Sunjoy L-GZ120PST-3 User manual

1
Assembly Instruction
10’x12’ Bay Window Gazebo
L-GZ120PST-3
Warning
1. When assembling and using this product, basic safety precautions should always be followed to reduce
the risk of personal injury and damage to equipment. Please read all instructions before assembly and
use.
2. Some parts may contain sharp edges, wear protective gloves if necessary. At least four or more people are
recommended for safe assembly.
3. Keep all children and pets away from assembly area.
4. Begin assembly not less than 6 feet from any obstruction such as fence, garage, house, overhanging
branches, laundry line or electrical wires.
5. Install on level ground. This gazebo cannot be permanently staked or attached to concrete floor or platform.
This gazebo is intended for decorative and sunshade purposes only and is not meant to withstand
inclement weather including high winds, rain and snow. Gazebo fabric is water resistant, not water proof
and may leak during exposure to precipitation.
6. Check all nuts and bolts for tightness before and during usage.
7. Keep all flame and heat sources away from this gazebo fabric. This gazebo is made with fabric that meets
CPAI-84 specifications for flame resistance. It is not fire proof. The fabric will burn if left in continuous
contact with any flame source. The application of any foreign substance to the gazebo fabric may render
the flame-resistant properties ineffective.

2
A
Big screen
4 pieces
B1
Left Screen
4 pieces
B2
Right Screen
4 pieces
C1
Long Bar
2 pieces
C2
Short Bar
2 pieces
D1
Long Mosquito Netting Guider
2 pieces
D2
Short Mosquito Netting
Guider
4 pieces
E
Larger Roof Connector
1 piece
F
Top Roof Supporter
4 pieces
G1
Corner Supporting Bar-Long
4 pieces
G2
Corner Supporting Bar-Short
4 pieces
H1
Side Supporting Bar-Long
2 pieces
H2
Side Supporting Bar-Short
2 pieces
J
Center Hook
1 piece
K1
Larger Canopy
1 piece
K2
Top Canopy
1 piece
N
Mosquito Netting
1 piece
Parts List

3
Assembly Tools: a ladder and a hammer
AA
M6×25mm Screw
16 pieces
BB
M6×20mm Screw
40 pieces
CC
M6 Washer
56 pieces
DD
Stake
8 pieces
EE
Plastic ring for mosquito netting
48 pieces
FF
Plastic Plug (10pcs preassembled)
10 pieces
WW
M6 Wrench
1 piece
Hardware Pack
AA
M6×25mm Screw
2 pieces
BB
M6×20mm Screw
4 pieces
CC
M6 Washer
6 pieces
EE
Plastic ring for mosquito netting
4 pieces
FF
Plastic plug
2 pieces
Snap link
3 pieces
Touch up paint
1 piece
Spare Hardware Pack

4
Step #1: Bottom Frame Set-up
Before assembly, please do following setup first: Attach the
Plastic Rings for Mosquito Netting (EE) to the Netting Guiders
(D1&D2) and the Big Screen (A) --- 8pcs EE onto D1,5pcs EE
onto D2, and 3pcs EE onto A. Use Plastic Plug (FF) to plug up
the mosquito netting guider to prevent the plastic rings gliding
out –as shown in the picture on right.
Fig. 1-1 & Fig. 1-2, Screens setup:
Insert the Left Screen (B1) into the
Big Screen (A), pull it down to fix
them; then use AA, CC to secure B1
& A; Do the same for B2 & A. Don’t
tighten the screws completely at
this time.
Fig. 1-3, Frame setup: Connect the Long Bar
(C1) and the assembled screens with Screw
(BB) and Washer (CC); Do the same for Short
Bars (C2) and the Screens, until you get the
complete frame setup as shown in Fig. 1.
Don’t tighten any of the screws completely at
this time.
Note: When aligning Bars C1 and C2, make
sure the holes on it are outside toward.
Fig. 1-4, Attach netting guiders: Attach the Short
Mosquito Netting Guider (D2) onto the Small Screen
(B1&B2) and the Long Bar (C1); Do the same for Long
Mosquito netting guider (D1) to (B1&B2) and (C2). Don’t fix
the middle point guider D1 at this time.

