Sunjoy L-PG155PST User manual

C
ountryofOrigin:China ProductionNumber:xxxxxxxx
RETRACTABLE SHADE PERGOLA
ASSEMBLY INSTRUCTION
ITEM#：L-PG155PST
Ifyouhaveanyissueswiththeproduct,donotreturn
theproductbacktothestore
Foranyquestionsorissuesaboutourproduct
CallSunjoyCustomerService
1-866-578-6569 /1-844-786-5691
8:00AMEST–8:00PMPST
Forfurtherassistance,pleasewritetous at
[e-mail]

CountryofOrigin:China
2 /19
Safety Information
 Two people are required for this assembly.
 Some parts may contain sharp edges. Wear
protective gloves.
 When assembling and using this product,
basic safety precautions should always be
followed to reduce the risk of personal
injury and damage to equipment. Please read
all instructions before assembly and usage.
Thelimitedwarrantyisextendedtotheoriginalpurchaserandappliestomaterialandmanufacturer’sdefectprovided
theitemismaintainedwithcareandusedonlyforpersonal,residentialpurposes.
Warranty: 1 Year
WHAT IS COVER?
IMPORTANT
KEEPTHISINSTRUCTIONMANUALFORFUTUREREFERENCE.
CAUTION: Do not climb on top of the
gazebo. Falling off the gazebo can
result in serious injury.
NOTICE: For outdoor use only.
DANGER: This unit is heavy! Do not assemble
this item alone.
W
ARNING: Do not leave the gazebo where there
is a risk of high wind, as possible damage will
occur to the structure.
W
ARNING: Keep all flame and heat sources
away from this gazebo fabric. This Gazebo is
made with fabric that meets CPAI-84
specifications for flame resistance. It is not fire
proof. The fabric will burn if left in continuous
contact with any flame source. The application
of any foreign substance to the gazebo fabric
may render the flame-resistant properties
ineffective.
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com

CountryofOrigin:China
3 /19
TOOLS NEEDED
IMPORTANT
How many people needed for the installation work
Provided in hardware pack
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com

CountryofOrigin:China
4 /19

EXPLODED DRAWING
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com

CountryofOrigin:China
5 /19
Parts List
LabelPart NumberDescription Qty Part Image
A P13059A01105 Top Beam 1 7
B P13060A01105 Top Beam 2 7
C P11069A01105 Beam 1
（Long Side） 2
D P11068A01105 Beam 2
（Long Side） 2
E P11071A01105 Beam 1
（Short Side） 2
F P11070A01105 Beam 2
（Short Side） 2
G1 P12908A01105 Corner 1 2
G2 P12909A01105 Corner 2 2
G3 P10908A01105 Angle Sleeve 4
H P11179A01105 Post 4
J P11629A01105 Base 4
K P11525A01105 Base Cover 4
L P11843A01105 Arc support 1 4
M P11844A01105 Arc support 2 4
N1 P12830A01105 Pipe For Pull
Cloth 1 7
N2 P12831A01105 Pipe For Pull
Cloth 2 7
N3 P12832A01105 Pipe For Pull
Cloth 3 2
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com

CountryofOrigin:China
6 /19
N4 P12833A01105 Pipe For Pull
Cloth 4 2
P P13704A01105 Hook 4
Q1 P12828A01105 Guide Tube 1 1
Q2 P12826A01105 Guide Tube 2 1
Q3 P12829A01105 Guide Tube 3 1
Q4 P12827A01105 Guide Tube 4 1
R P91506A07001 Pulley 14
S P00103P07025 Small Canopy 1
T P00104P07025 Big Canopy 1
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com

CountryofOrigin:China
7 /19
Hardware Pack
LabelPart NumberDescription Qty Add Part Image
AA H02015C11 Bolt M6*15 130 13
BB H19001C11 Flat washer
M6 17618
CC H09045C11 Bolt M6*45 14 2
DD H09015C11 Bolt M6*15 32 4
EE P12401A01001 Stake
Φ8*180 16 0
FF H00001C12 Wrench M6 1 0
Actual Size
Actual Size
Actual Size
Actual Size
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com

CountryofOrigin:China
8 /19
STEP1:Assembly of Corner and Angle Sleeve
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com
2x
8x
P12908A01105
2x
H02015C11
2xP12909A01105 4xP10908A01105
2x

CountryofOrigin:China
9 /19
STEP 2:Assembly of Beam
2x
2x
8x
P11071A01105
H19001C11
H02015C11
4x
P11070A01105
2x
2x
P11068A01105
P11069A01105
H02015C11
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com

CountryofOrigin:China
10 /19
STEP 3:Assembly of Corner and Beam and Hook
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com
24x
2x
H02015C11
2x
4x
4x
P13704A01105
4x
H19001C11
H02015C11

