Sunny SF-T7610 User manual

EASY ASSEMBLY FOLDING
TREADMILL
SF-T7610
USER MANUAL
English, Page 9 ~ 23 IMPORTANT! Please retain owner’s manual for maintenance and adjustment instructions. Your
satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE CONTACTED US:
[email protected] or 1-877-90SUNNY (877-907-8669).
Español, Page 24 ~ 38 ¡IMPORTANTE! Por favor Conserve el manual del usuario para las instrucciones de mantenimiento y
ajuste. Su satisfacción es muy importante para nosotros, SI AL PRODUCTO LE HACE FALTA PARTES,
POR FAVOR NO LO DEVUELVA HASTA TENER CONTACTO CON NOSOTROS:
[email protected] ó1-877-90SUNNY (877-907-8669).

1
IMPORTANT SAFETY INSTRUCTION
When using an electrical appliance, basic precautions should always be followed, including the following:
Read all instructions before using this treadmill.
DANGER–To reduce the risk of electrical shock:
1. Always unplug this appliance from the electrical outlet immediately after using and before cleaning.
WARNING –To reduce the risk of burns, fire, electric shock, or injury to persons:
1. The treadmill should never be left unattended when plugged in. Unplug from outlet when not in use and before putting on or taking
off parts.
2. Use this treadmill only for its intended use as described in this manual. Do not use attachments not recommended by the
manufacturer.
3. Never operate this treadmill if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or
dropped into water. Return this treadmill to a service center for examination and repair.
4. Keep the cord away from heated surfaces.
5. Never operate the treadmill with the air openings blocked. Keep the air openings free of lint, hair, and alike items.
6. Never drop or insert any object into any opening.
7. Do not use outdoors.
8. Do not operate where aerosol (spray) products are being used or where oxygen is being administered.
9. To disconnect, turn the treadmill off, then remove plug from outlet.
10.Connect this treadmill to a properly grounded outlet only. See grounding instructions.
CAUTION:
To avoid injury, use extreme caution when stepping onto or off of a moving belt. Read instruction manual before using.
SAVE THESE INSTRUCTIONS
INFORMACIÓN IMPORTANTE DE SEGURIDAD
Al usar un aparato eléctrico, siempre se deben seguir las precauciones básicas, incluidas las siguientes:
Lea todas las instrucciones antes de usar esta caminadora.
PELIGRO: Para reducir el riesgo de descarga eléctrica:
1. Desenchufe siempre este aparato de la toma de corriente inmediatamente después de usarlo y antes de limpiarlo.
ADVERTENCIA: para reducir el riesgo de quemaduras, incendios, descargas eléctricas o lesiones a personas:
1. La caminadora nunca debe dejarse desatendida cuando estáenchufada. Desenchúfela del tomacorriente cuando no estéen uso y
antes de poner o quitar partes.
2. Use esta caminadora solo para el uso previsto como se describe en este manual. No utilice accesorios no recomendados por el
fabricante.
3. Nunca opere esta caminadora si tiene un cable o enchufe dañado, si no estáfuncionando correctamente, si se ha caído o dañado,
o si se ha caído al agua. Devuelva esta caminadora a un servicio para su revisión y reparación.
4. Mantenga el cable alejado de las superficies calientes.
5. Nunca opere la caminadora con las aberturas de aire bloqueadas. Mantenga las aberturas de aire libres de pelusas, pelos y
artículos similares.
6. Nunca deje caer ni inserte ningún objeto en ninguna abertura.
7. No usar al aire libre.
8. No opere donde se estén utilizando productos en aerosol (aerosol) o donde se estéadministrando oxígeno.
9. Para desconectar, apague la caminadora, luego retire el enchufe del tomacorriente.
10.Conecte esta caminadora solo a un tomacorriente debidamente conectado a tierra. Vea las instrucciones de puesta a tierra.
PRECAUCIÓN:
Para evitar lesiones, tenga mucho cuidado al subirse o bajarse de una banda en movimiento. Lea el manual de instrucciones antes de
usar.
GUARDA ESTAS INSTRUCCIONES

