Sunricher SR-SBP2801K4-DIM-G2 User manual

Self Powered RF+Bluetooth DIM Remote Controller
70200001
Function introduction
Important: Read All Instructions Prior to Installation
Click to turn on zone 2, Press
and hold down to increase
light intensity
Click to turn off zone 2, Press
and hold down to increase
light intensity
Click to turn on zone 1,
Press and hold down to
increase light intensity
Click to turn off zone 1,
Press and hold down to
decrease light intensity
Front side
Back side
10.10 mm
86mm
86mm
The remote control can be fixed on the wall with 3M glue or screw.
With Glass Frame
Product Data
Protocol
Power Supply
Transmission Frequency
Transmission Range (free field)
Protection Type
Dimming Range
Dimensions
RF+Bluetooth
Self powered by built-in nano generator
2.4GHz
30m
IP20
0.1%-100%
80.5x80.5x14.7mm / 86x86x14mm
• DIM wall remote based on RF+Bluetooth Mesh
• Self-powered wall remote, no battery replacement & re-installation costs
• No wires, no batteries, no limits
• Ultra long lifetime, more than 1 million times pushing
• Easy & quick pairing to the RF+Bluetooth receivers by simply pushing the buttons
• Enables to control 2 zones of receivers
• Mesh network for further control distance, receivers can transmit signal to each other
• 2.4 GHz global operation
• The controlled receiver status can be quickly synchronized to the smart APP
• Transmission range between every two neighbor devices up to 30m
• Each receiver can be paired to max. 8 remote controls
• Enables to control universal DIM RF+Bluetooth devices
• Standard size, compatible with existing EU size frame
The remote control can be fixed on the wall with 3M glue or screw.
80.5 mm
80.5 mm
With Plastic Frame
14.7 mm

• DO NOT expose the device to moisture.
Safety & Warnings
Pair with RF+Bluetooth receiver
Step 3:Click or button of either of the two zones on the remote, e.g. button .
of zone 2, LED lights connected with the receiver flicker once means the
receiver is paired to the selected zone successfully.
Note: one receiver can be paired with max 8 remote controls.
Step 1:Do wiring the RF+Bluetooth receiver according to wiring diagram(please refer
to the instruction of RF receiver that you would like to pair with)
Prog.
RF+Bluetooth LED Receiver
The key part of this controller is a universal, extremely rotary standard switch element that can be integrated in
numerous frames by different manufactures as below list:
BEKER S1, B1, B3, B7 glass
GIRA Standard55, E2, Event, Esprit
JUNG A500, Aplus
MERTEN M-smart, M-Arc, M-Plan
Installation
With Plastic Frame With Glass Frame
Step 2:Click the “Prog. Key” or “Reset” button on RF+Bluetooth receiver (or reset
power of the receiver 3 times continuously if the button is not accessible) to set it into
pairing to RF remote status
