Sunjoy A102016300 User manual

Country of Origin: China Production Number: XXXXXXXXXX
Pais d’origine: Chine Numéro de fabrication: XXXXXXXX
A
SSEMBLY IN
S
TRUCTION
I
tem
/Article #
：
A102016300
WE HAVE YOU IN MIND, LET US SERVE YOU!
Nous pensons en vous, laissez nous vous aider!
Questions? Issues? / Questions? Problèmes?
CONTACT US / Contactez-nous
[e-mail]
www.sunjoyonline.com

2 / 41
Country of Origin: China
Pais d’origine: Chine
 This product is intended for domestic outdoor use only.
 The product should be placed on flat, horizontal ground.
 Ensure enough clearance around the product. Before assembling the product, find level
ground not less than 6' (1.8 m) away from any structures or obstructions, such as fences,
garages, houses, overhanging branches, laundry lines, or electrical wires.
 This gazebo is not to be regarded as part of a building/house structure. The gazebo is to be
anchored onto the ground for added safety. Do not assemble the gazebo onto soil/earth
ground. It is best advisable to have the gazebo built onto a wooden deck or concrete ground
for stability. If it is to be build onto a wooden deck/ground, do ensure that the wooden
deck/ground has a strong foundation. It is advisable to use appropriate floor plugs (not
provided) to anchor the gazebo onto the wooden/concrete ground.
 Some structures may require two or more people to install safely. Check for underground
utilities before digging or driving stakes into the ground.
 During installation, follow all safety warnings provided with your tools, and use safety glasses.
 In case you set up more than one gazebo, keep a minimum distance of 10' (3 m) between the
gazebos.
 Any assembly or maintenance of the product must be carried out by adults only.
 Arrange necessary manpower when assembling or moving the product.
 Some parts may contain sharp edges. Wear protective gloves if necessary.
 Keep children and pets away while setting up the gazebo.
 Check all nuts and bolts periodically to ensure bolts/nuts are tightened.
 Repairing and replacing parts should be done by a qualified technician.
 This gazebo is intended for decorative and sunshade purposes only, and it is not designed to
withstand harsh weather, including high winds, rain, and snow.
 Do not light any fires inside or near the product！
 Stay calm if fire breaks out. Search for the nearest exit. Do not return to the gazebo before
 firemen allow you to do so.
 Do not hang heavy weights on the roof frame.
 Do not climb onto the roof of the gazebo. Falling off the gazebo can result in serious injury.
 Retain the original packaging to store the gazebo.
Important Safety Instructions
Warning! To reduce the risk of serious injury, read the following safety instructions
before assembling and using the gazebo.
Please check with your local governing authority/local municipal codes regarding
installation of structures before assembly.
Caution! Proper placement of your gazebo is essential.
Do not place the product underneath electrical lines.
Keep children away during assembly.
This product contains small parts which can be swallowed by children.
Keep fingers away from the places where they can be pinched or trapped.
Do not attempt to assemble the gazebo if any parts are missing.

3/ 41
Country of Origin: China
Pais d’origine: Chine
Consignes de sécurité importantes
ATTENTION! 





Avertissement!



•
•
•



• 
 
 
 
 

•

•

• 

•
•
•
•
•

•
•

•
•

•
•

•

4 / 41
Country of Origin: China
Pais d’origine: Chine
• Please read and understand this manual before any assembly. Before beginning
assembly of product, make sure all parts are present. Compare parts with packaging
contents list.
•When assembling wooden parts, do not overtorque the bolts to avoid splitting the wood.
See image illustration.
•Place all parts from the box in a cleared area and position them on the floor in front of you.
•Remove all packing materials and place them back into the box. Do not dispose of the
packing materials until assembly is complete.
•Read each step carefully before beginning any assembly and make sure you understand each
step. If you are missing a part, please email [e-mail].
•Needed for assembly:（The following tools are not included）
IMPORTANT:
Cordless drill Hammer Screwdriver Ladder 5 people

5/ 41
Country of Origin: China
Pais d’origine: Chine
IMPORTANT:
•

•
•

•

•





Utilisez un niveau


Véfifiez avec un équerre


Serrer les boulons Mesurer la distance




   5 personnes

6 / 41
Country of Origin: China
Pais d’origine: Chine
EXPLODED DRAWING/ DESSIN ÉCLATÉ