2
IMPORTANT SAFETY INFORMATION
We thank you for choosing our product. To ensure your safety and health, please use this equipment correctly. It is important to read
this entire manual before assembling and using the equipment. Safe and effective use can only be achieved if the equipment is
assembled, maintained, and used properly. It is your responsibility to ensure that all users of the equipment are informed of all warnings
and precautions.
1. Before starting any exercise program, you should consult your physician to determine if you have any medical or physical conditions
that could put your health and safety at risk or prevent you from using the equipment properly. Your physician’s advice is essential if
you are taking medication that affects your heart rate, blood pressure or cholesterol level.
2. Be aware of your body’s signals. Incorrect or excessive exercise can damage your health. Stop exercising if you experience any of
the following symptoms: pain, tightness in your chest, irregular heartbeat, shortness of breath, lightheadedness, dizziness, or
feelings of nausea. If you do experience any of these conditions, you should consult your physician before continuing with your
exercise program.
3. Keep children and pets away from the equipment. The equipment is designed for adult use only.
4. Use the equipment on a solid, flat level surface with a protective cover for your floor or carpet. To ensure safety, the equipment
should have at least 8 feet (240 CM) of free space behind it and 2 feet (60CM) on each side. Do not place the treadmill on any
surface that blocks air openings. To protect the floor or carpet from damage, place a mat under the treadmill.
5. Ensure that all nuts and bolts are securely tightened before using the equipment. The safety of the equipment can only be
maintained if it is regularly examined for damage and/or wear and tear.
6. Always use the equipment as indicated. If you find any defective components while assembling or checking the equipment, or if you
hear any unusual noises coming from the equipment during exercise, discontinue use of the equipment immediately and do not use
until the problem has been rectified.
7. Wear suitable clothing while using the equipment. Avoid wearing loose clothing that may become entangled in the equipment.
8. Do not place fingers or objects into the moving parts of the equipment.
9. The maximum weight capacity of this unit is 220 pounds (100 KG).
10.The equipment is not suitable for therapeutic use.
11.To avoid bodily injury and/or damage to the product or property, proper lifting and moving is required.
12.Your product is intended for use in cool, dry conditions. You should avoid storage in extreme cold, hot or damp areas as this may
lead to corrosion and other related problems.
13.This equipment is designed for indoor and home use only, it is not intended for commercial use!
INFORMACIÓN IMPORTANTE DE SEGURIDAD
Gracias por haber elegido nuestro producto. Para garantizar su seguridad y salud, utilice este equipo correctamente. Es importante
que lea todo el manual antes de instalar y usar el equipo. Solo se puede archivar un uso seguro y eficaz del equipo si se instala,
mantiene y utiliza correctamente. Es su responsabilidad asegurarse de que todos los usuarios de los equipos conozcan todas las
advertencias y precauciones.
1. Antes de comenzar algún programa de ejercicios, deberá consultar con su médico para determinar si tiene alguna condición
médica o física que pudiera poner en riesgo su salud y seguridad o que pudiera impedir que utilice correctamente el equipo. Es
importante que reciba las recomendaciones de su médico en caso de que esté tomando un medicamento que afecte su ritmo
cardíaco, presión arterial o nivel de colesterol.
2. Esté atento a las señales que le envía su cuerpo. Ejercitarse incorrecta o excesivamente puede dañar su salud. Deje de hacer
ejercicio si experimenta alguno de los siguientes síntomas: dolor, opresión en el pecho, latidos cardíacos irregulares, extrema falta
de aire, sensación de desmayo, mareos o sensación de náuseas. Si presenta alguna de esas condiciones, deberáconsultar con su
médico antes de continuar con su programa de ejercicios.
3. Mantenga el equipo lejos del alcance de niños y mascotas. El equipo estádiseñado para el uso exclusivo de adultos.
4. Utilice el equipo sobre una superficie plana y sólida con una cubierta protectora para su piso o alfombra. Para garantizar la
seguridad, el equipo debe tener al menos 8 pies (240 CM) de espacio libre detrás de la máquina y 2 pies (60 CM) en cada lado. No
coloque la caminadora en ninguna superficie que bloquee las aberturas de aire. Para proteger el piso o la alfombra de daños,
coloque un tapete debajo de la caminadora.
5. Asegúrese de que todas las tuercas y pernos estén bien ajustados antes de usar el equipo. Solo puede conservarse la seguridad
del equipo si se inspecciona regularmente para detectar daños o desgaste.
6. Siempre utilice el equipo como se indica. Si encuentra algún componente defectuoso mientras instala o revisa el equipo, o si
escucha ruidos extraños que provienen de este mientras se ejercita, deje de utilizarlo inmediatamente y no lo utilice hasta que el
problema se haya corregido.
7. Use ropa adecuada cuando utilice el equipo. Evite usar ropa suelta que pueda enredarse en el equipo.
8. No coloque los dedos u objetos en las partes móviles del equipo.
9. La capacidad de peso máximo de esta unidad es de 220 libras (100KG).
10.El equipo no es adecuado para uso terapéutico.
11.Debe cuidarse al levantar y mover el equipo a fin de que no se dañe la espalda. Siempre utilice la técnica de levantamiento
adecuada y pida ayuda en caso de que sea necesario.
12.Su producto está diseñado para su uso en condiciones frescas y secas. Usted debe evitar el almacenamiento en zonas
extremadamente frías, calientes o húmedas, ya que pueden provocar corrosión y otros problemas relacionados.
13.¡Este equipo estádiseñado para el uso exclusivo en la casa y en interiores! ¡No es para uso comercial!

