Sunjoy A102007003 User manual

Country of Origin: China Production Number: XXXXXXXXXX
ASSEMBLY INSTRUCTION
ITEM#：A102007003
WE HAVE YOU IN MIND, LET US SERVE YOU!
Questions? Issues?
CONTACT US
24 hours / 7 days a week
www.sunjoyonline.com
[e-mail]

2/ 33
Country of Origin: China
•This product is intended for domestic outdoor use only.
•The product should be placed on flat, horizontal ground.
•Ensure enough clearance around the product. Before assembling the product, find level
ground not less than 6' (1.8 m) away from any structures or obstructions, such as
fences, garages, houses, overhanging branches, laundry lines, or electrical wires.
•This gazebo is not to be regarded as part of a building/house structure. The gazebo is
to be anchored onto the ground for added safety. Do not assemble the gazebo onto
soil/earth ground. It is best advisable to have the gazebo built onto a wooden deck or
concrete ground for stability. If it is to be build onto a wooden deck/ground, do
ensure that the wooden deck/ground has a strong foundation. It is advisable to use
appropriate floor plugs (not provided) to anchor the gazebo onto the wooden/concrete
ground.
•Some structures may require two or more people to install safely. Check for
underground utilities before digging or driving stakes into the ground.
•During installation, follow all safety warnings provided with your tools, and use safety glasses.
•In case you set up more than one gazebo, keep a minimum distance of 10' (3 m)
between the gazebos.
•Any assembly or maintenance of the product must be carried out by adults only.
•Arrange necessary manpower when assembling or moving the product.
•Some parts may contain sharp edges. Wear protective gloves if necessary.
•Keep children and pets away while setting up the gazebo.
•Check all nuts and bolts periodically to ensure bolts/nuts are tightened.
•Repairing and replacing parts should be done by a qualified technician.
•This gazebo is intended for decorative and sunshade purposes only, and it is not
designed to withstand harsh weather, including high winds, rain, and snow.
•Do not light any fires inside or near the product!
•Stay calm if fire breaks out. Search for the nearest exit. Do not return to the gazebo before
firemen allow you to do so.
•Do not hang heavy weights on the roof frame.
•Do not climb onto the roof of the gazebo. Falling off the gazebo can result in serious injury.
•Retain the original packaging to store the gazebo.
Important Safety Instructions
Warning! To reduce the risk of serious injury, read the following safety instructions
before assembling and using the gazebo.
Please check with your local governing authority/local municipal codes regarding
installation of structures before assembly.
Caution! Proper placement of your gazebo is essential.
Do not place the product underneath electrical lines.
Keep children away during assembly.
This product contains small parts which can be swallowed by children.
Keep fingers away from the places where they can be pinched or trapped. Do
not attempt to assemble the gazebo if any parts are missing.

3/ 33
Country of Origin: China
•Please read and understand this manual before any assembly. Beforebeginning
assembly of product, make sure all parts are present. Compare parts with packaging
contents list.
•When assembling wooden parts, do not overtorque the bolts to avoid splitting the wood.
See image illustration.
•Place all parts from the box in a cleared area and position themon the floor in front of
you.
•Remove all packing materials and place them back into the box. Do not dispose of the
packing materials until assembly is complete.
•Needed for assembly:（The following tools are not included）
IMPORTANT:

4/ 33
Country of Origin: China
EXPLODED DRAWING

5/ 33
Country of Origin: China
Parts List
Label Part Number Description Qty Part Image
08 P000200227 Post 4
10 P005000200 Arc Support 1 4
11 P005000201 Arc Support 2 4
27 P000400959 Inner Long Beam 4
06 P000400512 Inner Short Beam
(Short Side) 4
21 P000400960 Inner Short Beam
(Long Side) 4
25 P000400957 Out Side Left
Beam(Short) 4
26 P000400958 Out Side Right
Beam(Short) 4
AP00610021602Base Cover 4
BP00010025802Post Base 4
CP00560042801Decorative
(Middle) 4
DP00050025102Lower Connector
For Middle Beam 4
EP00560042901Decorative
(Corner) 4
FP00050024802Lower Connector
For Slanting Beam 4
JP00050157401Big Roof Short
Connector Tube 4

6/ 33
Country of Origin: China
AY P00060197201Big Roof Sloping
Beam 4
BA P00060198401Big Roof Middle
Beam 4
BB P00570027701Mosquito Netting
Rod(Left) 4
BC P00570035101Mosquito Netting
Rod(Right) 4
NP00060105901Small Roof Oblique
Beam 4
AU P00050156501Small Roof
Connector 1
QP00060196201Small Roff Top
Beam(Short
Side)
4
RP005800001 Hook 1
SP00070094501Small Roof Panel 4
UP00080019101Small Roof Inclined
Beam Cap 4
AV P00090015401 Top Cover 1
BD P00060203001Big Roof Top
Beam(Upper) 8
BE P00060203101Big Roof Left Panel
Flashing 4
BF P00060203201Big Roof Right
Panel Flashing 4

7/ 33
Country of Origin: China
BG P00070103201Big Roof Middle
Panel
4
BJ P00070102001Big Roof Big
Panel 4
BK P00070102501Big Roof Big
Panel(Right) 4
AR P00070101002Big Roof Left Small
Panel4
AS P00070101202Big Roof Right
Small Panel 4
BL P00080034501Big Roof Inclined
Beam Cap 4

8/ 33
Country of Origin: China
H1 H100010047 Bolt M6*20 148 9
H2 H100010069 Bolt M6*35 5 1
H3 H100010059 Bolt M6*45 8 1
H4 H010010449 Bolt M10*205 8 1
H5 H100010054 Bolt M8*25 24 2
H6 H100010055 Bolt M8*35 16 1
H7 H030050058 Screw M5*30 64 4
H8 H030050057 Screw M5*40 40 3
H9 H030030010 Bolt M8*35 16 1
H10 H030010031 Screw
M10*80 8 1
H11 H050080007 Flat Washer
M8 16 1
H12 H050080008 Flat Washer
M10 24 2
H13 H040050026 Non-slip Nuts
M10 8 1
Hardware Pack
Label Part Number Description Qty Add Part Image

9/ 33
Country of Origin: China
H15 H040090005
T-Nut
M8*20 16 1
H16 H090990002 M3 Drill 2 0
HS H070010003 Stake Φ8*180 8 0
HW1H090010017 M6 Wrench 2 0
HW2 H090030005 Allen Key M8 1 0
HW3 H090010015 M10 Wrench 2 0
H14 H040090004
T-Nut
M8*8 24 2

10 / 33
Country of Origin: China
1

11 / 33
Country of Origin: China
2

12 / 33
Country of Origin: China
3

13 / 33
Country of Origin: China
4

14 / 33
Country of Origin: China
5
Locating hole
10

15 / 33
Country of Origin: China
6

16 / 33
Country of Origin: China
7

17 / 33
Country of Origin: China
8
d1=d2
Rt∠90
Assembly Tip on Step 8:
Please measure to make sure the length of d1 is equal to d2
before moving to next step to ensure a square frame and best
results. Keep the beam at right angles to the post, the post
at right angles to the ground, and keep the beam horizontal.

18 / 33
Country of Origin: China
9

19 / 33
Country of Origin: China
10

20 / 33
Country of Origin: China
11
