressive care, med/surg, sub-acute care, and post anesthesia care unit (PACU) or other locations as pre-
scribed. Intended operators are health care professionals (nurses, nurse aids, doctors) which can use all bed operations
(e.g., bed motion functions, nurse call, siderail communications, bed exit, therapy options), patient and bystander, which
can use bed motion functions, nurse call & siderail communications, and trained professionals for installation, service,
and calibration.
Intended condition of use and expected life: Stryker Medical Bed products are designed for a 10 year expected service
life under normal use, conditions, and with appropriate periodic maintenance as described in the maintenance manual
for each device. Stryker warrants to the original purchaser that the welds on its Bed products will be free from structural
defects for the expected 10 year life of the Bed product as long as the original purchaser owns the products.
The product is intended to be used in a healthcare environment, including hospitals, surgery centers, long term acute
care centers, and rehabilitation centers. The intended environmental conditions are 10 to 40 degrees Celsius and 30 to
75% RH. The product is compatible with 35” x 84” surfaces, the facility nurse call system, standard Med-Surg equip-
ment, and the facility infrastructure. InTouch is intended to be used with a 6”-8.5” sleep surface; asleep surface or
overlay greater than 6” that offers therapeutic value may be used with, patient supervision.
Introduction

Return To Table of Contents
8 2131-409-002 REV C www.stryker.com
Nurse Control
Panel
Casters
ZOOM®Drive Wheel
(Model 2141 only)
(Under base -
not shown)
Siderails
Footboard
Control Panel
Footboard
Nurse Call
Foley Bag
Hooks
CPR Emergency
Release Pedal
Manual
Backup
Siderail
Release
Levers
Brake Control
Panel
Headboard
InTouch™
Screen
PRODUCT ILLUSTRATION
Introduction

Return To Table of Contents
www.stryker.com 2131-409-002 REV C 9
Introduction
SPECIFICATIONS
Safe Working Load
Note: Safe Working Load indicates the
sum of the patient, mattress and accessory
weight.
550 lbs 250 kg
Bed Weight 750 lbs 340.2 kg
Overall Bed Length 90” 228,6 cm
Overall Bed
Width
Siderails Up 42” 106,7 cm
Siderails Down 41” 104,1 cm
Base Underbed Clearance 5” 12,7 cm
Litter Patient Surface
• Width
• Length
• Length (with Optional Bed
Extender)
35”
84”
90”
88,9 cm
213,4 cm
228,6 cm
Seat Section
• Depth 18.5” 47 cm
Foot Section
• Length
• Angle
29”
0° to 50°
73,7 cm
0° to 50°
Fowler Section
• Length
• Width
• Angle
36”
34” to 35”
0° to 70°
91,4 cm
86,4 cm - 88,9 cm
0° to 70°
Gatch Section
• Length
• Width
• Angle
18”
34” to 35”
0° to 15°
45,7 cm
86,4 cm - 88,9 cm
0° to 15°
Cardiac Chair
• Standard Cardiac Chair Position
• Enhanced Cardiac Chair Position
Head: 65°, Seat: 17°, Foot: 30°, Trend: 3°
Head: 70°, Seat: 19°, Foot: 47°, Trend: 3°
Fowler Length 36.5” 92,7 cm
Bed Lift
System
Height (high) to top of litter 31” 78,7 cm
Height (low) to top of litter 16” 40,6 cm
Trendelenburg/Reverse Trendelenburg 12°
Bed Lift Time 35 seconds maximum from lowest to highest position
Scale System Capacity 550 lbs 250 kg
Accuracy:
• For weight from 100 lb to 550 lb
• For weight from 100 lb to 550 lb
• For weight under 100 lb
• For weight under 100 lb
+/- 2% when in Trendelenburg or Reverse Trendelenburg
+/- 1% when Flat
+/- 2 lb when in Trendelenburg or Reverse
Trendelenburg
+/- 1 lb when Flat
CPR System Speed to level bed from any position
• Fowler
• Foot
• Seat
15 seconds
60 seconds
30 seconds
Drive System Speed (Optional ZOOM®Drive)
• Forward
• Backwards
3.6 mph
2.5 mph
5.8 km/h
4.0 km/h

Return To Table of Contents
10 2131-409-002 REV C www.stryker.com
Introduction
SPECIFICATIONS (CONTINUED)
Mattress
Recommended Mattress Size 35” x 84” x 6” 88,9 cm x 213,4 cm x 15,2 cm
Recommended Air Mattress Size 35” x 84” x 6” - 8.5” 88,9 cm x 213,4 cm x
15,2 cm - 21,6 cm
Maximum
Current
Consumption
Without Optional Auxiliary Outlet
(120VAC Only) 4.8 Amps
With Optional Auxiliary Outlet(s)
(120VAC Only) 9.8 Amps
Environmental
Conditions
Storage
• Ambient Temperature
• Relative Humidity
• Atmospheric Pressure
-40°F to 158°F
10 to 100%
500 to 1060 hPa
-40°C to 70°C
Operating
• Ambient Temperature
• Relative Humidity
• Atmospheric Pressure
50°F to 104°F
30 to 75%
700 to 1060 hPa
10°C to 40°C
Electrical
Requirements
All electrical requirements meet CSA
C22.2 No. 601.1, UL 60601-1 and IEC
60601-1.60601-2-38 specifications.
100V~, 50-60Hz, 7.5A - Two 250V, 10A Fuses
120 ± 10% Vac, 50/60Hz - Two 250V, 10A Fuses
120V~, 50-60Hz, 4.0A (9.8A with 120V Optional Auxiliary
Outlet) - Two 250V, 10A Fuses
200V~, 50-60Hz, 3.2A -Two 250V, 10A Fuses
220V~, 50-60Hz, 2.9A -Two 250V, 10A Fuses
240V~, 50-60Hz, 2.7A -Two 250V, 10A Fuses
Battery
12 V, 17.6 Ahr, Sealed Lead-Acid Battery (Part Number QDF9188)
3.0 V 220mAh Lithium Battery, Size 20mm - Varta Int. CR2032
Coin Cell PC Battery Holder, Size 20mm - MDP Int. BA2032
Stryker reserves the right to change specifications without notice.
Specifications listed are approximate and may vary slightly from unit to unit or by power supply fluctuations.
WARNING / CAUTION / NOTE DEFINITION
The words WARNING, CAUTION, and NOTE carry special meanings and should be carefully reviewed.
WARNING
Alerts the reader about a situation, which if not avoided, could result in death or serious injury. It may also describe
potential serious adverse reactions and safety hazards.
CAUTION
Alerts the reader of a potentially hazardous situation, which if not avoided, may result in minor or moderate injury to the
user or patient or damage to the equipment or other property. This includes special care necessary for the safe and
effective use of the device and the care necessary to avoid damage to a device that may occur as a result of use or
misuse.
Note
This provides special information to make maintenance easier or important instructions clearer.