3
IMPORTANT OPERATING INSTRUCTIONS
1. Insert the power plug directly into the socket.
2. Read the manual before operating the treadmill.
3. Changes in speed do not occur immediately. Set your desired speed using the adjustment keys on the main console. The speed will
increase gradually.
4. While on the treadmill, move with caution as distractions may cause you to lose balance and stray from walking in the center of the
running belt. This may result in serious injury.
5. This unit starts at a very low speed. To begin use, hold onto the handrails and stand on the side rails while it starts up, then step
onto the running belt once it’s in motion.
6. Always hold the handrails when making changes in the settings.
7. A safety key is provided for emergency use. The treadmill will function only if the safety key is inserted into the computer console. In
case of emergency, remove the safety key to immediately stop the running belt and shut off the treadmill. The display screen will
reset once the safety key is reinserted.
8. The console control keys are precisely set and require very little finger pressure to use. To avoid damaging these keys, do not use
excessive pressure when operating these controls.
9. This treadmill is designed for adult use only! Children should not be allowed to use or play near this treadmill. When present,
children should always be supervised by an adult.
10.Women who are pregnant or nursing should consult a physician before attempting to begin any exercise program.
11.Always stay hydrated during and after exercise.
IMPORTANT NOTE:
The running belt must be lubricated before the first use! Please see Page 13 for instructions on how to properly apply
lubricant.
INSTRUCCIONES DE OPERACIÓN IMPORTANTES
1. Inserte el enchufe de alimentación directamente en la toma de corriente.
2. Lea el manual antes de operar el equipo.
3. Los cambios en la velocidad no ocurren inmediatamente. Establezca la velocidad deseada con las teclas de ajuste de la consola
principal. La velocidad aumentarágradualmente.
4. Mientras se encuentre en la caminadora, muévase con precaución ya que las distracciones pueden hacer que pierda el equilibrio y
se aleje de caminar en el centro del cinturón. Esto puede resultar en lesiones graves.
5. Esta unidad comienza a una velocidad muy baja. Para comenzar el uso, sostenga los pasamanos y párese en los rieles laterales
mientras se inicia, luego pise la correa una vez que estéen movimiento.
6. Mantenga siempre el pasamanos cuando realice cambios en la configuración.
7. Se proporciona una llave de seguridad para uso de emergencia. La máquina funcionarásolo si la llave de seguridad estáinsertada
en la consola de la computadora. En caso de emergencia, retire la llave de seguridad para detener inmediatamente el cinturón y
apagar la caminadora. La pantalla de visualización se reiniciaráuna vez que se reinserte la llave de seguridad.
8. Las teclas de control de la consola están ajustadas con precisión y requieren muy poca presión con los dedos para usarlas. Para
evitar dañar estas teclas, no ejerza una presión excesiva al operar estos controles.
9. ¡E ste equipo estádiseñado para uso exclusivo de adultos! No se debe permitir que los niños usen o jueguen cerca de este equipo.
Cuando están presentes, los niños siempre deben ser supervisados por un adulto.
10.Las mujeres embarazadas o en período de lactancia deben consultar a un médico antes de intentar comenzar cualquier programa
de ejercicios.
11.Mantente siempre hidratado durante y después del ejercicio.
NOTA IMPORTANTE:
¡La banda para caminadora debe lubricarse antes del primer uso! Consulte la página 30 para obtener instrucciones sobre
cómo aplicar correctamente el lubricante.

