Sub-Zero Designer Series User manual

Designer Series
Undercounter Wine Storage
Installation Guide
SPECIFICATIONS, INSTALLATION,
AND MORE

2 | Sub-Zero Customer Care 800.222.7820
Designer Series Undercounter Wine Storage
Contents
3Designer Series Undercounter Wine Storage
4Opening Dimensions
6Electrical Requirements
7Preparation
7Anti-Tip Bracket
890° Door Stop
8Placement
9Alignment
10 Door Panel
12 Panel Installation
14 Completion
Features and specifications are subject to change at any
time without notice. Visit subzero.com/specs for the most
up-to-date information.
Important Note
To ensure this product is installed and operated as safely
and eciently as possible, take note of the following types
of highlighted information throughout this guide:
IMPORTANT NOTE highlights information that is especially
important.
CAUTION indicates a situation where minor injury or prod-
uct damage may occur if instructions are not followed.
WARNING states a hazard that may cause serious injury or
death if precautions are not followed.
IMPORTANT NOTE: Throughout this guide, dimensions in
parentheses are millimeters unless otherwise specified.
IMPORTANT NOTE: Save these instructions for the local
electrical inspector.

subzero.com | 3
Designer Series Undercounter Wine Storage
Product Information
Important product information, including the model and
serial number, are listed on the product rating plate. For
the 24" model, the rating plate is located on the underside
of the control panel, on the left. For the 15" model, it is
located inside the cabinet, in the upper left. Refer to the
illustrations below.
If service is necessary, contact Sub-Zero Factory Certified
Service with the model and serial number. For the name of
the nearest Sub-Zero Factory Certified Service or for ques-
tions regarding the installation, visit the Product Support
section of our website, subzero.com, or call Sub-Zero
Customer Care at 800-222-7820.
RATING PLATERATING PLATE
Rating plate location
(24" model)
Rating plate location
(15" model)

4 | Sub-Zero Customer Care 800.222.7820
Site Preparation
Opening Dimensions
UNDERCOUNTER WINE STORAGE MODELS
W
OPENING WIDTH
H
OPENING
HEIGHT
TOP VIEW
SIDE VIEWF
RONT VIEW
NOTE: 3
1/2" (89) finished returns will be visible and should be finished to match cabinetry.
3/4" (19)
TYPICAL
FRAMED
CABINETRY
W
FILLER
31/2" (89)
FINISHED
RETURN
FRAMELESS
CABINETRY
W
3/4" (19)
TYPICAL
31/2" (89)
FINISHED
RETURN
24" (610)
OPENING
DEPTH
OPENING DIMENSIONS W H
24" Model (standard height) 24" (610) 34⁄" (876)
24" Model (ADA height) 24" (610) 32⁄" (826)
15" Model (standard height) 15" (381) 34⁄" (876)
The depth of each model is 23⁄" (587). Allow for panel
thickness when planning the finished opening depth. A
minimum 3⁄" (89) finished return is required on all sides of
the opening. Framed cabinets require additional finished
filler material behind the face frame for a proper installa-
tion. Refer to the illustration.

subzero.com | 5
Opening Dimensions
DUAL INSTALLATION
If two units are installed side by side, a dual installation kit
may be required. Installations without a custom filler strip
require a dual installation kit. If a dual installation kit is not
specified, a 2" (51) filler strip is recommended between the
units. Dual installations without a filler strip can only be
accomplished using two units with opposite hinges. Refer
to the illustrations.
Dual installation kits are available through an authorized
Sub-Zero dealer. For local dealer information, visit the find
a showroom section of our website, subzero.com. For
questions regarding the installation, call Sub-Zero Cus-
tomer Care at 800-222-7820.
DUAL OPENING WIDTH W
Two 15" Models 30" (762)
15" and 24" Models 39" (991)
Two 24" Models 48" (1219)
Dual installation kit required.
WITHOUT FILLER STRIP FILLER STRIP
Opposite hinges Same side hinges
Site Preparation

