Sunjoy 804800 User manual

PROMO GAZEBO - SUNJOY
THANK YOU
We appreciate the trust and confidence you have bought this gazebo. We strive to continually create quality products designed to
enhance your home. Visit us online www.sunjoyonline.com to see our full line of products available for your home improvement
needs. Thank you for choosing Hampton Bay!
USE AND CARE GUIDE
SKU#: 804800
Questions, problems, missing parts? Before returning to the store,
call Sunjoy Customer Service 1(866) 578-6569
from 8:00 am to 8:00 pm eastern standard time
or e-mail to [e-mail]
or fax your parts replacement order form together with the purchase receipt
to 1 [phone] for assistance.

2

Table of Contents
Table of Contents..........................................................2
Safety Information.........................................................2
Warranty.........................................................................2
What is Covered.........................................................2
What is Not Covered ..................................................2
Pre-Assembly................................................................3
Planning assembly..................................................... 3
Hardware Included..................................................... 3
Package Contents...................................................... 4
Assembly.......................................................................5
Care and Cleaning ........................................................8
Safety Information
1. Four people are recommended for this assembly.
2. Some parts may contain sharp edges. Wear
protective gloves.
3. When assembling and using this product, basic
safety precautions should always be followed to
reduce the risk of personal injury and damage to
equipment. Please read all instructions before
assembly and usage.
DANGER: Do not assemble this item alone.
WARNING: Do not leave the gazebo where there is
a risk of high wind, as possible damage will occur to
the structure.
WARNING: Keep all flame and heat sources away
from this gazebo/canopy fabric. This gazebo/canopy
is made with fabric that meets CPAI-84
specifications for flame resistance. It is not fire proof.
The fabric will burn if left in continuous contact with
any flame source. The application of any foreign
substance to the gazebo/canopy fabric may render
the flame-resistant properties ineffective.
Warranty
1 YEAR WARRANTY
WHAT IS COVERED
This limited warranty is extended to the original purchaser and applies to defects in materials and workmanship of your
item provided the item is maintained with care and used only for personal, residential purposes. The item is warranted to be
free from defects in material or workmanship for a period of 1 year.
WHAT IS NOT COVERED
We do not reimburse for transportation of delivery costs, or compensate the individual or any outside party for assembling
or disassembling the product.
Contact the Customer Service Team at 1(866) 578-6569 or visit www.sunjoyonline.com
CAUTION: Do not climb on top of the gazebo.
Falling off the gazebo can result in serious injury,
possibly even death.
NOTICE: For outdoor use only.

3

Pre-Assembly
PLANNING ASSEMBLY
Before beginning assembly of this product, make sure all parts are present. Compare parts with the Hardware Included
and Package Contents lists. If any part is missing or damaged, do not attempt to assemble the product. Contact
customer service for replacement parts.
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
AA BB CC
DD EE FF
Part Description Quantity
AA Stake 8PCS
BB Big stake 4PCS
CC Rope 4PCS
DD Netting rope 4PCS
EE Ring 32PCS
FF Bag 1 PCS


4

 
Pre-Assembly (continued)
PACKAGE CONTENTS
Part Description Quantity
A Pop up canopy frame 1PCS
B Connector 4PCS
C Small canopy 1 PCS
D Big canopy 1 PCS
E Netting 1 PCS
A B
C
D
E


5

 
Assembly
1
Taking out the canopy frame
2
Attaching the big canopy
Take out the canopy frame (A) from the bag (FF).
NOTE: To avoid destroying the finish, do not put the
parts on the ground directly.
Place the canopy frame (A) upright and attach the big
canopy (D) on top. Have four people holding the corner
posts and pulling outwards.
NOTE: To avoid destroying the finish, do not put the
parts on the ground directly.
3
Attaching the small canopy
4
Securing the connector
Attach the Small canopy (C) to the plastic parts of the
small top when pulling the canopy frame outwards
NOTE: To avoid destroying the finish, do not put the
parts on the ground directly.
Insert the other end of the connector (B) into the plastic
buckle on the post (A) and secure it. Attach the large
canopy (D) to four corners by using connectors (B).
NOTE: To avoid destroying the finish, do not put the
parts on the ground directly.


6

 
Assembly (continued)
5
Securing the plastic buckle
6
Adjust the post height and
securing
Pull the plastic buckle of the canopy frame post (A) to
the spring buckle and secure it.
NOTE: To avoid destroying the finish, do not put the
parts on the ground directly.
Pull the canopy post upwards up to the spring buckle to
secure in place.
NOTE: To avoid destroying the finish, do not put
the parts on the ground directly.
7
Tie one end of the netting
rope
8
Tie the other end of the
netting rope
Tie one end of the netting rope (DD) to one end of the
frame (A).
NOTE: To avoid destroying the finish, do not put the
parts on the ground directly.
Straighten the netting rope (DD) and tie it to the othe
r
end of the frame (A)
NOTE: To avoid destroying the finish, do not put the
parts on the ground directly.


7

 
Assembly (continued)
9
Attach the hook to post
10
Attaching the netting
Attach the hook on the big canopy (D) to the lower end
of each post and fix it. Attach the hook on the big
canopy (D) to the any of 3 holes on each post base on
actual tension condition of canopy and fix it.
NOTE: To avoid destroying the finish, do not put the
parts on the ground directly.
Pass the netting rope (DD) through the hook and loop
tape on the canopy (D) and tighten the netting rope
(DD). Attach the netting (E) to the netting rope (DD) b
y
rings (EE)..
NOTE: To avoid destroying the finish, do not put the
parts on the ground directly.
11
Tightening the netting rope
12
Netting assembled
Attach the hook and loop tape on big canopy (D) to
Gazebo frame (A), and put the Netting rope (DD)
through 3 hook and loop tape (which are circled on the
drawing below) on big canopy (D), then tighten two
sides of the netting rope (DD).
NOTE: To avoid destroying the finish, do not put the
parts on the ground directly.
Note: Netting should hang on the outside of the shelf
NOTE: To avoid destroying the finish, do not put the
parts on the ground directly.


8

 
Assembly (continued)
13 Securing gazebo by stakes and rope
Secure the canopy frame (A) to the ground by using stakes (AA) and attach the rope (CC) to four corners of the big
canopy (D) and secure each rope with big stakes (BB) at an angle of 90 degree.
14 How to collapse the gazebo.
 If you want to collapse the gazebo, tear down the netting, no need to tear down the
canopy, fold the pop up as below image shown and then put them into the wheels
bag together
NOTE: To avoid destroying the finish, do not put the
parts on the ground directly.
NOTE: To avoid destroying the finish, do not put the
parts on the ground directly.

9

Care and Cleaning
□Our steel components for gazebo and garden accessories are treated with rust inhibiting paint that protects it from rusting.
However, due to the nature of steel, surface oxidation (rusting) will occur if these protective coatings are scratched. This is
not a defect and thus not covered by the warranty. To minimize this condition, we recommend care when assembling &
handling the product to prevent scratching the paint. Should any scratching or damage occur, we recommend immediate
touch-up with rust inhibiting paint. Surface rust can also be easily removed with a very light application of regular cooking oil.
If surface oxidation (rusting) occurs and if no measure is taken to prevent this, the oxidation may start dripping onto deck or
patio and caused damaging stains, which may be difficult to remove. This can be prevented if the above-mentioned
measures are taken to keep the product from oxidizing.
□Do not use bleach, acid, or other abrasive cleaners on the roof or frame parts.
□Keep instruction manual for future reference.
□Keep the original packaging to store the gazebo.