4
EXPLODED DIAGRAM

5
PARTS LIST
No.
Description
Specification
Qty.
No.
Description
Specification
Qty.
A01
Base Frame
1
C26
Rubber Cushion
1
A02
Base Support Tube
2
C27
EVA Cushion 2
2
A03
Main Frame
1
C28
Tube Plug
2
A04
Handrail Connecting
Bracket
1
C29
Fixed Block
1
A05
Handrail Bracket
2
C30
Cushion
1
A06
Running Board Support
Tube
1
C31
Inner Cap
2
B01
Front Roller
1
C32
Safety Key
1
B02
Rear Roller
1
C33
Rubber Cushion
2
B03
Spanner w/ Screw Driver
S=13, 14, 15
1
D01
Console Display
1
B04
Allen Wrench
S5
1
D02
Control Board
1
B05
Locking Pin Iron
1
D03
Keyboard
1
B06
Pressure Spring
Φ10.5*30
1
D04
Connection Line
100mm
1
B07
Safety Key Plate
Φ20*0.3
1
D05
Console Upper Wire
650mm
1
B08
Transportation Wheel
Bushing
Φ11*φ8.5*7
4
D06
Console Lower Wire
1600mm
1
B09
Lock Knob
Φ45*62*M10
1
D07
Speed Sensor
200mm
1
C01
Console Top Cover
1
D08
DC Motor
1
C02
Console Bottom Cover
1
D09
AC Single Line
Blue 200mm
1
C03
Console Rotate Cover
1
D10
AC Single Line
Brown 200mm
1
C04
Left Upright Tube Cover
1
D11
Power Switch
1
C05
Right Upright Tube Cover
1
D12
Running Board
1
C06
Left Upright Tube Inner
Cover
1
D13
Magnetic Ring
1
C07
Right Upright Tube Inner
Cover
1
D14
Magnetic Core
1
C08
Motor Top Cover
1
D15
Power Wire
2150mm
1
C09
Motor Bottom Cover
1
D16
Filter
1
C10
Left Rear Cover
1
D17
AC Single Line
Blue 350mm
1
C11
Right Rear Cover
1
D18
AC Single Line
Brown 350mm
1
C12
Side Rail
2
D19
Filter Connecting Board
1
C13
Running Belt
1
E01
Nut
M6
4
C14
Rubber Cushion
4
E02
Nut
M8
4
C15
Blue Cushion
2
E03
Bolt
M10*60
2
C16
Foam
2
E04
Bolt
M8*50
2
C17
Foam
2
E05
Hexagon Socket Flat-
round Head Screw
M8*15
2
C18
Motor Belt
1
E06
Hexagon Socket Cap
Head Screw
M8*15
2
C19
Transportation Wheel
2
E07
Bolt
M6*45
1
C20
C Shape Foot Pad
2
E08
Bolt
M6*55
2
C21
C Shape Foot Pad
2
E09
Bolt
ST2.6*8
3
C22
Ring Protecting Wire Plug
2
E10
Bolt
M6*28
4
C23
Power Wire Buckle
1
E11
Bolt
M5*12 (including
washer)
3
C24
Plastic Holder
1
E12
Bolt
M5*8 (including
washer)
12
C25
Locking Pin
1
E13
Screw
ST4.2*12
17

