Sunlighten mPulse 3-in-1 Series User manual

mPulse
USER MANUAL
VERSION 03.03.21
ANDROID 6.0
APP 2.2.36

CONGRATULATIONS!
You are now the owner of an mPulse 3-in-1® sauna.
With Sunlighten infrared heat, you are empowered to improve your quality of
life. Just follow our ASSEMBLY INSTRUCTIONS and SAUNA PROTOCOL to begin
your wellness journey with the very best in infrared therapy.
PLEASE NOTE
Do not use this sauna to treat any health problems without consulting your health care practitioner.
Sunlighten does not provide medical advice, education or treatment. Our information should not be
relied on in making decisions about your health. Always consult your health care practitioner
for medical advice.
Our patented Solocarbon mPulse 3-in-1®
is the only sauna heater on the market to provide
all three infrared wavelengths in one place
and customisable to each user.
2

3
PRE-INSTALLATION
mPULSE 3-IN-1® SERIES SPECIFICATIONS 4
PRE-INSTALLATION CHECKLIST 5
ANDROID CONTROL PAD &SUNLIGHTEN APP
GENERAL OPERATING INSTRUCTIONS
CONTROL SCREEN: INITIAL SETUP 6
SAUNA SETTINGS 12
WELLNESS PROGRAMS 12
SCHEDULING SAUNA SESSIONS 16
MEDIA APPS 20
CHROMOTHERAPY 22
WARM UP TIME & USAGE GUIDELINES 24
SAUNA PROTOCOL 25
HEALTH &SAFETY 26
FAQS
ASSEMBLY 29
USAGE 29
MAINTENANCE 31
TROUBLESHOOTING 34
DIAGNOSTICS 35
WARRANTY 36
SAFETY CERTIFICATION 37
YOUR ASSEMBLY INSTRUCTIONS WILL BE EMAILED TO YOU FOR YOUR REFERENCE.
CONTENTS

PRE-INSTALLATION
mPulse 3-in-1® SERIES SPECIFICATION
DIMENSIONS 110cm x 106cm x 200cm (W x L x H)
POWER 240V, 2160 watts. Dedicated 10A circuit and 10A power socket
protected by a 16A RCBO installed in the meter box.
Minimum 1.5mm cable required for circuit;
2.5m cord exists from back left of base.
mPulse Aspire
DIMENSIONS 132cm x 121cm x 200cm (W x L x H)
POWER 240V, 2600 watts. Dedicated 15A circuit and 15A power socket
protected by a 16A RCBO installed in the meter box.
Minimum 2.5mm cable required for circuit;
2.5m cord exists from back left of base.
mPulse Believe
DIMENSIONS 179cm x 121cm x 200cm (W x L x H)
POWER 240V, 3400 watts. Dedicated 15A circuit and 15A power socket
protected by a 16A RCBO installed in the meter box.
Minimum 2.5mm cable required for circuit;
2.5m cord exists from back left of base.
mPulse Conquer
DIMENSIONS 179cm x 179cm x 200cm (W x L x H)
POWER 240V, 4600 watts. Hardwire to a 25A power supply protected
by a 25A RCBO installed in the meter box.
Minimum 4.0mm cable required for circuit;
2.5m cord exists from back left of base.
mPulse Discover
DIMENSIONS 217cm x 179cm x 200cm
POWER 240V, 4800 watts. Hardwire to a 25A power supply protected
by a 25A RCBO installed in the meter box.
Minimum 4.0mm cable required for circuit;
2.5m cord exists from back left of base.
mPulse Empower
4

