Four people are required for this assembly.
Some parts may contain sharp edges. Wear
protective gloves.
When assembling and using this product,
basic safety precautions should always be
followed to reduce the risk of personal
injury and damage to equipment. Please read
all instructions before assembly and usage.
Thelimitedwarrantyisextendedtotheoriginalpurchaserandappliestomaterialandmanufacturer’sdefectprovide
d
theitemismaintainedwithcareandusedonlyforpersonal,residentialpurposes.
Warranty: 1 Year
WHAT IS COVER?
CAUTION: Do not climb on top of the
gazebo. Falling off the gazebo can
result in serious injury.
NOTICE: For outdoor use
DANGER: This unit is heavy! Do not assemble
this item alone.
WARNING: Do not leave the gazebo where there
is a risk of high wind, as possible damage will
occur to the structure.
WARNING: Keep all flame and heat sources
away from this gazebo fabric. This Gazebo is
made with fabric that meets CPAI-84
specifications for flame resistance. It is not fire
proof. The fabric will burn if left in continuous
contact with any flame source. The application
of any foreign substance to the gazebo fabric
may render the flame-resistant properties
ineffective.

3/7
CountryofOrigin:China

Description Label Part# Qty Image
Knob AA P005100262 42
PartsList
HardwarePack1
Description Label Part# Qty Image
Post
Across screen
Slanting beam
Middle beam
Large top frame
Small top
slanting beam
Small top
connector
hook
Adjustable tube
Small canopy
Large canopy
Mosquito
netting
A
B
C
D
E
F
G
H
I
J
K
L
P000200457
P000400894
P000601341
P000601340
P000501175
P000601339
P000501174
P005800001
P005700658
P001100551
P001100552
P001200214
6
6
6
6
6
6
1
1
18
1
1
1
Netting rod M P005700659 6

4/7
CountryofOrigin:China

Fig.1:Using knob （AA ）lock across
screen（B）andpost（A）together。
HardwarePack2
Fig.1‐1:Usingknob（AA）,attach
nettingrod（M）toscreen（B）。

5/7
CountryofOrigin:China



Fig.2:Attachlargetop
frame(E) together ，then
fastenbyusingknob(I)。
Fig.3: Insert slanting
beam bottom end(C)
into connector of
Fig.4:Insertslantingbeam
upperend(C)intolargetop
frame(E)。
Fig.6:Insertmiddlebeambottom
end (D) into across beam(B)。
thenputlargecanopy(K)on
large top frame, do not spread
Fig.5:insertmiddlebeam
upper end (D) into large
topframe(E) 。
Fig.8:Screwhook(H)toconnectorof
smalltop(G)，theninsertsmalltop
slanting beam(F) into small top
connector(G)。
Fig.9:Insert small top slanting beam
bottomend(F)intolargetopframe(E)。
HardwarePack3
Description Label Part# Qty Image
GG Ф6*230
stake H070010022 18 PCS
BB ring P005100264 48 PCS
Fig.7：Attachadjustabletube（I）to
slanting middle beam，small top
slanting beam bottom end and
adjusttubelengthshortest。

6/7
CountryofOrigin:China


Fig.10: Coversmall canopy(J)
on small top frame ,then fix
the corner on frame, adjust
tubelengthtillcanopytight。
Fig.11:Spreadoutlargecanopy(K),fix
corner to frame ,then adjust tube
lengthtilllargecanopytight。
Fig.13: Fix assembled
gazeboongroundby
usingstake(GG)。
Fig.12:Hang mosquito
netting（L）onnetting
rod（M）byusingring
（BB）。
Fig.11‐1: Stick small top
nettingVecro(J)Large top
frame （E）。

7/7
CountryofOrigin:China
 Oursteelcomponentsforgardenaccessoriesandfurniturearetreatedwithrustinhibitingpaint
thatprotectsitfromrusting.However,duetothenatureofsteel,surfaceoxidation(rusting)will
occuroncetheseprotectivecoatingsarescratched.Thisisnotadefectandthusnotcoveredby
thewarranty.
 Tominimizethiscondition,werecommendcarewhenassembling&handlingtheproductto
preventscratchingthepaint.Shouldanyscratchingordamageoccur,werecommendimmediate
touch‐upwithrustinhibitingpaint.
 Surfacerustcanalsobeeasilyremovedwithaverylightapplicationofcommoncookingoil.If
surfaceoxidation(rusting)occursandifnomeasureistakentopreventthis,theoxidationmay
startdrippingontodeckorpatioandcauseddamagingstains,whichmaybedifficulttoremove.
Thiscanbepreventediftheabove‐mentionedmeasuresaretakentokeeptheproductfrom
oxidizing.
 Usedampclothtowipeoffthestainsasquicklyaspossible.
 Ifnecessary,washwithamildsolutionofsoapandwater;rinsethoroughlyanddrycompletely.
 Periodicallycheckandensurethatallboltsarewell‐tightenduringuse