6
No.
Description
Specification
Qty.
No.
Description
Specification
Qty.
E14
Screw
ST2.9*8
2
E21
Spring Washer
Φ8
2
E15
Screw
ST2.9*6
11
E22
Flat Washer C
Φ8
2
E16
Screw
ST4.2*12
5
E23
Bolt
M8*48
2
E17
Screw
ST3.5*10
6
E24
Bolt
M6*15
1
E18
Big Washer C
Φ26*Φ10*2.0
2
E25
Bolt
M6*25
2
E19
Arc Washer
Φ6
3
E26
Washer
Φ8
2
E20
Arc Washer
Φ8
6
E27
Bolt
M8*48
2
LISTA DE PIEZAS
n.°
Descripción
Especificación
Ctd.
n.°
Descripción
Especificación
Ctd.
A01
Estructura Inferior
1
C15
Almohadilla Azul
2
A02
Tubo de Soporte de la
Base
2
C16
Espuma
2
A03
Estructura Principal
1
C17
Espuma
2
A04
Soporte de Conexión del
Pasamanos
1
C18
Correa de Motor
1
A05
Soportes de Pasamanos
2
C19
Rueda de Transportación
2
A06
Tubo de Soporte del
Estribo
1
C20
Almodilla de Pie Forma C
2
B01
Rodillo Delantero
1
C21
Almodilla de Pie Forma C
2
B02
Rodillo Trasero
1
C22
Aro Protectora de Cable
del Enchufe
2
B03
Llave Inglesa con
Destornillador
S=13, 14, 15
1
C23
Hebilla de Alimentación
Eléctrica
1
B04
Llave Allen
S5
1
C24
Soporte de Plástico
1
B05
Clavija de Bloqueo
1
C25
Clavija de Bloqueo
1
B06
Resorte de Presión
Φ10.5*30
1
C26
Almohadilla de Goma
1
B07
Placa para Llave de
Seguridad
Φ20*0.3
1
C27
Cojín de EVA2
2
B08
Buje de Rueda de
Transporte
Φ11*φ8.5*7
4
C28
Tapón de Tubo
2
B09
Perilla de Bloqueo
Φ45*62*M10
1
C29
Bloque de Fijación
1
C01
Cubierta Superior de la
Consola
1
C30
Almohadilla
1
C02
Cubierta Inferior de la
Consola
1
C31
Tapa Interior
2
C03
Cubierta Giratoria de la
Consola
1
C32
Llave de Seguridad
1
C04
Tapa del Tubo Vertical
Izquierda
1
C33
Almohadilla de Goma
2
C05
Tapa del Tubo Vertical
Derecha
1
D01
Pantalla de la Consola
1
C06
Cubierta Interior de Tubo
Vertical Izquierda
1
D02
Tablero de Control
1
C07
Cubierta Interior de Tubo
Vertical Derecha
1
D03
Teclado
1
C08
Cubierta Superior de
Motor
1
D04
Connection Line
100mm
1
C09
Cubierta Inferior de Motor
1
D05
Cable Superior de la
Consola
650mm
1
C10
Cubierta Trasera Izquierda
1
D06
Cable Inferior de la
Consola
1600mm
1
C11
Cubierta Trasera Derecha
1
D07
Sensor de Velocidad
200mm
1
C12
Riel Lateral
2
D08
Motor CC
1
C13
Banda para Caminadora
1
D09
Cable Singular CA
Azul 200mm
1

7
n.°
Descripción
Especificación
Ctd.
n.°
Descripción
Especificación
Ctd.
D10
Cable Singular CA
Marrón 200mm
1
E10
Perno
M6*28
4
D11
Interruptor de Alimentación
1
E11
Perno
M5*12 (including
washer)
3
D12
Tabla para Caminadora
1
E12
Perno
M5*8 (including
washer)
12
D13
Aro Magnético
1
E13
Tornillo
ST4.2*12
17
D14
Núcleo Magnético
1
E14
Tornillo
ST2.9*8
2
D15
Cable de Enchufe
2150mm
1
E15
Tornillo
ST2.9*6
11
D16
Filtro
1
E16
Tornillo
ST4.2*12
5
D17
Cable Singular CA
Azul 350mm
1
E17
Tornillo
ST3.5*10
6
D18
Cable Singular CA
Marrón 350mm
1
E18
Gran Lavadora C
Φ26*Φ10*2.0
2
D19
Placa de Conexión del
Filtro
1
E19
Arandela
Φ6
3
E01
Tuerca
M6
4
E20
Arandela
Φ6
3
E02
Tuerca
M8
4
E21
Arandela de Presión
Φ8
2
E03
Perno
M10*60
2
E22
Arandela Plana C
Φ8
2
E04
Perno
M8*50
2
E23
Perno
M8*48
2
E05
Tornillo de Cabeza
Redonda Plana con
Hexágono Interior
M8*15
2
E24
Perno
M6*15
1
E06
Tornillo de Cabeza Hueca
Hexagonal
M8*15
2
E25
Perno
M6*25
2
E07
Perno
M6*45
1
E26
Arandela
Φ8
2
E08
Perno
M6*55
2
E27
Perno
M8*48
2
E09
Perno
ST2.6*8
3
HARDWARE PACKAGE

8
Ordering Replacement Parts (U.S. and Canadian Customers only)
Please provide the following information in order for us to accurately identify the
part(s) needed:
The model number (found on cover of manual)
The product name (found on cover of manual)
The part number found on the “EXPLODED DIAGRAM” and “PARTS LIST”
(found near the front of the manual
Please contact us at [email protected] or 1- 877 - 90SUNNY
(877-907-8669).
Pedido de piezas de repuesto (solo para clientes de EE. UU. y Canadá)
Por favor indique la siguiente información para que podamos identificar con
precisión las piezas necesarias:
El número de modelo (se encuentra en la portada del manual).
El nombre del producto (se encuentra en la portada del manual).
El número de pieza que se encuentra en el “ESQUEMA DE LAS PIEZAS” y
en la “LISTA DE PIEZAS” (se encuentra al principio del manual).
Contáctenos en [e-mail] o 1-877-90SUNNY (877-907-
8669).

9
ASSEMBLY INSTRUCTIONS
We value your experience using Sunny Health and Fitness products. For assistance with parts or
troubleshooting, please contact us at [e-mail] or 1-877-90SUNNY (877-907-
8669).
STEP 1:
Note: We recommend having two
people to do the assembly.
Open the carton box, take out the
contents, and place the Main Frame
(No. A03) on leveled ground.
STEP 2:
Note: Support Main Frame (No. A03)
at position “F” with one hand to
prevent it from falling during
assembly.
Attach the 2 Base Support Tubes
(No. A02) to Base Frame (No. A01).
Use Allen Wrench (No. B04) to
screw the 2 Bolts (No. E04), 4 Arc
Washers (No. E20), and 2 Nuts (No.
E02) into the Base Frame (No. A01).
Screw the 2 Bolts (No. E05) and 2
Arc Washers (No. E20) into both
sides of the Base Frame (No. A01).
S5
A0
3

10
We value your experience using Sunny Health and Fitness products. For assistance with parts or
troubleshooting, please contact us at [e-mail] or 1-877-90SUNNY (877-907-
8669).
STEP 3:
To avoid any possible injury, please
hold on to the Main Frame (No. A03)
at position “F” before you pull the
Locking Pin (No. C25) and ensure
that the space directly underneath is
clear of any objects. Once the Main
Frame (No. A03) is released, please
continue to hold on until it reaches
the floor.
Pull the Locking Pin (No. C25) and
lower the Main Frame (No. A03) to
the floor.
Note: The Locking Pin (No. C25)
will snap back into the treadmill. It
does not detach from the treadmill.
STEP 4:
Attach the 2 Handrail Brackets (No.
A05) into Handrail Connecting
Bracket (No. A04) by turning
clockwise.

11
We value your experience using Sunny Health and Fitness products. For assistance with parts or
troubleshooting, please contact us at [e-mail] or 1-877-90SUNNY (877-907-
8669).
STEP 5:
Insert Lock Knob (No. B09). Secure
the Base Frame (No. A01) to Main
Frame (No. A03) by turning Lock
Knob (No. B09) clockwise until tight.
STEP 6:
Turn the Console (No. B) to a right
angle.
The assembly is complete!
IMPORTANT NOTE!
You will need to lubricate
your treadmill before the first
use. See Page 13.

