Sunlighten Signature I User manual

E1x Floor
G1x Left Wall H1x Back Wall I1x Right Wall J1x Front Wall with Glass door
F1x Roof
2x
14x 24x 3
4x
A1x B1x C
1x
4
D1x Bench
ASSEMBLY INSTRUCTIONSASSEMBLY INSTRUCTIONS SIGNATURE I
1sunlighten.com.au 1sunlighten.com.au
20072022

•Attach the feet pegs with supplied Allen
wrench and bolts to the underside of floor
(see illustration 1.1).
• Cut the zip ties holding the floor grate,
the fabric will adhere to the Velcro on the
underside of the grate (see illustration 1.2).
TIP: One side of the fabric adheres better
NOTE: Make sure the floor panel is on a surface
that is perfectly level & relatively smooth.
2 E
A
•Un-pack each wall segment from the shipping material.
•Stage each wall segment in the room you will be assembling the unit.
* Failure to do so will void your sauna's warranty
and customer will assume liability for any electrical
damages to the sauna itself or the residence/business
in which the sauna is installed.
240V, 1673 watts. Dedicated 10A circuit and
10A power socket protected by a 10A RCBO
installed in the meter box.
Minimum 1.5mm cable required for circuit;
2.5m cord exists from back left of roof.*
See USER MANUAL
STEP 1
STEP 2
PRE-STEPS
A
2
4
1.1
1.2
• Place the back wall on the back of the floor panel .
• Be sure you have two people assisting with this step.
This is the side with the sauna information label
on the bottom edge.
HE
E
E
E
H
2sunlighten.com.au 2sunlighten.com.au

STEP 3
STEP 4
• Place right wall on the right side of floor panel .
This wall panel should sit flush once properly seated.
• Make sure no gaps are visible in the corner of the two
walls as you insert it. It should be inserted flush.
NOTE: The right wall of the sauna includes wire
connections underneath which will lead into
the floor panel (see illustration 3.2 below).
I E
3.2 Connect floor
heaters
• If you have not yet done so, the floor heaters
will need to be connected to the right wall wires.
The diagram to the left shows where the connection is made.
• You will need to remove the floor grate and
a small hatch covering the harness.
3
• As you insert each wall segment, you will insert
the U-clips in the pre-drilled holes in the corner.
This will keep the walls sealed together.
• The front wall will be inserted next. Be careful
of the glass door & panel as you insert the wall.
J
3
I
E
J
1sunlighten.com.au 3sunlighten.com.au

STEP 5
STEP 6
• After securing the U-clip , the left wall will
be the last to be inserted. Make sure it is flush and
no gaps are showing in the corners.
NOTE: If you ever have trouble getting a U-clip
to slide in, this can be resolved by tapping it with
a hammer.
3 G
3
3
3
• Remove the roof cover panels (see illustration 6.1 below).
• Once all the U-clips have been inserted in the corners,
the next step will be to place the roof on top without
roof cover panels.
• Make sure the side the main powercord receptacle
faces the back.
F
F
6.1
G
4sunlighten.com.au

C
B
1
4
STEP 7
STEP 8
• With the bench installed, the heater panel
frames can be inserted back into their
respectable walls.
• The door handles come with the hard-
ware and can easily be screwed right in.
• A second person should hold the handle
while the other screws the bolts in
with the Allen wrench.
• The dust cover should also be replaced.
• Please make all connections on the roof
of the sauna as illustrated
• Connect sauna to external power.
• Turn on the power to sauna (see illustration 7.1 below).
• Check all of the heaters are working by placing your
hand against the heater cover to feel the heat.
• Check the radio is operating by quickly tapping the SRC button.
• Check the lights turn on using the control panel
(see illustration 7.1 below).
• If all electronics are working, turn them off and
turn off the power to the sauna.
• Replace the roof panels.
• In the event a heater is not working, unplug the connection
and firmly plug back in. Then re-test with power on.
• If you require any support, please contact
our Technical Service team.
Left Wall Heaters
Back Wall Heaters Right Wall Heaters
Control Panel
Speakers & Lights
• Before the bench is placed, make sure
the heater frames are taken out to allow the bench
to be placed on its support.
D
D
heater frame
heater frame
CONGRATULATIONS your sauna is now ready to enjoy!
If you have any queries please call
Sunlighten Customer Support at 1800 786 544.
Power
Lights
°C
°F
7.1
on/off
