SX0918T: Parts Breakdown & Operating Manual
Instructions • Warning Information • Parts Breakdown
SX0918T
3/16"HEAVY DUTY RIVET GUN
Rivet Capacity ................................... 3/16"
Traction Power.............................1,983 lbf.
Stroke Length .................................. 11/16"
Air Inlet.........................................1/4" NPT
Air Supply Hose Size.................... 3/8" I.D.
Working Air
Pressure......................75-90 psig (6.2 bar)
Height..............................................12-3/8"
Weight...............................................3.9 lb.
SPECIFICATIONS
Some dust created by power sanding, sawing, grinding, drilling, and other
construction activities contains chemicals known to cause cancer, birth
defects or other reproductive harm. Some examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement and other masonry products, and
• arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this
type of work. To reduce your exposure to these chemicals: work in a well
ventilated area, and work with approved safety equipment, such as those
dust masks that are specially designed to filter out microscopic particles.
WARNING
WARNING
ALWAYS READ THIS MANUAL BEFORE OPERATING TOOL
ALWAYS WEAR EYE PROTECTION (USERS AND
BYSTANDERS) WHEN OPERATING OR PERFORMING
MAINTENANCE ON THIS TOOL
ALWAYS WEAR HEARING PROTECTION WHEN OPERATING
THIS TOOL (USERS AND BYSTANDERS)
ALWAYS WEAR FACE PROTECTION WHEN OPERATING THIS
TOOL (USERS AND BYSTANDERS)
AVOID PROLONGED EXPOSURE TO VIBRATION

SX0918T: Parts Breakdown & Operating Manual 2
WARNING
FAILURE TO OBSERVE THESE WARNINGS COULD RESULT IN INJURY
THIS INSTRUCTION MANUAL CONTAINS IMPORTANT SAFETY
INFORMATION.
READ THIS INSTRUCTION MANUAL CAREFULLY AND
UNDERSTAND ALL INFORMATION BEFORE OPERATING THIS
TOOL.
• Read and understand all instructions. Failure to follow
all instructions listed below, may result in electric
shock, fire, explosion and/or serious personal injury. It is
the responsibility of the owner to make sure all personnel
read this manual prior to using the device. It is also
the responsibility of the device owner to keep this
manual intact and in a convenient location for all to
see and read. If the manual or product labels are lost
or not legible, contact Sunex Tools for replacements.
If the operator is not fluent in English, the product
and safety instructions shall be read and discussed
with the operator in the operator's native language by
the purchaser/owner or his designee, making sure that
the operator comprehends its contents.
• Always operate, inspect and maintain this tool in
accordance with American National Standards Institute
Safety Code of Portable Air Tools (ANSI B186.1) and any
other applicable safety codes and regulations.
• For safety, top performance and maximum durability of
parts, operate this tool at 90 psig; 6.2 bar max air
pressure with 3/8" diameter air supply hose.
•
Always wear impact-resistant eye and face protection when
operating or performing maintenance on this tool. (users and
bystanders).
• High sound levels can cause permanent hearing loss.
Always use hearing protection as recommended by your
employer an OSHA regulations while using this tool
(users and bystanders).
• Keep the tool in efficient operating condition.
• Operators and maintenance personnel must be
physically able to handle the bulk, weight and power of
this tool.
• Air under pressure can cause severe injury. Never direct
air at yourself or others. Always turn off the air supply,
drain hose of air pressure and detach tool from air supply
before installing, removing or adjusting any accessory
on this tool, or before performing any maintenance on
this tool. Failure to do so could result in injury. Whip
hoses can cause serious injury. Always check for
damaged, frayed or loose hoses and fittings, and replace
immediately. Do not use quick detach couplings at tool.
See instructions for correct set-up.
• Keep tool out of reach of children.
• Air powered tools can vibrate in use. Vibration, repetitive
motions or uncomfortable positions over extended
periods of time may be harmful to your hands and arms.
Discontinue use of tool if discomfort, tingling feeling or
pain occurs. Seek medical advice before resuming use.
• Slipping, tripping and/or falling while operating air
tools can be a major cause of serious injury or
death. Be aware of excess hose left on the walking
or work surface.
• Keep body working stance balanced and firm. Do
not overreach when operating the tool.
• Do not point or indulge in any horseplay with this tool.
• Anticipate and be alert for sudden changes in motion
during start up and operation of any power tool.
• Do not carry tool by the hose. Protect the hose from
sharp objects and heat.
• Avoid direct contact with accessories during and after use.
Gloves will reduce the risk of cuts or burns.
• Keep away from end of tool. Do not wear jewelry or loose
clothing. Secure long hair. Scalping can occur if hair is not
kept away from tool and accessories. Choking can occur if
neckwear is notkept away from tool and accessories.
• Do not use (or modify) the tool for any other purpose
than that for which it was designed without consulting
the manufacturer's authorized representative.
• Do not exceed 100 psig maximum air pressure.
• Always disconnect air supply before proceeding with any
assembly or disassembly procedures.
• Keep exhaust port pointed away from face.
• Inspect the hydraulic section prior to use. Do not use if
cracked. Contact the distributor for repair or replacement.
• Do not pound on the nosepiece or the end of the head or
force the rivet into the hole of the nosepiece as this will
damage the tool.
• Make sure all parts are correctly and securely fastened.
• Always follow proper maintenance procedures.
• Keep clear of trigger when inserting rivets.
• Use accessories recommended by Sunex Tools.
• Do not lubricate tools with flammable or volatile liquids
such as kerosene, diesel or jet fuel.
• This tool is not insulated against electric shock.
• This tool must not be used in explosive atmospheres.
• Servicing and repairs should only be made by an
authorized service center.
• Do not force tool beyond its rated capacity.
• Do not remove any labels. Replace damaged labels.
• This product may contain one or more chemicals known
to the State of California to cause cancer and birth
defects or other reproductive harm. Wash hands
thoroughly after handling.
• Handling the brass parts of this product will expose you
to lead, a chemical known to the State of California to cause
birth defects and other reproductive harm. Wash hands after
handling.
• Failure to heed these warnings may result in personal injury
and/or property damage.

SX0918T: Parts Breakdown & Operating Manual 3
1 RS618101 Hydraulic Section 1
1A RS918108 Plunger Rod Guide 1
1B RSBR0913 Back-up Ring 1
1C RSOR0913 O-Ring 2
1D RSOR1823 O-Ring 1
1E RSOR2227 O-Ring 1
2 RSBR1014 Back-up Ring 1
3 RSOR1014 O-Ring 2
4 RS918301 Hydraulic Plunger 1
5 RSBR2025 Back-up Ring 1
6 RSOR2025 O-Ring 1
7 RS918309 Return Spring 1
8 RS918102 Rear Gland 1
9 RSOR2225 O-Ring 1
10 RS612306 Nut 1
11 RS612308 Spring 1
12 RS612302 Jaw Pusher 1
13 RS612303 Jaw "M" 2
14 RS612304 Jaw Housing 1
14A RS612305 Jaw Housing Coupler 1
15 RS612105 Head 1
15A RS612106 Lock Nut 1
16 RS918401 Air Cylinder Body 1
17 RS918109 Lock Nut 1
17A RSOR2832 O-Ring 1
18 RS918502 Packing Ring (incl. w/ #22A) 1
18A RS918503 Front Head Disc (incl. w/ #22A) 1
18B RS918504 Rear Head Disc (incl. w/ #22A) 1
18C RSOR0509 O-Ring (incl. w/ #22A) 1
19 RS918501 Plunger Rod (incl. w/ #22A) 1
20 RSPW0512 Washer (incl. w/ #22A) 1
21 RS508020 Lock Screw (incl. w/ #22A) 1
22 RS918505 Bumper Ring (incl. w/ #22A) 1