PRE-INSTALLATION
PRE-INSTALLATION CHECKLIST
1. Haveacertiedelectricianinstalladedicatedoutletforthesauna.  
Failure to do so will affect the operating performance of the sauna.
2. Remember your sauna should be assembled by 2 or more people.
3. Donotplaceplumbingorplumbingxturesinthesauna.
4. Keep all liquids away from the heating panels and electronics.
5. Install sauna on a level surface.
6. Install sauna in an area that is dry and protected from the weather.
7. Keepammableobjectsandcorrosivechemicalsubstancesaway
from the sauna.
8. Installation of the sauna in an area below standard room temperature
can increase warm up time.
READ BEFORE OPERATING
To reduce risk associated with hazardous voltage:
•Unplug the sauna from electrical outlet before storage or when not in use
for expanded periods of time.
•Do not operate the sauna if its not on a dedicated electrical circuit, or has
a damaged power cord/plug.
•If the sauna is not working properly or an odor persists, immediately unplug
the sauna.
•Do not leave the sauna unattended while heating for longer than the sauna’s
pre-set time periods.
• Nevercoverholesoroorgratewithtowels,mats,garments,etc.
5

GENERAL OPERATING INSTRUCTIONS:APP
ANDROID CONTROL PAD
POWER ON/OFF
TO TURN ON: Press and hold the power button in the lower right corner for 5 seconds,
until the screen turns on. The screen will be blank for a few seconds before
the Sunlighten logo appears.
TO TURN OFF: Press and hold the power button for 1-2 seconds and select “shutdown”
on the screen to turn off.
THE SUNLIGHTEN APP VERSION 2.2.36
Welcome to the new Sunlighten App! This guide will take you through the registration
and setup of your account and the most common and useful functions of your Android
Control Pad in operating your mPulse sauna.
ANDROID CONTROL PAD
6

GENERAL OPERATING INSTRUCTIONS:APP
ACTIVATION
SCREEN 1
On activating your Control Pad, you’ll be
greeted by a screen with some basic controls
at the bottom as illustrated below.
Circled in green is your App Tray along the side.
SCREEN 2
•Tap the App Tray button to extend the tray
and show all apps installed on the Pad
•Tap the gear icon to navigate to your Control
Pad’s Settings.
SCREEN 3
•You can also swipe down from the top of the
 screentoquicklyndthesettingsmenu.
•To expand your settings, tap on the gear
icon in the settings drop down.
7
Decrease
volume
gear icon
Increase
volume
Go back
to previous
screen
Go to
home
screen
Swap app
windows

ANDROID CONTROL PAD &SUNLIGHTEN APP GENERAL OPERATING INSTRUCTIONS
8
ACTIVATION
SCREEN 4
Therstsubsectionofyoursettingsyou’llsee
listed is Wi-Fi.
•Tap to navigate here and connect to your
wireless internet connection
•Tap the left-facing arrow to return to the
landing page.
•Tap the left-facing arrow once more to return
to your App Tray.
•Tap the lotus icon to start the Sunlighten App.
SCREEN 5
Theappwillstartwithaproleselectionscreen.
•Tap the plus icon to create a new account.
•You can create an account using the email
registered with Sunlighten (the email used
to receive this communication)
SCREEN 6
You will be required to enter the following
information:
•First Name
•Last Name
•Your email address registered with Sunlighten
•Create password (must be at least 8 characters)
ACCOUNT REGISTRATION

ANDROID CONTROL PAD &SUNLIGHTEN APP GENERAL OPERATING INSTRUCTIONS
9
SCREEN 7
•Tap the phrase ‘Terms of Use’ to read them
• Tap the box to agree to them
•Tap Create Account to complete the process.
SCREEN 8
Avericationcodewillbesenttothee-mail
address you used for registration.
•Enter your code
•Press the down-pointing arrow to dismiss
the keyboard.
•Tap ‘Verify’.
SCREEN 9
You’ll be returned to the login screen.
•Enter the information you’ve just used
for registration.
•Tap ‘Verify’.