7 / 41
Country of Origin: China
Pais d’origine: Chine
Parts List
Label Part Number Description Qty Part Image
A1 P000200412 Side Post 1 2
A2 P000200413 Side Post 2 2
B1 P000200414 Middle Post 1 2
B2 P000200415 Middle Post 2 2
C1 P000401122 Long Beam 1 2
C2 P000401123 Long Beam 2 2
D1 P000401124 Short Beam 1 2
D2 P000401125 Short Beam 2 2
E P002200122 Card Set 4
F1 P000500243 Beam Connector 1 4
F2 P000500244 Beam Connector 2 4
G P000500241 Connector for Cant
Beam 4
H P000500242 Connector for
Middle Beam 12
I P002200123 Middle Card Set 4
J1 P000601377 Rafter(Upper) 4
J2 P000601506 Rafter(Lower) 4

8 / 41
Country of Origin: China
Pais d’origine: Chine
Liste de Pièces
Étiquette Numéro de la Pièce Description Quantité Numéro de la Pièce Diagramme
A1 P000200412 Poteau Latéral 1 2
A2 P000200413 Poteau Latéral 2 2
B1 P000200414 Poteau centrale 1 2
B2 P000200415 Poteau centrale 2 2
C1 P000401122 Poutre Longue
1
2
C2 P000401123 Poutre Longue
2
2
D1 P000401124 Poutre Courte
1
2
D2 P000401125 Poutre Courte
2
2
E P002200122 jeu de cartes 4
F1 P000500243 Connexion de la 1 4
F2 P000500244 Connexion de la 2 4
G P000500241 Connecteur pour
Cant Beam 4
H P000500242 Connecteur pour
faisceau intermédiaire 12
I P002200123 Jeu de cartes du
milieut 4
J1 P000601377 chevron (supérieur) 4
J2 P000601506 chevron (inférieur) 4

9 / 41
Country of Origin: China
Pais d’origine: Chine
K1 P000601624 Big Roof Middle
Beam 4
K2 P000601752 Big Roof Middle
Short Beam 1 4
K3 P000601905 Big Roof Middle
Short Beam 2 4
L P000601906 Big Top Small Beam 1 8
M1 P000601907 Big Roof Panel
Flashing(Side) 1 4
M2 P000601908 Big Roof Panel
Flashing(Side) 2 4
N1 P000601909 Big Top Small Beam 2 4
N2 P000601910 Big Top Short Edge
Small Middle Beam 4
N3 P000601911
Big Roof Middle
Panel Flashing(Short
Side)
4
O1 P000601912 Big Top Small Beam 3 4
O2 P000601913 Big Top Long Edge
Small Middle Beam 4
O3 P000601914
Big Roof Middle
Panel Flashing(Long
Side)
4
P1 P000700018 Panel 1 4
P2 P000700021 Panel 2 4
P3 P000700026 Panel 3 4
P4 P000700029 Panel 4 4
P5 P000700032 Panel 5 4

10 / 41
Country of Origin: China
Pais d’origine: Chine
K1 P000601624 Poutre centrale de
grand toit 4
K2 P000601752 Petite Poutre milieu
du Grand Toit1 4
K3 P000601905 Petite Poutre milieu
du Grand Toit 2 4
L P000601906 Petite Poutre du
Grand Toit 1 8
M1 P000601907
Solin du Panneau
Latéral du Grand Toit
1
4
M2 P000601908
Solin du Panneau
Latéral du Grand Toit
2
4
N1 P000601909 Chapiteau petit
faisceau2 4
N2 P000601910
Grand Chapiteau Bord
Court Petit Poutre
Moyen 4
N3 P000601911
Solin du panneau
central du grand toit
(côté court)
4
O1 P000601912 Chapiteau petit
faisceau 3 4
O2 P000601913 Big Top Long Edge
Small Middle Beam 4
O3 P000601914
Grand solin de
panneau central de
toit (côté long)
4
P1 P000700018 Panneau 1 4
P2 P000700021 Panneau 2 4
P3 P000700026 Panneau3 4
P4 P000700029 Panneau 4 4
P5 P000700032 Panneau 5 4
