Sumake SS-1305HS User manual

SUMAKE PNEUMATIC TOOLS
HVLP Suction Type Air Spray Gun
W/1000cc Alu. Cup
SS-1305HS
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
Specification:
Free Type Pressure
Nozzle 1.3mm, 1.4mm, 1.5mm,
1.8mm, 2.0mm, 2.5mm
Air Consumption 6.2 CFM (175 L/min)
Air Inlet (NPS) 1/4” (6.35 mm)
Air Hose (NPS) 3/8” (10 mm)
Air Pressure 29psi (2kg/cm²) (2Bar)
Net Weight 1.87 lbs (0.85 kg)
Noise and Vibration:
Vibration Noise Remark
Sound Pressure Level
: 81.6 dB(A)
0.116 m/s²
Sound power level
: 92.6 dB(A)
Uncertainty
K= 1.5 m/s²Uncertainty
K= 3dB
Please always
wear ear
protector at
environment
noise level > 80
dB(A) due to
risk of impaired
hearing!
SS-1305HS-S-1503A-GW

EC DECLARATION OF CONFORMITY
We: SUMAKE INDUSTRIAL CO., LTD.
4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan
declare in sole responsibility that the equipment
Equipment：HVLP SUCTION TYPE AIR SPRAY GUN W/1000CC ALU. CUP
Model/ Serial No.：SS-1305HS
to which this declaration applies, complies with these normative documents:
Machinery Directive: 2006/42/EC
and conforms to the following EN standard,
EN ISO 12100: 2010
EN 1953:2013
Name and Signature/Position Date and Place
2022/12/1
Mike Su –Managing Director Taipei, Taiwan
SS-1305HS-D-2310B-GWF

SS-1305HS
HVLP SUCTION TYPE AIR SPRAY GUN
PARTS LIST
No. Parts No. Description Q'ty No. Parts No. Description Q'ty
1 1305-01
A
ir Cap 1 14 1305-14
A
ir Valve Spring 1
1305-02A Fluid Nozzle 1.0 [SS-1305HSPB) 1 15 1305-15 Fluid Adj. Guie Set 1
1305-02B Fluid Nozzle 1.3 1 1305-16A Fluid Needle 1.0 [SS-1305HSPB) 1
1305-02C Fluid Nozzle 1.4 1 1305-16B Fluid Needle 1.3 1
1305-02D Fluid Nozzle 1.5 1 1305-16C Fluid Needle 1.4 1
1305-02E Fluid Nozzle 1.8 1 1305-16D Fluid Needle 1.5 1
1305-02F Fluid Nozzle 2.0 1 1305-16E Fluid Needle 1.8 1
1305-02G Fluid Nozzle 2.5 1 1305-16F Fluid Needle 2.0 1
3A 1305-03A Needle Packing Set 1 1305-16G Fluid Needle 2.5 1
3A-1 1305-03A-1 Spring 1 17 1305-17 Needle Spring 1
4A 1305-04A Needle Packing Seat 1 18 1305-18 Fluid Adj. Knob 1
5 1305-05 Body Set 1 19 1305-19
A
ir Inlet Nipple 1
6 1305-06 Fluid Nipple 1 20 1305-20
A
ir Adj. Set 1
7 1305-07 Pattern Adj. Set 1 21 1305-21 Trigger 1
8 1305-08
A
ir Valve Shaft 1 22 1305-22 Gasket 2
9 1305-09 Packing Holder 1 23 1305-23 Trigger Stud 1
10 1305-10 O-Ring 1 24 1305-24 E-Ring 1
11 1305-11 Gasket 1 25 1305-25 Spanner 1
1305-12
A
ir Valve Seat Set 1 26 1305-26 Brush 1
1305-12-1 O-Ring 1 27 1305-27 Complete Lid Ass'y 1
1305-13
A
ir Valve Seat Set 1 28 1305-28 Gasket 1
1305-13-1 O-Ring 1 29 1305-29 Container 1
SS-1305HS-P-1106B-GW
216
12
13