ANDROID CONTROL PAD &SUNLIGHTEN APP GENERAL OPERATING INSTRUCTIONS
10
PROFILE SET UP
SCREEN 10
• Select your intended use from this screen,
either Residential or Commercial.
SCREEN 11
You’ll be asked to provide some personalizing
proleinformationforfuturecustomizationuse.
Once you’ve completed this information entry,
you’ll be asked if you’d like to update the time
zone settings.
SCREEN 12
This will take you to the Date & Time subsection
of your pad settings,
• Deactivate Automatic Date & Time
• Manually adjust both the Time Zone and Time.
• Tap the left-facing arrow and you’ll be taken to
the Sunlighten App Home Screen.
• To complete set up, tap the user icon in the
upper right corner of the screen
• Select My Saunas, and enter the serial number
and model of your Sunlighten sauna.

ANDROID CONTROL PAD &SUNLIGHTEN APP GENERAL OPERATING INSTRUCTIONS
11
WELCOME SCREEN
SCREEN 13
• Tap update model and an image of your
unit will appear.
• Tap the left-facing arrow to return to the
Home Screen.
SCREEN 14
The WELCOME SCREEN is where to begin using
the Sunlighten App.
• Hit the power icon to engage Quick Mode,
described in the next section.
• In the upper right corner, you’ll see the user
 icontoaddtooreditexistingornewprole
registrations.
SCREEN 15
QUICK MODE
The most commonly used, easily accessible, and
quickstarting mode of operation, Quick Mode
is ideal for a basic high-temperature experience
that utilizes the fullspectrum wavelengths at
maximum intensity to increase the temperature
of the cabin.
The maximum duration for Quick Mode use is
one hour. For longer sessions, in a commercial
use case for example, utilize the multi-segment
custom programs detailed on page 12.
user icon
0°
60°
28°C

ANDROID CONTROL PAD &SUNLIGHTEN APP GENERAL OPERATING INSTRUCTIONS
12
SAUNA SETTINGS
SCREEN 16
The SAUNA SETTINGS page is selected by tapping
Sauna Settings on the bottom-screen bar and is
home to all of your sauna’s basic information and
conguration.
SCREEN 17 - 18.1 to 18.6
Your mPulse comes with WELLNESS PROGRAMS
pre-programmed in your Android Control Pad,
eachonefocusedondifferentbenetsofusein
theircongurationasfollows.
DETOXIFICATION
Starts at a high intensity to increase the body’s core
temperature, then reduces to a lower intensity level.
Mid and far infrared combination improves vascular
accessowtoreachtoxinsatthecellularlevel.
WEIGHT LOSS
Starts at a high-intensity level to stimulate
the cardiovascular system, then reduces to a medium
level. As the body works to cool itself, there is
an increase in heart rate, cardiac output, and
metabolic rate, similar to exercise.

ANDROID CONTROL PAD &SUNLIGHTEN APP GENERAL OPERATING INSTRUCTIONS
13
RELAXATION
Far, mid, and near-infrared combination induces
deep relaxation as it relieves muscle tension at
a low,comfortable intensity promoting overall
stress reduction.
PAIN RELIEF
A far and mid-infrared blend provides natural pain
reliefbyreducinginammationandswellingwhile
near-infrared penetrates the tissue promoting cellular
repair at a medium, constant intensity level.
ANTI-AGING
A low, constant intensity level penetrates
tissue to help with various skin concerns.
Near-infrared improves overall skin tone, elasticity,
andrmness,promotinganti-agingbenets.
CARDIO
Starts at a high intensity to increase heart rate
and cardiac output, then lowers the intensity to
sustain heart rate level. Circulation increases
promoting healthy blood pressure.

ANDROID CONTROL PAD &SUNLIGHTEN APP GENERAL OPERATING INSTRUCTIONS
SAUNA SETTINGS
14
SCREEN 19
Creating a CUSTOM PROGRAM
Inadditiontothepre-conguredWellnessPro-
grams, you can also create your own Programs.
• Tap the plus icon to add a segment.
• Craft your own session with dynamic features
by doing so in segments.
• Determine the length of the session but
apply different wavelengths of infrared at
different points in the same session.
• The ‘Custom’ icon will be at the top of the
Programs screen after the presets.
SCREEN 20 - 21
You’ll be able to give your Program a name
and customize the intensity of heaters &
wavelengths used.