6 | Sub-Zero Customer Care 800.222.7820
Electrical Requirements
Installation must comply with all applicable electrical codes.
The electrical supply should be located within the shaded
area shown in the illustration below. A separate circuit ser-
vicing only this appliance is required. A ground fault circuit
interrupter (GFCI) is not recommended and may cause
interruption of operation.
The electrical outlet must be positioned with the ground-
ing prong to the right of the thinner blades.
ELECTRICAL REQUIREMENTS
Electrical Supply 115 VAC, 60 Hz
Service 15 amp dedicated circuit
Receptacle 3-prong grounding-type
CAUTION
The outlet must be checked by a qualified electrician
to be sure it is wired with the correct polarity. Verify
the outlet is properly grounded.
WARNING
If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly quali-
fied persons in order to avoid a hazard.
WARNING
Do not locate multiple portable socket-outlets,
power strip, or portable power supplies at the rear of
the appliance.
WARNING
Do not use an extension cord, two-prong adapter, or
remove the power cord ground prong.
Site Preparation
5"
(127) 2" (51)
4"
(102)
FLOOR
OPENING
Electrical supply location

subzero.com | 7
Preparation
Uncrate the unit and inspect for damage. Remove and
recycle packing materials. Do not discard the kickplate,
anti-tip bracket, and hardware.
Remove the kickplate by extracting the two mounting
screws. Refer to the illustration below.
SCREW
Kickplate removal
Site Preparation
Anti-Tip Bracket
WARNING
To prevent the unit from tipping forward, the anti-tip
bracket must be installed.
The anti-tip bracket should be attached to the wall behind
the unit with the bracket flange located ⁄" (6) above the
top of the unit. Refer to the illustration below. Failure to
properly position the anti-tip bracket will prevent proper
engagement.
1/4" (6)
ANTI-TIP
BRACKET
Anti-tip bracket

8 | Sub-Zero Customer Care 800.222.7820
Placement
CAUTION
Before moving the unit into position, secure the door
closed and protect any finished flooring.
WARNING
When positioning the appliance, ensure the supply
cord is not trapped or damaged.
Use an appliance dolly to move the unit near the opening.
If the unit has been on its back or side, it must stand
upright for a minimum of 24 hours before connecting
power.
Plug the power cord into the grounded outlet and slide
the unit into position. Verify the anti-tip bracket is properly
engaged.
Site Preparation
90° Door Stop
The door stop pins provided with the unit limit the door
swing to 90°.
IMPORTANT NOTE: If a 90° door opening is desired, the
pins must be installed prior to installing the unit into the
opening.
To install, open the door to approximately 80°. Insert one
pin into each hinge. Refer to the illustration below.
DOOR STOP PIN
90° door stop

subzero.com | 9
Alignment
LEVELING
Once the unit is in position, rotate the front legs clockwise
to raise and counterclockwise to lower. Rear height adjust-
ment can be made from the front. Using a Phillips drive,
turn clockwise to raise the unit or counterclockwise to
lower. Use the lowest torque setting when using a power
drill. Do not turn the leveling legs by hand. Refer to the
illustration below.
When the unit is properly leveled, door adjustments are
less likely to be necessary.
IMPORTANT NOTE: Level the unit to the floor, not the
surrounding cabinetry. This could aect the operation of
the unit, such as door closing.
WARNING
To reduce the possibility of the unit tipping forward,
the front leveling legs must be in contact with the
floor.
REAR
ADJUSTMENT
FRONT
ADJUSTMENT
Leveling
Installation
ANCHORING
CAUTION
If using a power drill to predrill holes or install
screws, verify the drill chuck does not contact the
units face frame.
Adjust the depth of the unit to fit flush with the surround-
ing cabinetry. Allow for panel thickness. Once aligned,
verify the door opens properly, then install a #8 x ⁄" flat-
decorative head screw in each bracket.
WARNING
To avoid a hazard due to instability of the appliance,
it must be fixed in accordance with the instructions.
Anchoring

10 | Sub-Zero Customer Care 800.222.7820
Custom Panel
A custom door panel and handle hardware must be
installed.
A ⁄" (16) minimum to ⁄" (19) maximum thick panel is
required. The panel cannot exceed the maximum panel
weight indicated in the chart below. The depth of each
model is 23⁄" (587). Allow for panel thickness when plan-
ning the finished opening depth.
Minimum ⁄" (3) reveals are required.
PANEL WEIGHT MAX
24" Model 22 lb (10 kg)
15" Model 15 lb (7 kg)
Finish all sides of the custom panel. They will be visible
when the door is open.
A D-style handle is recommended. Locate the door handle
near the edge of the panel opposite the hinge and cen-
tered top to bottom. Stainless steel tubular and pro handles
are available through an authorized Sub-Zero dealer. For
local dealer information, visit the find a showroom section
of our website, subzero.com.
Stainless Steel Panel
Stainless steel door panels are available through an autho-
rized Sub-Zero dealer. For local dealer information, visit the
find a showroom section of our website, subzero.com.
Minimum ⁄" (3) reveals are required.
Door Panel

subzero.com | 11
Door Panel
Custom Panel
TOE KICK CLEARANCE
The height of the toe kick area can extend beyond the
typical toe kick height, provided it does not exceed the
dimensions in the illustration below. For questions
regarding the installation, call Sub-Zero Customer Care
at 800-222-7820.
MAXIMUM DOOR OPENING
As the panel width and/or depth increases, so does the
potential for panel interference. Interference may be
minimized by using the 90° door stop.
3/8" (10)
DOOR CLOSED
3/4" (19) PANEL
1/8" (3) REVEAL
ADJACENT
CABINETRY
DOOR
OPEN
90°
DOOR OPEN
MAXIMUM 115°
Maximum door opening (top view)
DOOR
PANEL HINGE
231/8" (587)
TO BACK OF UNIT
2" (51)
TO
41/2" (114)
FROM
FLOOR
31/2" (89)
MAX DEPTH
11/8" (29)
KICKPLATE
ADJUSTMENT
341/2" (876)
OR
321/2" (826)
TYPICAL
PRODUCT
HEIGHT
DECORATIVE KICKPLATE
CANNOT EXTEND
BEYOND THIS
POINT
33/8" (86)*
DECORATIVE
KICKPLATE
HEIGHT
*Not included. Dimension will vary as the product height increases or decreases
from the typical product height.
Toe kick clearance (side view)

12 | Sub-Zero Customer Care 800.222.7820
Panel Installation
Panel Installation
DOOR PANEL INSTALLATION
Placement of the template must be adjusted for panels
exceeding the typical dimensions.
Place the panel face down on a protected work surface.
Position the template flush with the top and sides of the
panel. Verify the correct side of the template is being used,
then mark and drill pilot holes. Refer to the illustration
below.
Use a Torx drive to partially insert a #8 x ⁄" screw into the
second hole from the top on each side of the panel. The
screws should be approximately ⁄" (4) proud of the panel
and will support the weight of the panel during installation.
Align the support screws on the back of the panel with the
slotted holes on both door mounting brackets. Refer to
the illustration below. Opening the door slightly may help
with alignment. Once the panel is supported by the screws,
partially insert a #8 x ⁄" screw into the second hole from
the bottom on each side of the panel, but do not tighten.
CAUTION
As reveals between cabinetry and the unit decrease,
severe finger pinching can occur while the door is
closing.
BACK OF PANEL
Door panel mounting
TOP OF DOOR PANEL
TOP OF DOOR PANEL
USE THIS SIDE ON ALL
STANDARD HEIGHT DOORS
FLIP TEMPLATE
OVER FOR ADA
HEIGHT DOORS
LEFT SIDE DOOR PANEL
RIGHT SIDE DOOR PANEL
Door panel template

subzero.com | 13
Panel Installation
DOOR PANEL ADJUSTMENT
Close the door. Make any necessary adjustments to align
the panel and reveals.
For side-to-side adjustment, move the panel side to side,
then install and tighten all mounting screws.
For up-and-down and in-and-out adjustments, slightly
loosen the bracket screws. Depending on the level of
adjustment required, it may be helpful to loosen all of the
bracket screws which will allow for maximum adjustment.
Once the bracket screws are loosened, use a wrench to
rotate the cams to make adjustments. After the adjust-
ments have been made, tighten all bracket screws. Refer to
the illustrations below.
Panel Installation
BRACKET
SCREWS
IN-AND-OUT
CAM
BRACKET
SCREWS
UP-AND-DOWN
CAM
In-and-out adjustment Up-and-down adjustment

14 | Sub-Zero Customer Care 800.222.7820
KICKPLATE INSTALLATION
The kickplate must be removable for service. The floor
cannot interfere with removal. Finger-tighten the adjust-
ment bracket nuts. Refer to the illustration below. Make
in-and-out adjustments, then wrench-tighten the bracket
nuts. Install the kickplate with the provided screws.
A decorative kickplate can be attached to the factory-
installed kickplate. The three rows of vented louvers
cannot be covered.
To install a decorative kickplate, remove the paper backing
from the magnets and attach the decorative kickplate to
the magnets. The magnets allow the decorative kickplate
to be removed if necessary.
Installation
IN-AND-OUT
ADJUSTMENT SCREW
MAGNET
Kickplate adjustment Kickplate installation
Completion
DOOR TRIM INSTALLATION
After the door panel has been adjusted, install the deco-
rative side trim to the door. To install, start at the top
and align the trim with the front and rear flanges on the
bracket, then snap into place by pushing the trim toward
the back of the panel. Once the top is secure, continue the
installation downward until the remaining trim is com-
pletely secure. Refer to the illustration below.
SIDE TRIM INSTALLATION
Install the decorative trim strip to the handle side of the
unit. The side trim snaps over the brackets attached to the
handle side of the unit. Refer to the illustration below.
Door side trim Unit side trim

subzero.com | 15
Sub-Zero, Sub-Zero & Design, Sub-Zero & Snowflake Design, Dual Refrigeration, The Living Kitchen, Great American Kitchens The Fine Art of Kitchen Design, Wolf, Wolf &
Design, Wolf Gourmet, W & Design, red colored knobs, Cove, and Cove & Design are registered trademarks and service marks of Sub-Zero Group, Inc. and its subsidiaries.
All other trademarks are property of their respective owners in the United States and other countries.
Installation
Completion
WARNING
Follow all city and state laws when storing, recycling,
or discarding unused refrigerators and freezers.

2 | Atención al cliente de Sub-Zero 800.222.7820
Almacenamiento de vinos bajo el mostrador de la Serie de Diseño
Contenido
3Almacenamiento de vinos bajo el mostrador de la
Serie de Diseño
4Dimensiones de abertura
6Requisitos eléctricos
7Preparación
7Soporte antivuelco
8Tope para puerta a 90°
8Colocación
9Alineación
10 Panel de la puerta
12 Instalación del panel
14 Finalización
Las características y especificaciones están sujetas a
cambios sin previo aviso. Visite subzero.com/specs para
obtener la información más actualizada.
Aviso importante
Para garantizar que este producto se instale y opere de
la forma más segura y eficiente posible, tome nota de los
siguientes tipos de información resaltada en este manual:
AVISO IMPORTANTE señala la información que es
especialmente importante.
PRECAUCIÓN indica una situación en la que se pueden
sufrir heridas leves o provocar daños al producto si no se
siguen las instrucciones.
ADVERTENCIA indica peligro de que se produzcan
heridas graves o incluso la muerte si no se siguen las
precauciones.
AVISO IMPORTANTE: En toda esta guía, las dimensiones
entre paréntesis son milímetros, a menos que se
especifique lo contrario.
AVISO IMPORTANTE: Guarde estas instrucciones para el
inspector eléctrico local.

subzero.com | 3
Almacenamiento de vinos bajo el mostrador de la Serie de Diseño
Información del producto
La información importante del producto, incluidos el
modelo y el número de serie de la unidad, se encuentra en
la placa de datos del producto. Para el modelo de 24", la
placa de características está ubicada en la parte inferior del
panel de control, a la izquierda. Para el modelo de 15", está
ubicada dentro del gabinete, en la parte superior izquierda.
Consulte las ilustraciones siguientes.
Si necesita servicio, póngase en contacto con el centro
de servicio autorizado de Sub-Zero y tenga a la mano el
modelo y número de serie de la máquina. Para obtener
los datos del centro de servicio autorizado de Sub-Zero
más cercano o si tiene preguntas acerca de la instalación,
visite la sección de soporte técnico en nuestra página de
Internet subzero.com o llame a la línea de atención al
cliente de Sub-Zero al 800-222-7820.
RATING PLATERATING PLATE
Ubicación de la placa de datos
(modelo de 24")
Ubicación de la placa de datos
(modelo de 15")
PLACA DE DATOS PLACA DE DATOS

4 | Atención al cliente de Sub-Zero 800.222.7820
Preparación del sitio
Dimensiones de abertura
MODELOS DE ALMACENAMIENTO DE VINOS BAJO
EL MOSTRADOR
ANCHO DE LA
ABERTURA
W
ALTURA DE LA
ABERTURA
H
VISTA SUPERIOR
VIST
A LATERAL VISTA FRONTAL
NOTA: Los tubos de retorno de
31/2" (89) con acabados se podrán ver y se deben
terminar para que se ajusten a los gabinetes.
TÍPICO
DE 3/4" (19)
GABINETE
CON MARCO
W
RELLENO
TUBO DE
RETORNO
DE 31/2" (89)
CON ACABADOS
GABINETES
SIN MARCO
W
TÍPICO
DE 3/4" (19)
TUBO DE
RETORNO
DE 31/2" (89)
CON ACABADOS
PROFUNDIDAD DE
LA ABERTURA
DE 24" (610)
DIMENSIONES DE ABERTURA Ancho (W) Altura (H)
Modelo de 24" (altura estándar) 24" (610) 34⁄" (876)
Modelo de 24" (altura ADA) 24" (610) 32⁄" (826)
Modelo de 15" (altura estándar) 15" (381) 34⁄" (876)
La profundidad de cada modelo es de 23⁄" (587). Para
determinar la profundidad de la abertura ya con acabados,
considere el grosor del panel. Se necesita un tubo de
retorno de 3⁄" (89) con acabados en todos los lados de la
abertura. Los gabinetes con marco necesitan material de
relleno de acabado detrás del marco frontal para lograr
una instalación adecuada. Consulte la ilustración.

subzero.com | 5
Dimensiones de abertura
INSTALACIÓN DOBLE
Si se instalan dos unidades lado a lado, puede ser
necesario un kit de instalación doble. Las instalaciones
sin una tira de relleno personalizada requieren un kit de
instalación doble. Si el uso de un kit de instalación doble
no está especificado, se recomienda utilizar una tira de
relleno de 2" (51) entre las unidades. Las instalaciones
dobles sin una tira de relleno solo se pueden realizar
cuando se utilizan dos unidades con bisagras opuestas.
Consulte las ilustraciones.
Los kits de instalación doble están disponibles a través
de un distribuidor autorizado de Sub-Zero. Para obtener
más información acerca de los distribuidores locales,
consulte la sección “encuentre una sala de exhibición” en
nuestra página web subzero.com. Para preguntas sobre
la instalación, comuníquese con la línea de atención al
cliente de Sub-Zero al 800-222-7820.
ANCHURA DE ABERTURA DOBLE Ancho (W)
Dos modelos de 15" 30" (762)
Modelos de 15" y 24" 39" (991)
Dos modelos de 24" 48" (1219)
Se requiere kit de instalación doble.
SIN TIRA DE RELLENO TIRA DE RELLENO
Bisagras opuestas Bisagras en el mismo lado
Preparación del sitio

6 | Atención al cliente de Sub-Zero 800.222.7820
Requisitos eléctricos
La instalación debe cumplir con todos los códigos
eléctricos vigentes.
El suministro eléctrico debe colocarse dentro del área
sombreada que se muestra en la siguiente ilustración.
Se necesita un circuito independiente que le suministre
electricidad únicamente a este electrodoméstico. No es
recomendable utilizar un circuito de fallos de conexión
a tierra (GFCI, por sus siglas en inglés) ya que puede
interrumpir el funcionamiento de la unidad.
El tomacorriente eléctrico debe colocarse de tal forma que
la clavija con conexión a tierra quede a la derecha de las
aspas más delgadas.
REQUISITOS ELÉCTRICOS
Suministro eléctrico 115 V CA, 60 Hz
Servicio Circuito dedicado de 15 amperes
Receptáculo Conexión a tierra de 3 clavijas
PRECAUCIÓN
Un electricista calificado debe revisar el
tomacorriente para asegurarse de que la conexión
del cableado se haya realizado con la polaridad
correcta. Compruebe que el tomacorriente esté
debidamente conectado a tierra.
ADVERTENCIA
Si el cable de alimentación está dañado, debe ser
reemplazado por el fabricante, su agente de servicio
o personas calificadas de manera similar para evitar
un peligro.
ADVERTENCIA
No coloque múltiples tomas de corriente, enchufe
múltiple o suministros eléctricos portátiles en la
parte posterior del electrodoméstico.
ADVERTENCIA
No use un cable de extensión, adaptador de dos
clavijas ni retire la clavija con conexión a tierra del
cable de corriente.
Preparación del sitio
5"
(127) 2" (51)
4"
(102)
SUELO
APERTURA
Ubicación del suministro
eléctrico