12
MAINTENANCE & CARE
General cleaning will help prolong the life and performance of your treadmill. Keep the unit clean and
maintained by dusting the components on a regular basis. Clean both sides of the Running Belt (No.
C13) to prevent dust from accumulating underneath. Keep your running shoes clean so that dirt from
your shoes does not wear the Running Board (No. D12) and Running Belt (No. C13). Clean the
surface of the Running Belt (No. C13) with a clean, damp cloth.
To better maintain the treadmill and prolong its life, it is suggested that the treadmill be powered off
for 10 minutes every 2 hours and fully powered off whenever not in use.
CENTERING THE RUNNING BELT:
Place the treadmill on level ground and set it at 3-5mph to check if the Running Belt (No. C13) drifts
from the center.
1. If the Running Belt (No. C13)drifts to the
right, turn the right adjusting bolt ¼turn
clockwise, then turn the left adjusting bolt ¼
turn counter-clockwise. If the Running Belt
(No. C13) does not move, repeat this step
until it centers. Refer to Figure A.
2. If the Running Belt (No. C13) drifts to the
left, turn the left adjusting bolt ¼turn
clockwise, then turn the right adjusting bolt ¼
turn counter-clockwise. If the Running Belt
(No. C13) does not move, repeat this step
until it centers. Refer to Figure B.
3. Over time, the Running Belt (No. C13)
will loosen. To tighten the Running Belt (No.
C13) turn the Left & Right adjusting bolts
one full turn clockwise, check the tension of
the Running Belt (No. C13). Continue this
process until Running Belt (No. C13) is at
the correct tension. Make sure to adjust both
sides equally to ensure correct belt
alignment. Refer to Figure C.

13
LUBRICATING THE TREADMILL
IMPORTANT NOTE:
You will need to lubricate your treadmill before the first use.
RUNNING BELT & TREADMILL LUBRICANT:
Lubricating the Running Board (No. D12) and Running Belt (No. C13) is essential as the friction
affects the life span and operations of the treadmill. Inspect the Running Board (No. D12) and
Running Belt (No. C13) regularly. If you find any wear on the Running Board (No. D12), please
contact us at: [email protected].
WARNING: Always unplug the treadmill from the electrical outlet before cleaning, lubricating, or
repairing the unit.
HOW TO LUBRICATE:
1. Raise the Running Belt (No. C13) up on one side and apply lubricant to the Running Board (No.
D12). Use a rag to thoroughly wipe the lubricant over the Running Board (No. D12). Repeat this
process for the other side.
2.The moving parts should turn freely and quietly. Abnormal moving parts will affect the safety of the
treadmill. Inspect and tighten bolts regularly.
3.To better maintain the treadmill and prolong its lifespan, it is suggested that maintenance be done
on a regular basis.
4. DO NOT LOOSEN OR MAKE ANY ADJUSTMENTS TO THE RUNNING BELT WHILE APPLYING
LUBRICANT. A loose Running Belt (No. C13) will result in the runner sliding off during use, while too
tight of a Running Belt (No. C13) will negatively affect the motor’s performance and create more
friction between the roller and Running Belt (No. C13). The most suitable tightness for the Running
Belt (No. C13) is when it is pulled out 50-75mm from the Running Board (No. D12).
The following time table is recommended:
Light user (less than 3 hours/ week)
Medium user (3-5 hours/ week)
Heavy user (more than 5 hours/ week)
every three months
every two months
every six months

14
FOLDING INSTRUCTIONS
FOLDING:
Loosen the Lock Knob (No.
B09) counter-clockwise and pull
it out. Fold up the Main Frame
(No. A03).
Note: Remember where you
keep the Lock Knob (No. B09)
after you pull it out. You will
need it when you unfold the
treadmill.
Pull out the Locking Pin (No.
C25) with one hand, then lift up
the Main Frame (No. A03) at
position “F” with the other hand
until the Locking Pin (No. C25)
snaps into the hole of Fixed
Block (No. C29).

15
UNFOLDING:
Note: Before lowering the Main
Frame (No. A03), ensure that the
space directly underneath is clear
of any objects.
To avoid any possible injury,
please hold the Main Frame (No.
A03) at position “F” before you
pull the Locking Pin (No. C25).
Once the Main Frame (No. A03)
is released, continue to hold on at
position “F” until it reaches the
floor.
Secure Base Frame (No. A01) into
Main Frame (No. A03) by inserting
Lock Knob (No. B09) and turning
clockwise until tight.

16
HOW TO MOVE THE TREADMILL
Before attempting to move the
treadmill, make sure that it has
been properly folded. Unplug the
power cord.
To tilt, start by placing one hand at
position “P” to support the top end
of the treadmill. Next, place one
foot at position “K” to hold the
bottom end of the treadmill
steady. With your foot at “K”,
slowly tilt the top of the treadmill
downward towards the ground.
Once the Main Frame “P” reaches
a low enough point, the wheels of
the treadmill touch the ground.
To transport, hold the treadmill from
position “P” and tilt until the wheel’s
“K” are able to move on the ground.

17
HOW TO USE SAFETY KEY
Insert the Safety Key (No. C32) into the magnetic area of the Console (No.
B) and clip to your clothes.
Note: In an emergency, pull out the Safety Key (No. C32), and the treadmill
will stop.

18
IMPORTANT ELECTRICAL INFORMATION
WARNING: This treadmill requires a power source of 8 amps (100-120 V) in order to properly
operate. For your safety, as well as the safety of others, please verify that the power source is correct
before plugging the equipment. Any power source above or below this level could cause significant
damage to the equipment and/or user.
GROUNDING METHODS:
This product must be grounded. Should the treadmill malfunction or breakdown, grounding provides a
path of least resistance for electric current to reduce the risk of electric shock. This product is
equipped with a plug that has an equipment-grounding conductor and a grounding plug. The plug
must be plugged into an appropriate outlet that is properly installed and grounded in accordance with
all local codes and ordinances. Ensure that the product is connected to an outlet with the same
configuration as the plug. Do not use an adaptor for this product.
This product is for use on a nominal 100-120V circuit and has a grounding plug that looks like the
plug illustrated in sketch A.
DANGER:
Improper connection of the equipment-grounding conductor can result in risk of electric shock. Check
with a qualified electrician or serviceman if you are unsure whether the product has been properly
grounded. Do not modify the plug provided with the product. If it will not fit the outlet, have a proper
outlet installed by a qualified electrician.
WARNING!
1. NEVER use a ground fault circuit interrupt (GFCI) wall outlet with this treadmill. Route the power
cord away from all moving parts of the treadmill including the elevation mechanism and
transportation wheels.
2. NEVER operate the treadmill using a generator or UPS power supply.
3. NEVER remove any cover on this treadmill without first disconnecting power cord.
4. NEVER expose the treadmill to rain or moisture. This treadmill is not designed for outdoor use or
use in any other high humidity environment.
GROUNDING METHOD

19
THE DISPLAY CONSOLE
DISPLAY
SPEED: Displays current speed (range 0.5 - 6.5 MPH). When in setting mode, the window displays
H-1, H-2, H-3.
TIME: Displays running time. If the time reaches 99:59, the treadmill will stop smoothly and display
“End” then enter standby mode after 5 seconds. When in countdown mode, it will count from the
setting time to 0:00. When down to 0:00, the treadmill will stop smoothly and show “End”, then enter
standby mode after 5 seconds.
DISTANCE: Displays the distance traveled (range 0.0-99.9 MILES). When the clock reaches 99.9, it
will reset to 0.00 and begin counting again from 0.0. When in countdown mode, it will count down
from the distance you set to 0.00. When it reaches 0.00, the treadmill will stop smoothly and display
“End”, then enter standby mode after 5 seconds.
CALORIES: Displays user’s calories burned (range 0-999 KCAL). When it reaches 999, it will start
again from 0. In countdown mode, it will count from the number of calories you set to 0. When it
reaches 0, the treadmill will stop smoothly and show “End”, then enter standby mode after 5 seconds.