ANDROID CONTROL PAD &SUNLIGHTEN APP GENERAL OPERATING INSTRUCTIONS
SAUNA SETTINGS
15
SCREEN 22
The Customize Heaters screen allows you to
determine the intensity of mid and far infrared
on individually selected heaters during the
duration of a program segment, represented by
a slider bar that goes up to level 10. For ease of
selection, you can toggle between SAUNA VIEW
and a list of the heaters at the top of the screen.
In SAUNA VIEW, use the left, down, and right
arrows to navigate the sauna interior to select
heaters individually.
SCREEN 23
In HEATER LIST view, make edits to each heater’s
parameters by tapping the pencil icon. When
nished,gobackascreenandeitheradda
segment by tapping ‘Add Session’ or complete
the program by selecting ‘Save Program’. This
will return you to the Programs screen, where
you’ll see your newly created Custom Program
beneath the preset icons.

ANDROID CONTROL PAD &SUNLIGHTEN APP GENERAL OPERATING INSTRUCTIONS
SAUNA SETTINGS
16
SCREEN 24
SCHEDULE A SAUNA SESSION
• Tap on schedule icon in Sauna Settings to set
schedule your sauna session.
SCREEN 25
• Select the desired date from the calendar on
the left.
• Tap the plus icon on the right.
SCREEN 26
• Select the desired time.
• Select the desired program.

ANDROID CONTROL PAD &SUNLIGHTEN APP GENERAL OPERATING INSTRUCTIONS
SAUNA SETTINGS
17
SCREEN 28
LIGHTING
• Tap to control your interior and exterior
lighting.
• Use handheld remote to control the
Chromotherapy lighting.
SCREEN 27
• Review your selection.
• The sauna will be preheated and ready at
your selected start time.

ANDROID CONTROL PAD &SUNLIGHTEN APP GENERAL OPERATING INSTRUCTIONS
18
SAUNA SETTINGS
SCREEN 29
• Tap on the Support icon to access the
FREQUENTLY ASKED QUESTIONS (FAQs) page.
SCREEN 30
• Tap on the Question mark icon to see our FAQs.
SCREEN 26
If you have any additional questions or concerns
not addressed therein, please contact our Cus-
tomer Service Team, available Monday to Friday
9am to 5pm AEDT and Saturday 10am to 4pm
AEDT of each week to assist and support you.
e: [e-mail]
p: 1800 786 544

ANDROID CONTROL PAD &SUNLIGHTEN APP GENERAL OPERATING INSTRUCTIONS
SYSTEM UPDATE
19
SCREEN 32-35
If not running the latest version of the system
software, you may tap the user icon in the upper
right corner of the screen:
• Selectyouruserprolefromthelistofthose
on the tablet.
• Scroll to the bottom to select ‘Get latest APK.’
Each update of the app will be listed in
ascending order by the version number.
• To receive future updates, you will need
to reboot your Android Control Pad daily
by pressing the power button down for
1 second and choosing “Power Off” when
 you’renishedusingthesaunafortheday.
This will allow for your sauna to receive
updates automatically.

ANDROID CONTROL PAD &SUNLIGHTEN APP GENERAL OPERATING INSTRUCTIONS
MEDIA AND APPLICATIONS
20
SCREEN 36
APP REMOVAL
• From the App tray select the Gear icon
for Settings.
• Select the app to be removed from the list.
• Tap uninstall.
SCREEN 37
APP ADDITION
• Tap Google Play Store icon to add new third
party applications to the Android Control Pad
• Log in to the Google Play Store with your
Google account information.
• Sunlighten is not responsible for third party
Android app functionality.
• Compatibility is not guaranteed with every
application.