5
Step #2: Top Frame Set-up
Fig. 2-1: Screw Center Hook (J) into the Larger Roof Connector (E) and secure them properly.
Fig. 2-2: Connect Top Roof Supporter (F) with Larger Roof Connector (E). Attention here: the end of Label
“→F” affixed on Larger Roof Connector (E) is used to assemble F.
Fig. 2-3 & 2-4: A ladder is needed for this step--- When placing Larger Roof Connector (E), please make sure
that, the middle connecting end of E labeled with “→H2” should be directed to Long Bar (C1); while the part
labeled with the logo “→H1” be directed to Short Bar (C2).
Connect one end of the Corner Supporting Bar (G1&G2) and Top Roof Supporter (F), and fix the other end of
(G1&G2) with Big Screen (A).
Fig. 2- 5 & 2-6: Connect one end of Side Supporting Bar (Long) (H1) and Larger Roof Connector (E), and
secure the other end of (H1) with Long Mosquito Netting Guider (D1) together to the Short Bar (C2) with
Screws (BB) and Washers (CC).
Fig. 2-7: Do the same for Side Supporting Bar (short) (H2) and Larger Roof Connector (E), then fix them with
Long Bar (C1) using (BB) and (CC), to complete top frame assembly.

6
Step #3: Put on Canopy and Mosquito Netting
Fig. 3-1: Put Larger Canopy (K1) on to the top frame. Don’t unfold it completely at this time.
Fig. 3-2: Put on Top Canopy (K2) to Top Roof Supporter (F); tie the netting of Top canopy together with the straps
on Larger Canopy (K1).
Unfold Larger Canopy completely, and attach the hooks on the canopy to the holes in bars and screens.
Put the gazebo in a correct position/direction; tighten all the screws with Wrench (WW) properly.
Fig. 3-3: Attach Mosquito netting (N) onto Big Screen (A) and Long and Short Mosquito Netting Guider (D1&D2)
with Plastic Rings (EE). Pay attention to the difference of two sides with different length.
Fig. 3-4: Secure the completely assembled product on the ground with Stake (DD).

7
Care & Maintenance
Our steel components for garden accessories and furniture are treated with rust inhibiting paint that protects it from
rusting. However, due to the nature of steel, surface oxidation (rusting) will occur once these protective coatings
are scratched. This is a natural process and is not a defect! To minimize this condition, we recommend care when
assembling & handling the product to prevent scratching the paint. Should any scratching or damage occur, we
recommend immediate touch-up with rust inhibiting paint, which is included in the package. Surface rust can also
be easily removed with a very light application of common cooking oil. If surface oxidation (rusting) occurs and if no
measure is taken to prevent this, the oxidation may start dripping on to deck or patio and cause damaging stains,
which may be difficult to remove. This can be prevented if the measure is taken to keep the product from oxidizing.
Limited Warranty
The item is warranted to be free from defects in material or workmanship for a period of 1 year. However, we
don't reimburse for transportation or delivery costs, or compensate the individual or any outside party for
assembling or disassembling the product.
This limited warranty is extended to the original purchaser and applies to defects in materials and workmanship of
your item, provided the item is maintained with care and used only for personal, residential purposes.
Exclusions
Items used for commercial, contract, or other non-residential purposes, or items damaged due to acts of nature,
vandalism, misuse, or improper assembly are not covered. Corrosion or rusting of hardware is not covered. Proof
of purchase (dated register receipt) is required for warranty claims. Warranty is to the original purchaser and is
non-transferable. Any replacement of warranted items will be in the original style and color, or a similar style and
color if the original is unavailable or has been discontinued. As some states do not allow exclusions or limitations
on an implied warranty, the above exclusions and limitations may not apply. This warranty gives you specific rights,
and you may also have other rights, which vary from state to state.
Important
Please do not return this product to the store. For technical assistance on assembly or replacement parts, call
Sunjoy Industries at [phone] from 8:30 AM to 5:30 PM EST Monday to Friday; or For expedited
replacement parts order, fax the attached completed customer service replacement form to 740 283 3549; or email
[email protected]om for assistance