22A RS918500 Piston Assy (incl. #18 - #22) 1
23 RS918402 Air Cylinder Cap 1
23A RSOR5461 O-Ring 1
23B RSCH6063 Retaining Ring 1
24 RS918207 Throttle Valve 1
25 RS656204 Throttle Valve Spring 1
26 RSOR1417 O-Ring 2
27 RS612206 Valve Plug 1
28 RS918200 Valve Tube Assy 1
28A RS918204 Valve Tube Spring 1
28B RS618605 Brass Collar 1
28C RSOR0914 O-Ring 1
28D RSOR0812 O-Ring 1
29 RS612611 Trigger Lever 1
29A RS918602 Linkage 1
29B RS612603 Rocker Arm 1
29C RSSP3006 Roll Pin 2
29P RSSP3018 Roll Pin 2
30 RS612703 Nose Piece 3/32"(2.4mm) 1
RS612704 Nose Piece 1/8"(3.2mm) 1
RS612705 Nose Piece 5/32"(4.0mm) 1
RS612706 Nose Piece 3/16" (4.8mm) 1
31 RS922100 Swivel Joint Assy 1
(incl. #31A - #31D)
31A RS612715 Male Inlet Body (incl. w/ #31) 1
31B RS922A01 Female Inlet Body (incl. w/ #31) 1
31C RSCS1316 Snap Ring (incl. w/ #31) 1
31D RSOR1015 O-Ring (incl. w/ #31) 2
32 RS612901 Deflector 1
33 RS612904 Multi-Wrench (A) 1
34 RS918905 Multi-Wrench (B) 1
35 RS918403 Rubber Boot 1
RSSX0918TPLK Product Label Kit (not shown) 1
SX0918T
3/16"HEAVY DUTY RIVET GUN
DESCRIPTION DESCRIPTION DESCRIPTION
PART
NO. PART NO. PART NO.
REF.
NO. REF. NO. REF. NO.QTY. QTY. QTY.
15
30
12 11 26
28D
28
28B
28C
29C
29P
16
29B
31B
31C
31D
31D
31A
24
25
26
27
28A
29C
29A
29
29P
14A 10 3231
46
23A
23
23B
18C
19
17
17A
1D
1E
1A
1C
1B
22
35
18A
18
18B
20
21
57
98
32
33
34
15A 14 13

SX0918T: Parts Breakdown & Operating Manual 4
SERVICING PROCEDURES
1. Changing Nosepieces:
Hook up the tool to the air line and depress the lever. While
continuing to hold the lever down, use the maintenance tool to
remove the unwanted nosepiece and tighten the new nosepiece
in place again. When the lever is released and the tool is at rest, a
circular opening should be visible when looking through the
hydraulic section from the rear gland to the nosepiece.
2. Cleaning and Changing of the Jaws:
Disconnect the tool from the air line and then remove the head
with the maintenance tool. Hold the jaw housing coupler firmly
and remove the jaw housing. Clean the jaws with either a steel
brush or solvent. If excessive wear is apparent, replace them with
new jaws. Before reassembling, apply a thin coat of oil to the
sliding surface of the jaws. Reassemble the tool in the reverse
order while making sure that the chamfered end of the jaw pusher
is in contact with the jaws properly.
3. Jaw Opening Adjustment:
To obtain the maximum stroke of the tool, proper distance setting
between the jaw housing and the head is very important. First
loosen the lock nut. A rivet is then inserted into the nosepiece
which should be selected to match the rivet size to be set. While
screwing or unscrewing the head to achieve the minimum opening
of the jaws, check if the rivet mandrel can be removed and
inserted freely. Fasten the lock nut after the adjustment.
MAINTENANCE
1. Check the tightness of the connections between the jaw housing
coupler, nut, jaw housing, and the hydraulic plunger, the nosepiece,
the head and the lock nut.
2. If the jaws show excessive wear and/or are dirty, follow the steps
provided in the servicing procedures section.
AIR SUPPLY
Tools operate on a wide range of air pressures. It is recommended
that air pressure measures 90 psig at the tool with the trigger fully
depressed and no load applied to the tool. Higher pressure (over 90
psig; 6.2 bar) raises performance beyond the rated capacity of the
tool, which will shorten tool life and could cause injury.
Always use clean, dry air. Dust, corrosive fumes and/or water in the
air line will cause damage to the tool. Drain the water from air lines
and compressor prior to running tool. Clean the air inlet filter screen
weekly. The recommended hookup procedure can be viewed in FIG. 1.
The air inlet used for connecting air supply has standard 1/4" NPT.
Line pressure should be increased to compensate for unusually long
air hoses (over 25 feet). Minimum hose diameter should be 3/8" I.D.
and fittings should have the same inside dimensions and be tightly
secured.
Ensure an accessible emergency shut off valve has been installed
in the air supply line and make others aware of its location.
LUBRICATION AND MAINTENANCE
Lubricate the air motor daily with high quality air tool oil. If no air line
oiler is used, run 1/2 oz. of oil through the tool. The oil can be squirted
into the tool air inlet or into the hose at the nearest connection to
the air supply, then run the tool. A rust inhibitive oil is acceptable for
air tools.
WARNING: After an air tool has been lubricated, oil will discharge
through the exhaust port during the first few seconds of operation.
The exhaust port must be covered with a towel before applying air
pressure to prevent serious injury.
OPERATION
Always turn off the air supply, drain hose of air pressure and
detach tool from air supply before installing, removing or adjusting
any part or accessory on this tool, or before performing any
maintenance on this tool.
When the Lever/Trigger is depressed, the throttle valve is moved
down off its seat by the valve tube. Air enters the bottom of the air
cylinder, forcing the piston assembly up. As the piston assembly
rises, the plunger rod forces hydraulic fluid in to the upper part of
the hydraulic section, retracting the hydraulic plunger. Meanwhile,
the jaws grip the mandrel of the rivet, pulling until the rivet is set and
breaking the mandrel in the process.
When the lever is released, the throttle valve resets and shuts off the
air supply. The valve tube spring then lifts the valve tube and exhausts
the air throughout the hollow of the valve tube. The return spring
returns the hydraulic plunger to its original position. This opens the
jaws, releases the mandrel, and retracts the piston assembly back to
its original static site.
NOTE: During operation, safety goggles should always be worn to
guard against flying debris (users and bystanders).
Operating Instructions • Warning Information • Parts Breakdown
Drain Daily
RegulatorOilerQuick CouplerLeader
Hose
Nipple
Do Not Install
Quick Coupling
Here
Nipple
Filter
Air Supply
Whip Hose
fig. 1.

TROUBLESHOOTING
1. Rivet mandrel is gripped by the jaws but the rivet can not be set and mandrel can not be broken:
CAUSE: Low air pressure or loss of hydraulic fluid.
REMEDY:Increase air pressure to 7 bar (100 psi) maximum at tool. Make sure all fittings including rear gland and head are tight. If malfunction persists, call
authorized Sunex Tools®warranty center.
2. Mandrel does not fit completely into nosepiece or fails to eject:
CAUSE: Jaw Housing distance incorrect.
REMEDY: Loosen the head and check the rated stroke length. If shorter, search for worn or damaged o-rings and replace it.
CAUSE: Jaws are dirty or damaged.
REMEDY: Clean or replace the jaws.
CAUSE: Fatigued jaw pusher spring.
REMEDY: Replace the jaw pusher spring.
CAUSE: Fatigued Return Spring.
REMEDY: Replace the return spring.
CAUSE: Air leakage in vacuum system.
REMEDY:Search for worn or damaged seals in the vacuum system and replace it.
3. Tool takes more than two strokes under ideal conditions to set rivet and break mandrel:
CAUSE: Low air pressure.
REMEDY: Increase air pressure but do NOT exceed 7 bar (100 psig) at tool.
CAUSE: Loose Nosepiece or improper size of nosepiece.
REMEDY: Tighten nosepiece or use right size.
CAUSE: Rivet body too long for the thickness of the joint.
REMEDY: The rivet body should be 3-6mm longer than the thickness of joint only.
If malfunction persists, call an authorized Sunex Tools®warranty center.
Discover other air riveters on our website.
