Sunjoy L-GG035PST User manual

Domed Top Grill Gazebo Assembly Instruction
Item# L-GG035PST
SKU # 810138516

IMPORTANT:
Please read and follow all safety statements, warnings, assembly instructions, use & care
directions before attempting to assemble.
1. When installing and assembling your gazebo, it is recommended that 2 or more adults are
involved.
2. Do not use the unit during an electrical storm, as there is a remote chance of getting struck
by lightening.
3. Do not climb on top of the gazebo. Falling off the gazebo can result in serious injury,
possibly even death.
4. Do not leave the gazebo assembled when there is a risk of high wind, as possible damage
will occur to the structure.
5. This package contains small items and plastic bags that should be kept away from children.
6. Ensure that all connectors & poles are firmly secured in position fully. It is important to do so
before use so as to avoid collapsing or damage to the item, which could result in injury.
7. WARNING: Keep all flame and heat sources away from this tent fabric. This tent is made
with fabric that meets CPAI –84 specifications for flame resistance. It is not fire proof. The
fabric will burn if left in continuous contact with any flame source. The application of any
foreign substance to the tent fabric may render the Flame-resistant properties ineffective.
8. WARNING: Please take down the gazebo during strong wind. The manufacturer or retailer
is not liable for any loss of the product or other items due to the failure to take down the gazebo
during strong wind.
USE & CARE
1. This Gazebo is not a permanent structure and should be disassembled & stored away after
use.
2. Do not repack your gazebo until completely dry.
3. This Gazebo must be assembled by two adults or more.
4. This Gazebo must not be left erect in windy conditions.
WARNINGS
1. Assembly Instructions must be followed.
2. Pegs supplied must be used to hold this gazebo in place when upright.
3. Warranty does not cover damage due to extreme weather conditions.

Arch post 1
A
2
Arch post 2
B
2
Bottom crossbeam
C
2
Long screen
D
2
Short screen
E
2
Shelf
F
2
Side beam
G
4
Top connector
H
1
Hook
I
1
Small canopy
J
1
Large canopy
K
1
Parts List
AA
M6X15 Bolt
24 PCS
BB
M6 Flat washer
24 PCS
Z
M6 Wrench
2 PC
Hardware Pack1

Fig.1: Put the bottom
crossbeam (C) on the
floor, insert post 2 (B)
into bottom crossbeam
(C).
Fig.2: Attach short screen
(E) to post 1 (A) and post 2
(B) by bolt (AA) and flat
washer (BB).
Fig.3: Attach shelf (F)
to post 1 (A) and post 2
(B) by bolt (AA)
Fig.4: Attach long screen
(D) to post 1 (A) and post
2 (B) by bolt (AA) and flat
washer (BB).
CC
M6X35 Bolt
4 PCS
BB
M6 Flat washer
4 PCS
DD
M6 Nut
4 PCS
EE
Φ8X180MM Stake
4 PCS
Hardware Pack 2

Fig.5: Insert side beam
(G) to top connector (H),
then attach hook (I) to top
connector (H).
Fig.6: Attach side beam
(G) to post 1 (A) and post 2
(B) by bolt (CC), flat
washer (BB) and nut (DD).
Fig.9: Fix the gazebo to the grass
ground by stake (EE).
Fig.7: Put large
canopy (K) onto big
top, do not spread out,
then put small canopy
(J) onto small top.
Fig. ８:Spread out
large canopy (K).