CountryofOrigin:China
11 /19
STEP 4:Assembly of Pipe For Pull Cloth
7x P12830A01105
7x
P12831A01105
H09015C11
18x
H19001C11
2x P12832A01105
2x
P12833A01105
H09015C11
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com

Country of Origin: China
12 / 19
STEP 5:Assembly of Big Canopy and Pulley
H09015C11
14x
1x P00104P07025
H09015C11
H19001C11
14x
7x
2x 14x
P91506A07001
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com

Country of Origin: China
13/19
STEP 6:Assembly of
Guide Tube
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com
P12827A01105 12x
1x
P12826A01105
1x
2x
H02015C11
P12829A01105
P12828A01105
1x
1x
4x
4x

Coun
tryofOrigin:China
14 / 19
STEP 7:Assembly of Post and Base and Base Cover
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com
16x
4x
4x
4x
H02015C11
4x
P11179A01105
P11525A01105
P11629A01105

Country of Origin: China
15 /19
STEP 8:Assembly of Arc support
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com
48x
4x
4x
H02015C11
4x
8x
8x
P11843A01105 P11844A01105

Country of Origin: China
16/19
STEP 9:Assembly of Top Beam
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com
14x
7x
H02015C11
P13060A01105
P13059A01105
7x
7x

Country of Origin: China
17/19
STEP 10:Assembly of Top Beam and Small Canopy
1x
14x
H09045C11
H19001C11
P00103P07025
H09045C11
7x
H19001C11
H09045C11
4x
6x
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com

CountryofOrigin:China
18 /19
4x
P12401A01001
STEP 11:Assembly of Stake
Call 1-866-578-6569 /1-844-786-5691 for assistance.
Orvisitusatwww.sunjoyonline.com

CountryofOrigin:China
19 /19
 Oursteelcomponentsforgardenaccessoriesandfurniturearetreatedwithrustinhibitingpaintthatprotectsit
fromrusting.However,duetothenatureofsteel,surfaceoxidation(rusting)willoccuroncetheseprotective
coatingsarescratched.Thisisnotadefectandthusnotcoveredbythewarranty.
 Tominimizethiscondition,werecommendcarewhenassembling&handlingtheproducttopreventscratching
thepaint.Shouldanyscratchingordamageoccur,werecommendimmediatetouch‐upwithrustinhibitingpaint.
 Surfacerustcanalsobeeasilyremovedwithaverylightapplicationofcommoncookingoil.Ifsurfaceoxidation
(rusting)occursandifnomeasureistakentopreventthis,theoxidationmaystartdrippingontodeckorpatio
andcauseddamagingstains,whichmaybedifficulttoremove.Thiscanbepreventediftheabove‐mentioned
measuresaretakentokeeptheproductfromoxidizing.
 Usedampclothtowipeoffthestainsasquicklyaspossible.
 Ifnecessary,washwithamildsolutionofsoapandwater;rinsethoroughlyanddrycompletely.
 Periodicallycheckandensurethatallboltsarewell‐tightenduringuse
SUNJOYGroupwarrantstotheoriginalpurchaserthatthisitemisfreefromdefectsinworkmanshipandmaterialsfor
a period of 1 year from the date of purchase, provided the itemwasfactory‐sealedatthetimeofpurchaseandis
maintainedwithcareandusedonlyforpersonal,residentialpurposes.Shouldanymanufacturingdefectarisewithin
this warranty period, SUNJOY Group will replace (at our option) any defective merchandise or parts uponproofof
purchase;however,transportationanddeliverycosts,aswellaspaymentstoathirdpartyforassemblyordisassembly
of the item, remain the responsibility of the purchaser. A purchaser of an "open box," previously‐returned, or
"clearance"item,aswellasoriginalpurchasers outside ofthewarrantyperiod,mayobtainreplacementpartsfrom
SUNJOYGroupforproductsincurrentproduction,atnominalcost.
Items used for commercial, contract, or other non‐residential purposes, or items damaged due to acts of nature,
vandalism,misuse,orimproperassemblyarenotcovered.Corrosionorrustingofhardwareisnotcovered.Proofof
purchase (dated register receipt) is required for warranty claims. Warranty is to the original purchaser and is
non‐transferable.Anyreplacementofwarranteditemswillbeintheoriginalstyleandcolor,orasimilarstyleandcolor
orasimilarstyleandcoloriftheoriginalisunavailableorhasbeendiscontinued.Assomestatesdonotallow
exclusionsorlimitationsonanimpliedwarranty,theaboveexclusionsandlimitationsmaynotapply.Thiswarranty
givesyouspecificrights,andyoumayalsohaveotherrights,whichvaryfromstatetostate.
Care and Maintenance
Limited Manufacturer’s Warranty
Exclusions:
