Sunjoy A103002201 User manual

Country of Origin: China Production Number: xxxxxxxxxx
WE HAVE YOU IN MIND, LET US SERVE YOU!
Questions? Issues?
CONTACT US
24 hours / 7 days a week
www.sunjoyonline.com
1-(866)-578-6569
[email protected]
ITEMNO.:A103002201

2/ 6
Country of Origin: China
Post(1) A3 P000200393 2
Post(2) A4 P000200394 2
Base B1 P000100293 4
Base Cover C P006100097 4
Beam D1 P000601204 4
Large Top Connector F2 P000501025 1
Long Support H1 P000400796 2
Short Support I1 P000400797 2
Side Bar J1 P002100285 2
Hook K P005800001 1
Tool hook L P005800098 1
Small Canopy M1 P001100540 1
Lager Canopy N1 P001100539 1
Adjustable tube O P005700587 8
Parts List
Description Part#
Label Qty Image

3/ 6
Country of Origin: China
Hardware Pack 1
Step 1
Fig.1
Fig.2
Fig.3 Fig.6
Fig.5
Fig.4
Fig.2
Label Description Part# Qty Image
AA M6X15 Bolt H010030030 8PCS
BB M6 Flat Washer H050010057 16 PCS
CC M6X20 Bolt H010030032 8 PCS
DD M6 Wrench H090030002 1 PCS
Fig.1
C
A 3 ( 4 )
B B A A
A A B B
Fig.3、4
O
D 1

4/ 6
Country of Origin: China
Fig.1: Put the base cover（C）through post（A3、A4），then attach base(B1) to post bottom（A3、
A4）by using bolt（AA）flat washer（BB）.
Fig.2: Attach long/short support（H1、J1）to upper of post（A3、A4），fix by using Bolt（CC）flat washer（BB）。
Fig.3、4: Attach the adjustable tube（O）to bottom of beam（D1）.
Fig.5: Insert beam（D1）to large top connector（F2）。
Fig.6: Insert beam (D1）to upper connector of post（A3、A4）。
Hardware Pack 2
Fig.7: Fix small canopy(M1) to adjustable
tube(O) ，then adjust the tube(O) to
appropriate size.
Step 2
Fig.5 Fig.6
Fig.8
Fig.7
Fig.9
Fig.10
Fig.11
Label Description Part# Qty Image
AA M6X15 Bolt 11PCS
BB M6 Flat Washer 11PCS
FF Φ6X230MM “7”stake 8PCS
Fig.12
Fig.7
D 1
O
M 1
H010030030
H050010057
H070010001

5/ 6
Country of Origin: China
Fig.8: Fix large canopy (N1）to bottom of beam（D1），then adjust the tube (O) to appropriate size。
Fig.9: Attach side bar(J1) to post（A3、A4）, fix by using bolt（AA）flat washer（BB）.
Fig.10:Up the base cover （C）, fix the assembled gazebo on ground by using
stake(FF）.
Fig.9 Fig.10
Fig.11:Install the hook (K) onto the top connection.
Fig.12:Attach hook rack (L) to glass side bar (J1) by using bolt (AA) and flat washer (BB).

K
F2
Fig.11 Fig.12
J1
L
Fig.8
N 1
O
D 1

6/ 6
Country of Origin: China

 Oursteelcomponentsforgardenaccessoriesandfurniturearetreatedwithrustinhibitingpaintthatprotectsitfrom
rusting.However,duetothenatureofsteel,surfaceoxidation(rusting)willoccuroncetheseprotectivecoatingsare
scratched.Thisisnotadefectandthusnotcoveredbythewarranty.
 Tominimizethiscondition,werecommendcarewhenassembling&handlingtheproducttopreventscratchingthe
paint.Shouldanyscratchingordamageoccur,werecommendimmediatetouch‐upwithrustinhibitingpaint.
 Surfacerustcanalsobeeasilyremovedwithaverylightapplicationofcommoncookingoil.Ifsurfaceoxidation
(rusting)occursandifnomeasureistakentopreventthis,theoxidationmaystartdrippingontodeckorpatioand
causeddamagingstains,whichmaybedifficulttoremove.Thiscanbepreventediftheabove‐mentionedmeasures
aretakentokeeptheproductfromoxidizing.
 Usedampclothtowipeoffthestainsasquicklyaspossible.
 Ifnecessary,washwithamildsolutionofsoapandwater;rinsethoroughlyanddrycompletely.
 Periodicallycheckandensurethatallboltsarewell‐tightenduringuse
SunjoyGroupwarrantstotheoriginalpurchaserthatthisitemisfreefromdefectsinworkmanshipandmaterialsfora
periodof6monthsfromthedateofpurchase,providedtheitemwasfactory‐sealedatthetimeofpurchaseandis
maintainedwithcareandusedonlyforpersonal,residentialpurposes.Shouldanymanufacturingdefectarisewithinthis
warrantyperiod,SunjoyGroupwillreplace(atouroption)anydefectivemerchandiseorpartsuponproofofpurchase;
however,transportationanddeliverycosts,aswellaspaymentstoathirdpartyforassemblyordisassemblyoftheitem,
remaintheresponsibilityofthepurchaser.Apurchaserofan"openbox,"previously‐returned,or"clearance"item,aswell
asoriginalpurchasersoutsideofthewarrantyperiod,mayobtainreplacementpartsfromSunjoyGroupforproductsin
currentproduction,atnominalcost.
Itemsusedforcommercial,contract,orothernon‐residentialpurposes,oritemsdamagedduetoactsofnature,
vandalism,misuse,orimproperassemblyarenotcovered.Corrosionorrustingofhardwareisnotcovered.Proofof
purchase(datedregisterreceipt)isrequiredforwarrantyclaims.Warrantyistotheoriginalpurchaserandis
non‐transferable.Anyreplacementofwarranteditemswillbeintheoriginalstyleandcolor,orasimilarstyleand
coloriftheoriginalisunavailableorhasbeendiscontinued.Assomestatesdonotallowexclusionsorlimitationsonan
impliedwarranty,theaboveexclusionsandlimitationsmaynotapply.Thiswarrantygivesyouspecificrights,andyoumay
alsohaveotherrights,whichvaryfromstatetostate. 
Care and Maintenance
Limited Manufacturer’s Warranty
Exclusions:
