Sunlighten mPulse cONQUER User manual

ASSEMBLY INSTRUCTIONS
included in door handle
2x
5x 2x 1x 1x
1 2 3 5 6 7
4x 2x 4x 1x 1x
M6x70
Allen wrench Philips Screw Driver
47x
M6x55
A B C D
1x Roof
1x Back Wall
1x Left Wall with glass panel
1x Bench
1x Right Wall
1x Front Wall
1x Glass Front Door
E1x Floor F
G
I
K
J
L
H
ASSEMBLY INSTRUCTIONS Conquer
M 2x 11 in, 1x 3 1/2 ft.
1sunlighten.com

F
A
4
7
B
G
F
The first step to installing your new sauna
will be to insert the legs underneath the
floor panel. The holes are already pre-drilled
so all you need are the bolts and the
Allen wrench . This is necessary to allow
air circulation to flow underneath and
maintain the integrity of the unit. After legs are
in place, please turn floor panel 180° so the back
of the sauna connects with the back wall
as shown below.
4
7
Unpack each wall segment from the shipping material.Stage each
wall segment in the room you will be assembling the unit.
Remove the internal wooden heater frames during unpacking
of the wall segments, set these aside for installation after
the sauna is assembled.
Remove the small wooden wire covers at the base of each vertical
wall segment, set aside for placement after the sauna is assembled.
STEP 1
Before you begin installing the walls, be sure you
have at least:
• 6.2 in between the back of the sauna and the
outlet wall.
•12 in gap from the top of the sauna to the ceiling.
•Place the sauna next to the wall power outlet to
ensure you have access to the wall power socket
outlet to cut the power to the unit if required.
Make sure the floor panel is placed on a surface that
is relatively smooth and perfectly level. Failure to do
so can cause the door to not close all the way in the
later steps.
In this step make sure one person is holding the wall
while the other helps balance it and press it in place.
STEP 2
PRE-STEPS
* Failure to do so will void your sauna's warranty
and customer will assume liability for any electrical
damages to the sauna itself or the residence/business
in which the sauna is installed.
See USER MANUAL
240V, 3600 watts. Dedicated 20A circuit* (not found
in common electrical setups - may need a transformer
to accommodate.) and 20A power socket with no GFCI
or similar fault protection installed in the meter box.
GBack of sauna
180°
Back of sauna
Front of sauna
2sunlighten.com

H
I
5
J
5
STEP 3 STEP 4
The front wall will be the last to install.
There will be wire connections that need to be made
at the base of each wall panel. These can be accessed
by small hatches on the walls (floor hatch for the
front). If a cable gets stuck in the floor it can be
accessed by removing the wood piece that covers
the power box.
A diagram showing the connection locations
can be found on STEP 8.
NOTE: If you ever have trouble getting
a U-clip to slide in, this can be resolved by
tapping it with a hammer.
The following walls will be inserted the same way
as STEP 2. Make sure the wires coming out from
the bottom hatches don’t pinch when you mount
the walls.
STEP 5
After you place each wall segement, please
use the U-clips and insert them in each
upper corner to hold the walls together.
5
J
3sunlighten.com

STEP 6
After the roof is placed, remove the dust covers.
There should be the connections to the lights
and speakers at the top front. Connect those
so you can turn on the lights and listen to sound.
In addition there will be one metal-loop lead.
Those can be screwed into the radio antenna.
After all four U-clips are inserted
in the corners, the next step will be
to place the roof on top. The roof will also
reinforce the walls in position along with
the clips.
NOTE: The roof may require some slight
manipulation to fall into place on top of
the wall panels.
STEP 7
5
Lights, Speakers,
Antenna
E
5
5
4sunlighten.com

STEP 8
Left Wall Heaters
Front Wall Heaters,
Lights, Stereo,
Control Tablet
The dust cover should be replaced to protect
the lights and speakers from dust and other
floating residue. Place the heater frames in their
respective locations if you have not yet done so.
As mentioned in STEP 5, there are four
connections to be made in each bottom section of
the walls. If you have not yet done so,consult with
the diagram at the bottom of this page.
NOTE: Look at the back of the heater frames for
the “This Side Up” sticker for proper orientation.
After all four floor connections have
been made, please install the bench .K
Make surethe heater frames are not mounted
otherwise they will prevent the bench from resting
on the supports.
Back Wall Heaters
Right Wall Heaters
K
5sunlighten.com

L
STEP 9
After the bench is placed in the unit, the next step
will be inserting the glass door . Please ensure
you have at least one other person to assist with this
step. Do not put the door handles on as that will be
done in a later step after the door has been safely
attached in this step.
NOTE: You can use a paint stick to shim the glass
door at a desirable angle above the threshold as
you mount it.
STEP 10
L
Using the Allen wrench ,6you will tighten the
bolts into the hinges as the door is inserted.L
Make surethe bolt is inserted firmly. Each hinge
will have four plastic gaskets. The door will be
inserted between the four gaskets.
Make surethe rough-texture side of the gasket is
against the glass door as your insert it. This will
give it the grip needed to hang it. Likewise,
make sure the gaskets touching the hinges also
are doing so by the rough side.
6
6sunlighten.com 6sunlighten.com

D
C
3
2
1
STEP 11
The gaskets, bolts and washers , and
will come with the handles. The washers need to be
inserted into the door holes first before the gaskets
go on and eventually the bolts. The rough side of the
gaskets must be facing the glass door. Be sure to
have a second person hold the handle in place while
the other inserts the bolt.
1 2 3
STEP 12
Installation Guidance for the INTERIOR DOOR SEAL
After the glass door installation is completed, ensure
the gap between the glass door and wooden frame
is at least 1/8 in.
Open the glass door to 90°.
Carefully remove the blue protection film.
Make sureto clean the inside edge of the glass
with a wet towel, then dry before applying the strips.
90°
7sunlighten.com

CONGRATULATIONS, your sauna is now ready to enjoy!
If you have any questions, please call
Sunlighten Customer Support at 1-877-292-0020 x4
4062022
m1 m1
m2
m2
m1
L
M
STEP 12
2 strips x 11 in
m1
1 strip x 3 1/2 ft.
m2
Remove the backing layer of the 3M adhesive tape on the strip.
Adhere the shorter strip on the top and bottom section
to inside edge of glass door.
Adhere the longer strip on the middle section to inside
edge of the glass door.
Close the door slowly and check to make sure the strips don’t hit
the wooden frame which could cause the strips to peel off.
In case the strip hits the wooden frame, adjust the door hinge to
increase the gap between the door and the wooden frame.
m1
m2
8sunlighten.com
