Sunjoy A106005900 User manual

Country of Origin: China Production Number: xxxxxxxxxx
WE HAVE YOU IN MIND, LET US HELP YOU!
Questions? Issues?
CONTACT US
24 hours / 7 days a week
www.sun
j
o
y
online.com
amazon@sunjoygroup com
customer[email protected]
1-(866)-578-6569
ITEM NO.：A106005900

2/ 7
Country of Origin: China
Post1 A3 P000200258 2
Post2 A4 P000200259 2
Top beam1 B5 P000601186 4
Top beam 2 C P000600812 4
Short small across beam D2 P000600814 7
Long small across beam D3 P000600813 7
Top beam connector2 E2 P000500997 4
Corner decor G2 P005600135 4
Post top G3 P000300033 4
Support H P005000224 8
Railtubeconnector K P000500662 8
Tube1 L3 P005700233 2
Tube 2 L4 P005700232 2
Rail Tube M1 P005700234 4
Cover 1 O1 P005600114 2
Cover2 O2 P005600115 2
Protect cover P P006100102 4
Stake plate Q P000100162 4
Canopy N P006400008 1
Parts List

3/ 7
Country of Origin: China
AA M6*20 Cross hexagonal
bolt H02020C11 40 PCS
BB M6 washer H19001C11 72PCS
CC M6*60 hexagonal bolt H02060C11 16PCS
DD M6 Nut H14001C11 16PCS
LL M6 spring washer H13001C11 48PCS
Z M6 wrench H00001C12 2 PCS
Hardware Pack 1

4/ 7
Country of Origin: China
Fig.1: Put the protect cover(P) through post (A3/A4),then fix the stake plate (Q) to post bottom(A3/A4) by using
bolt (AA) and Washer(BB).
Fig.2: Attached the post top (G3) to post (A3/A4), set aside.
Fig.3-1: Attached the top beam connector 2 (E2) to top beam 2(C) by using bolt (AA), spring washer (LL) and
flat wash (BB).
Fig.3-2: Attached the cover 2 (O2) to top beam 2(C).
Fig.3-3: Attach the top beam2(C) the assembled connector2 (E2), and fasten by using bolt (AA), spring washer
(LL) and flat washer (BB).
Fig.4: Attached the assembled top beam 2(C) to post (A3/A4), then fasten by using bolt (AA), spring washer (LL)
and flat washer (BB).
Fig.5-1: Insert the top beam connector 2(E2) to top beam 1(B5) and fasten by using bolt (AA), spring washer(LL)
and flat washer (BB).
Fig.5-2: Install the cover 1 (O1) to the top beam 1(B5).as per arrow direction.
Fig.5-3: Attached top beam 1 (B5) to the top beam connector 2 (E2) and fasten by using the bolt (AA), Spring
washer ( LL) and flat washer (BB).

5/ 7
Country of Origin: China
BB M6 flat washer H19001C11 64 PCS
CC M6*60 bolt H02060C11 32 PCS
EE M6*15 bolt H09015C11 18 PCS
FF M6*70 bolt H02070C11 22PCS
LL M6 spring washer H13001C11 36PCS
GG Φ8*180 stake P12401A01001 8 PCS
Hardware Pack 2
Fig.6: Attached top beam 1 (B5) to the top beam 2 (C), by
using the bolt (CC), Spring washer ( LL), flat washer
(BB) and nut (DD).

6/ 7
Country of Origin: China
Fig.7: Attached the support (H) to the post (A3/A4) and top beam (B5/C), by using bolt (CC), spring washer (LL)
and flat washer (BB).
Fig.8: Connect the long small across beam (D3) to short small across beam (D2), and fix by using bolt (EE) and
flat washer (BB).
Fig.9: Attached the assembled small across beam (D2/D3) to beam 1(B5), and fix by use bolt (FF) and
washer (BB).
Fig.10: Insert the top of rail tube (M1) to the tube connector (K) and fix to the post (A3/A4) by using
the bolt (FF).
Fig.11: Insert tube 1(L3) to tube 2(L4), and fix by using bolt (EE), spring (LL) and flat washer (BB).
Fig.12: Insert the assembled tube 1 and tube 2(L3/L4) to bottom of canopy (N).
Fig.13: Insert the bottom of rail tube (M1) to the tube connector (K) and fix to the post (A3/A4) by using
the bolt (FF).
Fig.14. Fix the assembled pergola to ground by using stake (GG).

7/ 7
Country of Origin: China

Oursteelcomponentsforgardenaccessoriesandfurniturearetreatedwithrustinhibitingpaintthatprotectsit
fromrusting.However,duetothenatureofsteel,surfaceoxidation(rusting)willoccuroncetheseprotective
coatingsarescratched.Thisisnotadefectandthusnotcoveredbythewarranty.
Tominimizethiscondition,werecommendcarewhenassembling&handlingtheproducttopreventscratching
thepaint.Shouldanyscratchingordamageoccur,werecommendimmediatetouch‐upwithrustinhibiting
paint.
Surfacerustcanalsobeeasilyremovedwithaverylightapplicationofcommoncookingoil.Ifsurfaceoxidation
(rusting)occursandifnomeasureistakentopreventthis,theoxidationmaystartdrippingontodeckorpatio
andcauseddamagingstains,whichmaybedifficulttoremove.Thiscanbepreventediftheabove‐mentioned
measuresaretakentokeeptheproductfromoxidizing.
Usedampclothtowipeoffthestainsasquicklyaspossible.
Ifnecessary,washwithamildsolutionofsoapandwater;rinsethoroughlyanddrycompletely.
Periodicallycheckandensurethatallboltsarewell‐tightenduringuse.
Sunjoy Group warrants to the original purchaser that this item is free from defects in workmanship and materials for
a period of 6 months from the date of purchase, provided the item was factory-sealed at the time of purchase
and is maintained with care and used only for personal, residential purposes. Should any manufacturing defect arise
within this warranty period, Sunjoy Group will replace (at our option) any defective merchandise or parts upon proof of
purchase; however, transportation and delivery costs, as well as payments to a third party for assembly or disassembly
of the item, remain the responsibility of the purchaser. A purchaser of an "open box," previously-returned, or
"clearance" item, as well as original purchasers outside of the warranty period, may obtain replacement parts
from Sunjoy Group for products in current production, at nominal cost.
Items used for commercial, contract, or other non-residential purposes, or items damaged due to acts of nature,
vandalism, misuse, or improper assembly are not covered. Corrosion or rusting of hardware is not covered. Proof of
purchase (dated register receipt) is required for warranty claims. Warranty is to the original purchaser and is
non-transferable. Any replacement of warranted items will be in the original style and color, or a similar style and
color if the original is unavailable or has been discontinued. As some states do not allow exclusions or limitations on an
implied warranty, the above exclusions and limitations may not apply. This warranty gives you specific rights, and you
may also have other rights, which vary from state to state.
Care and Maintenance
Limited Manufacturer’s Warranty
Exclusions:
